Functional%20Programming

1
Functional Programming

• Universitatea Politehnica Bucuresti2008-2009
• Adina Magda Florea
• http//turing.cs.pub.ro/fp_09

2
Lecture No. 6

• Abstract data types in Scheme
• Structures in Scheme
• A unification algorithm

3
1. Abstract DT

• We can construct abstract data types, which are
  data types that represent higher-level concepts
  and use procedures to implement the operations.
• Use Scheme vectors to represent points, with each
  point represented as a small vector, with a slot
  for the x field and a slot for the y field.
• A constructor procedure make-point, which will
  create ("construct") a point object and
  initialize its x and y fields.
• a point is represented as a three-element
  vector, with the 0th
• slot holding the symbol point, the 1st slot
  representing
• the x field,, and the 2nd slot representing the
  y field.
• (define (make-point x y)
• (vector 'point x y))

4
Abstract DT

• (define (make-point x y)
• (vector 'point x y))
• (define p1 (make-point 2 3))
• p1 gt (point 2 3)

5
Abstract DT

• a predicate point? for testing whether an object
  is a point record.
• check to see if something is a point by
  checking to see if it's
• a vector whose 0th slot holds the symbol point.
• (define (point? obj)
• (and (vector? obj)
• (eq? (vector-ref obj 0) 'point)))
• (point? p1) gt t

6

• accessor procedures to get and set the x and y
  fields of our points
• accessors to get and set the value of a point's
  x field.
• (define (point-x obj)
• (vector-ref obj 1))
• (define (point-x-set! obj value)
• (vector-set obj 1 value))
• accessors to get and set the value of a point's
  y field.
• (define (point-y obj)
• (vector-ref obj 2))
• (define (point-y-set! obj)
• (vector-set! obj 2 value))

7

• This isn't perfect - we should probably test to
  make sure an object is a point before operating
  on it as a point.
• For example, point-x should be more like this
• (define (point-x obj)
• (if (point? obj)
• (vector-ref obj 1)
• (error "attempt to apply point-x to a
  non-point")))

8
Abstract DT

• We have defined an abstract data type in Scheme,
  by hand, using procedural abstraction.
• Doing this for every abstract data type is very
  tedious, so it would be good to automate the
  process and provide a declarative interface to
  it.
• We'd like to be able to write something like
  this
• (define-struct point x y) and have Scheme
  automatically construct the constructor, type
  predicate, and accessor procedures for us.

9
2. Structures in Scheme

• PLT MzScheme
• A new structure type can be created with
• (define-struct s (field ) inspector-expr)
• (define-struct (s t) (field )
  inspector-expr)
• - s, t, and each field are identifiers.
• - inspector-expr - produce an inspector or f.
• A define-struct expression creates
• structs, a structure type descriptor value that
  represents the new datatype. This value is rarely
  used directly.
• make-s - a constructor procedure that takes n
  arguments and returns a new structure value.

10
Structures in Scheme

• (define-struct s (field ))
• (define-struct (s t) (field ))
• s? - a predicate procedure that returns t for a
  value constructed by make-s (or the constructor
  for a subtype) and f for any other value.
• s-field - for each field, an accessor procedure
  that takes a structure value and extracts the
  value for field.
• set-s-field! - for each field, a mutator
  procedure that takes a structure and a new field
  value. The field value in the structure is
  destructively updated with the new value, and
  void is returned.
• s - a syntax binding that encapsulates
  information about the structure type declaration.
  This binding is used to define subtypes

11
Structures in Scheme

• (define-struct cons-cell (car cdr))
• (define x (make-cons-cell 1 2))
• (cons-cell? x) gt t
• (cons-cell-car x) gt 1
• (set-cons-cell-car! x 5)
• (cons-cell-car x) gt 5
• (define-struct student (name marks))
• (define stud1
• (make-student "jack" (make-vector 3 10)))
• (student-name stud1) gt "jack"
• (student-marks stud1) gt (10 10 10)

12
Structures in Scheme

• Each time a define-struct expression is
  evaluated, a new structure type is created with
  distinct constructor, predicate, accessor, and
  mutator procedures.
• If the same define-struct expression is evaluated
  twice, instances created by the constructor
  returned by the first evaluation will answer f
  to the predicate returned by the second
  evaluation.
• An inspector provides access to structure fields
  and structure type information without the normal
  field accessors and mutators. Inspectors are
  primarily intended for use by debuggers.

13

• (define-struct cons-cell (car cdr))
• (define x (make-cons-cell 1 2))
• (cons-cell? x) gt t
• (cons-cell-car x) gt 1
• (set-cons-cell-car! x 5)
• (cons-cell-car x) gt 5
• (define orig-cons-cell? cons-cell?)
• (define-struct cons-cell (car cdr))
• (define y (make-cons-cell 1 2))
• (cons-cell? y) gt t
• (cons-cell? x) gt f, cons-cell? now checks for
  a different type
• (orig-cons-cell? x) gt t
• (orig-cons-cell? y) gt f

14
Defining structures sub-types

• (define-struct (s t) (field ))
• Defines a structure sub-type t of s
• A structure subtype "inherits'' the fields of its
  base type.
• (define-struct cons-cell (car cdr))
• (define x (make-cons-cell 1 2))
• (define-struct (tagged-cons-cell cons-cell)
  (tag))
• (define z (make-tagged-cons-cell 3 4 't))
• (cons-cell? z) gt t
• (tagged-cons-cell? z) gt t
• (tagged-cons-cell? x) gt f
• (cons-cell-car z) gt 3
• (tagged-cons-cell-tag z) gt t

15
3. A unification algorithm

• Unification is a pattern-matching technique used
  in automated theorem proving, type-inference
  systems, computer algebra, and logic programming,
  e.g., Prolog

16
Expression unification

• Substitution ?
• Unifier
• Most general unifier ?
• Expression
• Unification algorithm

17
(No Transcript)
18
(No Transcript)
19
Implementation in Scheme

• For the purposes of the program, a symbolic
  expression can be a variable, a constant, or a
  function application.
• Variables are represented by Scheme symbols,
  e.g., x
• A function application is represented by a list
  with the function name in the first position and
  its arguments in the remaining positions, e.g.,
  (f x)
• Constants are represented by zero-argument
  functions, e.g., (a).

20
Implementation in Scheme

• The algorithm presented here finds the mgu for
  two terms, if it exists, using a continuation
  passing style approach to recursion on subterms.
• The procedure unify takes two terms and passes
  them to a help procedure, uni, along with an
  initial (identity) substitution, a success
  continuation, and a failure continuation.
• The success continuation returns the result of
  applying its argument, a substitution, to one of
  the terms, i.e., the unified result.
• The failure continuation simply returns its
  argument, a message.
• Because control passes by explicit continuation
  within unify (always with tail calls), a return
  from the success or failure continuation is a
  return from unify itself.

21
Implementation in Scheme

• Substitutions are procedures.
• Whenever a variable is to be replaced by another
  term, a new substitution is formed from the
  variable, the term, and the existing
  substitution.
• Given a term as an argument, the new substitution
  replaces occurrences of its saved variable with
  its saved term in the result of invoking the
  saved substitution on the argument expression.
• Intuitively, a substitution is a chain of
  procedures, one for each variable in the
  substitution.
• The chain is terminated by the initial, identity
  substitution.

22
Implementation in Scheme

• (unify 'x 'y)   y(unify '(f x y) '(g x y))
  gt "clash"(unify '(f x (h)) '(f (h) y))
  gt (f (h) (h))(unify '(f (g x) y) '(f y x))   gt
  "cycle"(unify '(f (g x) y) '(f y (g x)))
  gt (f (g x) (g x))(unify '(f (g x) y) '(f y z))
  gt (f (g x) (g x))

23
Implementation in Scheme

• (define unify f)(let ()   occurs? returns
  true if and only if u occurs in v  (define occurs
  ?    (lambda (u v)      (and (pair? v)
    (let f ((l (cdr v)))             (and (pair? l)
                    (or (eq? u (car l))
             (occurs? u (car l))
     (f (cdr l))))))))

24
Implementation in Scheme

•  sigma returns a new substitution procedure
• extending  s by the substitution of u with
   v
•   (define sigma    (lambda (u v s)      (lambda
   (x)        (let f ((x (s x)))          (if (sym
  bol? x)              (if (eq? x u) v x)
       (cons (car x) (map f (cdr x))))))))

25

•    try-subst tries to substitute u for v but
   may require a   full unification if (s u) is n
  ot a variable, and it may   fail if it sees tha
  t u occurs in v.
• (define try-subst    (lambda (u v s ks kf)
  (let ((u (s u)))        (if (not (symbol? u))
           (uni u v s ks kf)            (let ((v (s
   v)))              (cond                ((eq? u
  v) (ks s))                ((occurs? u v) (kf "cyc
  le"))                (else (ks (sigma u v s))))))
  )))

26

•  uni attempts to unify u and v with a con
  tinuation-passing   style that returns a substi
  tution to the success argument   ks or an error
   message to the failure argument kf.  The   sub
  stitution itself is represented by a procedure fro
  m   variables to terms.
•   (define uni    (lambda (u v s ks kf)      (con
  d        ((symbol? u) (try-subst u v s ks kf))
        ((symbol? v) (try-subst v u s ks kf))
    ((and (eq? (car u) (car v))              ( (le
  ngth u) (length v)))         (let f ((u (cdr u))
  (v (cdr v)) (s s))           (if (null? u)
           (ks s)               (uni (car u)
                (car v)                    s
                (lambda (s) (f (cdr u) (cdr v) s))
                     kf))))        (else (kf "clash
  ")))))

27

•  unify shows one possible interface to uni, w
  here  the initial substitution is the identity
   procedure
• the initial success continuation returns
• the unified term, and the initial failure
   continuation returns the error message.
• (set! unify    (lambda (u v)      (uni u
        v           (lambda (x) x)           (lamb
  da (s) (s u))           (lambda (msg) msg)))))
