Title: UML


1
UML Class DiagramsLesson - 9
2
Objectives
  • What is UML?
  • UML Diagrams
  • Use Case Diagram
  • Class Diagram

3
What is UML?
  • The Unified Modeling Language (UML) is a
    standard  language for specifying, visualizing,
    constructing, and documenting the artifacts of
    software systems, as well as for business
    modeling and other non-software systems.
  • UML uses graphical notations to express the
    design of software projects.
  • Modeling is necessary for readability and reuse
    of systems.

4
UML Diagrams
  • UML modeling consists of nine different diagrams
    to model a software system.
  • Each UML diagram is designed to let developers
    and customers view a software system from a
    different perspective and in varying degrees of
    abstraction.

5
UML Diagrams
  • Use case Diagram
  • Class Diagram
  • Object Diagram
  • State Diagram
  • Activity Diagram
  • Sequence Diagram
  • Collaboration diagram
  • Component diagram
  • Deployment diagram

6
Use case Diagram
  • Use case diagram displays the relationship among
    actors and use cases.
  • Actors An actor is any entity that performs
    certain roles in a given system. For example, In
    a banking application, a customer entity
    represents an actor. Similarly, the person who
    provides service at the counter is also an actor.

7
Use case Diagram
  • Use Case A use case in a use case diagram is a
    visual representation of a distinct business
    function in a system. For example, In a banking
    application, a deposit function represents a use
    case.
  • To identify use cases, you should list the
    discrete business functions the user might do in
    order to complete an action.
  • For a banking application it might be
  • deposit money
  • withdraw money

8
Use case Diagram
9
Class Diagram
  • Class diagrams model class structure and contents
    using design elements such as classes, packages
    and objects.
  • A class diagram is a diagram showing a collection
    of classes and interfaces, along with the
    collaborations and relationships among classes
    and interfaces.
  • A class diagram is composed of
  • Class A class has a business functionality
    called methods, and properties that reflect
    unique features of a class. The properties of a
    class are called attributes.

10
Class Diagram
  • For example Let us take a class named Student.
    The Student class encapsulates student
    information such as student id , student name,
    and so forth. Student id, student name, and so on
    are the attributes of the Student class. The
    Student class also exposes functionality to other
    classes by using methods such as
    getStudentName(), getStudentId(), and the like.
    Let us take a look at how a class is represented
    in a class diagram.

11
Class Diagram
  • The following diagram shows a typical class in a
    class diagram

12
Elements of a Class Diagram
  • Attributes correspond to the class level
    variables (but not variables declared within the
    body of a method).
  • Operations correspond to methods in Java.
  • Public members (attributes or operations) can be
    referenced directly by any classes in this or any
    other model package (more on packages later).
  • Private members can only be referenced in the
    same class where theyre declared.
  • Protected members can be referenced in the same
    class or in any descendants of that class (more
    on inheritance later).
  • Package scope members can be referenced by any
    classes in the same UML package only.

13
Access Specifiers
14
Static Members
Static members can be referenced without
instantiating the class to which they belong.
In UML, static members are underlined.
15
Abstract Classes
  • Abstract classes are partially implemented and
    force us to extend it before we can use its
    functionality. In class diagrams, the name of an
    abstract class is specified in italics
  • Abstract methods that must be implemented in
    subclasses of the abstract class are again
    specified in italics.

16
Dependencies
  • A dependency is a using relationship that states
    that a change in a specification of one thing may
    effect another thing that uses it
  • You will use dependencies in the context of
    classes to show that one class uses another class
    as an argument in its methods signature.

17
Generalization
  • A generalization is a relationship between a
    general thing (a superclass) and a more specific
    kind of that thing (a subclass).
  • It is a is-a-kind-of relationship.

18
Association
  • An association represents a relationship that
    specifies that objects of one thing are connected
    to objects of another.

19
Aggregation
  • An association in which one class represents a
    larger thing, which consists of smaller things is
    called an aggregation relation
  • It is a has-a relationship meaning an object of
    the whole has objects of the part.

20
Composite
  • In a composite aggregation, an object may be a
    part of only one composite at a time. For
    example, a Frame belongs to exactly one Window.
  • In simple aggregation, a part may be shared by
    several wholes. For example a Wall may be a part
    of one or more Room objects.

21
Realization-Interfaces
  • A realization relationship shows that one class
    implements the interface of another class.
  • A realization can be represented in two ways.
  • Design View (canonical form)
  • Systems Implementation View (elided form)

22
Realization
23
Packages
24
Package - Client
25
Package - Policies
26
Package - GUI
