Aerospace Dimensions Module 6 SPACECRAFT Lecture by LtCol W' C' Courtney, CAP

1
Aerospace DimensionsModule 6SPACECRAFTLectureb
yLtCol W. C. Courtney, CAP
2
Chapter 1 - Unmanned Spacecraft

• After completing this chapter, you should be able
  to
• Define a satellite
• Describe an orbit
• Define apogee and perigee
• Identify Sputnik
• Define a space probe
• Describe the related parts that make up a
  satellite system

3
Important Terms

• Satellite - natural or artificial object in space
  that orbits the Earth or other object
• Orbit - the path a satellite takes around a
  celestial body
• Apogee - the highest point of an orbit
• Perigee - the lowest point of an orbit
• Sputnik - the first artificial satellite (Russian)

4
Important terms continued

• COMSAT - communications satellites
• INTELSAT - International Telecommunications
  Satellite Organization
• NAVSTAR - navigation satellites
• LANDSAT - satellites that locate natural
  resources monitor conditions on the Earths
  surface
• GOES - Geostationary Operational Environmental
  Satellites

5
Origin of Satellites

• German astronomer Johannes Kepler discovered
  objects orbiting Jupiter
• He named them satellites of Jupiter
• Satellite is French for guard or attendant
• Russians launched the first manmade satellite in
  1957. It was called Sputnik
• Earths only natural satellite is the Moon

6
COMSTATs

• Huge business
• First commercial satellite was a COMSAT the
  Telstar 1 in 1962
• Now includes, satellite television, radio etc
• Communication satellites provide reliable
  timely communications information around the
  world
• DSN - Deep Space Network
• consists of 3 deep space com complexes
• Provide continuous com for planetary spacecraft
  probing deep space

7
Navigational Satellites

• First navigation satellite was Transit, developed
  to provide Polaris missile subs with accurate
  fixes
• NAVSTAR is the GPS (Global Positioning System)
• A constellation of navigation satellites and
  ground control facility

8
NATURAL RESOURCE SATELlITES

• Locate natural resources monitor other
  conditions on the Earths surface
• LANDSAT series does this
• measures radiant energy
• monitors agricultural conditions
• aids urban planners in future development
  management of coastal resources

9
Geostationary Orbits

• Orbit over the equator (0 degrees latitude)
• Longitude may vary
• Satellite orbits at the same speed as the
  rotation of the earth
• Therefore it remains over the same point on the
  earth

10
Geostationary Orbits continued

• Keplers 3rd law says that the time it takes a
  satellite to orbit a point increases with
  altitude
• Low orbit objects (200-400 miles up) take 15 to
  16 orbits a day
• The moon approx 240,000 away takes about 30 days
  to make a complete rotation
• At 22,300 miles it takes one day to rotate
• So it rotates at the same speed as the earth and
  remains above the same spot on the earth

11
Geostationary Orbits Continued

• Satellite TV satellites are geostationary
• Disadvantage is that far north locations have
  trouble seeing them

12
Why Geostationary TV satellites are a problem in
the far north
Ea
Earth
Satellite
Not to scale
13
GEOS

• Geostationary Operational Environmental
  Satellites (GEOS)
• Weather satellites

14
Space Probes

• Satellites or spacecraft that either fly by,
  orbit or land on a celestial body other than
  earth
• They probe space
• Ranger - first to take photos of Moon
• Mariner series - probed Venus Mercury
• Pioneer probes - Jupiter Saturn
• Viking - Mars
• Voyager 1 2 - also Jupiter Saturn

15
Satellite Systems

• A system is composed of all the elements that
  make the item work the sub-systems
• People
• Command control
• Propulsion
• Airframe
• Etc
• User defines the purpose requirement of the
  satellite

16
Items dangerous to satellites

• Radiation
• Charged particles
• Solar flares
• Micrometeorites
• Space junk

17
ORBITS

• An orbit is the path a satellite takes around a
  celestial body
• Copernicus - in 1400 developed a heliocentric
  theory of the universe
• He theorized that the universe revolved (orbited)
  around our sun
• He was wrong

18
Johannes Kepler

• First Law - the orbit of a planet is an ellipse,
  with the sun at one of the foci
• Shape of ellipse can vary to include almost
  circular
• Applies to satellites orbiting earth

Sun
19
Ellipse

abconstant
20
Interesting property of Keplers 2nd Law
Apogee
Perigee

• Area a Area b
• Time it takes to sweep Area a time it takes
  to sweep Area b
• Satellite travels faster sweeping area b
• Velocity _at_ Perigee higher than _at_ Apogee

21
Apogee Perigee
Earth
Apogee
Perigee
Satellite
22
Gravity Centrifugal Forces

• Force of gravity is towards the center of the
  Earth
• To remain in orbit that force must be balanced by
  centrifugal force
• Centrifugal force provided by giving satellite
  escape velocity

23
Activity One
24
Chapter 2 - Manned Spacecraft

• After completing this chapter you should be able
  to
• List the manned space flight projects their
  missions
• Identify the American Russian joint manned
  spacecraft mission
• Describe the accomplishments of Alan Shepard
  Neil Armstrong
• State specific facts about the Hubble Space
  Telescope

25
Important Terms

• Mercury - 1st USA manned space flight program
• Gemini - 1st 2 man spacecraft space walk
• Apollo - project that put man on moon
• Skylab - USA space lab
• Apollo-Soyuz - USA Soviet spacecraft link up
• Space Shuttle - Space Transportation System (STS)

26
Project Mercury (6 Flights)

• First USA manned space flights
• Purpose was to investigate ability of man to
  function in space
• Original 7 astronauts
• Alan Shepard became the 1st American in space
  (Naval Aviator)
• John Glenn first American to orbit the Earth
  (Marine Aviator)

27
Project Mercury
28
Project Gemini (10 flights)

• 1st two man capsule
• 1st space walk
• Gathered enough data to convince scientists that
  space flight could safely last of for weeks or
  months

29
Gemini in formation
30
Gemini Recovery
31
Project Apollo (11 flights)

• Mission - To put man on the moon
• Manned Apollo flights were numbers 7-17
• Apollo 7 - earth orbit
• Apollo 8 - 1st lunar orbit
• Apollo 11 - 1st landing on the Moon
• Neil Armstrong - 1st man to walk on moon
• Apollo 13 - failed to land on moon (not so lucky
  13)

32
Apollo Command Module
33
Apollo Lunar Lander
34
Apollo on the Moon
35
Neil Armstrong on the Moon
36
Project Skylab

• Mission to put a laboratory in space
• 3 different crews manned it at different times
• Last mission lasted 84 days
• Main lesson was that humans could exist in space
  for at least 3 months

37
Skylab on Launchpad
38
Skylab in Orbit
39
Skylab flyby
40
Project Apollo-Soyuz

• Last manned space launch before Space Shuttle -
  July 1975
• Apollo and Soviet spacecraft Soyuz rendezvous and
  connect
• Soviet and American crews move back and forth
  between spacecraft

41
Artist rendition of Apollo-Soyuz
42
Soviet American Astronauts on Apollo-Soyuz
43
Space Shuttle

• First reusable space vehicle
• First launch in 1981
• 5 vehicles produced to fly in space
• 2 have been lost, Challenger Columbia
• Has provided much space research
• Flew the European Space Agencys SPACELAB
• Deployed Hubble Space Telescope in 1990
• Because Hubble is beyond Earths atmosphere it
  provides incredible images

44
Space Shuttle
45
Soviet Space Program

• In 1957 launched 1st satellite, SPUTNIK, into
  space
• In 1961 put 1st man into space
• In 1963 put 1st woman into space
• In 1965 1st astronaut to walk in space
• MIR is largest Soviet space station and had
  longest longevity - Launched in 1986 and fell to
  Earth in 2001

46
Chapter 3 - Living Working in Space

• After completing this chapter, you should be able
  to
• Describe Space station Alpha
• Explain the differences between Mir and Skylab
• Define Spacelab
• Recall the significance of Salyut 1
• Describe the living working conditions in space
• Describe the different space suits

47
Important Terms

• Space Station Alpha - Current space station, a
  joint venture with USA, Europe, Canada, Japan
  Russia (Also called ISS - International Space
  Station)
• Mir - Russias space station of the 1980s
  1990s
• Salyut - Russias first space station
• Skylab - USAs first space station
• Spacelab - European Space Agencys 1st space
  station

48
Space Stations

• Salyut 1 - In April 1971 Russians were 1st with a
  space station (7 in the Salyut series)
• Mir - next Russia space station (1986-2001)
• Skylab - USAs 1st (1973) proved man could live
  work in space for at least 3 months
• Spacelab - European Space Agencys lab inside the
  shuttle

49
Soviet Space Station MIR
50
Space Station Environment Including Shuttle

• Air is mixture of oxygen nitrogen - remember
  danger with 100 oxygen
• Comfortable temperature maintained
• Conduct research experiments
• Perform daily physical exercise

51
Extravehicular Activities (EVA)

• Russian Aleksei Leonov did 1st EVA in March
  1965( 20 min)
• American Ed White was next in June 1965 (22 min)
• Since then many more and longer EVAs including
  moon walks
• Astronaut orbits at about 18,000 MPH

52
Space Suits

• Evolved
• Started as pressure suits
• Gemini flights used light weight removable space
  suit
• Apollo moon suit more advanced
• Suits need to protect from high and low temps
  -256F to 248F

53
Manned Maneuvering Unit (MMU)

• First used in 1984
• Fits on back
• Enables astronaut to move around without being
  tied to the spacecraft for up to 6 hrs
• Move up to 300 ft from orbiter
• Nitrogen gas thrusters
• Redundant systems

54
Later MMU
55
Future in space

• Space Station Alpha (ISS) is now scheduled to be
  completed in 2010 when the shuttle will be
  retired
• Shuttle to be replaced by an Apollo type
  spacecraft called CEV - Crew Exploration Vehicle

56
CEV landing on Earth
57
After studying this module you should be able to

• Define a satellite
• Describe an orbit
• Define apogee and perigee
• Identify Sputnik
• Define a space probe
• describe the related parts that make up a
  satellite system

58
Study objectives continued

• List the manned space flight projects their
  missions
• Identify the American Russian joint manned
  spacecraft mission
• Describe the accomplishments of Alan Shepard
  Neil Armstrong
• State specific facts about the Hubble Space
  Telescope

59
Study objectives continued

• Describe Space station Alpha
• Explain the differences between Mir and Skylab
• Define Spacelab
• Recall the significance of Salyut 1
• Describe the living working conditions in space
• Describe the different space suits

60
The End
