Estimating Surface Normals in Noisy Point Cloud Data

1
Estimating Surface Normals in Noisy Point Cloud
Data

• Niloy J. Mitra, An Nguyen

Stanford University
2
The Normal Estimation Problem

• GivenNoisy PCD sampled from a curve/surface

3
The Normal Estimation Problem

• GivenNoisy PCD sampled from a curve/surface
• GoalCompute surface normals at each point p
• Error bound the normal estimates

4
A Standard Solution

• Use least square fit to a neighborhood of
• radius r around point p

5
A Standard Solution

• Use least square fit to a neighborhood of
• radius r around point p
• PROBLEM !! what neighborhood size to choose?

6
Contributions of this paper

• Study the effects of curvature, noise, sampling
  density on the choice of neighborhood size.
• Use this insight to choose an optimal
  neighborhood size.
• Compute bound on the estimation error.

7
Outline

• Problem statement
• Related work
• Neighborhood Size Estimation
• Analysis in 2D and 3D
• Applications
• Future Work

8
Related Work

• Surface reconstruction
• crust, cocone, etc
• Guarantees about the surface normals
• Mostly works in absence of noise
• Curve/Surface fitting
• pointShop3D, point-set
• Works in presence of noise
• Performance guarantees?

9
Least Square Fit

• Assume
• best fit hyperplane aTpc
• Minimize
• Reduces to the eigen-analysis ofthe covariance
  matrix
• Smallest eigenvector of M is the estimate of the
  normal

10
Deceptive Case
11
Deceptive Cases
12
Outline

• Problem statement
• Related work
• Neighborhood Size Estimation
• Analysis in 2D and 3D
• Applications
• Future Work

13
Assumptions

• Noise
• Independent of measurement
• Zero mean
• Variance is known (noise need not be bounded)
• Data
• Sampling criterion satisfied
• Evenly distributed data
• To prevent biased estimates
• Curvature is bounded

14
Sampling Criteria (2D)

• Sampling density
• lower bound (like Nyquist rate)
• upper bound (to prevent biased fits)

Evenly distributed Number of points in a disc of
radius r bounded above and below by ?(1)r? (?,?)
sampling condition Dey et. al. implies evenly
distributed.
15
Modeling (2D)

• At a point O
• Points of PCD inside a disc of radius r comes
  from a segment of the curve
• y g(x) define the curve for all x?-r,r
• Bounded curvature g(x)lt? for all x
• Additive Noise(n) in y-direction (x,g(x)n)
• ?r, ?n/r assumed to be small

16
Proof Idea

• Eigen-analysis of covariance matrix

17
Proof Idea

• covariance matrix
• let, ?(m12m22)/m11

18
Proof Idea

• covariance matrix
• let, ?(m12m22)/m11
• error angle bounded by,
• to bound estimation error, need to bound ?

19
Bounding Terms of M

• For evenly distributed samples it follows,

20
Bounding m12

• Evenly sampled distribution
• Noise and measurement are uncorrelated
• E(xn) E(x)E(n) 0
• Var(xn) ?(1)r2?n2
• Chebyshev Inequality
• bound with probability (1-?)
• Finally,

21
Bounding Estimation Error

• ?(m12m22)/m11

22
Final Result in 2D

• ? 0,
• take as large a neighborhood as possible

23
Final Result in 2D

• ? 0, take as large a neighborhood as possible
• ?n 0
• take as small a neighborhood as possible

24
Experiments in 2D
25
Result for 3D

• A similar but involved analysis results in,
• A good choice of r is,

26
How can we use this result?

• Need to
• know
• estimate suitable values for
• estimate locally

27
Estimating c1, c2
Exact normals known at almost all points

• c11, c24
• same constants used for
• following results

28
Algorithm

• For each point, start with k 15
• Iterate and refine (maximum of 10 steps)
• Compute r, ?, ? Gumhold et al. locally
• Use them to compute rnew
• knew ?rnew2 ?old
• Stop if
• kgtthreshold
• k saturates

29
Effect of Curvature on Neighborhood Size
1x noise
30
Effect of Noise on Neighborhood Size
2x noise
1x noise
31
Estimation Error gt 5
o
2x noise
1x noise
32
Increasing Noise
Can still get good estimates in flat areas
1x noise
2x noise
4x noise
33
Future Work

• How to find a suitable neighborhood size for
  good curvature estimation
• Find a better way for estimating c1, c2
• Design of a sparse query data structure for
  quick extraction of normal, curvature, etc from
  PCDs

34
Different Noise Distribution (same variance)
gaussian
uniform
35
Result phone
1x noise
36
Varying neighborhood size
Neighborhood size at all points being shown using
color-coding. Purple denotes the smallest
neighborhood and turns blue as the neighborhood
size increases
