Integrated Management of Whiteflies in Arizona

1
Integrated Management of Whiteflies in Arizona

• Peter C. Ellsworth, Ph.D.
• IPM Specialist, University of Arizona
• Maricopa, AZ, USA
• Steve Naranjo, Ph.D.
• Research Scientist, USDA-ARS, WCRL
• Phoenix, AZ, USA

2
World Distribution of Outbreaks of B. tabaci
3
State of Arizona, U.S.A.
Maricopa Agricultural Center (350 m)
Majority of cotton production in AZ
Yuma Agricultural Center (50 m)
4
Impact of SWF on Arizona

• Whiteflies (biotype B) invaded Arizona in the
  early 1990s.
• Losses to the agricultural industry were
  catastrophic.
• Honeydew excreted by SWF caused sticky cotton
  that could not be sold at a premium price after
  outbreaks in 1992 1995.

5
AZ Lint Lost Value
0

• In the late 1980s, AZ enjoyed a premium for its
  cotton lint relative to New York Futures.
• The 1992 1995 outbreaks led to depressed prices
  for AZ lint, a loss that we continue to endure in
  spite of clean cotton.

6
Pest Trends in Arizona (1990-2000)

• The 1995 outbreak led to a 25-yr high in foliar
  insecticide use in cotton.
• There was a major shift in insecticide use in
  1996...

7
Arizona IPM Plan Introduced

• due to the introduction of insect growth
  regulators, Bt cotton, and the Arizona IPM plan.
• 1999 was a 25-yr low in foliar insecticide use in
  cotton.

8
Whitefly IPM
depends on 3 basic keys
3
2
1
9
Avoidance
all practices that serve to prevent or maintain
pests below economic levels.
1
10
Crop Management
some factors lead to increased SWF numbers, such
as water-stress, excess N, or hairy-leafed
cultivars
11
Exploitation of Pest Biology Ecology
knowing your enemy will help guide prevention
efforts, such as specific information on how SWFs
are dying the role of natural enemies
12
Area-Wide Impact
is needed for this mobile polyphagous pest
includes elements of cooperation, source
reduction attention to SWF movement...
13
Areawide Impact
also depends on stable systems of management to
be in place for all sensitive crops in order to
reduce area-wide pressure.
14
When SWF are damaging...
we depend on the top two levels of the pyramid
3
2
1
15
Sampling
sits atop the pyramid serves all layers of
management.
16
Sampling ( 7 min. / field)

• Locate 5th leaf (below terminal)
• Score as infested with adults when
• 3 or more adults present
• Examine quarter-sized leaf disk
• Score as infested with nymph when
• 1 or more LARGE nymphs present
• Tally up 30 leaves 30 leaf disks

17
Field Sampling for Nymphs
Determine infested
18
Action Thresholds
with sampling, can be used to precisely time
sprays with IGRs (Stage I) other insecticides
(Stage II III).
19
Whitefly Thresholds

• Timing of IGRs (Stage I)
• 40 of leaves infested with 3 or more adults
• 40 of disks infested with 1 or more large
  nymphs
• Timing Stage II III conventional sprays
• 57 of leaves infested with 3 or more adults

20
Selective Effective Chemistry
the insect growth regulators sit at the center
of our pyramid.
21
Major Points of Insect Growth Regulation
pyriproxyfen
Knack

Knack

Adult
4th,

Egg
pupa
Crawler
2nd
3rd
Applaud

Applaud

buprofezin
22
IGRs Natural Enemy Conservation
demonstrate the interaction between levels of
the pyramid to produce bioresidual...
23
What is Bioresidual?

• Overall killing power of an insect control
  technology including the direct effects of the
  technology (i.e., chemical residual) PLUS the
  associated natural biological mortality.
• Ellsworth Martinez-Carrillo, 2001

biological
insectice
24
IGRs v. Conventional Chemistry
Bioresidual via natural mortality extends the
effectiveness of IGRs, while conventional sprays
kill natural enemies require repeated sprays.
4 conventional sprays vs. just 1 IGR spray in
1997.
commercial-scale studies are shown for two
years here...
One IGR spray lasts ONLY 14 days chemically
3 conventional sprays, or just 1 IGR spray
needed in 1999.
1999
1997
78 weeks
bioresidual
bioresidual
6 weeks
threshold
25
Recommended Strategy

• 1) Use IGRs first (1 use each only)
• 40 infested leaves AND
• 40 infested disks
• 2) Use IGRs without mixing with other chemicals
  (if possible)
• dont waste the bioresidual
• 3) Delay the use of follow-up sprays for 1421
  days
• i.e., at least 1 generation of whiteflies

26
Resistance Management
is a shared responsibility to ensure efficacy of
our valuable chemistry. All chemistry falls into
1 of 3 stages...
27
Three Stage Strategy

• Stage I Use IGR of choice when counts exceed
  threshold
• Follow-up with alternate IGR, if needed
• Use each no more than once
• Stage II Use Stage II (non-pyrethroid) materials
  at least once before Stage III materials
• Do not use foliar neonicotinoids in multi-crop
  communities or more than twice in cotton areas
• Stage III Reserve use of pyrethroid mixtures
  until end of season, and no more than twice

28
Conclusions (1)

• With the adoption of the AZ IPM plan, SWF sprays
  have been reduced by 71 to around 1 spray per
  season, and growers have saved over 100 million
  in control costs and yield savings in the last 5
  years.
• The AZ IPM plan depends on multiple elements of
  Sampling Effective Chemical Use built on a
  foundation of Avoidance.

29
Conclusions (2)

• Six years of success have been based on
• research-based guidelines for sampling
  thresholds,
• access to powerful selective IGRs with proven
  guidelines for their use,
• the extended suppressive interval, known as
  bioresidual, which maximizes natural mortality
  factors of the SWF creates area-wide benefits,
  and
• an organized comprehensive educational campaign

30
Information
ACIS

• All University of Arizona crop production crop
  protection information is available on our web
  site,
• Arizona Crop Information Site (ACIS), at
• http//ag.arizona.edu/crops
