A General Approach to Creating FORTRAN Interface for C Application Libraries

1
A General Approach to Creating FORTRAN Interface
for C Application Libraries

• Yang Wang, R. Reddy, R. Gomez, Junwoo Lim, and S.
  Sanielevici
• Pittsburgh Supercomputing Center, Carnegie Mellon
  University, Pittsburgh, PA 15213
• Jaideep Ray, James Sutherland, and Jackie Chen
• Sandia National Laboratories, Livermore, CA
  94550-0969

2
Outline

• Motivation
• FORTRAN/C inter-language calling convention
• Challenges
• Our approach to the solution
• Applications
• Conclusion

3
Motivation
4
FORTRAN/C Inter-language Calling Convention

• Most FORTRAN compilers convert the name of its
  routines and common blocks to low case letters
  and extend the name with an underscore
• In C, put an underscore at the end of a FORTRAN
  routine name in low case letters to call it from
  C.
• In C, declare the name of a routine in low case
  letters and extend the name with an underscore to
  make the routine callable from FORTRAN.
• FORTRAN passes arguments by reference
• For a variable name in a routine call from
  FORTRAN, the corresponding C routine receives a
  pointer to that variable.
• When calling a FORTRAN routine, the C routine
  must explicitly pass addresses (pointers) in the
  argument list.

5
FORTRAN/C Inter-language Calling
Convention - continued

• C routines expect that character strings are
  delimited by the null character.
• From FORTRAN to C, the length of each character
  string is passed as an implicit additional
  INTEGER (KIND4) value, following the explicit
  arguments.
• From C to FORTRAN, when a function returns a
  character string, the address of the space to
  receive the result is passed as the first
  implicit argument to the function, and the length
  of the result space is passed as the second
  implicit argument, preceding all explicit
  arguments.
• Arrays in FORTRAN are stored in a column-major
  order, whereas in C they are stored in a
  row-major order.

6
FORTRAN/C Inter-language Calling Convention -
example

• FORTRAN calling C

7
(No Transcript)
8
Challenges
For making a C numerical library usable by a
FORTRAN application, we need to know

• How to construct and destruct a C object via
  FORTRAN routine calls?
• How to access the public member functions of a
  C object via FORTRAN routine calls?
• How to make a memory space of basic data type
  allocated in C routine that is accessible by a
  FORTRAN pointer?
• How to make a multi-dimensional FORTRAN pointer
  an alias of a one dimensional array allocated in
  C routine?

9
Possible Ways to Get Around

• The driver, in C, calls the constructor and the
  destructor.
• The life of the objects spans over the entire job
  process
• Wrap" the C member function with a C-style
  function and calls the constructor and the
  destructor in the wrapper.
• Frequent creation and destruction of an object
  can be costly

10
Possible Ways to Get Around - continue

• CNF library (www.starlink.rl.ac.uk/static_www/soft
  _further_CNF.html)
• C macros to hide the different ways that
  computers pass information between subprograms
• C functions to handle the difference between
  FORTRAN and C character strings, logical values,
  and pointers to dynamically allocated memory
• Nonstandard FORTRAN pointers (CRAY, Compaq, etc.)
• Limited portability
• Babel (a Scientific Interface Definition Language
  compiler)
• Tedious
• FORTRAN 90 support is still in testing
• FORTRAN 2003 (?)

11
Our Approach to the Solution

• Build a wrapper for the C library that allows
  us to
• hide the implementation details of the numerical
  library from the FORTRAN code
• handle the request from FORTRAN calls to create
  and destroy the objects defined in the C
  library
• return FORTRAN pointer aliased to the memory
  allocated in the C library
• support function overloading.
• The wrapper is made of two components a C
  component and a FORTRAN 90 component
• Written in standard C and FORTRAN 90,
  together with the conventional inter-language
  calling method.
• Changes to the application source code is minimal
  and can be automated.

12
Our Approach to the Solution - continue

• The C component
• Contains a pointer to the C object, which needs
  to be created and destroyed via FORTRAN calls, in
  its global space.
• Provides a C interface between the FORTRAN 90
  component and the public functions defined in the
  C library.
• Calls the alias function provided by the FORTRAN
  90 component to make the FORTRAN pointer aliased
  to the memory allocated dynamically in the C
  library.

13
Our Approach to the Solution - continue

• The FORTRAN 90 component
• Contains a FORTRAN 90 module that provides a set
  of public functions for the FORTRAN application
  to call.
• Each of these public functions corresponds to a
  function implemented in the C library, and it
  calls the corresponding function via the C
  component.
• The FORTRAN 90 module also holds one- or multi-
  dimensional FORTRAN pointers in its global space.
• Provides an alias function for the C component
  to call that makes the one- or multi- dimensional
  FORTRAN pointer aliased to the memory space
  allocated dynamically in the C library.

14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
Applications

• Building a FORTRAN 90 interface for GrACE
• GrACE is a C library for grid generation, load
  balance maintenance, grid function update, and
  adaptive mesh refinement
• S3D code, written in FORTRAN 90, is a 3D direct
  numerical simulation package for flow-combustion
  interactions
• Building CCA component for FORTRAN modules,
  subroutines, and/or functions
• CCA (Common Component Architecture) components
  are the basic units of software that can be
  combined to form applications, and ports are the
  abstract interfaces of the components.
• Instances of components are created and managed
  within a framework, which also provides basic
  services for component interoperability and
  communication.

18
Conclusion

• The procedure to build a FORTRAN interface for a
  C library
• A FORTRAN 90 module
• A FORTRAN alias routine
• A C wrapper to mediate between the FORTRAN 90
  module and the C library
• Advantages
• Portable
• Low overhead cost
• The need for changing the legacy code is minimal
• Extension
• The same technique can be applied to build a C
  interface for FORTRAN 90 libraries.

19
Acknowledgement

• The work is supported in part by U.S. Department
  of Energy, Terascale High-Fidelity Simulations
  of Turbulent Combustion with Chemistry project
  under SciDAC program, Contract No.
  DE-FC02-01ER25512
