FORENSIC SEROLOGY

1
FORENSIC SEROLOGY

• Chapter 8, Part 2

2
Stain Patterns of Blood

• The location, distribution, and appearance of
  bloodstains and spatters give useful information
  for reconstructing the events that produced the
  blood.
• Surface texture and the stains shape, size, and
  location must be considered when determining the
  direction, dropping distance, and angle of impact
  of a bloodstain.

FORENSIC SEROLOGY
3
Stain Patterns of Blood

• Surface texture is important. The harder and less
  porous the surface, the less spatter.
• The direction of travel of blood striking an
  object may be determined because the pointed end
  of a bloodstain always faces its direction of its
  travel.
• The impact angle of blood on a flat surface can
  be determined by measuring the degree of circular
  distortion. At right angles the blood drop is
  circular, as the angle decreases, the stain
  becomes elongated.
• The origin of a blood spatter in a
  two-dimensional projection can be established by
  drawing straight lines through the long axis of
  several individual bloodstains. The intersection
  or point of convergence of the lines represents
  the origin point.

FORENSIC SEROLOGY
4
Projection of Blood

• Forensic investigators can determine how
• blood was projected from the body by
• examining factors such as
• Type of injuries
• The order in which the wounds were received
• Whose blood is present
• The type of weapon that caused the injuries
• Whether the victim was in motion or lying still
  when the injury was inflicted
• Whether the victim was moved after the injury was
  inflicted
• How far the blood drops fell before hitting the
  surface where they were found.

5
Blood Crime SceneCategories of Blood Patterns

• Pools of blood have evidentiary value in
• collecting a wet sample. Drops of blood can
• reveal the height and angle from which the
• blood fell onto the surface. According to
• forensic scientists, the blood spatter
• analysis claims that blood which falls
• perpendicular to the floor from a distance
• of zero to two feet would create a circular
• drop with slightly frayed edges. Drops from
• a higher distance would have more distinct
• tendrils extending off the edges.

6
Blood Crime SceneCategories of Blood Patterns

• A blood smear on the wall or floor can
• indicate the direction of force of the
• blow.  The direction of force is always in the
• direction towards the tail, or smaller end, of
• the smear. In other words, the largest area
• of the smear is the point of origin. Blood
• crusts must be tested with crystalline
• techniques to verify that they are actually
• blood. Refrigerated red blood cells have a
• shelf life of about forty-two days, and the
• serum containing white blood cells can be
• refrigerated much longer, almost up to a
• year.  DNA can be extracted from blood (if
• white blood cells which always contain a
• nucleus are present), and also from sperm,
• bone marrow, tooth pulp, and hair roots.

7
Blood Crime Scene

• Regardless of what type of analysis is used
• on the blood at the crime scene, care must
• be taken to handle it properly and to
• prevent putrefaction.  Photographs and
• notes should be taken before any blood is
• lifted.  Samples should not be exposed to
• heat, moisture, or bacterial contamination,
• because these factors can shorten the
• survival time of proteins, enzymes, and
• antigens.  Delays in bringing samples to the
• lab must be avoided at all cost, because it
• can diminish evidential value.

8
Court Significance

• Experts in bloodstain examination are
• usually law enforcement personnel. In
• certain jurisdictions, a police investigator
• or blood specialist may testify on the core
• issue because blood evidence is usually a
• vital aspect of the crime scene.
• An expert in bloodstain examination has
• Completed specialized training
• Conducted a sufficient number of
• examinations
• Accumulated enough reference patterns
• to reinforce an argument

9
Heredity and Paternity

• The transfer of hereditary material is
  accomplished by means of units called genes,
  located on chromosomes.
• Alleles Alternative forms of genes that
  influence a given characteristic (such as eye
  color or blood type).
• Paternity testing has historically involved the
  A-B-O blood typing system, along with blood
  factors such as Rh (D).
• DNA test procedures raise the odds of
  establishing paternity beyond 99.

FORENSIC SEROLOGY
10
Principles of Heredity

• Transmission of Traits
• Accomplished by genes, which is the basic unit of
  heredity.
• Genes are on chromosomes (46 in 23 pairs).
• The human egg and human sperm contain 23
  chromosomes, which combine during fertilization.
• A female has XX chromosome, and male has XY
  chromosome.
• Transmission of Traits
• Genes and chromosomes come in pairs.
• The position of a gene on the chromosome is
  called the locus.
• Alleles are alternative forms of genes that
  influence an inherited characteristic.
• An example of allele genes is the A-B-O blood
  type system.

11
Principles of Heredity

• Transmission of Traits
• A-B-O blood types
• When a gene is made of two similar genes, they
  are said to be homozygous. Examples include AA or
  BB.
• If the gene is made up of two different genes, it
  is said to be heterozygous. An example would be
  AB.
• A and B genes are dominant, while O genes are
  recessive.
• A pair of A-B-O allele genes together are the
  genotype of an individual.
• The phenotype of an individual is the outward
  characteristic of the individual.
• There is no lab test to determine a persons
  A-B-O genotype.
• If the genotypes of both parents are known, a
  Punnet square may be constructed to determine
  potential genotype of offspring.

12
Blood DNA Testing

• Blood is used in DNA testing, as shown by
• the following steps
• 1. Blood samples are collected from the
• victim, defendant, and crime scene.
• 2. White blood cells are separated from red
• blood cells.
• 3. DNA is extracted from the nuclei of white
• blood cells.
• 4. A restrictive enzyme is used to cut
• fragments of the DNA strand.
• 5. DNA fragments are put into a bed of gel
• with electrodes at either end.
• 6. Electric current sorts DNA fragments by
• length.
• 7. An absorbent blotter soaks up the imprint it
• is radioactively treated, and an X-ray
• photograph, called an autoradiograph, is
• produced.

13
Forensic Characteristics of Semen

• Normal male can ejaculate 2.5-6 ml of seminal
  fluid
• Each ml contains 100 million or more spermatozoa

14
Testing for Semen

• Stain must be located and collected
• Acid Phosphatase Color Test
• Purple color indicates the presence of semen
• Spermatozoa Test
• Semen is diluted with water and dried on filter
  paper
• Microscopic examination looks for spermatozoa

15
Testing for Seminal Stains

• Many of the cases sent to a forensic laboratory
  involve sexual offenses, making it necessary to
  examine exhibits for the presence of seminal
  stains.
• The best way to locate and at the same time
  characterize a seminal stain is to perform the
  acid phosphatase (an enzyme found in seminal
  fluid) color test.
• A purple color indicates acid phosphatase enzyme.

• Semen are identified by either the presence of
  spermatozoa or of p30, a protein unique to
  seminal plasma.
• Forensic scientists can link seminal material to
  an individual by DNA typing.

FORENSIC SEROLOGY
16
Rape Evidence

• Presence of seminal fluid
• Physical injuries such as bruising or bleeding
  confirms a violent sexual assault took place
• Transfer of physical evidenceblood, semen,
  fibers, and hairare usually present

17
Rape Evidence

• The rape victim must undergo a medical
  examination as soon as possible after the
  assault.
• At that time the appropriate items of physical
  evidence including clothing, hairs, and swabs can
  be collected for subsequent laboratory
  examination.
• All outer and undergarments should be carefully
  removed and packaged separately in paper (not
  plastic) bags.
• Bedding, or any objects upon which the assault
  took place, may also be carefully collected.

FORENSIC SEROLOGY
18
An antibodyantigenantibody sandwich or complex
is seen as a colored band. This signifies the
presence of PSA in the extract of a stain and
positively identifies human semen.
19
PSA testing by electrophoresis.
20
Collection of Rape Evidence

• All outer and undergarments are collected and
  packaged separately in paper bags
• Trace evidence is collected by standing on a
  clean sheet while removing clothing
• Bedding may be recovered if seminal stains are
  present
• Medical Examination of the victim

21
Rape Evidence

• If a suspect is apprehended within 24 hours of
  the assault, it may be possible to detect the
  victims DNA on the males underwear or on a
  penile swab of the suspect.
• Items routinely collected from the suspect
  include all clothing, pubic hair, head hair,
  penile swab, and a blood sample or buccal swab
  for DNA typing.
• The forceful physical contact between victim and
  assailant may result in a transfer of such
  physical evidence of blood, semen, saliva, hairs,
  and fibers.

FORENSIC SEROLOGY
22
Medical Examination of Victim

• Pubic Combings
• Pubic Reference Samples from victim
• Vaginal swabs and smear
• Rectal swabs
• Oral swabs
• Head hairs
• Blood sample
• Fingernail scrapings
• All clothing
• Urine specimen

23
Medical Examination of Suspect

• All clothing
• Pubic hair combings
• Pulled head and pubic hairs for reference samples
• Penile swab
• Blood sample or buccal swab
