4G Plus 4th Generation Platform Launching Ubiquitous Services

1
4G Plus 4th Generation Platform Launching
Ubiquitous Services

• 4 April 2003
• Herma van Kranenburg

2
Setting
Heterogeneous networks and technology
Each domain connected via IP to an all-IP core
backbone
3
User perspective
User wants always anytime everywhere Optimal and
cheapest connectivity Tailored to circumstancial
needs and capabilities Ambient aware Minimal
botherded, maximal flexibility
4
Solutionsresearched in project

• Core issues
• Architectural framework federated service control

• Mobility management
• In this area the seamless roaming of users,
  sessions, terminals and services over
  heterogeneous networks based on different
  technologies is studied. (Dynamic, vertical)
  handoffs.
• Multimedia Session Control
• Multimedia management deals with setup, breakdown
  and maintenance of end-to-end QoS enabled
  multimedia connections.
• Prototype platform proof of concept
• Uniqueness
• Open environment, integrated solutions,
  integrating existing SPs and operators

Facilitating Infrastructure at service control
layer 4G Service Platform
5
Facts and figures

• Classification Freeband Research Project
• Duration 1 May 2002 1 April 2004
• Size 3 M in total, 1.8 M in 2003
• Project Manager Herma van Kranenburg
• Partners Lucent Technologies, Telematica
  Instituut
• KPN/TNO Telecom

4G service platform
Goal service control solution for seamless
roaming between heterogeneous B3G networks (WLAN,
3G mobile, enterprise, )

• Status per end of 2002
• Finished requirements, initial scenarios,
  initial architecture,
• initial lab setup, overview studies
• Focus in 2003
• Complete architecture and prototype of platform
• Proof of concept for seamless roaming, session
  control and mobility management in heterogeneous
  4G environment
• Links
• Website http//4gplus.freeband.nl
• Deliverables https//doc.freeband.nl/dscgi/ds.py/
  ViewFB/Collection-5657

6
First Demonstrator

• Includes
• Authentication Authorization for Network
  Service
• (based on certificates, 802.1x, RADIUS, SAML,
  SSL)
• Automatic access network selection and Mobile IP
• (initial implementation on iPAQ with Linux)
• Seamless Roaming (integrated with AAA, Mobile IP)
• SIP infrastructure (Lucent KPN - TI)
• Network Charging Accounting
• User Location service and infrastructure
• 3 scenarios, 3 demonstrations, showing
• Benefits for end-user
• Benefits for 3rd Party Service Provider
• Benefits for Access Network Operator
• Demo at Freeband business event (6 May 2003)

7
End-user demonstration
3rd party Service Provider
Internet
4G Service Platform
Jack arrives at the train station offering a WLAN
hotspot. He switches on his laptop and gets
immediate access to the Internet.
End of scenario
8
Conclusions

• After one year of 4G
• Good team, challenging research issues, project
  progress according to schedule, research focus
  for 2nd year.
• Nice prelimenary results, good starting point for
  coming research period for innovative federated
  service control solutions for seamless roaming in
  B3G heterogeneous environments.
• Further work
• Promising 2nd year lying ahead!
• Please come and see live demonstration
• at Freeband event

9
End-User Functional view

• A. Service Authentication
• Secure to 3rd Party SP
• Exchange ID, sign-on and service information
• Redirect to 4G SP log-in manage privacy
• Redirect to 3rd Party SP authorized

Restaurant Service
3rd party Service Provider
Internet
Jill
Profiles Privacy

• B. Roaming with Mobile IP
• Mobile IPv4, with co-located Care-off Address
• iPAQ/laptop client with Linux
• MP3 streaming application

4G Service Platform
Home Agent

• C. SIP sessions
• Session Initiation Protocol (SIP)
• User Agents MSN Messenger 4.6, LinPhone
• Federated call direct
• Reachable after roaming

Mobile IP tunnel
Mobile IP

• D. Value Added Services
• Roaming
• User Location
• Profiles Privacy

Jack
10
3PSP Functional view

• A. Service Authentication
• Secure to 3rd Party SP

Restaurant Service

• Exchange ID, sign-on and service information

3rd party Service Provider

• Redirect to 4G SP log-in manage privacy
• Redirect to 3rd Party SP authorized

Jill
Internet
Charging

• B. User Location
• Access controlled by end-user
• Abstraction of access network
• (interface destination)

4G Service Platform

• C. Charging
• Charge user via 4G Service Platform
• User has insight in cost on-line

Profiles Privacy
OSA/Parlay
Parlay X

• D. Non - 4G user (Jill)
• Restaurant service must ask Jills location
• No charging no extra revenue

Jack
11
Access Network Provider Functional view

• A. Network Authentication
• Federated Authentication Authorization
• No subscriber database at access network
• Uses 802.1x, certificates and RADIUS

Subscriber database
Internet
4G Service Platform
Radius server

• B. Local Services
• After authentication update of URL to SP
• SP web portal shows Local Service URL
• Changes when roaming to other access network

Radius
Charging

• C. Charging
• Charge user via 4G Service Platform
• Charge per volume, duration etc.
• User has insight in cost on-line

• D. Non - 4G user (Jill)
• No access to Internet
• Possibly access to Local Service only

Jill
Jack
