Current Affairs in the Finnish Nuclear Sector

1
Current Affairs in the Finnish Nuclear Sector

• The 21st Meeting of the IAEA TWG-NPPCI
• May 23-25, 2007
• Vienna
• Janne Valkonen

2
Contents of the presentation

• Finnish nuclear industry in brief
• Loviisa (Fortum) activities
• Olkiluoto (TVO) activities
• Research activities
• Recommendations

3
Finnish nuclear industry in brief
Olkiluoto 1 BWR 75, 840MWe, 1979 Olkiluoto 2
BWR 75, 840MWe, 1982 (Olkiluoto 3 EPR, 1600MWe,
2010-11)
Loviisa 1 VVER-440, 488MWe, 1977 Loviisa 2
VVER-440, 488MWe, 1981
4
Finnish nuclear industry in brief

• Power utilities
• Regulatory authority
• Research centre
• Waste management

5
Activities related to IC systemsin the Loviisa
NPP

• IAEA-TWG-NPPCI
• (Technical Working Group on Nuclear Power Plant
  Control and Instrumentation)
• May 2007
• Slides by Martti Välisuo

6
Loviisa 1 and 2 automation renewal (LARA-project)

• In the LARA-project the IC systems of the plant
  will be renewed gradually there will be four
  stages per plant unit.
• The first system commissioning will take place
  this year (2007) and the last in the year 2014.

7
Automation renewal supports the operation of the
plant

• The goals of the plant operation are
• maintaining safety on its current good level
• maintaining availability on its current good
  level
• long operation time (50 years).

8
Scope of the renewal project
To be renewed
Control room
IC cabinets (Data acquistion, control logic)
Switchgear
Training simulator
Measurements
Actuators
9
Main principles of the renewal

• The IC functions will remain as they are, as a
  rule.
• Tolerance of CCFs will be built in the IC
  concept.
• New IC cabinets will be placed in new buildings
  that fulfill all new requirements.
• Fortum selected a competent supplier with
  applicable products.
• Simulators will be used extensively for various
  purposes
• process and control design
• transient and accident analyses
• development and validation of the HMI
• testing of IC
• operator training.

10
Stages of renewal (1)

• There will be four renewal stages
• Part of reactor IC and nuclear water treatment
  IC
• Reactor protection system
• Scram
• ESFAS
• IC of the emergency diesel generators
• IC of the primary circuit and the relating
  auxiliary systems
• IC of the secondary circuit and the relating
  auxiliary systems

11
Stages of renewal (2)
12
Supplier and platforms

• Fortum has made a contract of the first three
  stages with the consortium of AREVA NP (former
  Framatome ANP) and Siemens AG.
• AREVA's platforms are used for the safety IC
• TELEPERM XS
• QDS (Qualified Display System)
• Hardwired equipment (for the Manual Backup of the
  Reactor Protection System).
• Siemens' platforms are used for the operational
  IC (and for the Automatic Backup of the Reactor
  Protection System)
• SPPA T2000 (former TELEPERM XP)
• OM690 (operating stations).

13
Diversity

• The Reactor Protection functions will be
  implemented with two independent and diverse
  protection layers.
• Protection layer 1
• Reactor Protection System (automatic)
• TELEPERM XS
• Protection layer 2
• Manual Backup
• Hardwired equipment
• Automatic Backup (includes only urgent functions)
• SPPA T2000
• Additionally, functional diversity is designed
  inside each protection layer.

14
Illustration of the future control room
15
New control building (Loviisa 1, building 2.
Autumn 2005)
16

• TVO 1 AND 2
• MAIN IC ACTIVITIES
• 9.5.2007

17
GENERAL

• OL1 and OL2 plants have operated well without any
  remarkable technical disturbances
• Average capacity factor 2006 was 95,4 and total
  production 14,3 TWh
• Lot of effort have been concentrated to
  management of ageing

18
MAIN RENEWAL

• 2006 were finalized turbine island modernization
  including
• HP-turbine modifications
• New 2-stage reheater
• New steam dryer (moisture 0,3 -gt 0,01)
• New turbine automation system including control
  room equipment
• New 6,6 kV switchgears
• Net power increase about 20 MW per unit
• Also water handling and desalination system
  automation were modernized

19
IC MAIN ACTIVITIES DURING 2007

• Gas turbine plant will be finalized, 100 MW unit
  for grid support and emergency power
• Minor IC renewals will be started
• Plant radiation monitoring system renewal
• Environment radiation monitoring system
• Weather station
• Seawater cleaning screens automation

20
IC FUTURE PLANS (not fixed)

• Half-long service outage 2010-2011
• Low-pressure turbine modernisation
• Low pressure turbine renewal
• Turbine vibration monitoring renewal
• Automation for condensation water handling
• Generator renewal
• Reactor main steam line isolation valves
• Long service outage 2015-2016
• Renewal of reactor automation
• Renewal of reactor automation
• Core shroud and other internals
• High pressure turbine optimization
• Cables

21
Source TVO image archive
22
Source TVO image archive
23
Research activities at VTT

• SAFIR 20032006 research programme ended
• New programme SAFIR2010 just started
• Total volume in 2007 approximately 46 person
  years and 6,3 M

24
SAFIR2010 research areas

• SAFIR2010 research programme is divided in eight
  research areas, which are
• 1. Organisation and human factors
• 2. Automation and control room
• 3. Fuel and reactor physics
• 4. Thermal hydraulics
• 5. Severe accidents
• 6. Structural safety of reactor circuit
• 7. Construction safety
• 8. Probabilistic safety analysis (PSA)
• These research areas include both research
  projects of the named topic and interdisciplinary
  co-operation projects.

25
SAFIR2010 Projects 2007Area 2 Automation and
control room

• MODSAFE Model-based safety evaluation of
  automation systems
• CERFAS Certification facilities for software
• OPRACTICE Operator practices and human-system
  interfaces in computer-based control stations

26
MODSAFE - Model-based safety evaluation of
automation systems (1)

• Background
• Formal models can be/are used in various phases
  of automation design (e.g. functional block
  diagrams, state machines, UML-models etc.)
• Tools for model checking are available
• Possibilities to get into a hazardous situation
  can be identified by analysing models
• Need of tools for analysis of safety functions
  based on programmable technology

27
MODSAFE - Model-based safety evaluation of
automation systems (2)

• Objectives
• Development of methods for model based safety
  evaluation of NPP automation
• Application of the methods in selected case
  studies
• Evaluation of the suitability of formal model
  checking methods for NPP automation analysis
• Operationalization of model based safety
  evaluation as a part of safety case of safety
  automation systems
• Development of recommendations for the practical
  application of the methods

28
O'PRACTICE - Operator practices and human-system
interfaces in computer-based control stations (1)

• Starting point
• Challenges caused by control room (CR) and
  human-system interface (HSI) upgrades
• Objectives
• Develop practices of Human Factors Engineering
  (HFE) for the design, operation and evaluation of
  human-system interfaces at NPP control rooms
• Promote safe use of digital technologies
• Develop new methods and practices for the
  management of design process and evaluation of
  the safety of HSIs
• Develop expertise on user-centred design of
  complex industrial systems in Finland
• Promote international collaboration with research
  and expert organizations, and institutions
• Strengthen delivery of expertise in the field of
  user-centred design.

29
O'PRACTICE - Operator practices and human-system
interfaces in computer-based control stations (2)

• Key research activities in 2007
• New tools of collaboration for operating
  personnel
• Survey user needs for collaborative tools such as
  large screen displays
• Study usage practices of large-screen displays
  and computer-based procedures
• Development of new concept of operation for
  fully-digitalized control rooms
• Study the use of Information Rich large screen
  displays for process control purposes
• Develop a novel operating support system
  prototype based on methods of semantic modelling,
  dialogic interviews and user studies
• Evaluation of control rooms and human-system
  interfaces
• Study the adequacy, effectiveness and safety of
  hybrid human-system interfaces

30
CERFAS - Certification facilities for software

• Purpose is to develop facilities for a software
  certification service
• Networking in the area of software certification
  services. Certifiers must have competing products
  and unique features that are desired by the
  clients.
• The objective is to develop facilities for
  flexible, supported, commercially exploitable,
  high quality software certification service able
  to certify safety critical and safety related
  software.
• Also advanced methods for evaluation of software
  process and artefacts, that is, documents, code,
  test plans, etc. competence development to
  provide facilities for software certification
  service.

31
Recommendations to the TWG-NPPCI (1)

• Possibilities of Open Souce in the area of
  safety-critical software.
• Design and licencing patterns as a means to
  enhance readiness to develop and evaluate
  safety-critical software.
• Automated tools for the analysis of software
  modules (model based approaches).
• Managing the large difference in lifetime between
  nuclear power plants and their IC systems.

32
Recommendations to the TWG-NPPCI (2)

• Concept of operations and operator practices in
  digitalised control rooms.
• Functional task analysis for operator
  functions.
• Information tools for improving collaboration
  between operations and maintenance.
• Role of large screen displays in supporting
  situation awareness.
• New methods to analyse and control mental effort
  in stress situations.
• Human Factors Engineering practices in design of
  automation and control stations.

33
Acknowledgements

• Martti Välisuo, Fortum Nuclear Services
• Olli Hoikkala, TVO
• Juhani Hyvärinen, STUK
• Hannu Harju, VTT
• Jari Laarni, VTT
• THANK YOU FOR YOUR ATTENTION!
