Fast Algorithms

1
Fast Algorithms Data Structures for
Visualization and Machine Learning on Massive
Data Sets

• Alexander Gray
• Fundamental Algorithmic and Statistical Tools
  Laboratory (FASTlab)
• Computational Science and Engineering Division
• College of Computing
• Georgia Institute of Technology

2
The FASTlab

• Arkadas Ozakin Research scientist, PhD
  theoretical physics
• Dong Ryeol Lee PhD student, CS Math
• Ryan Riegel PhD student, CS Math
• Parikshit Ram PhD student, CS Math
• William March PhD student, Math CS
• James Waters PhD student, Physics CS
• Nadeem Syed PhD student, CS
• Hua Ouyang PhD student, CS
• Sooraj Bhat PhD student, CS
• Ravi Sastry PhD student, CS
• Long Tran PhD student, CS
• Michael Holmes PhD student, CS Physics
  (co-supervised)
• Nikolaos Vasiloglou PhD student, EE
  (co-supervised)
• Wei Guan PhD student, CS (co-supervised)
• Nishant Mehta PhD student, CS (co-supervised)
• Wee Chin Wong PhD student, ChemE (co-supervised)
• Abhimanyu Aditya MS student, CS
• Yatin Kanetkar MS student, CS

3
Goal

• New displays for high-dimensional data
• Isometric non-negative matrix factorization
• Rank-based embedding
• Density-preserving maps
• Co-occurrence embedding
• New algorithms for scaling them to big datasets
• Distances Generalized Fast Multipole Method
• Dot products Cosine Trees and QUIC-SVD
• MLPACK

4
Plotting high-D in 2-D
Dimension reduction beyond PCA manifolds,
embedding, etc.
5
Goal

• New displays for high-dimensional data
• Isometric non-negative matrix factorization
• Rank-based embedding
• Density-preserving maps
• Co-occurrence embedding
• New algorithms for scaling them to big datasets
• Distances Generalized Fast Multipole Method
• Dot products Cosine Trees and QUIC-SVD
• MLPACK

6
Isometric Non-negative Matrix Factorization

• NMF maintains the interpretability of components
  of data like images or text or spectra (SDSS)
• However as a low-D display it is not faithful in
  general to the original distances
• Isometric NMF Vasiloglou, Gray, Anderson, to be
  submitted SIAM DM 2008 preserves both distances
  and non-negativity geometric prog formulation

7
Rank-based Embedding

• Suppose you dont really have meaningful or
  reliable distances but you can say A and B are
  farther apart than A and C, e.g. in document
  relevance
• It is still possible to make an embedding! In
  fact there is some indication that using ranks is
  more stable than using distances
• Can be formulated using hyperkernels becomes
  either an SDP or a QP Ouyang and Gray, ICML 2008

8
Density-preserving Maps

• Preserving densities is statistically more
  meaningful than preserving distances
• Might allow more reliable conclusions from the
  low-D display about clustering and outliers
• DC formulation (Ozakin and Gray, to be submitted
  AISTATS 2008)

9
Co-occurrence Embedding

• Consider InBio data 3M occurrences of species in
  Costa Rica
• Densities are not reliable as the sampling
  strategy is unknown
• But the overlapping of two species densities
  (co-occurrence) may be more reliable
• How can distribution distances be embedded (Syed,
  Ozakin, Gray to be submitted ICML 2009)?

10
Goal

• New displays for high-dimensional data
• Isometric non-negative matrix factorization
• Rank-based embedding
• Density-preserving maps
• Co-occurrence embedding
• New algorithms for scaling them to big datasets
• Distances Generalized Fast Multipole Method
• Dot products Cosine Trees and QUIC-SVD
• MLPACK

11
Computational problem

• Such manifold methods are expensive typically
  O(N3)
• But it is big datasets that are often the most
  important to visually summarize
• What are the underlying computations?
• All-k-nearest-neighbors
• Kernel summations
• Eigendecomposition
• Convex optimization

12
Computational problem

• Such manifold methods are expensive typically
  O(N3)
• But it is big datasets that are often the most
  important to visually summarize
• What are the underlying computations?
• All-k-nearest-neighbors (distances)
• Kernel summations (distances)
• Eigendecomposition (dot products)
• Convex optimization (dot products)

13
Distances Generalized Fast Multipole Method

• Generalized N-body Problems (Gray and Moore NIPS
  2000 Riegel, Boyer, and Gray TR 2008) include
• All-k-nearest-neighbors
• Kernel summations
• Force summations in physics
• A very large number of bottleneck statistics and
  machine learning computations
• Defined using category theory

14
Distances Generalized Fast Multipole Method

• There exists a generalization (Gray and Moore
  NIPS 2000 Riegel, Boyer, and Gray TR 2008) of
  the Fast Multipole Method (Greengard and Rokhlin
  1987) which
• specializes to each of these problems
• is the fastest practical algorithm for these
  problems
• elucidates general principles for such problems
• Parallel THOR (Tree-based Higher-Order Reduce)

15
Distances Generalized Fast Multipole Method

• Elements of the GFMM
• A spatial tree data structure, e.g. kd-trees,
  metric trees, cover-trees, SVD trees, disk trees
• A tree expansion pattern
• Tree-stored cached statistics
• An error criterion and pruning criterion
• A local approximation/pruning scheme with error
  bounds, e.g. Hermite expansions, Monte Carlo,
  exact pruning

16
kd-trees most widely-used space-partitioning
tree Bentley 1975, Friedman, Bentley Finkel
1977,Moore Lee 1995
17
A kd-tree level 1
18
A kd-tree level 2
19
A kd-tree level 3
20
A kd-tree level 4
21
A kd-tree level 5
22
A kd-tree level 6
23
Example Generalized histogram
bandwidth h
query point q
24
Range-count recursive algorithm
25
Range-count recursive algorithm
26
Range-count recursive algorithm
27
Range-count recursive algorithm
28
Range-count recursive algorithm
Pruned! (inclusion)
29
Range-count recursive algorithm
30
Range-count recursive algorithm
31
Range-count recursive algorithm
32
Range-count recursive algorithm
33
Range-count recursive algorithm
34
Range-count recursive algorithm
35
Range-count recursive algorithm
36
Range-count recursive algorithm
Pruned! (exclusion)
37
Range-count recursive algorithm
38
Range-count recursive algorithm
39
Range-count recursive algorithm
fastest practical algorithm Bentley 1975 our
algorithms can use any tree
40
Dot productsCosine Trees and QUIC-SVD

• QUIC-SVD (Holmes, Gray, Isbell NIPS 2008)
• Cosine Trees Trees for dot products
• Use Monte Carlo within cosine trees to achieve
  best-rank approximation with user-specified
  relative error
• Very fast, but with probabilistic bounds

41
Dot productsCosine Trees and QUIC-SVD

• Uses of QUIC-SVD
• PCA, KPCA eigendecomposition
• Working on fast interior-point convex
  optimization

42
Bigger goal make all the best statistical/learnin
g methods efficient!

• Ground rules
• Asymptotic speedup as well as practical speedup
• Arbitrarily high accuracy with error guarantees
• No manual tweaking
• Really works (validated in a big real-world
  problem)
• Treating entire classes of methods
• Methods based on distances (generalized N-body
  problems)
• Methods based on dot products (linear algebra)
• Soon Methods based on discrete structures
  (combinatorial/graph problems)
• Watch for MLPACK, coming Dec. 2008
• Meant to be the equivalent of linear algebras
  LAPACK

43
So far fastest algs for

• 2000 all-nearest-neighbors (1970)
• 2000 n-point correlation functions (1950)
• 2003,05,06 kernel density estimation (1953)
• 2004 nearest-neighbor classification (1965)
• 2005,06,08 nonparametric Bayes classifier (1951)
• 2006 mean-shift clustering/tracking (1972)
• 2006 k-means clustering (1960s)
• 2007 hierarchical clustering/EMST (1960s)
• 2007 affinity propagation/clustering (2007)

44
So far fastest algs for

• 2008 principal component analysis (1930s)
• 2008 local linear kernel regression (1960s)
• 2008 hidden Markov models (1970s)
• Working on
• linear regression, Kalman filters (1960s)
• Gaussian process regression (1960s)
• Gaussian graphical models (1970s)
• Manifolds, spectral clustering (2000s)
• Convex kernel machines (2000s)

45
Some application highlights so far

• First large-scale dark energy confirmation top
  Science breakthrough of 2003)
• First large-scale cosmic magnification
  confirmation (Nature, 2005)
• Integration into Google image search (we think),
  2005
• Integration into Microsoft SQL Server, 2008
• Working on
• Integration into Large Hadron Collider pipeline,
  2008
• Fast IP-based spam filtering (Secure Comp, 2008)
• Fast recommendation (Netflix)

46
To find out more

• Best way agray_at_cc.gatech.edu
• Mostly outdated www.cc.gatech.edu/agray
