Shader Basics

1
Shader Basics

• Chap. 2 of Orange Book

2
Contents

• Why write shaders
• OpenGL programmable processors
• Language overview
• System overview

3
Visual Summary of Fixed Functionality
4
Why Write Shaders

• Increasingly realistic materials metals, stone,
  wood, paints,
• Increasingly realistic lighting effects area
  lights, soft shadows,
• Natural phenomena fire, smoke, water, clouds,
• Advanced rendering effects global illumination,
  ray-tracing,
• Non-photorealistic materials painterly effects,
  pen-and-ink drawings, simulation of illustration
  techniques,
• New uses for texture memory storage of normals,
  gloss values, polynomial coefficients,
• Procedural textures dynamically generated 2D and
  3D textures, not static texture images
• Image processing convolution, unsharp masking,
  complex blending,
• Animation effects key frame interpolation,
  particle systems, procedurally defined motion
• User programmable anti-aliasing methods
• General computation sorting, mathematical
  modeling, fluid dynamics,

5
About GLSL

• The OpenGL Shading Language is a high-level
  procedural language.
• As of OpenGL 2.0, it is part of standard OpenGL,
  the leading cross-platform, operating-environment-
  independent API for 3D graphics and imaging.
• The same language, with a small set of
  differences, is used for both vertex and fragment
  shaders.
• It is based on C and C syntax and flow control.
• It natively supports vector and matrix operations
  since these are inherent to many graphics
  algorithms.
• It is stricter with types than C and C, and
  functions are called by value-return.
• It uses type qualifiers rather than reads and
  writes to manage input and output.
• It imposes no practical limits to a shader's
  length, nor does the shader length need to be
  queried.

6
Programmable Processors
7
Tasks of a Vertex Processor

• Vertex transformation
• Normal transformation and normalization
• Texture coordinate generation
• Texture coordinate transformation
• Lighting
• Color material application

8
Vertex Processor

• The design of the vertex processor is focused on
  the TL functions of a single vertex.
• Vertex shaders must compute the homogeneous
  position of the coordinate in clip space and
  store the result in the special output variable
  gl_Position.
• Values to be used during user clipping and point
  rasterization can be stored in the special output
  variables gl_ClipVertex and gl_PointSize.
• Conceptually, the vertex processor operates on
  one vertex at a time (but an implementation may
  have multiple vertex processors that operate in
  parallel). The vertex shader is executed once for
  each vertex passed to OpenGL.

9
Vertex Processor
10
Vertex Processor

• OpenGL operations that remain as fixed
  functionality in between the vertex processor and
  the fragment processor include
• perspective divide
• viewport mapping
• primitive assembly
• frustum and user clipping
• backface culling
• two-sided lighting selection
• polygon mode
• polygon offset
• selection of flat or smooth shading
• depth range.

11
(No Transcript)
12
Attribute Variables
Variables defined in a vertex shader

• There are two types of attribute variables built
  in and user defined. Standard built-in attribute
  variables in OpenGL include color, surface
  normal, texture coordinates, and vertex position.
• Within the OpenGL API, generic vertex attributes
  are defined and referenced by numbers from 0 up
  to some maximum value. The command glVertexAttrib
  sends generic vertex attributes to OpenGL by
  specifying the index of the generic attribute to
  be modified and the value for that generic
  attribute.
• glBindAttribLocation allows an application to tie
  together the index of a generic vertex attribute
  and the name with which to associate that
  attribute in a vertex shader.

13
Uniform Variables

• pass data values from the application to either
  the vertex processor or the fragment processor.
• A shader can be written so that it is
  parameterized with uniform variables. The
  application can provide initial values for these
  uniform variables,
• But uniform variables cannot be specified between
  calls to glBegin and glEnd, so they can change at
  most once per primitive.

14
Uniform Variables (cont)

• supports both built-in and user-defined uniform
  variables. Vertex shaders and fragment shaders
  can access current OpenGL state through built-in
  uniform variables containing the reserved prefix
  "gl_".
• Applications can make arbitrary data values
  available directly to a shader through
  user-defined uniform variables.
• glGetUniformLocation obtains the location of a
  user-defined uniform variable that has been
  defined as part of a shader.

15
Varying Variables

• Variables that define data that is passed from
  the vertex processor to the fragment processor
  are called VARYING VARIABLES.
• Both built-in and user-defined varying variables
  are supported. They are called varying variables
  because the values are potentially different at
  each vertex and perspective-correct interpolation
  ref is performed to provide a value at each
  fragment for use by the fragment shader.

16
Varying Variables (cont)

• Built-in varying variables include those defined
  for the standard OpenGL color and texture
  coordinate values. A vertex shader can use a
  user-defined varying variable to pass along
  anything that needs to be interpolated colors,
  normals (useful for per-fragment lighting
  computations), texture coordinates, model
  coordinates, and other arbitrary values.

17
Tasks of a Fragment Processor

• Operations on interpolated values
• Texture access
• Texture application
• Fog
• Color sum

18
Fragment Processor

• A fragment shader typically writes into one or
  both of the special variables gl_FragColor or
  gl_FragDepth.
• To support parallelism at the fragment-processing
  level, fragment shaders are written in a way that
  expresses the computation required for a single
  fragment, and access to neighboring fragments is
  not allowed.
• The fragment processor does not replace the fixed
  functionality graphics operations that occur at
  the back end of the OpenGL pixel processing
  pipeline
• coverage, pixel ownership test, stippling, tests
  (scissor, alpha, depth, stencil), alpha blending,
  logical operations, dithering, and plane masking.

19
Input Variables

• The window coordinate position of the fragment is
  communicated through the special input variable
  gl_FragCoord. An indicator of whether the
  fragment was generated by rasterizing a
  front-facing primitive is communicated through
  the special input variable gl_FrontFacing.
• A fragment shader is free to read multiple values
  from a single texture or multiple values from
  multiple textures.
• The result of one texture access can be used as
  the basis for performing another texture access
  (a DEPENDENT TEXTURE READ).
• There is no inherent limitation on the number of
  such dependent reads that are possible, so
  ray-casting algorithms can be implemented in a
  fragment shader.

20
Fragment Processor
21
(No Transcript)
22
Language Overview

• C-basis GLSL is based on the syntax of the ANSI
  C programming language,
• Addition to C Vector types are supported for
  floating-point, integer, and Boolean values.
  Operators work as readily on vector types as they
  do on scalars.
• Floating-point matrix types are also supported as
  basic types.
• Samplers are a special type of opaque variable
  that access a particular texture map. 1D2D3D
  texture map, cube map textures and shadow
  textures are supported

23
Overview (cont)

• GLSL defines built-in functions for a variety of
  operations
• Trigonometric operations sine, cosine, tangent,

• Exponential operations power, exponential,
  logarithm, square root, and inverse square root
• Common math operations absolute value, floor,
  ceiling, fractional part, modulus,
• Geometric operations length, distance, dot
  product, cross product, normalization,
• Relational operations based on vectors
  component-wise operations such as greater than,
  less than, equal to,
• Specialized fragment shader functions for
  computing derivatives and estimating filter
  widths for antialiasing
• Functions for accessing values in texture memory
• Functions that return noise values for procedural
  texturing effects

24
Differences does not support

• automatic promotion of data types
• pointers, strings, or characters,
• double-precision floats byte, short, or long
  integers or unsigned data types
• unions, enumerated types, bit fields in
  structures, and bitwise operators.
• Finally, the language is not file based, so you
  won't see any include directives or other
  references to file names.

25
Differences

• constructors, rather than type casts, are used
  for data type conversion.
• unlike the call-by-value calling convention used
  by C, GLSL uses CALL BY VALUE-RETURN.
• Input parameters are copied into the function at
  call time, and output parameters are copied back
  to the caller before the function exits.
• Qualifiers in, out, inout

26
(No Transcript)
27
To install and use OpenGL shaders, do the
following

• Create one or more (empty) shader objects by
  calling glCreateShader.
• Provide source code for these shaders by calling
  glShaderSource.
• Compile each of the shaders by calling
  glCompileShader.
• Create a program object by calling
  glCreateProgram.
• Attach all the shader objects to the program
  object by calling glAttachShader.
• Link the program object by calling glLinkProgram.
• Install the executable program as part of
  OpenGL's current state by calling glUseProgram.

28
GLSL API
glGetProgram glGetProgramInfoLog glGetShader glGet
ShaderInfoLog glGetShaderSource glGetUniform glGet
UniformLocation glGetVertexAttrib glGetVertexAttri
bPointer glIsProgram glIsShader glLinkProgram glSh
aderSource glUniform glUseProgram glValidateProgra
m glVertexAttrib glVertexAttribPointer
glAttachShader glBindAttribLocation glCompileShade
r glCreateProgram glCreateShader glDeleteProgram g
lDeleteShader glDetachShader glDisableVertexAttrib
Array glEnableVertexAttribArray
glGetActiveAttrib glGetActiveUniform glGetAttache
dShaders glGetAttribLocation
More details later
29
Key Benefits

• Tight integration with OpenGL
• Runtime compilation
• No reliance on cross-vendor assembly language
• Unconstrained opportunities for compiler
  optimization plus optimal performance on a wider
  range of hardware
• A truly open, cross-platform standard
• One high-level language for all programmable
  graphics processing
• Support for modular programming
• No additional libraries or executables
