Cardiac Complications

1
Cardiac Complications

• Lynn McGugan Clark
• ACNP
• Duke University
• mcgug001_at_mc.duke.edu

2
Tamponade

• Heart too large for pericardial space
• Apparent immediately after chest closure
• r/t edema
• Fluid accumulation
• Pericardium or anterior mediastinum
• Un-drained blood and clots
• Correcting coagulopathy -gt pericardial clot
• Chest tubes unable to drain

3
Tamponade

• Delayed
• Occurs up to several weeks after operation
• May occur after pacing wire or LA catheter
  removal
• More common in anticoagulated patients
• Possibly from postpericardiotomy syndrome
• May be caused by chylopericardium
• Not prevented by prolonged drainage of
  pericardial space

4
Pathophysiology

• Stage 1 Accumulation of fluid causes increased
  ventricular stiffness - gt need higher filling
  pressures
• Stage 2 Pericardial pressure rises above
  ventricular filling pressure
• CO decreases
• Stage 3 Further decrease in CO occurs r/t
  equalization of pericardial and ventricular
  filling pressures
• Transmural distending pressures are insufficient
  to overcome pericardial pressures
• Septal shift
• Reduced diastolic filling

5
Widened Mediastinum
6
Signs and Symptoms

• Widened mediastinal silhouette
• Rapid increase in right and left atrial pressures
• Narrow pulse pressure
• Increased diastolic pressure an attempt to
  compensate for decreased CO by sending blood back
  to the heart
• Decreased CO
• Associated conditions (low UOP, low Sv02,
  acidosis)
• Tachycardia

7
Signs and Symptoms

• Prominent x descent on CVP waveform
• Pulsus paradoxus
• Drop in BP on inspiration by at least 10 mmHg
• Becks triad
• Hypotension (r/t decreased CO)
• Muffled heart sounds (r/t insulating fluid)
• JVD (r/t lack of forward blood flow
  accumulation in venous system)

8
Pulsus Paradoxus
http//www.rhc.ac.ir/PTC/PDFs/PTCC73.pdf
9
CVP in Tamponade
http//www.rhc.ac.ir/PTC/PDFs/PTCC73.pdf
10
Diagnostic Tests

• Echocardiogram
• Hamid et al (2006) found only 20 of patients
  with tamponade met radiographic criteria for
  tamponade, while 100 of patients showed
  pericardial effusions on echo
• Unclotted blood appears as black space around
  heart, LV appears small and underfilled, vena
  cava appear distended, RA collapse in diastole
• CXR
• CT

11
Regional Tamponade

• Clot anterior to R atrium/ventricle
• High CVP, low wedge
• Clot behind L atrium
• PAWP high, CVP low

12
Management

• Maintain perfusion
• give fluid and inotropes
• Reduce positive pressure ventilation
• Milk/strip CT
• Monitor for PEA
• Return to OR/emergent opening of the chest

13
Emergent Opening of the Chest
14
Indications

• Bleeding
• Cardiac Arrest
• Clinical Suspicion of Tamponade
• Hemodynamic Instability
• Peri-op MI
• Arrhythmias
• Graft malfunction

15
Post-Op Cardiac Surgery Arrest Statistics

• Incidence post cardiac surgery 1-5
• Survival of arrests occurring in ICU 33-79
• Most common causes VF, tamponade
• Chest reopening within 10 minutes improves
  survival

?
16
VF Post Cardiac Surgery

• Best Evidence Topic
• 15 papers reviewed
• Chance of successful defibrillation
• 1st attempt 75-78
• 2nd attempt 35
• 3rd attempt 14
• Conclusions Three shocks should be quickly
  delivered. If these do not succeed the chance of
  a 4th shock succeeding is likely to be lt10 and
  immediate chest reopening should be performed.
• Richardson, L., Dissanayake, A. Dunning, J.
  (2007). What cardioversion protocol for
  ventricular fibrillation should be followed for
  patients who arrest shortly post-cardiac surgery?
  Interactive Cardiovascular and Thoracic Surgery,
  6(6), pp 799-805. Retrieved January 7, 2008 from
  http//www.ncbi.nlm.nih.gov/pubmed/17693437?ordin
  alpos1itoolEntrezSystem2.PEntrez.Pubmed.Pubmed_
  ResultsPanel.Pubmed_RVDocSum

17
Etiology and Precipitating Causes

• VF/VT
• Myocardial injury/infarction
• Reperfusion injury
• R-on-T with asynchronous pacing
• Acquired (hypokalemia/drug toxicity/long QT
  syndrome)
• Cardioversion with unsynchronized shocks

18
Etiology and Precipitating Causes

• PEA
• Hypovolemia
• Tamponade
• Massive MI
• Tension PTX
• Lung hyperinflation
• Drug toxicity
• Anaphylaxis

19
Exacerbating Factors

• Hypoxemia
• Hypercarbia
• Acidosis
• Hypokalemia
• Hypomagnesemia
• Hypothermia

20
Etiology and Precipitating Causes

• Asystole/Heart Block/Bradycardia
• Injured/edematous conduction system
• Hyperkalemia
• Acidosis
• Drug toxicity
• After prolonged VF
• Pacing problem (wires/connections/box)
• Discontinuation of overdrive pacing

21
Which Patients Benefit from Opening the Chest?

• 6 year prospective study
• Results 25 survival to discharge
• Favorable determinants of outcome were
• Arrest within 24 h of surgery
• Reopening within 10 minutes of arrest
• Arrest in intensive care unit (ICU)
• All patients who were reopened outside the ICU
  died
• Mackay, J. H., Powell, S. J., Osgathorp, J.
  Rozario, C. J. (2002). Six year prospective
  audit of chest reopening after cardiac arrest.
  European Journal of Cardiothoracic Surgery,
  22(3), pp. 421-425.

22
Patient Risk Factors

• Older
• Procedure other than CABG
• Urgent/emergent initial operation
• Reoperation
• Chronic renal insufficiency
• Longer CPB and aortic cross clamp time
• ?Pre-op ASA and prolonged bleeding times
• Pre-op myocardial infarction

23
Initial Evaluation

• Validate check for pulse, evaluate waveforms
• Ensure ETT patency and position
• Exclude ventilator as cause
• Manual bagging
• Paralyze if suspect ventilator dysynchrony
• Consider 30 second disconnect to exclude
  hyperinflation

Adapted from Sidebotham Gillham, 2007
24
Initial Evaluation

• Exclude tension PTX
• Auscultate chest
• Palpate trachea
• Consider re-opening early if tamponade suspected
• Stop sedatives and hypotensive agents
• Ensure vasoactive gtts are being delivered

25
Additional Evaluation

• What is the MAP?
• lt 30 mmHg gt initiate cardiac arrest algorithm,
  reopen chest

Adapted from Sidebotham Gillham, 2007
26
Additional Evaluation

• 30-50 mmHg
• evaluate treat for arrhythmias
• Fluid challenge
• Phenylephrine bolus 50-100 mcg or Epinephrine
  bolus 100-200 mcg
• Consider reopening chest if unresponsive to above
• If responsive, start/increase epi/vasopressin and
  evaluate cause with ECG, ABG, labs, CXR, CO, TEE,
  consider IABP

27
Additional Evaluation

• gt 50 mmHg gt
• Zero transducers, ensure gtts delivered,
  auscultate heart and lungs, examine CT
• Inform surgeon
• Consider paralysis and sedation, manually bag
  patient
• Pace at 90 bpm, fluid challenge, increase/start
  inotropes
• PA catheter placement/TEE

28
Preparation

• Decision made by surgeon/senior resident
• Sterile attire and field
• Drapes
• Caps, gowns, masks
• Prepped with betadine
• Hallway partitioned off
• OR nurse if available
• Light source
• Set up and get blood products to bedside
• Sterile suction tubing and catheters

29
Procedure

• Incision made beside staples/suture line
• Wires cut and removed
• Soft tissues and sternal edges inspected
• Clots evacuated
• Inspect all operative sites

30
Procedure

• Sutures, clips, thrombostatic material applied to
  bleeding sites
• Drainage tubes cleared of blood and clots, pacing
  wires re-attached
• Internal cardiac massage if needed
• Chest closed or packed and left open

31
Outcomes

• Median amount of blood removed 1L
• Chest bleeding found in gt 90
• Focal bleeding gt 55
• Diffuse ooze approximately 33
• Initiation of mechanical assistance possible
• 48 of patients with cardiac arrest responded to
  open chest CPR (Anthi et al., 1998) and survived
  to discharge

32
Complications

• Sternal Wound Infection
• Increased Mortality
• Renal Failure
• Respiratory Failure
• ARDS
• Sepsis
• Atrial Arrhythmias

33
Complications

• Stroke
• Longer ICU and hospital LOS
• Disadvantages
• No positive pressure ventilation systems, laminar
  air flow or restricted personnel entry

34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
Wire Cutters
39
Wire Cutters
40
Forceps/Pickups
41
Chest Retractor/Finochetto/Baby Chest
42
(No Transcript)
43
Lisch Blade/ Lepsche Knife
Hammer
44
Vascular Clamp/Big Kelley/Mayo Clamp
45
Aortic Side Biting Clamp/Satinsky Clamp
46
Vascular Cross Clamp
47
Vascular Cross Clamp
48
Needle Holders/Drivers
Scissors
Kocher Clamps
Kelly Clamps
49
DELAYED STERNAL CLOSURE
50
Delayed Sternal Closure

• Occurs more often in combined procedures
• Rationale
• Provides space for edematous heart
• Minimizes harmful effects of tamponade
• Arrhythmias
• Hemodynamic instability
• /- stabilizers
• Concerns re infection
• Anticipate broad spectrum antibiotics

51
Delayed Sternal Closure

• 4.2 of 3373 cardiac surgery patients
• Occurs approximately 2.0 (range 0.5-8 days) post
  op
• More frequently after combined cardiac surgery
  (9.6) than after CABG alone (3.7) or valve
  operation (2.6)
• COMPLICATIONS
• Superficial sternal wound infection 1.6
• Mediastinitis 0.8
• Sternal dehiscence in 3 (2.4) patients
• Christenson, J., Maurice, J., Simonet, F.,
  Velebit, V. Schmuziger, M. (1996). Open chest
  and delayed sternal closure after cardiac
  surgery. European Journal of Cardio-Thoracic
  Surgery, (10), pp. 305-311

52
Delayed Sternal Closure

• RESULTS 78.9 survived and were discharged an
  average of 8.6 days after closure. Mortality was
  related to indications for OC
• low cardiac output 38.6
• hemodynamic collapse on closure 0
• diffuse bleeding 33.3
• arrhythmias 27.3
• Christenson, J., Maurice, J., Simonet, F.,
  Velebit, V. Schmuziger, M. (1996). Open chest
  and delayed sternal closure after cardiac
  surgery. European Journal of Cardio-Thoracic
  Surgery, (10), pp. 305-311

53
Lynn McGugan Clark, ACNP, CTICU mcgug001_at_mc.duke.e
du
54
References

• Anthi, A., Tzelepis, G. E., Alivizatos, P.,
  Michalis, A., Palatianos, G. M., Geroulanos, S.
  (1998). Unexpected cardiac arrest after cardiac
  surgery incidence, predisposing causes, and
  outcome of open chest cardiopulmonary
  resuscitation. Chest, 113(1), pp. 15-19.
• Charalambous, C. P., Zipitis, C. S. Keenan, D.
  J. (2006). Chest reexploration in the intensive
  care unit after cardiac surgery a safe
  alternative to returning to the operating
  theatre. Annals of Thoracic Surgery, 81(1), pp.
  191-4.
• Dulak, S. B. (2005). Hands-on help. Cardiac
  tamponade. RN, 68(4), pp 32ac1-4.
• Hamid, M., Khan, M. U. Bashour, A. C. (2006).
  Diagnostic value of chest X-ray and
  echocardiography for cardiac tamponade in post
  cardiac surgery patients. Journal of the Pakistan
  Medical Association, 56(3), pp. 104-107.
• Lewis, A. M. (1999). Cardiovascular emergency!
  Nursing, 29(6), pp. 49-51.
• Moulton, M. J., Creswell, L. L., Mackey, M. E.,
  Cox, J. L. Rosenbloom, M. (1996).
  Reexploration for bleeding is a risk factor for
  adverse outcomes after cardiac operations.
  Journal of Thoracic and Cardiovasc Surgery, 111,
  pp. 10371046.
• Mackay, J. H., Powell, S. J., Osgathorp, J.
  Rozario, C. J. (2002). Six year prospective
  audit of chest reopening after cardiac arrest.
  European Journal of Cardiothoracic Surgery,
  22(3), pp. 421-425.
• Richardson, L., Dissanayake, A. Dunning, J.
  (2007). What cardioversion protocol for
  ventricular fibrillation should be followed for
  patients who arrest shortly post-cardiac surgery?
  Interactive Cardiovascular and Thoracic Surgery,
  6(6), pp 799-805. Retrieved January 7, 2008 from
  http//www.ncbi.nlm.nih.gov/pubmed/17693437?ordina
  lpos1itoolEntrezSystem2.PEntrez.Pubmed.Pubmed_R
  esultsPanel.Pubmed_RVDocSum
• Wahba, A., Gotz, W. Birnbaum, D. E. (1997).
  Outcome of cardiopulmonary resuscitation
  following open heart surgery. Scandinavian
  Cardiovascular Journal, 31(3), pp. 147-149.
