How to: Some Basic Principles for Leveling

1
How toSome Basic Principles forLeveling

• Tilo Schöne
• GFZ, Germany
• tschoene_at_gfz-potsdam.de

2
Lecture Overview

• Equipment
• Introduction to Leveling
• Observation, Field Notes, and Computation
• Errors and their effects

3
Equipment
4
Equipment

• Level Instrument
• Tripod
• Staff/Pole
• Change plate (German Frog/Frosch)
• Pole staff bubble (bull eye)
• Marker

5
Equipment Level Instrument

• Automated Levels
• Easy to use (not power!)
• Needs experience
• Robust even in hostile environment
• Digital Levels
• Push-button technique
• No reading errors, special staff
• Readings are stored and analyzed digitally

6
Automated Levels (Compensator)
Pendulum
Bull Eye
Tribrach
Courtesy Deumlich, Vermessungskunde
7
Digital Levels

• Uses Barcode staffs
• Internal storage of data
• Download to the computer
• Automated height computation adjustment
• No feeling for quality anymore
• You frequently need power plugs

8
Equipment

• Level Instrument
• Tripod
• Staff/Pole
• Change plate (German Frog/Frosch)
• Pole staff bubble (bull eye)
• Marker

9
Equipment Tripod

• Wooden design or aluminum
• From easy to sit to ops, this is
  high

10
Equipment

• Level Instrument
• Tripod
• Staff/Pole
• Change plate (German Frog/Frosch)
• Pole staff bubble (bull eye)
• Marker

11
Equipment Staff/Pole

• Wood, aluminum
• INVAR type for high precision leveling

Barcode for Digital Levels
Conventional (E-type)
12
Equipment

• Level Instrument
• Tripod
• Staff/Pole
• Change plate (German Frog/Frosch)
• Pole staff bubble (bull eye)
• Marker

13
Equipment Change Plate

• For long survey lines
• Allows change of instruments
• Best is a metal change plate
• Screws e.g. at fences
• Sharp stones or nails
• Beware of dark colors

Its not the Indonesian- German Dictionary, Its
the nail!
14
Equipment

• Level Instrument
• Tripod
• Staff/Pole
• Change plate (German Frog/Frosch)
• Pole staff bubble (bull eye)
• Marker

15
Equipment Bubble

• Keep the pole upright
• Any tilt will disturb your readings

16
Equipment

• Level Instrument
• Tripod
• Staff/Pole
• Change plate (German Frog/Frosch)
• Pole staff bubble (bull eye)
• Marker

17
Survey Markers

• Gives you a fixed point
• Should be of good quality
• Should be long-term
• Preferable in bedrock, settled buildings, or
  bridges
• Do not use fences or walls

18
Introduction to Leveling
19
Some Basic Definitions

• Level surface (e.g. the geoid)
• A water surface with no motion
• Gravity gradient is the normal to the level
  surface
• The Instruments Bubble is in the normal (!)
• Horizontal surface
• At the instruments axis, the horizontal surface
  is tangent to the level surface
• Over short distances (lt100 m) the horizontal
  surface and the level surface will coincide
• For long leveling lines the effects of the
  gravity field must be considered

20
Basic Principle of Leveling

• Measures height differences between points
• Along a line
• Several points from one occupation

fs
bs
Dh bs - fs
21
Definitions

• Back sight (BS)
• The first reading from a new instrument stand
  point (i.e. take the height to the instrument)
• Fore sight (FS)
• The last reading from the current instrument
  station (i.e. give the height to a benchmark)
• Intermediate sight (IS)
• Any sighting that is not a back sight or fore
  sight

22
Reading a Staff

• Read the m, dm cm
• Estimate the mm
• Check yourself for frequent used numbers (2/3)
  or (7/8)

1422
23
Basic Rules for Leveling

• Always start and finish a leveling run on a
  Benchmark (BM or TGBM) and close the loops
• Keep fore sight and back sight distances as equal
  as possible
• Keep lines of sight short (normally lt 50m)
• Never read below 0.5m on a staff (refraction)
• Use stable, well defined change points
• Beware of shadowing effects and crossing waters

24
Observation, Field Notes, and Computation
25
How to A sample loop
26
How To Field Notes
S2
1327
3982
2365
2347
0986
3753
3724
1101
S1
27
Date, Observer, Instrument
Instrument Check
SD
Back
Fore
28
Compute levels
100 000
1327
3982
2365
97 345
7345
1
0986
98 724
2347
1379
8624
3724
3753
97 348
1101
2652
100 000
9793
0
0
9792
-0001
0000
0001 (SOLL IST)
29
Loop misclosure

• Misclosure Error
• The difference of the measured height difference
  (DHmeas) to the known height (closed loops 0,
  known benchmarks height difference)
• Misclosure DHSOLL DHIST
• Point errors at double observed points

30
Achievable Accuracy

• Instrument dependent
• Roughly from the instrument
• NI002 0,2mm/km (doubled line)
• NI025 2.5mm/km (doubled line)
• Survey line length dependent
• ms m1km ?s, s in km
• mH (m1km/2) ?s, s in km (middle of the line)

31
An acceptable misclose?

• Small misclosures in closed level loops are
  expected because of the accumulation of random
  errors and can be adjusted
• If the misclosure is large, the loop (or part of
  it) must be repeated
• Misclosures can also result from errors in
  published BM levels and from BM instability

32
Testing the misclose

• The amount of misclosure acceptable using a
  specific instrument and survey line length
• For our example, a second order leveling standard
  is adopted
• misclosure ? 2,5?s mm
• where s is the length of the line in km
• Dependent on your contrys rules and the
  instrument used

33
Our example

• The misclosure is 1 mm
• The length of the loop is 0.4 km
• Acceptable error is
• 2.5?(0.4) 1.6 mm
• The misclosure of 1 mm is within the limit
• Mean error for NB1 2.5/2 ?(0.4)

34
Errors and their effects(many, but only a few
addressed)
35
Errors in leveling, e.g.

• Collimation, Parallax
• Change point / staff instability
• Instrument or Benchmark instability
• Refraction
• Uncalibrated staff or levels
• Reading, booking, or computation errors
• Fore- and backsight distances different

36
Systematic and Random Errors

• Earth curvature
• Refraction
• Collimation errors

37
Effect of Earth Curvature
Horizontal Level
Curvature effect
(r Dh)2 r2 s2 gt Dh ? s2/(2r)
www.fh-oow.de/institute/ima/personen/weber/VK_12/V
L_VK1/geo_niv_6.htm
38
Refraction
Mean Gradient 0,2 C / m
www.fh-oow.de/institute/ima/personen/weber/VK_12/V
L_VK1/geo_niv_6.htm
39
Collimation error

• Occurs when the line of sight (as defined by the
  lens axis and cross-hairs) is not horizontal
• Leads to an incorrect staff reading

line of sight
error
horizontal line
40
Instrument test Nähbauer
a'2 a22e b'2 b2e ?h a2-b2 ?h'2
a'2-b'2 a2e-b2 ?he ?h ?h'2-e
a'1 a1e b'1 b12e ?h a1-b1 ?h'1
a'1-b'1 a1-b1-e ?h-e With ?h'1e ?h'2-e
?h'2-?h'1 2
e
41
Summary
42
Procedure of leveling

• The instrument must be check before use! (see
  lecture)
• The instrument and level must be stable
  settled-up
• The bubble tube must be leveled before the
  reading
• Beware of sun exposure (will wander)
• Ensure the instruments pendulum is in-limit
• The instrument must be set up in the middle
  between two staffs
• Prevents curvature effects
• If impossible, use the same distances, but
  opposite for the next readings
• You must not use the parallax screw between the
  backsight and foresight readings

43
Procedure of Leveling

• Readings must be taken 30-50 cm above the ground
• Surface refractions
• Beware also of temperature gradients
  (inside/outside buildings) !!!!
• Staff should be set up vertically
• A change plate should be used
• Leveling must be done in two opposite directions
  but the same line (beware of gravity gradients)
• Staff should be calibrated, especially if INVAR
• Be careful when crossing rivers (large water
  surfaces)
• Use same-time (mutual) observations
• Repeat it during different times of the day

44
An Unhappy Surveyor

• having a 2 centimeter difference
