Materialized%20View%20Selection%20in%20a%20Multidimensional%20Database

1
Materialized View Selection in a Multidimensional
Database

• Presenter Dong Wang
• 3/14/2006

2
outlines

• What is multidimensional database.
• Why materialize views.
• The cost evaluation.
• The MDred-lattice.

3
Multidimensional Database

• A multidimensional database (MDDB) is a data
  repository that provides an integrated
  environment for decision support queries that
  require complex aggregations on huge amounts of
  historical data.
• An MDDB is a relational data warehouse where the
  information is organized following the so-called
  star-model.

4
A Practical Example

• Consider the MDDB for a large store chain,
  characterized by a large number of stores, each
  of which is a supermarket selling a wide variety
  of different products. We can identify the
  following dimensions
• Product, which can be characterized by
  Product_id, Department, Manufactured_date and
  Price.
• Store, which can be characterized by Store_id,
  store address (which can be decomposed into City,
  State, and Zip).
• Time, which can be characterized by Timestamp,
  Date, Week, Month, Quarter, Year.

5
The schema of the example
Sales
Transaction_id Timestamp Product_id Store_id
6
Example queries

• Query 1 the total sales for year 2003.
• SELECT SUM (Price)
• FROM Sales, Time, Product
• WHERE Sales.Product_id Product.Product_id
• AND Sales.Timestamp Time.Timestamp
• AND Time.Year 2003
• Query 2 the total sales for store at Ohio.
• SELECT SUM (Price)
• FROM Sales, Store, Product
• WHERE Sales.Product_id Product.Product_id
• AND Sales.Store_id Store.Store_id
• AND Store.State Ohio

7
How many views an MDDB can have?

• It depends on the number of attributes of the
  dimensions of the MDDB
• without hierarchies on the dimensional tables,
  the number is
• In our example database with only 3 dimension
  tables of 6, 4, 4 attributes, this number is
  18785, but for a real-world database with 50
  attributes, this number is 2501015,

8
outlines

• What is multidimensional database.
• Why materialize views.
• The cost evaluation.
• Data-cube lattice, MD-lattice and MDred-lattice.

9
Materialized View

• A materialized view is the result of some
  queries, which we choose to store in the
  database, rather than reconstructing it as needed
  in response to queries.
• INSERT INTO SalesV1
• SELECT SUM (Price)
• FROM Sales, Time, Product
• WHERE Sales.Product_id Product.Product_id
• AND Sales.Timestamp Time.Timestamp
• GROUP BY (Time.Year)

The materialized view SalesV1 can answer the
query 1 directly.
10
outlines

• What is multidimensional database.
• Why materialize views.
• The cost evaluation.
• MDred-lattice.

11
The MDmat-Problemthe cost

• Query cost the cost of computing query qi,
  given a set of materializations M. We want to
  minimize this cost.
• Update cost , here mi is the ith view in M
  and
• fmi is the frequency mj is updated and cu(mi) is
  the update cost for mi. We want to minimize this
  cost too.
• So, given the query set and the materialized
  view set, the cost of this solution is the sum of
  the above two costs

12
choose the right views to materialize

• Compare to the possible views we can have, the
  number of queries is extremely small. Consider
  the data-cube lattice we have below, among the
  total 16 nodes, only 4 nodes may be used to
  answer queries. So we can only select a small
  number of views to materialize.

13
Functional Dependence

• Functional dependency is a constraint on the
  content of the dimension table
• for each tuple pair t1,t2 and fd Al?Ar,
  t1Alt2Al?t1Art2Ar
• Examples
• 1. In the dimension table Store, we have fds1
  Store_id ?Zip, fds2 Zip ? City, fds3 City
  ?State.
• 2. In the dimension talbe Time, we have fdt1
  timestamp ?week, fdt2 timestamp ?date, fdt3
  date ?month, fdt4 month ?quarter, fdt5 quarter
  ?year.

Use the attributes hierarchy, we can get the
multidimensional lattice.
14
The MD-lattice
Timestamp
Date
Week
Month
Quarter
Year
all
all
The MD-lattice of the Store dimension
The MD-lattice of the Time dimension
15
Candidate Views

• Its impossible (and no need) to materialize all
  the possible views in the data cube. We only need
  the views which can help us to answer the
  queries.
• We only consider the views that can provide some
  contribution to reduce the total cost, the
  candidate views.
• A view vi belonging to an MD-lattice is a
  candidate view if one of the following two
  conditions holds
• 1. View vi is associated to some query qi
• 2. There exist two candidate views vj and vk,
  and vi is the least upper bound of vj and
  vk.

16
The materialization of a non-candidate view will
not help

• Suppose there is a non-candidate view vi and its
  materialized. We consider two cases
• There is no candidate view depending on vi. Since
  vi will not change the query cost, and the update
  cost for view vi is always positive, so
  materialize vi will not help.
• At least one candidate view exists depending on
  vi. Say theres a candidate view vj depending on
  vi. Since the size of vj is smaller than vi, we
  can see the update cost of vj is always smaller
  than vi. That means the materialization of vi
  always costs more.
• Conclusion we should always choose the candidate
  view to materialize.

case 1 case 2 Both views are
materialized only the non-candidate view is
materialized
17
Candidate views examples

• For query 1 on slide 5, we can choose the view
  SalesV1 to materialize.
• For query 2, we can do
• CREAT MATERIALIZED VIEW SalesV2
• SELECT SUM (Price)
• FROM Sales, Store, Product
• WHERE Sales.Product_id Product.Product_id
• AND Sales.Store_id Store.Store_id
• GROUP BY (Store.State)
• In both examples, we choose the view which is
  associated to the query to materialize.

18
outlines

• What is multidimensional database.
• Why materialize views.
• The cost evaluation.
• The MDred-lattice.

19
The MDred-lattice

• Given an MD-lattice and a set of queries Q, the
  set of its candidate views forms the
  MDred-lattice.
• The MDred-lattice Construction Algorithm

20
An MD-lattice construction

• Suppose we have two queries
• query 1 the total sale of the week 50.
• query 2 the total sale of the 3rd quarter of
  year 2005.
• From the MDred-lattice construction algorithm,
  first we need to materialize the views group by
  attribute Week and attribute Quarter to answer
  the queries, then we need to extend the view set
  by adding the least upper bound, attribute
  Timestamp to the view set.

21
The cost evaluation

• Suppose we have two queries qj and qk, consider
  both the query cost and the update cost, we have
  two options
• Option 1 materialize vj and vk. The total cost
  is
• Option 2 only materialize vi, which is the
  least upper bound of vj and vk. The total cost is

22
The cost evaluation (cont.)

• For option 1, let fu0.8, cu(vj)100, fqj0.5,
  cqj(vj)100, cu(vk)100, cqk(vk)100, we can get
• C10.81000.51000.81000.5100260.
• For option 2, let fu0.8, the update cost will be
  larger (since the cardinality of vi is larger),
  say cu(vi)120, the query cost will also be
  larger (since additional aggregation will be used
  to answer the queries), say cqj(vi)110,
  cqk(vi)110, we can get
• C20.81200.51100.5110206.
• So option 2 is the better choice!

23
References

• Materialized view selection in a multidimensional
  database. Elena Baralis, Stefano Paraboschi and
  Ernest Teniente. Proceedings of the 23rd VLDB
  Conference.1997
• Designing Data Warehouses. Dimitri Theodoratos,
  Timos Sellis. 1999
