Apprentissage par Renforcement Reinforcement Learning

1
Apprentissage par RenforcementReinforcement
Learning

• Kenji Doya
• doya_at_atr.co.jp
• ATR Human Information Science Laboratories
• CREST, Japan Science and Technology Corporation

2
Outline

• Introduction to Reinforcement Learning (RL)
• Markov decision process (MDP)
• Current topics
• RL in Continuous Space and Time
• Model-free and model-based approaches
• Learning to Stand Up
• Discrete plans and continuous control
• Modular Decomposition
• Multiple model-based RL (MMRL)

3
Learning to Walk (Doya Nakano, 1985)

• Action cycle of 4 postures
• Reward speed sensor output
• Multiple solutions creeping, jumping,

4
Markov Decision Process (MDP)

• Environment
• dynamics P(ss,a)
• reward P(rs,a)
• Agent
• policy P(as)
• Goal maximize cumulative future rewards
• E r(t1) g r(t2)
• 0g1 discount factor

5
Value Function and TD error

• State value function
• V(s) E r(t1) g r(t2) s(t)s, P(as)
• 0g1 discount factor
• Consistency condition
• d(t) r(t) g V(s(t)) - V(s(t-1)) 0
• new estimate - old estimate
• Dual role of temporal difference (TD) error d(t)
• Reward prediction d(t) ? 0 in average
• Action selection d(t)gt0 better than average

6
Example Navigation

• Reward field

7
Actor-Critic Architecture
critic V(s)
reward r
TD error d
environment
action a
actor P(as)
state s

• Critic future reward prediction
• update value DV(s(t-1)) ? d(t)
• Actor action reinforcement
• increase P(a(t-1)s(t-1)) if d(t) gt 0

8
Q Learning

• Action value function
• Q(s,a) E r(t1) g r(t2) s(t)s,
  a(t)a, P(as) E r(t1) g V(s(t1))
  s(t)s, a(t)a
• Action selection
• a(t) argmaxa Q(s(t),a) with prob. 1-e
• Update
• Q(s(t),a(t)) r(t1) g maxa Q(s(t1),a)
• Q(s(t),a(t)) r(t1) g Q(s(t1),a(t1))

9
Dynamic Programming and RL

• Dynamic Programming
• given models P(ss,a) and P(rs,a)
• off-line solution of Bellman equation
• V(s) maxa ?rrP(rs,a) g?sV(s)P(ss,a)
• Reinforcement Learning
• on-line learning with TD error
• d(t) r(t) gV(s(t) - V(s(t-1))
• DV(s(t-1)) a d(t)
• DQ(s(t-1),a(t-1)) a d(t)

10
Model-free and Model-based RL

• Model-free e.g., learn action values
• Q(s,a) r(s,a) g Q(s,a)
• a argmaxa Q(s,a)
• Model-based forward model P(ss,a)
• action selection
• a argmaxa E R(s,a) g Ss V(s)P(ss,a)
• simulation learn V(s) and/or Q(s,a) off-line
• dynamic programming solve Bellman eq.
• V(s) maxa E R(s,a) g Ss V(s)P(ss,a)

11
Current Topics

• Convergence proofs
• with function approximators
• Learning with hidden states POMDP
• estimate belief states
• reactive, stochastic policy
• parameterized finite-state policies
• Hierarchical architectures
• learn to select fixed sub-modules
• train sub-modules
• both

12
Partially Observable Markov Decision Process
(POMDP)

• Update the belief state
• observation P(os) not identity
• belief state b(P(s1), P(s2),) real valued
• P(sko) ? P(osk) Si P(sksi,a) P(si)

13
Tiger Problem (Kaelbing et al., 1998)

• state a tiger is in left,right
• action left, right, listen
• observation with 15 error
• policy tree finite state policy

14
Outline

• Introduction to Reinforcement Learning (RL)
• Markov decision process (MDP)
• Current topics
• RL in Continuous Space and Time
• Model-free and model-based approaches
• Learning to Stand Up
• Discrete plans and continuous control
• Modular Decomposition
• Multiple model-based RL (MMRL)

15
Why Continuous?

• Analog control problems
• discretization ? poor control performance
• how to discretize?
• Better theoretical properties
• differential algorithms
• use of local linear models

16
Continuous TD learning

• Dynamics
• Value function
• TD error
• Discount factor
• Gradient Policy

17
On-line Learning of State Value

• state x(angle, angular vel.)
• V(x)

18
Example Cart-pole Swing up

• Reward height of the tip
• Punish crash to wall

19
Fast Learning by Internal Models

• Pole balancing (Stefan Schaal, USC)
• Forward modelof pole dynamics
• Inverse modelof arm dynamics

20
Internal Models for Planning

• Devil sticking (Chris Atkeson, CMU)

21
Outline

• Introduction to Reinforcement Learning (RL)
• Markov decision process (MDP)
• Current topics
• RL in Continuous Space and Time
• Model-free and model-based approaches
• Learning to Stand Up
• Discrete plans and continuous control
• Modular Decomposition
• Multiple model-based RL (MMRL)

22
Need for Hierarchical Architecture

• Performance of control
• Many high-precision sensors and actuator
• Prohibitively long time for learning
• Speed of learning
• Search in low-dimensional, low-resolution space

23
Learning to Stand up (Morimoto Doya, 1998)

• Reward height of the head
• Punishment tumble
• State pitch and joint angles, their derivatives
• Simulation ? many thousands of trials to learn

24
Hierarchical Architecture

• Upper level
• discrete state/time
• kinematics
• action subgoals
• reward total task
• Lower level
• continuous state/time
• dynamics
• action motor torque
• reward
• achieving subgoals

Q(S,A)
sequence ofsubgoals
V(s) ag(s)
25
Learning in Simulation
Upper level subgoals
Lower level control
early learning
after 700 trials
26
Learning with Real Hardware (Morimoto Doya,
2001)

• after simulation
• after 100 physical trials
• Adaptation by lower control modules

27
Outline

• Introduction to Reinforcement Learning (RL)
• Markov decision process (MDP)
• Current topics
• RL in Continuous Space and Time
• Model-free and model-based approaches
• Learning to Stand Up
• Discrete plans and continuous control
• Modular Decomposition
• Multiple model-based RL (MMRL)

28
Modularity in Motor Learning

• Fast De-adaptation and Re-adaptation
• switching rather than re-learning
• Combination of Learned Modules
• serial/parallel/sigmoidal mixture

29
Soft Switching of Adaptive Modules

• Hard switching based on prediction errors
• (Narendra et al., 1995)
• Can result in sub-optimal task decomposition with
  initially poor prediction models.
• Soft switching by softmax of prediction
  errors
• (Wolpert and Kawato, 1998)
• Can use annealing for optimal decomposition.
• (Pawelzik et al., 1996)

30
Responsibility by Competition

• predict state change
• responsibility
• weight output/learning

31
Multiple Linear Quadratic Controllers

• Linear dynamic models
• Quadratic reward models
• Value functions
• Action outputs

32
Swing-up control of a pendulum

• Red module 1 Green module 2

33
Non-linearity and Non-stationarity

• Specialization by predictability in space and time

34
Swing-up control of an Acrobot

• Reward height of the center of mass
• Linearized around four fixed points

35
Swing-up motions

• R0.001 R0.002

36
Module switching

• trajectories x(t) R0.001 R0.002
• responsibility li symbol-like representation
• 1-2-1-2-1-3-4-1-3-4-3-4 1-2-1-2-1-2-1-3-4-1-
  3-4

37
Stand Up by Multiple Modules

• Seven locally linear models

38
Segmentation of Observed Trajectory

• Predicted motor output
• Predicted state change
• Predicted responsibility

39
Imitation of Acrobot Swing-up

• q1(0)p/12 q1(0)p/6 q1(0)p/12 (imitation)

40
Outline

• Introduction to Reinforcement Learning (RL)
• Markov decision process (MDP)
• Current topics
• RL in Continuous Space and Time
• Model-free and model-based approaches
• Learning to Stand Up
• Discrete plans and continuous control
• Modular Decomposition
• Multiple model-based RL (MMRL)

41
Future Directions

• Autonomous learning agents
• Tuning of meta-parameters
• Design of rewards
• Selection of necessary/sufficient state coding
• Neural mechanisms of RL
• Dopamine neurons encoding TD error
• Basal ganglia value-based action selection
• Cerebellum internal models
• Cerebral cortex modular decomposition

42
What is Reward for a robot?

• Should be grounded by
• Self preservation self recharging
• Self reproduction copying control program
• Cyber Rodent

43
The Cyber Rodent Project

• Learning mechanisms under realistic constraints
  of self-preservation and self-reproduction
• acquisition of task-oriented internal
  representation
• metalearning algorithms
• constraints of finite time and energy
• mechanisms for collaborative behaviors
• roles of communication
• abstract/emotional, concrete/symbolic
• gene exchange rules for evolution

44
Input/Output

• Sensory
• CCD camera
• range sensor
• IR proximity x8
• acceleration/gylo
• microphone x2
• Motor
• two wheels
• jaw
• R/G/B LED
• speaker

45
Computation/Communication

• CPU Hitachi SH-4 CPU
• FPGA image processor
• IO modules
• Communication
• IR port
• wireless LAN
• Software
• learning/evolution
• dynamic simulation
