Hibernate

1
Hibernate
2
Hibernate

• Hibernate is a powerful, high performance
  object/relational persistence and query service.
  Hibernate lets you develop persistent classes
  following object-oriented idiom - including
  association, inheritance, polymorphism,
  composition, and collections. Hibernate allows
  you to express queries in its own portable SQL
  extension (HQL), as well as in native SQL, or
  with an object-oriented Criteria and Example API.
• Unlike many other persistence solutions,
  Hibernate does not hide the power of SQL from you
  and guarantees that your investment in relational
  technology and knowledge is as valid as always.
  The LGPL open source license allows the use of
  Hibernate and NHibernate in open source and
  commercial projects.

3
Java Persistence with Hibernate

• The Java Persistence API is the standard
  object/relational mapping and persistence
  management interface of the Java EE 5.0 platform.
  As part of the EJB 3.0 specification effort, it
  is supported by all major vendors of the Java
  industry.
• Hibernate implements the Java Persistence
  object/relational mapping and persistence
  management interfaces with the Hibernate
  Annotations and Hibernate EntityManager modules,
  on top of the mature and powerful Hibernate Core.
• The Hibernate modules can be stacked and combined
  as desired. You can use the Hibernate Java
  Persistence provider in any environment, Java SE
  5.0 or Java EE 5.0. The Hibernate Java
  Persistence provider is fully certified and
  passes the Sun TCK.

4
Hibernate Annotations

• Project Lead Emmanuel BernardLatest release
  3.4.0 GA (Changelog) (Road Map)Release date
  20.08.2008Requirements Hibernate Core 3.3.x, JDK
  5.0Hibernate, like all other object/relational
  mapping tools, requires metadata that governs the
  transformation of data from one representation to
  the other (and vice versa). As an option, you can
  now use JDK 5.0 annotations for object/relational
  mapping with Hibernate 3.2. You can use
  annotations in addition to or as a replacement of
  XML mapping metadata.
• The Hibernate Annotations package includes
• Standardized Java Persistence and EJB 3.0 (JSR
  220) object/relational mapping annotations
• Hibernate-specific extension annotations for
  performance optimization and special mappings
• You can use Hibernate extension annotations on
  top of standardized Java Persistence annotations
  to utilize all native Hibernate features.

5
More jar file downloads

• You will need persistence and ejb jar files ejb,
  persistence, jndi, geronimo-ejb, ejb3-persistence
  and javaee.
• Hibernate tutorials
• http//www.hibernate.org/hib_docs/reference/en/htm
  l/tutorial.html
• http//www.roseindia.net/hibernate/index.shtml
• http//www.hibernate.org/hib_docs/reference/en/htm
  l/tutorial-webapp.html
• http//www.inf.ed.ac.uk/teaching/courses/ec/handou
  ts/quickstart.pdf

6
Hibernate tutorials

• I hope to put two or three tutorials here. Right
  now there is just one, an application program
  running against a mysql db, with just one table,
  using hibernate.
• Hibernate standardizes the db interface. A config
  file specifies the actual db service and the
  dialect to use, and other config files, called
  hbm, map the individual tables. Instead of
  provider-specific connection and query details,
  the program uses the hibernate interface to
  interact with the database.

7
First hibernate tutorial

• Using hibernate with a mysql database and a few
  simple java classes.
• Link for tutorial http//www.hibernate.org/hib_do
  cs/reference/en/html/tutorial-firstapp.html
• This tutorial has many omissions, most notably
  library jar files needed, also a few errors or
  typos about where files go. I also had to modify
  some classes (HibernateUtil) somewhat to get it
  to work.

8
ant

• Youll use ant and a build file appears in the
  next slide. If you change directories or file
  names youll have to make modifications in the
  ant script.
• Recall, ant must be in the system path and all
  your java stuff must be in the path/classpath for
  the ant build to work.
• Note, the build requires directories called src,
  bin and lib. Contents are detailed later.

9
build.xml

• ltproject name"hibernate-tutorial"
  default"compile"gt
• ltproperty name"sourcedir" value"basedir/s
  rc"/gt
• ltproperty name"targetdir" value"basedir/b
  in"/gt
• ltproperty name"librarydir"
  value"basedir/lib"/gt
• ltpath id"libraries"gt
• ltfileset dir"librarydir"gt
• ltinclude name".jar"/gt
• lt/filesetgt
• lt/pathgt
• lttarget name"clean"gt
• ltdelete dir"targetdir"/gt
• ltmkdir dir"targetdir"/gt
• lt/targetgt
• lttarget name"compile" depends"clean,
  copy-resources"gt
• ltjavac srcdir"sourcedir"
• destdir"targetdir"
• classpathref"libraries"/gt
• lt/targetgt
• lttarget name"copy-resources"gt

10
Notes about lib directory

• Youll need the following jars
• hibernate
• cp30
• antlr
• jta
• dom4j
• commons logging and collections
• Just 2 files from slf4j(simple and api)note
  screen shot!!!
• You wont need hsqldb thats another db service
  connector, but you will need the mysql-java db
  connector

11
My lib directory
12
Directory structure

• Your_App_dir
• bin
• src
• log4j.properties
• hibernate.cfg.xml
• Event.hbm.xml
• hibernate.properties --- not included in this
  example
• events(dir)
• Event.java
• util(dir)
• EventManager.java
• HibernateUtil.java
• Lib (see previous slide)

13
HibernateUtil.java

• package util
• //you can find this class in eclipse, netbeans or
  online, with few variations
• import org.hibernate.
• import org.hibernate.cfg.
• public class HibernateUtil
• private static final SessionFactory
  sessionFactory
• static
• try
• System.out.println("in try for build session
  factory")
• // Create the SessionFactory from
  hibernate.cfg.xml
• sessionFactory new
  Configuration().configure().buildSessionFactory()

• System.out.println("back from build
  session factory")
• catch (Throwable ex)
• // Make sure you log the exception,
  as it might be swallowed
• System.err.println("Initial
  SessionFactory creation failed." ex)
• System.out.println("Initial
  SessionFactory creation failed." ex)
• throw new ExceptionInInitializerError(
  ex)
• public static SessionFactory
  getSessionFactory()

14
EventManager.java entirety also in slide notes

• package events
• import org.hibernate.
• import org.hibernate.cfg.
• import java.util.Date
• import java.util.
• import util.HibernateUtil
• public class EventManager
• public static void main(String args)
  //main
• EventManager mgr new EventManager()
• System.out.println("Event Manager before if")
  /////I stuck in all these
  println
• if (args0.equals("store")) //if
• System.out.println("create and store")
• mgr.createAndStoreEvent("My Event", new
  Date())
• //if
• else if (args0.equals("list"))
• System.out.println("list events")
• List events mgr.listEvents()
• for (int i 0 i lt events.size() i)

15
EventManager.java continued

• private List listEvents()
• System.out.println("Event Manager... in list
  events method")
• SessionFactory sessionFactory
  HibernateUtil.getSessionFactory()
• Session session sessionFactory.openSession()

• session.beginTransaction()
• List result session.createQuery("from
  Event").list()
• session.getTransaction().commit()
• return result
• private void createAndStoreEvent(String
  title, Date theDate)
• System.out.println("Event Manager... create and
  store method")
• SessionFactory sessionFactory
  HibernateUtil.getSessionFactory()
• Session session sessionFactory.openSession(
  )
• System.out.println(".. before begin
  transaction")
• session.beginTransaction()
• System.out.println(".. transaction started")
• Event theEvent new Event()
• theEvent.setTitle(title)

16
Event.java

• package events
• import java.util.Date
• public class Event
• private Long id
• private String title
• private Date date
• public Event()
• public Long getId()
• return id
• private void setId(Long id)
• this.id id
• public Date getDate()
• return date
• public void setDate(Date date)
• this.date date

17
Event.hbm.xml --such a file (and the
corresponding java class) is needed for each
table mapped.

• lt?xml version"1.0"?gt
• lt!DOCTYPE hibernate-mapping PUBLIC
• "-//Hibernate/Hibernate Mapping DTD
  3.0//EN"
• "http//hibernate.sourceforge.net/hibernat
  e-mapping-3.0.dtd"gt
• lthibernate-mappinggt
• ltclass name"events.Event" table"EVENTS"gt
• ltid name"id" column"EVENT_ID"gt
• ltgenerator class"native"/gt
• lt/idgt
• ltproperty name"date" type"timestamp"
  column"EVENT_DATE"/gt
• ltproperty name"title"/gt
• lt/classgt
• lt/hibernate-mappinggt

18
hibernate.cfg.xml contains connection info, db
name, user name pw and other information

• lt?xml version'1.0' encoding'utf-8'?gt
• lt!DOCTYPE hibernate-configuration PUBLIC
• "-//Hibernate/Hibernate Configuration DTD
  3.0//EN"
• "http//hibernate.sourceforge.net/hibernate-config
  uration-3.0.dtd"gt
• lthibernate-configurationgt
• ltsession-factorygt
• lt!-- Database connection settings --gt
• ltproperty name"connection.driver_class"gtcom.mysql
  .jdbc.Driverlt/propertygt
• ltproperty name"connection.url"gtjdbcmysql//local
  host/mydblt/propertygt
• ltproperty name"connection.username"gtrootlt/propert
  ygt
• ltproperty name"connection.password"gtlt/propertygt
• lt!-- JDBC connection pool (use the built-in) --gt
• ltproperty name"hibernate.connection.pool_size"
  gt10lt/propertygt
• lt!-- MySQL dialect//different for different
  Database --gt
• ltproperty name"dialect"gtorg.hibernate.dialect.MyS
  QLDialectlt/propertygt
• lt!-- Echo all executed SQL to stdout --gt
• ltproperty name"show_sql"gttruelt/propertygt
• ltproperty name"hbm2ddl.auto"gtupdatelt/propertygt
• ltmapping resource"Event.hbm.xml"/gt

19
Log4j.properties

• log4j.appender.stdoutorg.apache.log4j.ConsoleAppe
  nder
• log4j.appender.stdout.TargetSystem.out
• log4j.appender.stdout.layoutorg.apache.log4j.Patt
  ernLayout
• log4j.appender.stdout.layout.ConversionPatternd
  ABSOLUTE 5p c1L - mn
• log4j.rootLoggerinfo, stdout
• log4j.logger.org.hibernate.testinfo
• log4j.logger.org.hibernate.tool.hbm2ddldebug

20
remark

• Youll need to create a mysql database and table
  for this example and you need to start the
  database server before running the example.
• Run the example in the root directory on the
  commandline either with
• ant run Dactionstore
• Or
• ant run Dactionlist

21
black screen output for store (when it works)

• C\hibernateexamplegtant run -Dactionstore
• Buildfile build.xml
• clean
• delete Deleting directory C\hibernateexample
  \bin
• mkdir Created dir C\hibernateexample\bin
• copy-resources
• copy Copying 6 files to C\hibernateexample
  \bin
• copy Copied 2 empty directories to 1 empty
  directory under C\hibernateex
• ample\bin
• compile
• javac Compiling 3 source files to
  C\hibernateexample\bin
• run
• java Event Manager before if
• java create and store
• java Event Manager... create and store
  method
• java in try for build session factory
• ltltltomitted a lotsee slide notesgtgtgt
• java 719 main INFO
  org.hibernate.tool.hbm2ddl.SchemaUpdate - schema
  upd
• ate complete

22
Run list when it worksentirety in notes

• C\hibernateexamplegtant run -Dactionlist
• Buildfile build.xml
• clean
• copy-resources
• compile
• javac Compiling 3 source files to
  C\hibernateexample\bin
• run
• ltltleft out a lot of output heregtgtgtgt
• java 531 main INFO
  org.hibernate.impl.SessionFactoryImpl - building
  ses
• sion factory
• java 719 main INFO org.hibernate.impl.Ses
  sionFactoryObjectFactory - Not
• binding factory to JNDI, no JNDI name configured
• java 719 main INFO org.hibernate.tool.hbm
  2ddl.SchemaUpdate - Running hb
• m2ddl schema update
• java 719 main INFO org.hibernate.tool.hbm
  2ddl.SchemaUpdate - fetching d
• atabase metadata
• java 719 main INFO org.hibernate.tool.hbm
  2ddl.SchemaUpdate - updating s

23
Your project
24
notes

• First, of course, get the original tutorial
  working.
• Modify the EventManager so it opens a JFrame with
  two button, list and store, a textfield and a
  textarea.
• You are welcome to make a different table but you
  dont have to.
• (E.C. You may want another button to delete
  from db/table)
• List button will display stored events in a
  textarea.
• Store button will get data for the event from a
  textfield.
• E.C. The tutorial code uses a timestamp, but
  maybe something else like a string with MM/DD/YY
  format would be nicer.

25
So whats the point of hibernate?

• A uniform connection (that session thingy) and
  sql dialect in your object. This doesnt change
  as you port your application.
• The hibernate.cfg.xml (NOT your java code) gets
  modified if you port your app, or change database
  servers.

26
The hibernate webapp
27
WEB-INF\web.xml

• lt?xml version"1.0" encoding"UTF-8"?gt
• ltweb-app version"2.4"
• xmlns"http//java.sun.com/xml/ns/j2ee"
• xmlnsxsi"http//www.w3.org/2001/XMLSchema-in
  stance"
• xsischemaLocation"http//java.sun.com/xml/ns
  /j2ee http//java.sun.com/xml/ns/j2ee/web-app_2_4.
  xsd"gt
• ltservletgt
• ltservlet-namegtEvent Managerlt/servlet-namegt

• ltservlet-classgtevents.EventManagerServletlt
  /servlet-classgt
• lt/servletgt
• ltservlet-mappinggt
• ltservlet-namegtEvent Managerlt/servlet-namegt

• lturl-patterngt/eventmanagerlt/url-patterngt
• lt/servlet-mappinggt
• lt/web-appgt

28
Where do files go? Shown in another slide but
note

• Hibernate.cfg goes in classes dir
• Event.hbm.xml goes into Events dir (I think)

29
The 1-table hibernate web app

•     http//www.hibernate.org/hib_docs/reference/en
  /html/tutorial-webapp.html
• This tutorial came from hibernate.org. I think it
  is basically correct, although I made changes to
  the servlet trying to fix unrelated problems. I
  also used my own HibernateUtil class (shown in
  previous tutorial).
• Not very many details about the directory
  structure were given in the tutorial, but I give
  them here.

30
Servlet running in tomcat
31
Servlet entirety in slide notes

• package events
• import java.io.
• import java.net.
• import java.text.SimpleDateFormat
• import java.util.Date
• import java.util.Iterator
• import java.util.List
• import javax.servlet.
• import javax.servlet.http.
• import util.HibernateUtil
• import org.hibernate.
• public class EventManagerServlet extends
  HttpServlet
• SessionFactory sessionFactory
• Session session

32
Servlet continued

• protected void processRequest(HttpServletRequest
  request, HttpServletResponse response)
• throws ServletException, IOException

• response.setContentType("text/htmlcharset
  UTF-8")
• SimpleDateFormat dateFormatter new
  SimpleDateFormat("dd.MM.yyyy")
• PrintWriter out response.getWriter()
• out.println("lthtmlgtltheadgtlttitlegtEvent
  Managerlt/titlegtlt/headgtltbodygt")
• try
• // Begin unit of work
• // HibernateUtil.getSessionFactory().ge
  tCurrentSession().beginTransaction()
• sessionFactory HibernateUtil.getSess
  ionFactory()
• session sessionFactory.openSession()

• session.beginTransaction()
• // Handle actions
• if ("store".equals(request.getParamete
  r("action")))
• String eventTitle
  request.getParameter("eventTitle")
• String eventDate
  request.getParameter("eventDate")
• if ("".equals(eventTitle)
  "".equals(eventDate))
• out.println("ltbgtltigtPlease
  enter event title and date.lt/igtlt/bgt")

33
Servlet continued

• private void printEventForm(PrintWriter out)
• out.println("lth2gtAdd new eventlt/h2gt")
• out.println("ltformgt")
• out.println("Title ltinput
  name'eventTitle' length'50'/gtltbr/gt")
• out.println("Date (e.g. 24.12.2009)
  ltinput name'eventDate' length'10'/gtltbr/gt")
• out.println("ltinput type'submit'
  name'action' value'store'/gt")
• out.println("lt/formgt")
• private void listEvents(PrintWriter out,
  SimpleDateFormat dateFormatter)
• List result HibernateUtil.getSessionFact
  ory().getCurrentSession().createCriteria(Event.cla
  ss).list()
• if (result.size() gt 0)
• out.println("lth2gtEvents in
  databaselt/h2gt")
• out.println("lttable border'1'gt")
• out.println("lttrgt")
• out.println("ltthgtEvent titlelt/thgt")
• out.println("ltthgtEvent datelt/thgt")

34
Servlet continued

• protected void createAndStoreEvent(String title,
  Date theDate)
• Event theEvent new Event()
• theEvent.setTitle(title)
• theEvent.setDate(theDate)
• HibernateUtil.getSessionFactory().getCurre
  ntSession().save(theEvent)
• protected void doGet(HttpServletRequest
  request, HttpServletResponse response)
• throws ServletException, IOException

• processRequest(request, response)
• protected void doPost(HttpServletRequest
  request, HttpServletResponse response)
• throws ServletException, IOException

• processRequest(request, response)

35
One line added to cfg

• lt?xml version'1.0' encoding'utf-8'?gt
• lt!DOCTYPE hibernate-configuration PUBLIC
• "-//Hibernate/Hibernate Configuration DTD
  3.0//EN"
• "http//hibernate.sourceforge.net/hibernate-config
  uration-3.0.dtd"gt
• lthibernate-configurationgt
• ltsession-factorygt
• lt!-- Database connection settings --gt
• ltproperty name"connection.driver_class"gtcom.mysql
  .jdbc.Driverlt/propertygt
• ltproperty name"connection.url"gtjdbcmysql//local
  host/mydblt/propertygt
• ltproperty name"connection.username"gtrootlt/propert
  ygt
• ltproperty name"connection.password"gtlt/propertygt
• lt!-- JDBC connection pool (use the built-in) --gt
• ltproperty name"hibernate.connection.pool_size"
  gt10lt/propertygt
• lt!-- MySQL dialect//different for different
  Database --gt
• ltproperty name"dialect"gtorg.hibernate.dialect.MyS
  QLDialectlt/propertygt
• lt!-- Echo all executed SQL to stdout --gt
• ltproperty name"show_sql"gttruelt/propertygt
• ltproperty name"hbm2ddl.auto"gtupdatelt/propertygt
• ltproperty name"current_session_context_class"gtthr
  eadlt/propertygt

36
This build puts webapp war file one directory up
(like in C)

• ltproject name"hibernate-tutorial"
  default"compile"gt
• ltproperty name"sourcedir" value"basedir/s
  rc"/gt
• ltproperty name"targetdir" value"basedir/b
  in"/gt
• ltproperty name"librarydir"
  value"basedir/lib"/gt
• ltpath id"libraries"gt
• ltfileset dir"librarydir"gt
• ltinclude name".jar"/gt
• lt/filesetgt
• lt/pathgt
• lttarget name"clean"gt
• ltdelete dir"targetdir"/gt
• ltmkdir dir"targetdir"/gt
• lt/targetgt
• lttarget name"compile" depends"clean,
  copy-resources"gt
• ltjavac srcdir"sourcedir"
• destdir"targetdir"
• classpathref"libraries"/gt
• lt/targetgt
• lttarget name"copy-resources"gt

37
Package things in WEB-INF as shown here

• WEB-INF
• classes (dir)
• events(dir)
• Event.class (no changes to this file)
• EventManagerServlet.class
• Event.hbm.xml (no changes to this file)
• util(dir)
• HibernateUtil.class (this file same as in
  previous project)
• Hibernate.cfg.xml (shown above one line added)
• If it cant find tableclass.hbm.xml then put them
  here
• lib(dir) (no changes to this)
• log4j.properties(no changes to this)
• web.xml (shown above)

38
Jar

• I used jar instead of ant build
• jar cvf appname.war WEB-INF
• Creates a jar called appname.war from contents of
  WEB-INF
• Youll need to move files and directories as per
  earlier slide before creating a war file.

39
Whats next?

• I will put a 2nd hibernate project here to be
  assigned after the hibernate desktop app. I
  havent finished working on it, but it will
  likely involve CRUD against a database using one
  or more servlets, like your servlet database
  project, except use a hibernate interface.

40
Two examples multiple tables crud

• documentation http//www.hibernate.org/hib_docs/re
  ference/en/html/

41
(No Transcript)
42
Adding to tables listing

• I modified previous example, adding a people
  table and displaying contents of two tables.
• I did not do a select, I just printed the event
  title in the same position. But since the
  numbers are allocated sequentially, I could have
  used select title from Event where idnumber

43
My tables

• My People table and my Event table both have ids
  as primary key, autoincremented.
• In the hbm, these are identified as

44
Dir structure

• WEB-INF
• log4j.properties
• web.xml
• lib (contents shown later)
• classes
• hibernate.cfg.xml
• util
• Same HibernateUtil.java as previous
• events
• Same Event.java as previous
• People.java
• EventManagerServlet.java
• People.hbm.xml
• Event.hbm.xml (unchanged from prev example)

45
some of these may be unnecessary but I whittled
it down some
46
Entire Servlet in notes

• package events
• import java.io.
• import java.net.
• import java.text.SimpleDateFormat
• import java.util.Date
• import java.util.Iterator
• import java.util.List
• import javax.servlet.
• import javax.servlet.http.
• import util.HibernateUtil
• import org.hibernate.
• public class EventManagerServlet extends
  HttpServlet
• SessionFactory sessionFactory
• List result1,result2
• Session session
• protected void processRequest(HttpServletReque
  st request, HttpServletResponse response)
• throws ServletException, IOException

• response.setContentType("text/htmlcharset
  UTF-8")

47
Servletprint form, get session

• // Handle actions
• if ("store".equals(request.getParameter
  ("action")))
• String eventTitle
  request.getParameter("eventTitle")
• String eventDate
  request.getParameter("eventDate")
• String name request.getParameter("name")
• String phone request.getParameter("phone")
• if ("".equals(eventTitle)
  "".equals(eventDate)name.equals("")phone.equal
  s(""))
• out.println("ltbgtltigtPlease
  enter person, event title and date.lt/igtlt/bgt")
• else
• System.out.println("before call to create
  and store")
• createAndStoreEvent(name,
  phone,eventTitle, dateFormatter.parse(eventDate))

• out.println("ltbgtltigtAdded
  event.lt/igtlt/bgt")
• // Print page

48
Servlet the form and table of events

• private void printEventForm(PrintWriter out)
• out.println("lth2gtAdd new eventlt/h2gt")
• out.println("ltformgt")
• out.println("Title ltinput
  name'eventTitle' length'50'/gtltbr/gt")
• out.println("Date (e.g. 24.12.2009)
  ltinput name'eventDate' length'10'/gtltbr/gt")
• out.println("Contact person ltinput
  name'name' length'50'/gtltbr/gt")
• out.println("Phone(e.g. [phone]
  ltinput name'phone' length'50'/gtltbr/gt")
• out.println("ltinput type'submit'
  name'action' value'store'/gt")
• out.println("lt/formgt")
• private void listEvents(PrintWriter out,
  SimpleDateFormat dateFormatter)
• result1 session.createCriteria(Event.class).l
  ist()
• if (result1.size() gt 0)
• out.println("lth2gtEvent Info in
  databaselt/h2gt")
• out.println("lttable border'1'gt")
• out.println("lttrgt")

49
Servlet list table of people

• int num0
• result2 session.createCriteria(People.clas
  s).list()
• if (result2.size() gt 0)
• out.println("lth2gtPeople Info in
  databaselt/h2gt")
• out.println("lttable border'1'gt")
• out.println("lttrgt")
• out.println("ltthgtPersonlt/thgt")
• out.println("ltthgtPhonelt/thgt")
• out.println("ltthgtEvent
  coordinatinglt/thgt")
• out.println("lt/trgt")
• String unknown"unknown"
• for (Iterator it
  result2.iterator() it.hasNext())
• People person(People)it.next()
• out.println("lttrgt")
• out.println("lttdgt"
  person.getName() "lt/tdgt")
• out.println("lttdgt"
  person.getPhone() "lt/tdgt")
• out.println("lttdgt" ((Event)result1.get(num)).get
  Title() "lt/tdgt")
• num

50
Create and store

• protected void createAndStoreEvent(String
  name,String phone,String title, Date theDate)
• System.out.println("in create and store
  method")
• Event theEvent new Event()
• People personnew People()
• theEvent.setTitle(title)
• theEvent.setDate(theDate)
• person.setName(name)
• person.setPhone(phone)
• System.out.println("about to get current
  session and save event")
• session.save(theEvent)
• System.out.println("about to get current
  session and save person")
• session.save(person)
• System.out.println("done with saves")
• protected void doGet(HttpServletRequest
  request, HttpServletResponse response)
• throws ServletException, IOException

• System.out.println("in do get")

51
events.People.java

• public class People
• private String name
• private String phone
• private long id
• public People()
• public long getId()return id
• public void setId(long id)this.idid
• public String getName()
• return name
• public void setName(String name)
• this.name name
• public String getPhone()

52
The primary key may be generated, native or
assigned. The strategy must be specified in the
hbm.xml. This is People.hbm.xml

• lt?xml version"1.0"?gt
• lt!DOCTYPE hibernate-mapping PUBLIC
• "-//Hibernate/Hibernate Mapping DTD
  3.0//EN"
• "http//hibernate.sourceforge.net/hibernat
  e-mapping-3.0.dtd"gt
• lthibernate-mappinggt
• ltclass name"events.People" table"people"gt
• ltid name"id" column"id"gt
• ltgenerator class"native"/gt
• lt/idgt
• ltproperty name"name"/gt
• ltproperty name"phone"/gt
• lt/classgt
• lt/hibernate-mappinggt

53
Same hibernate.cfg.xml except People table has
been added.

• lt?xml version'1.0' encoding'utf-8'?gt
• lt!DOCTYPE hibernate-configuration PUBLIC
• "-//Hibernate/Hibernate Configuration DTD
  3.0//EN"
• "http//hibernate.sourceforge.net/hibernate-config
  uration-3.0.dtd"gt
• lthibernate-configurationgt
• ltsession-factorygt
• lt!-- Database connection settings --gt
• ltproperty name"connection.driver_class"gtcom.mysql
  .jdbc.Driverlt/propertygt
• ltproperty name"connection.url"gtjdbcmysql//local
  host/mydblt/propertygt
• ltproperty name"connection.username"gtrootlt/propert
  ygt
• ltproperty name"connection.password"gtlt/propertygt
• lt!-- JDBC connection pool (use the built-in) --gt
• ltproperty name"hibernate.connection.pool_size"
  gt10lt/propertygt
• lt!-- MySQL dialect//different for different
  Database --gt
• ltproperty name"dialect"gtorg.hibernate.dialect.MyS
  QLDialectlt/propertygt
• ltproperty name"cache.provider_class"gtorg.hibernat
  e.cache.NoCacheProviderlt/propertygt
• lt!-- Echo all executed SQL to stdout --gt
• lt!-- Echo all executed SQL to stdout --gt
• ltproperty name"show_sql"gttruelt/propertygt

54
ant build still needs to be modified to build
WEB-INF and classes dirs, and copy files to
there, then jar

• ltproject name"hibernate-tutorial"
  default"compile"gt
• ltproperty name"sourcedir" value"basedir/s
  rc"/gt
• ltproperty name"targetdir" value"basedir/b
  in"/gt
• ltproperty name"librarydir"
  value"basedir/lib"/gt
• ltpath id"libraries"gt
• ltfileset dir"librarydir"gt
• ltinclude name".jar"/gt
• lt/filesetgt
• lt/pathgt
• lttarget name"clean"gt
• ltdelete dir"targetdir"/gt
• ltmkdir dir"targetdir"/gt
• lt/targetgt
• lttarget name"compile" depends"clean,
  copy-resources"gt
• ltjavac srcdir"sourcedir"
• destdir"targetdir"
• classpathref"libraries"/gt
• lt/targetgt
• lttarget name"copy-resources"gt

55
CRUD example

• The student table

56
Hibernate student info servlet
57
remarks

• Just one table marked
• Link above gives good information on how to
  conduct queries.
• I used radiobuttons to indicate function desired.
• I used the same ant/build and jar commands as
  before.
• Same directory structure.
• Servlet in slide notes

58
Student.hbm.xml

• lt?xml version"1.0"?gt
• lt!DOCTYPE hibernate-mapping PUBLIC
• "-//Hibernate/Hibernate Mapping DTD
  3.0//EN"
• "http//hibernate.sourceforge.net/hibernat
  e-mapping-3.0.dtd"gt
• lthibernate-mappinggt
• ltclass name"data.Student" table"Students"gt
• ltid name"id" column"id"gt
• ltgenerator class"native"/gt
• lt/idgt
• ltproperty name"name"/gt
• ltproperty name"age"/gt
• ltproperty name"gpa"/gt
• ltproperty name"sex"/gt
• ltproperty name"year"/gt
• lt/classgt

59
Some bits of the servlet

• try
• // Begin unit of work
• // HibernateUtil.getSessionFactory().ge
  tCurrentSession().beginTransaction()
• sessionFactory HibernateUtil.getSess
  ionFactory()
• session sessionFactory.openSession()

• session.beginTransaction()
• if ("store".equals(request.getParameter
  ("action")))
• String name request.getParameter
  ("name")
• String gpa request.getParameter(
  "gpa")
• String year request.getParameter("year")
• String age request.getParameter("age")
• String sex request.getParameter("sex")
• if ("".equals(name)
  "".equals(sex)year.equals("")gpa.equals("")a
  ge.equals(""))
• out.println("ltbgtltigtPlease
  enter name, age, sex, gpa, year and
  sex.lt/igtlt/bgt")
• else
• System.out.println("before call to create and
  store")
• createAndStoreEvent(name,
  age,year,sex,gpa)
• out.println("ltbgtltigtAdded
  event.lt/igtlt/bgt")
• else if ("list".equals(request.getParam
  eter("action")))

60
Delete action

• else if ("delete".equals(request.getParameter("ac
  tion")))
• String name request.getParameter("name")
• List markedsession.createQuery("from Student as
  student where student.name?").setString(0,name).l
  ist()
• if(marked.size()gt0)
• Student student(Student)marked.get(0)
• out.println("deleting...." student.getName())
• session.delete(student)
• else out.println("no match found")

61

• else//update
• String name request.getParameter("name")

• String gpa request.getParameter("g
  pa")
• String year request.getParameter("year")
• String age request.getParameter("age")
• String sex request.getParameter("sex")
• List markedsession.createQuery("from Student as
  student where student.name?").setString(0,name).l
  ist()
• if(marked.size()gt0!"".equals(sex)!year.equal
  s("")!gpa.equals("")!age.equals(""))
• Student student(Student)marked.get(0)
• student.setAge(Integer.parseInt(age))
• student.setYear(year)
• student.setGpa(Double.parseDouble(gpa))
• student.setSex(sex)
• session.update(student)
• else out.println("no match found")
• /else a getinfo choice could look about the
  same

62
I used radiobuttons

• private void printStudentForm(PrintWriter out)
• out.println("lth2gtStudent info
  formlt/h2gt")
• out.println("ltformgt")
• out.println("Name ltinput name'name'
  length'40'/gtltbr/gt")
• out.println("Age ltinput name'age'
  length'10'/gtltbr/gt")
• out.println("Sex(Male/Female) ltinput
  name'sex' length'10'/gtltbr/gt")
• out.println("Year ltinput name'year'
  length'15'/gtltbr/gt")
• out.println("GPA ltinput name'gpa'
  length'10'/gtltbr/gt")
• out.println("ltinput type'radio'
  name'action' value'list'gt Listltbrgt")
• out.println(" ltinput type'radio'
  name'action' value'store' checkedgt Storeltbrgt")
• out.println("ltinput type'radio'
  name'action' value'update'gt Updateltbrgt")
• out.println(" ltinput type'radio'
  name'action' value'delete'gt Deleteltbrgt")
• out.println("ltinput type'submit' /gt")
• out.println("lt/formgt")

63
List students

• private void listStudents(PrintWriter out)
• result1 session.createCriteria(Student.class)
  .list()
• if (result1.size() gt 0)
• out.println("lth2gtStudent
  Infolt/h2gt")
• out.println("lttable border'1'gt")
• out.println("lttrgt")
• out.println("ltthgtStudent namelt/thgt")
• out.println("ltthgtStudent Agelt/thgt")
• out.println("ltthgtGPAlt/thgt")
• out.println("ltthgtSexlt/thgt")
• out.println("ltthgtYearlt/thgt")
• out.println("lt/trgt")
• for (Iterator it result1.iterator()
  it.hasNext())
• Student student (Student)
  it.next()
• out.println("lttrgt")

64
Hibernate configuration

• lt?xml version'1.0' encoding'utf-8'?gt
• lt!DOCTYPE hibernate-configuration PUBLIC
• "-//Hibernate/Hibernate Configuration DTD
  3.0//EN"
• "http//hibernate.sourceforge.net/hibernate-config
  uration-3.0.dtd"gt
• lthibernate-configurationgt
• ltsession-factorygt
• lt!-- Database connection settings --gt
• ltproperty name"connection.driver_class"gtcom.mysql
  .jdbc.Driverlt/propertygt
• ltproperty name"connection.url"gtjdbcmysql//local
  host/mydblt/propertygt
• ltproperty name"connection.username"gtrootlt/propert
  ygt
• ltproperty name"connection.password"gtlt/propertygt
• lt!-- JDBC connection pool (use the built-in) --gt
• ltproperty name"hibernate.connection.pool_size"
  gt10lt/propertygt
• lt!-- MySQL dialect//different for different
  Database --gt
• ltproperty name"dialect"gtorg.hibernate.dialect.MyS
  QLDialectlt/propertygt
• lt!-- Echo all executed SQL to stdout --gt
• ltproperty name"show_sql"gttruelt/propertygt
• ltproperty name"hbm2ddl.auto"gtupdatelt/propertygt
• ltmapping resource"Student.hbm.xml"/gt

65
web-xml

• lt?xml version"1.0" encoding"UTF-8"?gt
• ltweb-app version"2.4"
• xmlns"http//java.sun.com/xml/ns/j2ee"
• xmlnsxsi"http//www.w3.org/2001/XMLSchema-in
  stance"
• xsischemaLocation"http//java.sun.com/xml/ns
  /j2ee http//java.sun.com/xml/ns/j2ee/web-app_2_4.
  xsd"gt
• ltservletgt
• ltservlet-namegtStudentInfolt/servlet-namegt
• ltservlet-classgtdata.StudentInfoServletlt/se
  rvlet-classgt
• lt/servletgt
• ltservlet-mappinggt
• ltservlet-namegtStudentInfolt/servlet-namegt
• lturl-patterngt/studentinfolt/url-patterngt
• lt/servlet-mappinggt
• lt/web-appgt
