CDMA / EVDO/ LTE Interoperability and migration plans

1
CDMA / EVDO/ LTE Interoperability and migration
plans
B.V.Raman CDMA Development Group bvraman_at_cdg.org
Colombo, Sri Lanka, 7-10 April 2009
2
Key Messages

• CDMA and OFDM are different technologies with
  different capabilities
• CDMA2000 offers high-performance mobile
  broadband and voice services today and will
  continue to be enhanced to provide greater
  broadband speeds and voice capacity
• OFDM leverages wider-bandwidths up to 20 MHz to
  provide greater speed and capacity
• OFDM-based backhaul, broadcast and broadband
  networks will complement CDMA2000
• Augmenting CDMA2000 in high-tele density areas
  and leveraging CDMA2000s ubiquitous coverage
  with multimode devices to provide seamless
  continuity of services

Notes 1. OFDM is the air interface used by WLAN,
mobile broadcast and next-generation mobile
broadband technologies (LTE,
etc.) 2. 4G will be defined by the
ITU-R as a result of the IMT.Advanced
standardization effort.
3
Key Messages (Contd)

• Global mass market adoption timing of
  wider-bandwidth OFDM-based solutions will vary
  from Market to Market
• Wider-bandwidth spectrum availability will drive
  OFDM-based network deployments
• Mass market adoption of OFDM-based solutions will
  depend on ubiquitous coverage, low-cost handset
  availability, VoIP replacing circuit-switch voice
  services and roaming

Notes 1. OFDM is the air interface used by WLAN,
mobile broadcast and next-generation mobile
broadband technologies (LTE,
etc.) 2. 4G will be defined by the
ITU-R as a result of the IMT.Advanced
standardization effort.
4
Key Messages (Contd)

• Meanwhile, EV-DO offers substantial long-term
  industry value by remaining the core technology
  driving most operators ARPU well into the next
  decade
• CDMA2000 operators will be among the first
  enabled to augment their networks with by
  wider-bandwidth OFDM-based solutions
• CDMA2000 WorldModeTM devices will enable this
  competitive advantage
• CDMA2000 networks will be interoperable with
  OFDM-based radio technologies
• No need to deploy GSM or UMTS to obtain this
  advantage

Notes 1. OFDM is the air interface used by WLAN,
mobile broadcast and next-generation mobile
broadband technologies (LTE,
etc.) 2. 4G will be defined by the
ITU-R as a result of the IMT.Advanced
standardization effort.
5
CDMA and OFDM-based Technologies
CDMA and OFDM are different technologies with
different capabilities
Wide bandwidth OFDM-based networks will
complement 3G broadband networks for Broadband
Broadcast
Backhaul
Additional Broadband Capacity
MFLO DVB-H ISDB-T T-DMB S-DMB
WiMAX (802.16d)
LTE Mobile WiMAX (802.16e/m) Wi-Fi (802.11n)
OFDM leverages wider-bandwidths up to 20 MHz
6
Next Generation Broadband Business Case
3G is generating the demand and proving the
business case for Next-G
Broadcast HDTV
Mobile Broadband
Consumer Electronics
Fixed Broadband Access
Business Applications
Concurrent Services
Push-to-Media (SWIS)
Ultra Mobile Portable Computers
The business case for wider-bandwidth mobile
broadband networks is being created and
validated by Rev. A
Including broadcasting content to motor
vehicles Including video telephony, distance
learning, remote medicine and other video-enabled
field services See What I See
(SWIS) For example, telephony, chat,
push-to-talk, data casting, position location and
mobile commerce during 3D multiplayer gaming.
7
OFDMA Broadband Overlay Timeline
OFDM-based solutions will be built-out over time
as demand grows and spectrum becomes available
3G CDMA WAN Coverage
Today
Next 10 years (Coexistence)
3G CDMA 3G CDMA
OFDM Hotzone
OFDM Hotzone
OFDM Hotzone
Beyond 10 years (Migration)
OFDMA WAN Coverage

• 3G CDMA WAN networks will coexist with OFDM-based
  solutions until
• next generation broadband networks are fully
  capable of delivering
• Ubiquitous coverage
• Carrier-grade VoIP
• Low-cost devices
• Global roaming

Harmonization of spectrum for OFDM-based
solutions will be necessary to build economies of
scale and enable global roaming
8
CDMA2000 Roadmap
CDMA2000 offers a long-term evolutionary path
forward
CDMA2000 1X
1X Enhancements
CDMA2000 Roadmap
VoIP
EV-DO Enhancements
1xEV-DO Rel. 0
Multicarrier EV-DO Rev. B
S/W
H/W
DL 2.4 Mbps UL 153 kbps (1.25 MHz, FDD)
DL 3.1 Mbps UL 1.8 Mbps (1.25 MHz, FDD)
DL 14.74 Mbps UL 5.4 Mbps (5 MHz, FDD)
2011
2006
2005
2004
2003
2002
2007
2008
2010
2001
2009
1 Capacity increase to 55 users per sector
(1.25MHz BW) with new EVRV-B codec and handset
interference cancellation (QLIC). 2 Capacity
increase of more than double 35 calls/sector is
primarily due to UL and DL interference
cancellation and mobile receive diversity 3 Peak
rate for 3 EV-DO carriers with software upgrade.
Standard supports up to 15 aggregated Rev. A
carriers 4 Peak rate for 3 EV-DO carriers with
64QAM in the DL. Standard supports up to 15
aggregated Rev A carriers 5 EV-DO Enhancements
include Femtocell support, MIMO and 64QAM in the
DL and 16 QAM in the UL to enable peak data rates
shown within4 EV-DO carriers
9
High-capacity, multi-purpose All-IP networks
lower the total cost of network ownership and
enable a larger selection of revenue streams
Number of Simultaneous Voice Calls per Sector
10
CDMA2000 Roadmap
CDMA2000 Flexible Migration Path
CDMA2000 allows operators the flexibility to
design an evolution path that meets their unique
needs
1.25 MHz Channel
1X Enhanced
CDMA2000 1X
1xEV-DO Rel. 0
1xEV-DO Rev. A
Scalable up to 20 MHz
DO Enhanced
EV-DO Rev. B
2011
2006
2007
2008
2010
2005
2004
2003
2002
2001
2000
2009
11
Coexistence of CDMA and OFDM
CDMA2000 will be complemented with OFDM-based
solutions in many markets
CDMA2000 Evolution Path
CDMA2000 1X
1X Enhancements
1xEV-DO Rev. A
Multicarrier EV-DO Rev. B
EV-DO Enhancements
OFDMA Broadband Technologies
LTE
or
Mobile WiMAX (802.16e)
802.16m
2005
2004
2003
2002
2006
2007
2008
2010
2011
2009
2001
Complementary CDMA and OFDM Solutions
12
Graceful CDMA to LTE EvolutionStandards
alignment, driven by service providers

• CDMA2000 core networks with IMS and VCC will play
  a key role in expanding 3G and 4G deployments
• e.g. Seamless call handoffs between 2G, 3G and 4G
  networks
• e.g. EV-DO and LTE femtocells
• CDMA2000 operators will be among the first to
  deploy LTE
• CDGs evolution, device and roaming teams are
  working to ensure interoperability

IP Core Networks and VCC Bridge CDMA and LTE
13
CDMA vs. OFDMA
CDMA and OFDMA are different technologies with
different capabilities

• CDMA

OFDM-based Technologies
Codes are spread over channel
Sub-carriers are independent over the channel and
scale with additional bandwidth
15MHz
10MHz
5 MHz
20MHz
1.25MHz
CDMA2000 1X and EV-DO are more efficient in
bandwidths up to 5 MHz
OFDMA-based solutions offers a simpler
implementation inbandwidths greater than 10 MHz
14
Spectrum Flexibility
CDMA2000 offers operators the flexibility to meet
incremental market demands

• CDMA2000 1X and EV-DO offer operators the
  flexibility to uniquely service diverse market
  demands

Rev. B
Increasing Demand for Data Services
Rev. A
Rev. A
Rev. A
1X
1.25MHz
1.25MHz
1.25MHz
1.25MHz
1.25MHz
1.25MHz
10 MHz
Rev. A
Rev. A
1X
1.25MHz
1.25MHz
1.25MHz
5MHz
Rev. A
1X
1.25MHz
1.25MHz
1X
1.25MHz
Clearing spectrum and deploying smaller
carriers is easier and more affordable
15
Advanced Convergence Network Architecture
An evolution to a flexible and flat IP-based
network architecture
CDMA2000 networks will support both legacy and
advanced IP network architectures
IP Network (Ethernet)
Gateway
Internet
PSTN
IMS
Next generation broadband technologies will be
integrated into CDMA2000 IP networks
UMB LTE Mobile WiMAX
16
Next Generation Multimode Devices
Next generation mobile broadband devices will
leverage the learning curve of CDMA2000
WorldModeTM devices
LTE UMB WiMAX WCDMA HSPA GPS EV-DO Rev. B EV-DO
Rev. A EV-DO Rel. 0 CDMA2000 1X
LTE UMB WiMAX GPS EV-DO Rev. B EV-DO Rev.
A EV-DO Rel. 0 CDMA2000 1X
EV-DO Rel. 0 GPRS GSM GPS CDMA2000 1X
Radio Frequency Links 450 MHz 700 MHz
800 MHz 1500 MHzGPS 1700 MHz
1800 MHz 1900 MHz AWS 2100 MHz
2500 MHz 3500 MHz
CDMA2000 operators will be among the first
operators to offer next generation mobile
broadband services
WiMAX is enabled using a separate chipset
MDM 9800 and MDM 9600 chipsets will support FDD
and TDD duplex modes and different carrier
bandwidths.
17
Penetrating the Market
Next generation mobile broadband handset pricing
trends will be similar to UMTS
Next generation multimode handsets will need to
approach existing handset prices to penetrate the
market and build economies of scale
18
CDMA2000 Strong Global Presence
CDMA2000 has built a strong ecosystem and
enormous economies of scale
More than 276 operators in more than 102
countries have deployed or are planning to deploy
CDMA2000
463 million CDMA2000 Subscribers
1X EV-DO Rel. 0 EV-DO Rev. A
Commercial 276 106 59
In Deployment/Trial 23 43 34
CDMA2000 will continue to be the core business
for hundreds of operators for well over a decade
19
Migration Timeline
With an increasing number of subscribers, the
migration process is lengthening
Migration of Subscribers
Putting things into perspectiveMass adoption of
wide-bandwidth OFDM-based solutions will take
many years Voice will remain the Killer
Application.
20
CDMA2000 Strong Evolution Path
CDMA ecosystem is continuing to enhance the
CDMA2000 roadmap

• Mass market adoption of Rev. A advanced broadband
  services is strong
• 26 commercial operators in 18 countries (1/2
  billion POPs covered) 31 more in deployment
• Multicarrier Rev. B will meet demand for
  additional capacity well into the future
• Interoperability with OFDM-based broadcast and
  wide-bandwidth broadband solutions will be
  supported to supplement core CDMA2000 services

Mobile Broadband Global Cumulative Subscribers
Sources Strategy Analytics, Worldwide Cellular
User Forecast, July 2007, and Mobile Broadband
Subscriptions Forecast, November 2006
Wireless Intelligence World Cellular
Subscriber Forecast, October 2007
Yankee Group, Global Mobile Forecast, October
2007 In-Stat/MDR, April 2007
Informa, Future Mobile Broadband
HSPA, EV-DO, WiMAX LTE, 2007
Yankee Group, Modest WiMAX Grows Despite
Uncertainty, January 2007
21
CDMA2000 Long-Term Value Proposition
CDMA2000 is strongly positioned to serve operator
requirements for the long run
Substantial Long-term Industry Value
