Title: Synthesis of Software Programs for Embedded Control Application


1
Synthesis of Software Programs for Embedded
Control Application
  • Felice Balarin, Massimiliano Chiodo, Paolo
    Giusto, Harry Hsieh, ASV, etc.

Presented by Guang Yang
2
Outline
  • Introduction
  • Preliminaries
  • Software Graphs
  • Generation of the
  • Real-Time Operating System
  • Experimental Results
  • Conclusions

3
Introduction
  • Embedded Systems
  • Electronic components of a physical system that
    typically
  • Monitor variables of the physical system
  • Process information
  • Output signals
  • Implementation of Embedded Systems
  • Full hardware configuration
  • Full software implementation
  • Mixed configuration

4
Introduction(cont.)
  • The problem Software Synthesis
  • software development ? software analysis
  • right-for-the-first-time
  • Inadequate SW synthesis vs HW synthesis
  • SW synthesis vs SW compilation
  • Optimization translation process
  • vs
  • Close to implementation level

5
Introduction(cont.)
  • The problem Software Synthesis
  • software development ? software analysis
  • right-for-the-first-time
  • Inadequate SW synthesis vs HW synthesis
  • SW synthesis vs SW compilation
  • Optimization translation process
  • (1970 theoretical work?)
  • vs
  • Close to implementation level

6
Introduction(cont.)
  • Compiler Technology
  • 20 years progress
  • High level constructs ???
  • Intermediate code ???
  • Machine code
  • Why semilocal?
  • Time
  • Complexity

Semilocal opt.
Arch. spec. opt.
7
Introduction(cont.)
  • SW vs HW Compilation
  • functional reg allocation scheduling,
  • component synthesis optimization
  • vs
  • reg allocation, instruction selection,
  • and local optimization
  • HW syntheis is stronger than SW synthesis
  • Synthesize SW HW in a single system
  • make SW HW-like

8
Introduction(cont.)
  • Restricted Application Domains
  • Simpler and more optimal
  • In this paper
  • Control-dominated embedded sys.
  • MoC FSM
  • Advantages
  • Easily understand widely used
  • Abundant theoretical practical results
  • Disadvantages
  • No good support for computation
  • Previous FSM extension pays too much
  • CFSM

9
Introduction(cont.)
  • This papers approach to SW synthesis
  • Assumption
  • Specification written in a network of CFSMs
  • A Real-Time OS
  • An existing general purpose C compiler
  • Includes
  • Optimization techniques, function description and
    coupling of optimization and estimation

10
Introduction(cont.)
  • Approach
  • Optimized translation of the transition function
    of a given CFSM into an s-graph (using BDD)
  • S-graph optimization and code-size estimation
  • Translation of the s-graph into a target lang.
  • Scheduling CFSMs and generating RTOS
  • Compilation into machine code

11
PreliminariesPrevious work
  • Software synthesis
  • synchronous language (Esterel)
  • (v3) single FSM implementation (fast but big)
  • (v4) multi-FSM implementation (linear size, but
    no low-level opt., cant opt. module-by-module.)
  • CFSM approach
  • User can choose granularity of CFSMs
  • User can manipulate CFSM hierarchy in synthesis
  • Opt. done close to final c-code implementation
  • Both Boolean-circuit and decision-tree based
    optimization

12
Previous work (cont.)
  • Software synthesis
  • high-level language
  • Scheduling of operations to satisfy timing
    constraints
  • CFSM approach
  • Software generation for each CFSM
  • Scheduling of CFSM transitions to satisfy timing
    constraints

13
Hardware High-Level Synthesis
  • Behavioral/RT level synthesis
  • Input Sequential specification
  • Without/with fixed timing and actions
  • Output cycle-by-cycle register and register
    changes/gate level netlist
  • Behavioral-level synthesis operates on
    structurally similar description to the original
    one but outputs are in a form that facilitates
    BDD logic opt.
  • BDD-like structures are very efficient program
    implementations.

14
Hardware Simulation
  • Software synthesis techniques come from
    cycle-based hardware simulation.
  • (Efficiently compute on a sequential machine
    the transition function of an FSM)
  • There are differences
  • Starting point large syn. circuit at gate level
    vs explicit representation of an Extended FSM
  • Target execution on high-end workstation vs very
    small embedded controllers

15
Binary Decision Diagrams
  • An efficient representation for Boolean
    functions.
  • Node-Variable
  • Edge-Value
  • Size, reduce
  • Canonicity

16
Characteristic Functions
  • or
  • where
  • Restriction
  • Projection
  • Support
  • The support of an output is the set of inputs
    that the output depends on.

17
Network of Codesign FSMs
  • Globally Asynchronous Locally Synchronous
  • Locally Synchronous
  • Take snapshot of inputs (valued or value-less)
  • Perform computation
  • Change state or emit output events
  • Globally Asynchronous
  • Events happen at any time and independently
  • No guarantee to receive events

18
Synchrony Asynchrony
  • Asynchronous comm. does not overly restrict the
    implementation domain.
  • Synchronous lang.s restriction is too strong. (0
    computation time)
  • Imply single large FSM
  • Formal verification and analysis technieques
  • Small solution space
  • Synchronous program must be analogous to
    combinational circuit.

19
Asynchronous comm. Model
  • Nondeterministic
  • Complicate design and verification
  • Ease modeling unpredictability of reaction delay
    at spec level and implementation level
  • Software implemented in RTOS

20
Reasons for introducing CFSM
  • A network of components can express a complex
    behavior while keeping the complexity of each
    component at a reasonable level
  • Behavior spec is extended with computation.
  • Delays are useful to model and constrain timing.
  • Asynchronous comm. is more efficient for
    representing interactions among tasks.

21
Software Graphs
  • module simple
  • input cinteger
  • output y
  • var ainteger in
  • loop
  • await c
  • if a?c then
  • a0
  • emit y
  • else
  • aa1
  • end if
  • end loop
  • end var
  • end module
  • Input output signals are associated with two
    values, boolean and value.
  • State variable is associated with current and
    next states.

22
S-Graphs
  • S-Graph model resemble but differ from branching
    programs and BDD.
  • Single variable predicated on TEST nodes
  • Assignments to only a single output

23
Evaluation of multioutput function
24
Evaluation of multioutput function
25
S-Graphs
  • Definition 2 Let G be an s-graph, and let be
    partitioned among input and output variables as
    assumed by procedure evaluate.
  • G is functional if every output variable
    zj
  • 1) is assigned by eval_step at least one
    defined (i.e., different from ?) value for each
    combination of values of the input variables
  • 2) has a defined value whenever a predicate
    or a function depending on zj is visited by
    eval_step.
  • It is easy to show that for a functional s-graph,
    evaluate defines a completely specified I/O
    function.
  • It is easy to check that a non-functional s-graph
    denotes
  • Either an incompletely specified funciton
  • Or a relation between the input and the output
    variables

26
S-Graph Implementation and Optimization
  • Represent CFSM
  • Again, focus on control part, but support date
    computation
  • Set T of tests on input and state variables
  • Set A of actions (output emissions or assignments
    to state variables)
  • Reactive function

27
An example
  • Tests
  • present.c
  • a?c

28
CFSM
  • Transition function is executed in 3 phases
  • Tests are evaluated
  • S-Graph is evaluated to get output variables
  • Actions corresponding to output variables with
    value one, are executed
  • Assumption
  • Expressions do not have side effects
  • (order independent)

29
Initial S-Graph Implementation
30
Initial S-Graph Implementation (cont.)
  • Theorem1 Let be the
    characteristic function of multioutput function
    , such that and let v be the
    BEGIN vertex of the s-graph G returned by
    procedure build. Then, for all
  • Input to this algorithm could be function or
    relation.
  • There may be dont care.

31
S-Graph Optimization
  • Optimization by reordering
  • Output after its support
  • Minimum depth s-graph?minimum exec time
  • Heuristically optimal for code size
  • Output before its support
  • No test vertices
  • All exec take the same time
  • In principle, better in practice, worse.
  • Other orderings
  • Optimization by collapsing test nodes
  • Closed subgraph approach
  • No improvement in experiment

32
S-Graph to C Translation
  • Straightforward due to direct correspondence
    between s-graph node types and basic C primitives
  • TEST node ? if, goto, switch
  • ASSIGN ? assignment
  • Users do not see the low level code, they debug
    the original code

33
Software Cost and Performance Estimation
  • HW/SW partitioning and SW synthesis for real-time
    embedded systems require accurate and quick
    estimates of code size and of minimum and maximum
    execution time.
  • The structure of the code
  • The system on which the program will run
  • Cost estimation on the s-graph
  • Determining cost parameters
  • Apply parameters to the s-graph
  • Details are covered by another presentation.

34
Generation of RTOS
  • To implement the correct behavior of CFSM
    network, we need
  • Schedule individual CFSM
  • Provide a mechanism to emit and detect events
    between SW-CFSMs
  • Provide a mechanism to transfer events between
    SW-CFSMs and HW-CFSMs
  • Ensure the semantics of input event consumption

35
Generation of RTOS
  • Scheduling of SW-CFSMs
  • Enable disable
  • Offline scheduling policies
  • Communicating Events Between SW-CFSMs
  • Communicating Events Between HW- and SW-CFSMs
  • SW ? HW (memory mapped I/O port)
  • HW ? SW (polling, interrupts(default))

36
Consumption of Events
  • SW-CFSMs is running, no transitions are enabled
    ? preserve input events
  • When a CFSM starts reading its input event flags,
    no new flags can be set until the CFSM finishes
    its execution.
  • E.g.

1) the CFSM checks the flag and finds that A has
not occurred, 2) the CFSM is interrupted, 3) A
occurs, 4) B occurs, 5) the CFSM continues the
execution, finds that B has occurred and
executes a transition which is enabled only if B
has occurred and A has not.
37
Comparison with Commercial RTOSs
  • When taking commercial RTOSs
  • Implement event emission and detection only using
    the event flags services provided by the RTOS
  • Provide enough info to RTOS
  • Advantages of authors approach
  • Event emission and detection can be efficient or
    avoided in some cases.
  • Size of RTOS is often much smaller.
  • Experiment with tradeoff is easy.

38
Experimental Result
  • Dashboard Controller (Estimation)

39
Experimental Result
  • Dashboard (Diff. Orderings)

40
Experimental Result
  • Comparison with Esterel v5

41
Experimental Result
  • The Shock Absorber Controller

Synthesised Implementation Hand-designed Implementation diff
ROM (byte) 46639 32K 42
RAM (byte) 10229 8K 25
42
Conclusion
  • A new technology for synthesis of software for
    embedded real-time control dominated systems
    based on CFSM
  • Quick and fairly precise cost- and
    performance-estimation
  • Convincing experimental results
Write a Comment
User Comments (0)
About PowerShow.com
