Networklayer mobility in wireless ad hoc access networks

1
Network-layer mobility in wireless ad hoc access
networks

• Robert Brännström

2
Outline of the presentation

• Project goal and focus
• Research issues
• Background
• Publications and contribution
• Outcomes
• Conclusions and future work

3
Overall project goal

• To improve the efficiency of wireless Internet
  access for roaming users

Current focus

• The thesis work focuses on network-layer mobility
  and connectivity of wireless multi-hop ad hoc
  networks to the Internet

4
Scenario
5
Research issues

• Network-layer metrics
• - Evaluation of gateway selection and handover
  decisions
• Multihomed global connectivity
• - How to deploy Multihomed Mobile IP in MANETs
• Gateway connectivity in global connectivity
  networks
• - How to maintain gateway connectivity
• Destination locality in global connectivity
  networks
• - How to decide locality

6
Introduction - Wireless Internet access

• Wireless access could be provided by many
  different network types with different coverage
  and capacity
• Access networks to wired All IP backbone
• Heterogeneous access network

7
Introduction - Mobile Ad hoc Networks (MANET)

• Global connectivity network, gateway bridging
  routing differences
• Multi-hop network, direct peer-to-peer
  communication
• Ad hoc routing, hop count
• Extended service area

8
Introduction - Mobility

• Addressing and routing problem - dual meaning of
  IP address
• Identifier for endpoint and location
• User mobility migrate sessions
• Network mobility switch network attachment

9
Introduction - Mobile IP

• Provides network-layer mobility
• FA advertise its service on the foreign network
• MH registration with HA through FA
• Tunneling between HA and FA

10
Background - network-layer metrics (WLAN)

• Overlapping service areas
• Gateway selection
• Current solution SNR
• Problem High SNR ? high throughput

11
Background - network-layer metrics (ad hoc)

• Ad hoc routing
• Current solution Hop count
• Problem Lower hop count ? higher throughput

12
Background - network-layer metrics

• Mobile IP agent advertisements sent with discrete
  intervals from FA
• Mobile Host measures variance in arrival time
• Running Variance Metric (RVM)
• Include RTT to HA gt Relative Network-layer Load
  (RNL)

13
Background - network-layer metrics

• Related work challenging discrete models
• - Statistical modeling of ad hoc links
• - Stable links
• - Load balancing
• - Join procedure

14
Background - multihomed global connectivity

• Gateway implements MIP foreign agent
• MIP needs to be adapted for the multi-hop
  environment
• Ad hoc networking enables connectivity to more
  than one gateway at a time
• M-MIP enables multiple registrations

15
Background - multihomed global connectivity

• Just rebroadcast advertisements?
• Forwarding condition needed

16
Background gateway connectivity

• Internet traffic gtgt local traffic
• Mobile hosts roaming around, keeping sessions
  active
• Importance of maintaining gateway connectivity

17
Background destination locality

• Ad hoc routing protocol proactively or on-demand
  finds the route to a destination.
• Proactive discovery gives high overhead
• On demand discovery gives high latency

18
Background destination locality

• Related work
• - Reactive destination discovery
• - Advertisements solicitation
• - Single hop prefix matching

19
Publications road map
Running Variance Metric for evaluating
performance of Wireless IP Networks in the
MobileCity Testbed (Chapter 4)
Agent Selection Strategies in Wireless Networks
with Multihomed Mobile IP
M-MIP extended Mobile IP to maintain multiple
connections to overlapping wireless access
networks (Chapter 5)
Maintaining Gateway Connectivity in multi-hop Ad
hoc Networks (Chapter 6)
Implementing multi-hop ac hoc Internet access in
the MobileCity testbed (Chapter 7)
Mobility Management for multiple diverse
applications in heterogeneous wireless networks
20
Publications and contribution

• C. Åhlund, R. Brännström, and A. Zaslavsky.
• Agent Selection Strategies in Wireless Networks
  with Multihomed Mobile IP
• In Proceedings of The First International
  Workshop on Service Assurance with Partial and
  Intermittent Resources ( SAPIR 2004 ). August
  2004, Fortaleza, Brazil.
• C. Åhlund, R. Brännström, and A. Zaslavsky.
• Running Variance Metric for evaluating
  performance of Wireless IP Networks in the
  MobileCity Testbed.
• In Proceedings of The First International
  Conference on Testbeds and Research
  Infrastructures for the DEvelopment of NeTworks
  and COMmunities (Tridentcom 2005). February
  2005, Trento, Italy.
• C. Åhlund, R. Brännström, and A. Zaslavsky.
• M-MIP extended Mobile IP to maintain multiple
  connections to overlapping wireless access
  networks.
• In Proceedings of the 4th International
  Conference on Networking (ICN 2005). April 2005,
  Reunion Island, France.

21
Publications and contribution

• R. Brännström, C. Åhlund, and A. Zaslavsky.
• Maintaining Gateway Connectivity in multi-hop Ad
  hoc Networks.
• In Proceedings of the Fifth International IEEE
  Workshop on Wireless Local Networks (WLN 2005).
  November 2005, Sidney, Australia.
• R. Brännström, R. Kodikara E, C. Åhlund, and A.
  Zaslavsky.
• Implementing Global Connectivity and Mobility
  support in a Wireless multi-hop ad hoc Network.
• To appear in Proceedings of the 4th Asian
  International Mobile Computing Conference (AMOC
  2006). January 2006, Kolkata, India.
• R. Brännström, R. Kodikara E, C. Åhlund, and A.
  Zaslavsky.
• Mobility Management for multiple diverse
  applications in heterogeneous wireless networks.
• To appear in Proceedings of the IEEE Consumer
  Communications and Networking Conference (CCNC
  2006). January 2006, Las Vegas, USA.

22
Implementation - network-layer metrics

• Evaluation of RNL compared to SNR
• Evaluation of RNL compared to hop count
• Implementation in
• GloMoSim 2.0

23
Implementation - network-layer metrics

• Confirming results with prototype
• Implemented in C on Linux

24
Results - network-layer metrics

• Real-world

• Simulator
• Enables the mobile host to select the gateway
  with best performance

25
Implementation - multihomed global connectivity

• Gateway implements Mobile IP foreign agent
• One agent advertisement - RVM
• M-MIP Registration
• Default gateway

26
Implementation - multihomed global connectivity

• M-MIP over AODV including RVM and RNL
• Simulator implementation (GloMoSim)
• Implementation in Linux
• - Hooks into protocol stack
• - Routing table manipulation
• - Gateway IPC - MIP and AODV

27
Results - multihomed global connectivity

• Updated information - select the best gateway
• Old registrations soft state
• Multiple registered FAs enables soft handover

28
Implementation - gateway maintenance

• Mobile IP over AODV
• MH install routes based on agent advertisement
  broadcast
• - Uplink neighbors (previous hop)
• - Gateway (via best previous hop, RVM)
• Creates a tree structure
• Reverse route from MIP registration request

29
Results - gateway maintenance

• Routes to gateways proactive
• Routes discovery delays avoided

30
Implementation - destination locality

• Combines reactive and proactive approaches
• Prefix matching with default gateway (known by
  advertisements)
• Match gt RREQ.
• Mismatch gtTunnel to GW
• Mobility adds complexity
• RREQ
• - Host respond with RREP
• - Gateway respond with Proxy RREP for away
  hosts
• Tunnel to default GW
• - Gateway forward packet to Internet destination
• - Gateway respond with ICMP redirect for
  visiting hosts

31
Results - destination locality

• Avoids route request delay (on demand routing)
• Uses established links to gateways (Tunneling)
• Uses gateway knowledge (Mobile IP)

32
Outcomes

• An analysis of gateway selection and handover
  decision based on network-layer metrics. The
  analysis is carried out for both single-hop and
  multi-hop networks
• A deployment proposal of multihomed Mobile IP in
  global connectivity networks with an enhanced
  interconnection with the reactive routing
  protocol AODV
• A proposal to maintenance of gateway connectivity
  in global connectivity networks based on Mobile
  IP messages
• A destination locality decision strategy for
  mobile hosts in global connectivity networks
  based on advertised information and foreign agent
  knowledge.

33
Prototypes

• Global Connectivity

34
Prototypes

• Multihomed Mobile IP (WLAN and GPRS/UMTS)

35
Conclusions

• Mobile IP
• Network layer
• Fast mobility detection
• Deployment MIPv4
• Ad hoc
• Extended service area, multiple gateways
• Ad hoc routing, radio channel
• Gateways

36
PhD plans

• PhD Polis project, collaboration with Monash
  University
• Two years to PhD
• Mobility support in heterogeneous access networks
• Mobility support system
• Combining MIP and SIP
• Cross layer mobility detection
• Mobility adoption of multimedia
• Ongoing work, one publication within Polis
  project
• Target
• 1-2 conference publications
• 1 journal publication in a year

37
PhD plans

• Heterogeneous access
• Cross layer context awareness, Ruwini (MU)
  Polis project
• Communication between moving vehicles
• Vertical handover
• Using multiple access networks
• Ongoing work within Polis project
• Target
• 1-2 conference publications
• 1 journal publication in two years

38
Thank you! lt/presentationgt
