Use of New Tools for Managing Risks Microbial
Source Tracking
Joan B. Rose (rosejo_at_msu.edu) Department of
Fisheries and Wildlife
2
Microbial Source Tracking

• Tools are now available to determine the
  molecular fingerprint of the fecal pollution.
• Health risks
• Remediation
• Prioritization
• Responsibility

3
Microbial Source Tracking

• Indicator bacteria E.coli dont provide source
  of pollution
• MST methods have developed using genetic
  approaches to identify source.
• Can be library dependent or library
  independent/host specific

4
Why host specific ?

• Host specific method is library independent
• For Library-dependent, DNA libraries are built
  using isolates from animals human sources in
  the area
• Library dependent methods use these libraries to
  match to the unknown environmental sample
• Host specific method requires no library, the
  marker is specific to the host, and has fewer
  false(-) and false() the library methods

5
Muck in Saginaw Bay

• Algae, detritus, muck - not a new development
• Documented problem in Saginaw Bay since the
  1960s
• Problem in other areas of the Great Lakes

Bay City State Park in 1929
6
The Problem

• Perceived increase in duration and spatial
  distribution compared to past years
• Degradation of the aesthetic value of beaches
• Public and landowner concerns
• Detection of fecal indicators
• Potential human health implications

Photo by Dr. Juli Dyble NOAA
7
The water/ muck interface notice lots of
aquatic vegetation both in water and dried on
shore Photos by Dr. Juli Dyble NOAA
8
Looking out toward the water very turbid Photos
by Dr. Juli Dyble NOAA
9
Digging in the muck at the water line reveals
lots of vegetation holding it all together Photos
by Dr. Juli Dyble NOAA
10
Moving a little further away from the waterline
you sink right in! Photos by Dr. Juli Dyble NOAA
11
Sinking even deeper in muck Photos by Dr. Juli
Dyble NOAA
12
Closer to the water, if you dig into the muck,
you find more vegetation
Further up, if you wipe off the top layer, it is
green beneath A muck mat? Photos by Dr. Juli
Dyble NOAA
13
Most abundant Filamentous diatom
Second most abundant A tightly coiled Spirogyra?
2 representative pennate diatoms
Another common diatom
Spirogyra saw some, but not abundant
Cyanobacteria Anabaena only saw a couple
Cyanobacteria Microcystis
Cyanobacteria Oscillatoria or Lyngbya?
All pics are 40X except Spirogyra (20X), bright
field Photos by Dr. Juli Dyble NOAA
Cladophora?
14
What are Fecal Indicators?

• A microorganism that
• is present when feces and presumably pathogens
  are present (health risk)
• occurs in high concentrations in polluted waters
  and has a relationship to the degree of pollution
• is easy to cultivate and identify

Adapted from Bonde 1966
15
E. coli

• Part of the fecal indicator bacteria which are
  generally harmless themselves
• Found in high numbers in the gut of humans and
  other warm blooded animals, including birds
• Excreted daily in the feces of people and mammals
• Used to indicate the potential presence of
  pathogens, microorganisms that come from the gut
  and cause diseases such as diarrhea

16
Where are fecal indicators found?

• Sewage (even treated)
• Septic tank effluent (the liquid from the septic
  tank)
• Septage (solids from the septic tank)
• Manure and animal waste lagoons
• Bird and other animal droppings
• Rainfall can wash the fecal wastes and associated
  indicator bacteria into nearby water bodies
• Almost all surface waters have some background of
  fecal indicators due to wildlife, with the levels
  increasing the closer you get to sewage/feces

17
Water quality Standards/Criteria For
Recreational Water
Indicator Geometric Means Michigan EPA

E.Coli CFU lt130/100ml lt126cfu/100ml
Enterococci CFU None lt33cfu/100ml
18
Our Approach host-specific markers

• Use multiple source tracking markers
• Host specific genetic marker (esp)
• Differentiate Human/non human
  pollution
• Traditional MF method and PCR used to detect the
  gene. A culture dependent library independent
  method
• Bacteriodes use PCR

19
What is PCR?

• Enzymatic reaction that makes many copies of DNA
  from single molecule
• 2n copies of DNA from single molecule where n
  No. of cycles
• So, 35 cycles of PCR would yield 235 copies of DNA

20
Polymerase Chain Reaction (PCR)

• Developed in 1985 by Kary Mullis
• Dr. Mullis received the Nobel Prize in Chemistry
  in 1993
• PCR is considered as one of the most important
  discoveries in molecular biology

21
PCR Machine
22
Enterococci

• EPA recommended
• Esp (Enterococcus surface protein) as human
  marker
• Only found in human feces
• Cause of urinary tract and gastrointestinal
  infection
•


23
Enterococcus membrane filtration (MF)
24
Human Pollution Marker Validation
Source esp marker
Sewage 67/67
Septic tank 14/16
Poultry 0/8
Swine 0/12
Cattle 0/35
Canada Geese 0/12
Seagull 0/28
Pelican 0/7
Wild Birds 0/10
Scott et al., 2005. Env. Sci. Technol., 39
283-287
25
BACTERIODES

• Bacteroides are specialists in the intestinal
  environment of animals.
• Are the most numerous types of bacteria
  approximately 30 of what is excreted.
• These bacteria are anaerobes and can not grow in
  the presence of oxygen.
• Specific genetic targets have been identified in
  cattle, humans and swine.
•


26
Host Specific Markers are Key to Source Tracking
Future

• Bacteroides (genetic approaches PCR)
• 4/4 sewage 4/4 human 4/5 cow (lowest
  concentration missed) 4/4 dogs however no marker
  for Birds Missed 2 samples with dog and 2 with
  cow that were mixed.
• E.coli Toxin genes able to detect sewage (4/4).
• Enteroviruses and Adenoviruses found in 3 of 4
  sewage samples.
• Enterococci ESP marker found in 100 of 109 human
  sewage water samples and zero of 80 animal
  samples.

27
Prevalence of Human and Bovine Markers
HUMAN
28
Prevalence Of esp Human marker
Silver Beach At Lake Michigan
At Lake Michigan
29
Prevalence Of Human And Bovine Markers
30
Conclusions

• New tools allow for the detection of multiple
  sources of pollution using a tool box approach.
• This will help address the types of pathogens of
  concern.
• This will also help to determine type of future
  controls on land that will protect water quality.
• More samples need to be collected and assayed in
  the future.

31

• THANK YOU
