Syntax Directed Translation

1
Syntax Directed Translation

• CMSC 431
• Shon Vick

2
Phases of a Compiler

• 1. Lexical Analyzer (Scanner)
• Takes source Program and Converts into tokens
• 2. Syntax Analyzer (Parser)
• Takes tokens and constructs a parse tree.
• 3. Semantic Analyzer
• Takes a parse tree and constructs an abstract
  syntax tree with attributes.

3
Phases of a Compiler- Contd
Syntax Directed Translation

• 4.
• Takes an abstract syntax tree and produces an
  Interpreter code (Translation output)
• 5. Intermediate-code Generator
• Takes an abstract syntax tree and produces un-
  optimized Intermediate code.

4
Motivation Parser as Translator

• Syntax-directed translation

Parser
ASTs, byte code assembly code, etc
Stream of tokens
Syntax translation rules (often hardcoded in
the parser)
5
Important

• Syntax directed translation attaching actions to
  the grammar rules (productions).
• The actions are executed during the compilation
  (not during the generation of the compiler, not
  during run time of the program!). Either when
  replacing a nonterminal with its rhs (LL,
  top-down) or a handle with a nonterminal (LR,
  bottom-up).
• The compiler-compiler generates a parser which
  knows how to parse the program (LR,LL). The
  actions are implanted in the parser and are
  executed according to the parsing mechanism.

6
Example Expressions

• E ? E T
• E ? T
• T ? T F
• T ? F
• F ? ( E )
• F ? num

7
Synthesized Attributes

• The attribute value of the terminal at the left
  hand side of a grammar rule depends on the values
  of the attributes on the right hand side.
• Typical for LR (bottom up) parsing.
• Example T?TF .val1.val?3.val.

T.val
T.val
F.val
8
Example Expressions In LEX

• E ? E T .val1.val3.val
• E ? T .val1.val
• T ? T F .val1.val3.val
• T ? F .val1.val
• F ? ( E ) .val2.val
• F ? num 1.val1.val

9
Example 2Type definitions

• D ? T L
• T ? int
• T ? real
• L ? id , L
• L ? id

10
Inherited attributes

• The value of the attributes of one of the symbols
  to the right of the grammar rule depends on the
  attributes of the other symbols (left or right).
• Typical for LL parsing (top down).
• D ? T 2.type1.type L
• L ? id , 3.type1.type L

D.type
L.type
,
id
L.type
T.type
L.type
11
Type definitions

• D ? T 2.type1.type L
• T ? int .typeint
• T ? real real
• L ? id , L gen(id.name,.type)
• 3.type.type
• L ? id gen(id.name,.type)

T.type
int
12
Type definitions LL(1)

• D ? T 2.type1.type L
• T ? int .typeint
• T ? real real
• L ? id gen(id.name,.type)
• 2.type.type R
• R ? , id gen(id.name,.type)
• R ? ?

T.type
int
13
How to arrange things for LL(1) on stack?

• Include on the stack, except for the grammar
  symbol also the actions, and a shadow copy for
  each nonterminal.
• Each time one sees an action on the stack,
  execute it.
• Shadow copies are used to get synthesized values
  and pass them further to the right of the rule.

14
LR parser
UMBC

• Given the current state on top and current
  token, consult the action table.
• Either, shift, i.e., read a new token, put in
  stack, and push new state, or
• or Reduce, i.e., remove some elements from
  stack, and given the newly exposed top of stack
  and current token, to be put on top of stack,
  consult the goto table about new state on top of
  stack.

a

b

LR(k) parser
sn
X0
sn-1
Xn-1
action goto
s0
15
LR parser adapted.
a

b

• Same as before, plus
• Whenever reduce step, execute the action
  associated with grammar rule.If left-to right
  inherited attributes exist, can also execute
  actions in middle of rule.
• Can put record of attributes, associated with a
  grammar symbol, on stack.

Attributes
LR(k) parser
sn
X0
sn-1
Xn-1
action goto
s0
16
LL parser

• If top symbol X a terminal, must match current
  token m.
• If not, pop top of stack. Then look at table TX,
  m and push grammar rule there in reverse order.

17
234 num.type2
num 34 F?num F.type2
F 34 T?F T.type2
T 34 E?T E.type2
E 34 shift
E 34 shift num.type3
Enum 4 F?num F.type3
EF 4 T?F F.type3
ET 4 shift
ET 4 shift num.type4
ETnum F?num F.type4
ETF T?TF T.type12
ET E?ET E.type14
18
LL parser Adapted
UMBC

• If top symbol X a terminal, must match current
  token m.
• Put actions into stack as part of rules. Hold for
  each nonterminal a record with attributes.
• If nonterminal, replace top of stack with shadow
  copy. Then look at table TX, m and push
  grammar rule there in reverse order.
• If shadow copy, remove. This way nonterminal can
  deliver values down and up.

a

b

Attributes
LL(k) parser
Y
X
Z

Parsing table
Actions
19
On stack to be read rule action
D int a,b
(D)LT int a,b D?TL
(D)L(T)int int a,b T?int
(D)L(T) a,b T.typeint
(D)L a,b L.typeint
(D)(L)Rid a,b L?idR
(D)(L)R ,b Gen(a,int), R.typeint
(D)(L)(R)id, ,b R?, id
(D)(L)(R)id b
(D)(L)(R) Gen(b,int), R.typeint
20
Expressions in LLEliminating left recursion

• E ? E T
• E ? T
• T ? T F
• T ? F
• F ? ( E )
• F ? num

• E ? T E
• E ? T E
• E ? ?
• T ? F T
• T ? F T
• T ? ?
• F ? ( E )
• F ? num

21
UMBC
(23)4

• E ? T E
• E ? T E
• E ? ?
• T ? F T
• T ? F T
• T ? ?
• F ? ( E )
• F ? num

3
22
Actions in LL
E

• E ? T 2.down1.up
• E .up2.up
• E ? T 3.down.down2.up
• E .up3.up
• E ? ? .up.down
• T ? F 2.down1.up
• T .up2.up
• T ? F 3.down.down2.up
• T .up3.down
• T ? ? .up.down
• F ? ( E ) .up2.up
• F ? num .up1.up

E
T
?
T
F
E
T
F
(
)

4
E
T
?
E

T
T
F
2
F
T
?
?
3
?
23
Syntax Directed Translation Scheme

• A syntax directed translation scheme is a syntax
  directed definition in which the net effect of
  semantic actions is to print out a translation of
  the input to a desired output form.
• This is accomplished by including emit
  statements in semantic actions that write out
  text fragments of the output, as well as
  string-valued attributes that compute text
  fragments to be fed into emit statements.

24
Syntax-Directed Translation

• Values of these attributes are evaluated by the
  semantic rules associated with the production
  rules.
• Evaluation of these semantic rules
• may generate intermediate codes
• may put information into the symbol table
• may perform type checking
• may issue error messages
• may perform some other activities
• in fact, they may perform almost any activities.
• An attribute may hold almost any thing.
• a string, a number, a memory location, a complex
  record.
• Grammar symbols are associated with attributes to
  associate information with the programming
  language constructs that they represent.

25
Syntax-Directed Definitions and Translation
Schemes

• When we associate semantic rules with
  productions, we use two notations
• Syntax-Directed Definitions
• Translation Schemes

26
Schemes

• Syntax-Directed Definitions
• give high-level specifications for translations
• hide many implementation details such as order of
  evaluation of semantic actions.
• We associate a production rule with a set of
  semantic actions, and we do not say when they
  will be evaluated.
• Translation Schemes
• indicate the order of evaluation of semantic
  actions associated with a production rule.
• In other words, translation schemes give a little
  bit information about implementation details.

27
Syntax-Directed Definitions

• A syntax-directed definition is a generalization
  of a context-free grammar in which
• Each grammar symbol is associated with a set of
  attributes.
• This set of attributes for a grammar symbol is
  partitioned into two subsets called
• synthesized and
• inherited attributes of that grammar symbol.
• Each production rule is associated with a set of
  semantic rules.
• Semantic rules set up dependencies between
  attributes which can be represented by a
  dependency graph.
• This dependency graph determines the evaluation
  order of these semantic rules.
• Evaluation of a semantic rule defines the value
  of an attribute. But a semantic rule may also
  have some side effects such as printing a value.

28
Annotated Parse Tree

1. A parse tree showing the values of attributes at
   each node is called an annotated parse
   tree.
2. The process of computing the attributes values at
   the nodes is called annotating (or decorating) of
   the parse tree.
3. Of course, the order of these computations
   depends on the dependency graph induced by the
   semantic rules.

29
Syntax-Directed Definition

• In a syntax-directed definition, each production
  A?a is associated with a set of semantic rules
  of the form
• bf(c1,c2,,cn)
• where f is a function and b can be one of the
  followings
• ? b is a synthesized attribute of A and
  c1,c2,,cn are attributes of the grammar symbols
  in the production ( A?a ).
• OR
• ? b is an inherited attribute one of the grammar
  symbols in a (on the right side of the
  production), and c1,c2,,cn are attributes of the
  grammar symbols in the production ( A?a ).

30
Attribute Grammar

• So, a semantic rule bf(c1,c2,,cn) indicates
  that the attribute b depends on attributes
  c1,c2,,cn.
• In a syntax-directed definition, a semantic rule
  may just evaluate a value of an
  attribute or it may have some side effects such
  as printing values.
• An attribute grammar is a syntax-directed
  definition in which the functions in the semantic
  rules cannot have side effects (they can
  only evaluate values of attributes).

31
Syntax-Directed Definition -- Example

• Production Semantic Rules
• L ? E return print(E.val)
• E ? E1 T E.val E1.val T.val
• E ? T E.val T.val
• T ? T1 F T.val T1.val F.val
• T ? F T.val F.val
• F ? ( E ) F.val E.val
• F ? digit F.val digit.lexval
• Symbols E, T, and F are associated with a
  synthesized attribute val.
• The token digit has a synthesized attribute
  lexval (it is assumed that it is evaluated by the
  lexical analyzer).

32
Annotated Parse Tree -- Example
33
Dependency Graph
34
Syntax-Directed Definition Example2

• Production Semantic Rules
• E ? E1 T E.locnewtemp(), E.code E1.code
  T.code
• add E1.loc,T.loc,E.loc
• E ? T E.loc T.loc, E.codeT.code
• T ? T1 F T.locnewtemp(), T.code T1.code
  F.code
• mult T1.loc,F.loc,T.loc
• T ? F T.loc F.loc, T.codeF.code
• F ? ( E ) F.loc E.loc, F.codeE.code
• F ? id F.loc id.name, F.code
• Symbols E, T, and F are associated with
  synthesized attributes loc and code.
• The token id has a synthesized attribute name (it
  is assumed that it is evaluated by the lexical
  analyzer).
• It is assumed that is the string
  concatenation operator.

35
Syntax-Directed Definition Inherited Attributes

• Production Semantic Rules
• D ? T L L.in T.type
• T ? int T.type integer
• T ? real T.type real
• L ? L1 id L1.in L.in, addtype(id.entry,L.in)

• L ? id addtype(id.entry,L.in)
• Symbol T is associated with a synthesized
  attribute type.
• Symbol L is associated with an inherited
  attribute in.

36
A Dependency Graph Inherited Attributes

• Input real p q
• D L.inreal
• T L T.typereal L1.inreal
  addtype(q,real)
• real L id addtype(p,real)
  id.entryq
• id id.entryp
• parse tree dependency graph

37
Syntax Trees

• Decoupling Translation from Parsing-Trees.
• Syntax-Tree an intermediate representation of
  the compilers input.
• Example Procedures mknode, mkleaf
• Employment of the synthesized attribute nptr
  (pointer)
• PRODUCTION SEMANTIC RULE
• E ? E1 T E.nptr mknode(,E1.nptr ,T.nptr)
• E ? E1 - T E.nptr mknode(-,E1.nptr ,T.nptr)
• E ? T E.nptr T.nptr
• T ? (E) T.nptr E.nptr
• T ? id T.nptr mkleaf(id, id.lexval)
• T ? num T.nptr mkleaf(num, num.val)

38
Draw the Syntax Tree
a-4c
to entry for c
num 4
to entry for a
39
Directed Acyclic Graphs for Expressions
a a ( b c ) ( b c ) d
40
Examples

• 1. Postfix and Prefix notations
• We have already seen how to generate them.
• Let us generate Java Byte code.
• E -gt E E emit(iadd)
• E-gt E E emit(imul)
• E-gt T
• T -gt ICONST emit(sipush ICONST.string)
• T-gt ( E )

41
Abstract Stack Machine

• We now present (from Java Virtual Machine Spec
  see http//java.sun.com/docs/books/vmspec/2nd-edit
  ion/html/VMSpecTOC.doc.html) a simple stack
  machine and illustrate how to generate code for
  it via syntax-directed translations.
• The abstract machine code for an expression
  simulates a stack evaluation of the postfix
  representation for the expression. Expression
  evaluation proceeds by processing the postfix
  representation from left to right.

42
Evaluation

• 1. Pushing each operand onto the stack when
  encountered.
• 2. Evaluating a k-ary operator by using the value
  located k-1 positions below the top of the stack
  as the leftmost operand, and so on, till the
  value on the top of the stack is used as the
  rightmost operand.
• 3. After the evaluation, all k operands are
  popped from the stack, and the result is pushed
  onto the stack (or there could be a side-effect)

43
Example

• Stmt -gt ID expr stmt.t expr.t
  istore a
• Applied to a 3b c
• bipush 3
• iload b
• imul
• iload c
• isub
• istore a

44
Java Virtual Machine

• Analogous to the abstract stack machine, the Java
  Virtual machine is an abstract processor
  architecture that defines the behavior of Java
  Bytecode programs.
• The stack (in JVM) is referred to as the operand
  stack or value stack. Operands are fetched from
  the stack and the result is pushed back on to the
  stack.
• Advantages VM code is compact as the operands
  need not be explicitly named.

45
Data Types

• The int data type can hold 32 bit signed integers
  in the range -231 to 2(31) -1.
• The long data type can hold 64 bit signed
  integers.
• Integer instructions in the Java VM are also used
  to operate on Boolean values.
• Other data types that Java VM supports are byte,
  short, float, double. (Your project should handle
  at least three data types).

46
Selected Java VM Instructions

• Java VM instructions are typed i.e., the operator
  explicitly specifies what operand types it
  expects.
• Expression Evaluation
• sipush n push a 2 byte signed int on to stack
• iload v load/push a local variable v
• istore v store top of stack onto local var v
• iadd pop two elements and push their sum
• isub pop two elements and push their difference

47
Selected Java VM Instructions

• imul pop two elements and push their product
• iand pop two elements and push their bitwise and
• ior pop two elements and push their bitwise or
• ineg pop top element and push its negation
• lcmp pop two elements (64 bit integers), push the
  comparison result. 1 if Vs0ltvs1, 0 if
• vs0vs1 otherwise -1.
• i2l convert integers to long
• l2i convert long to integer

48
Selected Java VM Instructions

• Branches
• GOTO L unconditional transfer to label l
• ifeq L transfer to label L if top of stack is 0
• ifne L transfer to label L if top of stack !0
• Call/Return Each method/procedure has memory
  space allocated to hold local variables (vars
  register), an operand stack (optop register) and
  an execution environment (frame register)

49
Selected Java VM Instructions

• Invokestatic p invoke method p. pop args from
  stack as initial values of formal parameters
  (actual parameters are pushed before calling).
• Return return from current procedure
• ireturn return from current procedure with
  integer value on top of stack.
• Areturn return from current procedure with
  object reference return value on top of stack.

50
Selected Java VM Instructions

• Array Manipulation Java VM has an object data
  type reference to arrays and objects
• newarray int create a new array of integers
  using the top of the stack as the size. Pop the
  stack and push a reference to the newly created
  array.
• Iaload pop array subscript expression on top of
  stack and array pointer (next stack element).
  Push value contained in this array element.
• iastore

51
Selected Java VM Instructions

• Object Manipulation
• new c create a new instance of class C (using
  heap) and push the reference onto stack.
• getfield f push value from object field f of
  object pointed by object reference at the top of
  stack.
• putfield f store value from vs1 into field f of
  object pointed by the object reference vs0

52
Selected Java VM Instructions

• Simplifying Instructions
• ldc constant is a macro which will generate
  either bipush or sipush depending on c.

53
Byte Code (JVM Instructions)

• No-arg operand (instructions needing no
  arguments hence take only one byte.)
• examples aaload, aastore,aconsta_null, aload_0,
  aload_1, areturn, arraylength, astore_0, athrow,
  baload, iaload, imul etc
• One-arg operand bipush, sipush,ldc etc
• methodref op
• invokestatic, invokenonvirtual, invokevirtual

54
Byte Code (JVM Instructions)

• Fieldref_arg_op
• getfield, getstaic, putfield, pustatic.
• Class_arg_op
• checkcast, instanceof, new
• labelarg_op (instructions that use labels)
• goto, ifeq, ifne, jsr, jsr_w etc
• Localvar_arg_op
• iload, fload, aload, istore

55
Translating an If statement

• Stmt -gt if expr then stmt1
• out newlabel()
• stmt.t expr.t ifnnonnull out stmt1.t

• label out nop
• example
• if ( a 907) x x1 x x3

56
Translating a while statement

• Stmt -gt WHILE (expr) stmt1
• in newlabel()
• out newlabel()
• emit( stmt.t label in nop expr.t
  ifnonnull out stmt1.t goto in
  label out)

57
References

• Compilers Principles, Techniques and Tools, Aho,
  Sethi, and Ullman , Chapter 5
• http//www.cs.rpi.edu/moorthy/Courses/compiler98/
  Lectures/lecturesinppt/lecture15.ppt
• http//www.cs.wisc.edu/bodik/cs536/NOTES/lecture1
  4.ppt
• http//www.ece.utexas.edu/doron/yacc.ppt
• Appel, Chapter 4 and 5
• http//203.208.166.84/dtanvirahmed/cse309N/CSE309-
  5.1-3.ppt
