Information Security and Computer Systems: An Integrated Approach

1
Information Security and Computer Systems An
Integrated Approach

• Mark A. Holliday and Bill Kreahling,
• Dept of Mathematics and Computer Science
• Western Carolina University

2
Acknowledgements

• Thank-you for financial support from
• Software Producibility, Office of Naval Research,
  Award N000140510817, 2005-2006.

3
Overview

• Motivations for Change
• Guidelines ACM, IEEE-CS, ABET-CAC
• New Curriculum Framework
• Initial Information Security Option
• Final Information Security Option
• InfoSec I and Internet Protocols
• InfoSec II and Operating Systems
• Conclusions

4
Motivations for Change

• Issue How to create a prominent role for
  Information Security in
• a B.S. in Computer Science curriculum
• consistent with ACM/IEEE-CS/ABET-CAC guidelines
• a small computer science program
• a way that shows the close connection to computer
  systems
• Result One Design and Rationale

5
Motivations for Change

• Why?
• Information security is of increasing importance
• Want to reinforce the computer systems courses
  and the information security courses by showing
  their interconnections
• Goal is technical insight, not technical skill
  per se
• Want to provide the students more choices
• in a way that organizes those choices into
  coherent themes

6
Motivations for Change

• Additional constraints
• Must be consistent with curriculum guidelines for
  a B.S. in Computer Science degree
• Must be feasible for a small computer science
  program (70 majors 10-15 graduates per year)
• We present one design and its rationale that
  meets these constraints

7
Guidelines ACM, IEEE-CS, ABET-CAC

• 2001 ACM/IEEE Computer Society Curriculum
  Guidelines for Computer Science
• Encourages a small core combined with options
• Body of Knowledge (BoK)
• Subset of BoK that should be in any computer
  science curriculum

8
Guidelines ACM, IEEE-CS, ABET-CAC

• ABET-CAC (Computing Accreditation Commission)
  Accreditation Criteria
• IV-6. The core materials must provide basic
  coverage of algorithms, data structures, software
  design, concepts of programming languages, and
  computer organization and architecture.

9
(No Transcript)
10
New Curriculum Framework The Options

• How many courses and how many prerequisites?
• Ideal
• Many courses in an option to cover the area well
• Student must have completed all of the courses in
  the core (with at least a grade of C)

11
New Curriculum Framework The Options

• Reality
• Degree needs to be 120 credit hours
• 54 credit hours of Liberal Studies and General
  Electives
• Student must be able to graduate in four years
  (assuming satisfactory progress)
• 22 Transfer students with an A.S. degree should
  be able to graduate in two years

12
New Curriculum Framework The Options

• Compromise
• Major has 40 hours of CS courses and 31 hours of
  Mathematics and Sciences
• CS Core is 25 hours
• Options are 15 hours (5 courses of 3 credit
  hours)
• Option courses have as prerequisites
• second programming course (our CS2, locally
  CS151)
• our intro to computer systems course (for most
  option courses)

13
New Curriculum Framework The Options

• Three Options
• Computer Systems
• Information Security
• Custom
• All options allow at least one free choice
• Recall goal of more student choices
• gt at most four required courses in an option

14
Initial Information Security Option

• Two key computer systems courses
• Operating Systems and Internet Protocols
• Pair each with an information security course
  that covers the corresponding security issues
• Operating Systems gt Computer Security
• Internet Protocols gt Internet Security
• The two pairs are independent

15
(No Transcript)
16
Final Information Security Option

• Independence does not work because so many topics
  build on cryptography and its security uses
• Solution
• Order them with new names
• Information Security I and II
• Internet Protocols co-req first
• Since cryptographic applications are more
  naturally developed for internet security

17
(No Transcript)
18
InfoSec I and Internet Protocols

• Example Cross-Connections
• InfoSec I authentication and example attacks
• Internet Protocols TCP connection establishment
  handshake
• 3-way, random start sequence numbers, including
  random start sequence number for the other side

19
InfoSec I and Internet Protocols

• Example Cross-Connections
• InfoSec I message integrity and non-repudiation
• gtDigital signatures and message digests
• gt Hash functions
• Internet Protocols hash functions for error
  detection
• Checksums in UDP, TCP, and IP
• Cyclic Redundancy Check in Ethernet

20
InfoSec I and Internet Protocols

• Example Cross-Connections
• InfoSec I trusted intermediaries, key
  distribution, and certification
• Internet Protocols development of IPC
  (Inter-Process Communication)
• Sockets
• Remote Procedure Call/Remote Method Invoc.
• Web services
• Grid computing (Globus, SimpleCA certificate
  authority)

21
InfoSec I and Internet Protocols

• Example Cross-Connections
• InfoSec I firewalls and packet filtering rules
• Internet Protocols IP routing tables and key
  packet header fields
• IP addresses
• UDP/TCP source and destination ports
• ICMP message type
• Other TCP header bits SYN and ACK

22
InfoSec II and Operating Systems

• Example Cross-Connections
• InfoSec II process address space
  vulnerabilities
• Operating Systems segment protection (read-only
  versus read-write), stack overflow, memory
  management protection features (segmentation
  faults during address translation)

23
InfoSec II and Operating Systems

• Example Cross-Connections
• InfoSec II program vulnerabilities, buffer
  overflows and software reverse engineering
• Operating Systems assembly language, code
  analysis, automatic bounds checking

24
InfoSec II and Operating Systems

• Example Cross-Connections
• InfoSec II system vulnerabilities
• Operating Systems
• trapping to the kernel (PSW and Interrupt Vector
  Table) and changing from user mode to kernel mode
  (not allowed machine instructions)
• access control, file permission modes, setuid bit

25
Conclusions

• Issue How to create a prominent role for
  Information Security in
• a B.S. in Computer Science curriculum
• consistent with ACM/IEEE-CS/ABET-CAC guidelines
• a small computer science program
• in a way that shows the close connection to
  computer systems
• Result One Design and Rationale
