ASE 131: Troubleshooting ASE

1
ASE 131 Troubleshooting ASE
David WeinPrincipal Product Support
Engineer david.wein_at_sybase.com July 17th, 2003
2
Agenda

• Introduction
• Presentation Goals
• Problem Solving Resources
• Understanding ASE Diagnostics
• Finding information in error messages
• Decoding stack traces
• Picking good key words for research
• Trace Flags
• The shared memory dump facility
• Types of Problems
• Performance Issues
• Locking / Blocking / Deadlocking
• Low-Level Task Related Problems
• Backup and Recovery Issues

3
Presentation Goals

• Help you help yourself
• What resources are available to customers?
• Understand how Sybase Tech Support works on
  problems
• What is the process? What can you do to help?
• Understand ASEs diagnostics
• Errors, stack traces, and memory dumps
• Understand how to deal with specific problems
  that may be encountered with ASE
• Minimize impact by understanding what is
  happening within ASE and how to handle it.

4
Online Problem Solving Resources

• Online support home is http//www.sybase.com/suppo
  rt
• Product Manuals
• Technical Documents
• Newsgroups
• Solved Cases / Existing Change Requests
• EBF Downloads
• Case Management
• ASE documents are very strong
• Troubleshooting Guide
• Early chapters are a wealth of information on
  getting out of trouble and staying out of
  trouble.
• Also contains detailed write-ups on many ASE
  messages and should always be checked as a first
  step.
• System Administration (SAG) and Performance and
  Tuning (PT) guides are also very useful for
  understanding the area of ASE where you may be
  having problems

5
Online Problem Solving Resources, Continued

• Public newsgroups are an invaluable service
• Over a dozen ASE newsgroups covering general
  issue to specific topcis such as High
  Availability and Linux
• Searchable archive
• Informally monitored by many Sybase employees and
  lots of experienced customers
• Solved cases contains over 17,000 searchable
  support cases with answers
• Common problems and their answers are well
  documented in this knowledge base.
• Hundreds of additional entries are added every
  month
• Change Requests (CRs or bugs) are also searchable
• Contains most CRs reported by customers starting
  in May of 2002.
• Contains a summary and applicable version

6
PT Newsgroup Screenshot
7
Agenda

• Introduction
• Problem Solving Resources
• Working with Sybase Tech Support
• Change Request / Bug Fix Process
• Understanding ASE Diagnostics
• Finding information in error messages
• Decoding stack traces
• Picking good key words for research
• Trace flags
• The shared memory dump facility
• Types of Problems
• Performance Issues
• Locking / Blocking / Deadlocking
• Low-Level Task Related Problems
• Backup and Recovery Issues

8
ASE Error Message Formats

• Messages that appear in the log have a header
  string that provides good information
• 0200000000562002/12/16 234049.14 kernel
  current process (0x11890001) infected with 11
• Use this information to isolate overlapping
  messages on multi-engine systems

Date / Time
Family ID
ASE Layer
Process ID
Engine ID
9
ASE Error Message Formats, Continued

• ASE uses both numbered and unnumbered messages
• The numbered messages correspond to what is
  found in the sysmessages table.
• The unnumbered messages are more internal in
  nature, do not exist in sysmessages, and are not
  sent to the client.
• Examples
• Numbered message
• Msg 208, Level 16, State 1
• Line 1 foo not found. Specify owner.objectname
  or use sp_help to check whether the object exists
  (sp_help may produce lots of output).
• Unnumbered message
• 2002/09/05 164449.82 kernel  sddone write
  error on virtual disk 16 block 3990498

10
Severity and State

• Numbered messages consist of four components
• The message number itself, i.e. 208, 695, 1105,
  etc.
• A severity level between 10 and 24.
• Severity determines how ASE responds to the error
• Levels 10 18 represent a user error. These are
  non-fatal. 10 16 can be corrected by the user.
  17 and 18 may require DBA intervention.
• Levels 19 26 are fatal and will result in a
  terminated client session. These are more severe
  problems and represent internal inconsistencies
• Severity determines how the error is reported
• Non-SA client only receive non-fatal errors (lt
  18). They receive an alternate message for
  severity 19 and higher.
• SA clients receive errors regardless of severity
• Only severity 19 and higher are sent to the
  errorlog / console.
• If traceflag 3602 is enabled, severity 10-18 are
  also sent to the errorlog.
• A state value
• States identify the instance of an error. For
  errors raised several places, this isolates the
  code location that raised the instance.
• This is very important for tech support!
• The actual text of the message

11
Stack Traces
An invaluable diagnostic tool

• Stack traces provide useful information relating
  to what a task was doing when a fatal condition
  was encountered
• Stack traces go to the errorlog and console when
  a fatal error is encountered
• Fatal conditions such as time slice violations
  and signals also cause stack traces to be
  generated
• Trace flag 3601 was cause a stack trace to be
  generated for non-fatal errors as well, but this
  is not normally advisable.
• Stack traces are often preceded or followed by
  relevant information
• Be sure to save the entire errorlog if you see a
  stack trace
• If you are working with Tech Support, they will
  want to see the entire log, not just a cut and
  paste of the stack trace.
• Picking good key words out of a stack may help
  you find the cause online
• Using good key words for searches may turn up the
  answer in the known problems or solved cases
  databases.

12
Stack Traces, Continued
An example stack trace

• 0500000000742002/06/21 085821.17 kernel
  current process (0x128b007b) infected with
  11
• 0500000000742002/06/21 085821.23 kernel
  Address 0x0068b7f8 (getnext_ctlib_subst0x138),
  siginfo (code, address) (1, 0x0000010a)
• 0500000000742002/06/21 085821.23 kernel

• 0500000000742002/06/21 085821.23 kernel  SQL
  causing error execute etcm.etcm.ap_get_ba_addres
  s1 _at_country 'CAN', _at_addr_type 'I', _at_basicba
  '999999', _at_addrsub '99', _at_baname ''
• 0500000000742002/06/21 085821.23 kernel

• 0500000000742002/06/21 085821.23 server  SQL
  Text execute etcm.etcm.ap_get_ba_address1
  _at_country 'CAN', _at_addr_type 'I', _at_basicba
  '999999', _at_addrsub '99', _at_baname ''
• 0500000000742002/06/21 085821.23 kernel
  curdb 13 pstat 0x10100 lasterror 0
• 0500000000742002/06/21 085821.23 kernel
  preverror 0 transtate 0
• 0500000000742002/06/21 085821.23 kernel
  curcmd 197 program

13
Stack Traces, Continued

• 0500000000742002/06/21 085821.24 kernel  pc
  0x0064f8dc pcstkwalk0x24(0x29b869a0, 0x00000000,
  0x0000270f, 0x00000002, 0xfffffff8)
• 0500000000742002/06/21 085821.24 kernel  pc
  0x0064f7e8 ucstkgentrace0x194(0x128b007b,
  0x2d3ccd58, 0x2d3ccd58, 0x2bb795c8, 0x00000000)
• 0500000000742002/06/21 085821.24 kernel  pc
  0x0061cc90 ucbacktrace0xa8(0x2bb795c8,
  0x00000001, 0x128b007b, 0x2d14f238, 0x00000000)
• 0500000000742002/06/21 085821.25 kernel  pc
  0x000f62e0 terminate_process0xd70(0x00beef50,
  0x000054e8, 0x000054e4, 0xffffffff, 0x00005000)
• 0500000000742002/06/21 085821.25 kernel  pc
  0x006324d4 kisignal0x1e0(0x29b8745c, 0x29b871c4,
  0x0000000b, 0x29b87198, 0x29b87450)
• 0500000000742002/06/21 085821.26 kernel  pc
  0xff34b7dc _getfp0x220(0x0000000b, 0x29b87450,
  0x29b87198, 0x006322f4, 0x00bf3424)
• 0500000000742002/06/21 085821.26 kernel  pc
  0xff3484c0 _fork0x864(0x0000000b, 0x00bf3380,
  0x00000000, 0x00000000, 0x00000000)

14
Stack Traces, Continued

• 0500000000742002/06/21 085821.26 kernel  pc
  0x0068b77c getnext_ctlib_subst0xbc(0x00000200,
  0x00000000, 0x00000000, 0x00000000, 0x38433e50)
• 0500000000742002/06/21 085821.26 kernel
  Handler pc 0x006886ec omni_backout installed by
  the following function-
• 0500000000742002/06/21 085821.26 kernel  pc
  0x0068b490 omni_getnext0x2c0(0x38433e50,
  0x2c65f574, 0x2d3ccd58, 0x2c662c5c, 0x2d3d2298)
• 0500000000742002/06/21 085821.27 kernel  pc
  0x0042a760 exec_eop0x1750(0x00002000,
  0x2d3ccd58, 0x00000000, 0x00000000, 0x000005c5)
• 0500000000742002/06/21 085821.27 kernel  pc
  0x004297ac exec_eop0x79c(0x00007000, 0x2d3ccd58,
  0x45478880, 0x00000000, 0x00000000)
• 0500000000742002/06/21 085821.28 kernel
  Handler pc 0x0042e510 execerr installed by the
  following function-
• 0500000000742002/06/21 085821.28 kernel
  Handler pc 0x0056f508 jcsExHandler installed by
  the following function-
• 0500000000742002/06/21 085821.30 kernel
  Handler pc 0x003dfe84 sortmerr installed by the
  following function-

15
Stack Traces, Continued

• 0500000000742002/06/21 085821.30 kernel
  Handler pc 0x0042e510 execerr installed by the
  following function-
• 0500000000742002/06/21 085821.30 kernel
  Handler pc 0x0042e510 execerr installed by the
  following function-
• 0500000000742002/06/21 085821.30 kernel
  Handler pc 0x00365b38 aritherr installed by the
  following function-
• 0500000000742002/06/21 085821.30 kernel  pc
  0x00428960 execute0xb80(0x455e96d0, 0x0000702c,
  0x455e96d0, 0x2d3ccd58, 0x00005000)
• 0500000000742002/06/21 085821.30 kernel  pc
  0x0038aebc s_execute0x2404(0x80000000,
  0x000000c5, 0x455e9348, 0x00005393, 0x00001000)
• 0500000000742002/06/21 085821.30 kernel
  Handler pc 0x003a4e50 s_handle installed by the
  following function-
• 0500000000742002/06/21 085821.30 kernel  pc
  0x003a1e8c sequencer0x10d8(0x00be0400,
  0x00beec00, 0x29025200, 0x00005388, 0x2d3ccd58)
• 0500000000742002/06/21 085821.30 kernel  pc
  0x003921f8 execproc0x79c(0x00005388, 0x00007000,
  0x2d3ccd58, 0x00005000, 0x0000001f)

16
Stack Traces, Continued

• 0500000000742002/06/21 085821.30 kernel  pc
  0x0038b3d4 s_execute0x291c(0x00beec00,
  0x00be2800, 0x29025200, 0x00000008, 0x00000000)
• 0500000000742002/06/21 085821.30 kernel
  Handler pc 0x003a4e50 s_handle installed by the
  following function-
• 0500000000742002/06/21 085821.30 kernel  pc
  0x003a1e8c sequencer0x10d8(0x00be0400,
  0x00beec00, 0x29025200, 0x00005388, 0x2d3ccd58)
• 0500000000742002/06/21 085821.30 kernel  pc
  0x003921f8 execproc0x79c(0x00005388, 0x00007000,
  0x2d3ccd58, 0x00005000, 0x0000001b)
• 0500000000742002/06/21 085821.30 kernel  pc
  0x0038b3d4 s_execute0x291c(0x00beec00,
  0x00be2800, 0x29025200, 0x00000008, 0x00000000)
• 0500000000742002/06/21 085821.30 kernel
  Handler pc 0x003a4e50 s_handle installed by the
  following function-
• 0500000000742002/06/21 085821.30 kernel  pc
  0x003a1e8c sequencer0x10d8(0x00be0400,
  0x00beec00, 0x29025200, 0x00005388, 0x2d3ccd58)

17
Stack Traces, Continued

• 0500000000742002/06/21 085821.30 kernel  pc
  0x003921f8 execproc0x79c(0x00005388, 0x00007000,
  0x2d3ccd58, 0x00005000, 0x0000001b)
• 0500000000742002/06/21 085821.30 kernel  pc
  0x0038b3d4 s_execute0x291c(0x00beec00,
  0x00be2800, 0x29025200, 0x00000008, 0x00000000)
• 0500000000742002/06/21 085821.30 kernel
  Handler pc 0x003a4e50 s_handle installed by the
  following function-
• 0500000000742002/06/21 085821.30 kernel  pc
  0x003a1e8c sequencer0x10d8(0x00be0400,
  0x00beec00, 0x29025200, 0x00005388, 0x2d3ccd58)
• 0500000000742002/06/21 085821.30 kernel  pc
  0x0011cf9c tdsrecv_language0xb4(0x00be0400,
  0x00befc00, 0x00000001, 0x00005000, 0x00005400)
• 0500000000742002/06/21 085821.30 kernel
  Handler pc 0x0013d9ec hdl_backout installed by
  the following function-
• 0500000000742002/06/21 085821.31 kernel
  Handler pc 0x0033fe1c ut_handle installed by
  the following function-
• 0500000000742002/06/21 085821.31 kernel
  Handler pc 0x0033fe1c ut_handle installed by
  the following function-

18
Stack Traces, Continued

• 0500000000742002/06/21 085821.31 kernel  pc
  0x0012c6bc conn_hdlr0x20f0(0x00befc00,
  0x00be0400, 0x00000000, 0x000054e4, 0x00005400)
• 0500000000742002/06/21 085821.31 kernel  pc
  0x00662618 _coldstart(0x00000081, 0x0012a5cc,
  0x00000000, 0x00000000, 0x00000000)
• 0500000000742002/06/21 085821.31 kernel  end
  of stack trace, spid 74, kpid 311099515, suid 141

19
Good Information from Stack Traces

• While most of the stack is only relevant for
  internal Sybase folks, some of it can be used to
  help match problems with exiting cases or bugs.
• First, make note of the problem. Here it is an
  infected with 11
• 0500000000742002/06/21 085821.17 kernel
  current process (0x128b007b) infected with
  11
• Next, note which function was executing when the
  signal arrived
• 0500000000742002/06/21 085821.23 kernel
  Address 0x0068b7f8 (getnext_ctlib_subst0x138),
  siginfo (code, address) (1, 0x0000010a)
• Here the function getnext_ctlib_subst() is where
  the problem was encountered.
• This line is only relevant for signal stack
  traces and doesnt apply to time slices or most
  other errors.

20
Good Information from Stack Traces, Continued

• The SQL causing error can help you reproduce or
  avoid the problem.
• 0500000000742002/06/21 085821.23 kernel  SQL
  causing error execute etcm.etcm.ap_get_ba_addres
  s1 _at_country 'CAN', _at_addr_type 'I', _at_basicba
  '999999', _at_addrsub '99', _at_baname '
• Lines that follow contain the current database
  (pcurdb) as well as any errors that were
  encountered prior to the event that triggered the
  stack trace.

21
Picking Good Key Words for Research

• Use good searching strategies, such as
  remembering synonyms.
• When researching stack traces, search on
  functions near the top of the stack.
• For infected with issues, try searching on the
  function in the address line following the
  infected with 11.
• In the stack example we just looked at, we would
  search on getnext_ctlib_subst.
• Search example on following slides

22
Picking Good Keywords for Research, Continued

• Some ASE functions appear in almost every stack
  trace, and are therefore poor keywords to use
  when doing research
• Avoid searching based on these functions

• pcstkwalk
• ucstkgentrace
• ucbacktrace
• os_backtrace
• terminate_process
• kisignal
• hdl_default
• hdl_backout

• s_handle
• execerr
• aritherr
• ex_raise
• close_network
• execute
• s_execute
• exec_eop

• sequencer
• s_compile
• tdsrecv_language
• conn_hdlr
• _coldstart
• kaclkintr
• _fork
• _getfp

• Functions towards the top of the stack are more
  likely to be relevant than those on the bottom
• If you match the bottom of the stack but not the
  top, you likely havent matched the problem.

23
Researching our Stack Trace
Step 1 Search solved cases
Keyword we have entered
24
Researching our Stack Trace, Continued
Step 2 Get the results
25
Researching our Stack Trace, Continued
Step 3 Click on the case number and see the
details
26
Researching our Stack Trace, Continued
Step 4 Search for CR details
Changed search type
27
Researching our Stack Trace, Continued
Step 5 Get more details on the CR
28
ASE Trace Flags

• ASE has many, many trace flags that affect the
  server behavior.
• Some are officially documented, some are not.
• Some basic rules apply for all trace flags
• Dont turn on a trace flag unless you understand
  what it does and what the side effects are.
• Document who turned the flag on, when it was
  turned on, and why it was turned on.
• Dont ever add a trace flag to a RUN_server file
  without adding a comment detailing why it is
  there.

29
ASE Trace Flags How they work

• With few exceptions, trace flags are not tracked
  on a per-connection basis.
• A single, server-wide, mask of activated trace
  flags is maintained.
• When a connection turns on a trace flag, it will
  inherit the behavior of all other activate trace
  flags within the server.
• Example
• Spid 10 runs dbcc traceon (3604, 302, 310)
• Spid 11 runs dbcc traceon (8399)
• Trace 302 and 310 output will be generated for
  any query spid 11 runs. However, the output will
  not be sent back to the client since spid 11 did
  not activate trace 3604
• Some trace flags will automatically apply to all
  connections, regardless of whether or not they
  have activated other flags.
• Access to the ASE code is required to determine
  which flags have this behavior, therefore when in
  doubt you should consult Sybase Tech Support
• Most flags that affect query processing fall into
  this category
• The only flags that must appear in the RUN_server
  file are those that affect the boot-time behavior
  and initialization of the server.

30
The Sybmon Utility
ASEs advanced diagnostic facility

• Diagnostic utility built into the dataserver
  binary
• Provides access to shared memory structures
• May be used to analyze live servers or dumped
  shared memory images of servers
• Non-intrusive and requires no prior planning
  before invoking
• The halt and restart commands are intrusive
  and will cause the server to suspend processing.
  However, these are the exceptions.
• Sybmon dumps provide a snapshot image into a
  server
• This snapshot is often times very useful in
  determining the cause of a problem
• However, Sybmon dumps alone cannot answer every
  problem
• Problems that occur over time (example loss of
  SIGALRMs) cant be seen with a snapshot
• Problems that are occur outside of the shared
  memory segment cant be seen.

31
The Shared Memory Dump Facility (CSMD)

• ASE has the ability to copy its shared memory to
  a file for examination by Sybase Tech Support
• The shared memory dump can be manually triggered,
  or it can be event based
• The event based dump is called a Configurable
  Shared Memory Dump or CSMD
• CSMD can be configured for
• A specific error or a group of errors, such as
  605 or 6xx
• All errors with a severity equal to or greater
  than that configured
• A signal, such as signal 10 or 11 (infected with
  10 or 11)
• A timeslice violation
• A panic / stack overflow
• An unnumbered message that might appear in the
  log
• Memory dumps can be analyzed by Sybase to
  determine the state of the server and the
  contents of memory structures at the time of a
  fault

32
sp_shmdumpconfig Stored Procedure
The interface to CSMD

• The sp_shmdumpconfig stored procedure interfaces
  with the CSMD facility
• Add or drop dump conditions
• View configured dump conditions
• View and modify dump defaults
• To view current setup, run sp_shmdumpconfig with
  no arguments
• Example on the next slide
• For details on syntax and usage, see the notes
  section of this slide
• Two relevant sp_configure parameters
• dump on conditions set to 1 to turn on, set to
  0 (default) to turn off
• max dump conditions sets the maximum number of
  dump conditions that can be configured (default
  10)

33
sp_shmdumpconfig Sample Output

• gt sp_shmdumpconfig
• gt go
• Type       Value Maxdumps Page_Cache Proc_Cache
  Unused_Space Est_File_Size
•          Filename          Directory
• ---------- ----- -------- ---------- ----------
  ------------ -------------
  ------------------------------         ----------
• Error      813   Default  Default    Default
  Default      13 MB
• Default File Name          Default Directory
• Signal     10    Default  Include    Default
  Default      22 MB
•    Default File Name          Default Directory

• Timeslice  ---   Default  Default    Default
  Default      13 MB
•   Default File Name          Default Directory
• Panic      ---   Default  Default    Default
  Default      13 MB
•   Default File Name          Default Directory
• Defaults   ---   1        Omit       Omit
  Omit         13 MB
•   Generated File Name          /opt/sybase/csmd
• Current number of conditions 4
• Maximum number of conditions 10

34
Sybmon and CSMD What You Should Know

• Sections of memory included in dump files are
  configurable
• Core data structures are always included
• Page cache, procedure cache, and unused space are
  optional
• Inclusion of procedure cache is recommended
• Dump files can be very large
• Size is based on the amount of memory ASE is
  configured for and the optional memory modes
• ASE processing will stop while the dump file is
  being written
• This is done to achieve a consistent image of
  memory in the dump file
• Time of the halt is based on the size of the dump
  and the speed of the I/O system
• Specify a dump directory, but dont specify a
  file name
• It is best to let ASE generate the name for the
  dump file. This prevents dump files from being
  overwritten
• Always FTP dump files in binary mode

35
Should You Be Proactive With CSMD?

• Some shops setup CSMD before they encounter
  problems to help speed resolution should they
  encounter any
• Do this at your own discretion.
• Keep in mind that generating a CSMD causes ASE to
  halt while the file is being written
• Some conditions to consider
• Signals 4 (very rare), 10, 11 (signal 0xC0000005
  on NT)
• Timeslice, panic
• Fatal errors (configure for severity 19)
• Keep in mind that the dump file may not be that
  useful and Tech Support may not be interested in
  it
• Based on the specifics of the issue the CSMD may
  not be the best way to approach the problem

36
Agenda

• Introduction
• Problem Solving Resources
• Working with Sybase Tech Support
• Change Request / Bug Fix Process
• Understanding ASE Diagnostics
• Finding information in error messages
• Decoding stack traces
• Picking good key words for research
• Trace Flags
• The shared memory dump facility
• Types of Problems
• Performance Issues
• Locking / Blocking / Deadlocking
• Low-Level Task Related Problems
• Backup and Recovery Issues

37
Performance Problems

• Planning ahead greatly simplifies the resolution
  of performance problems.
• Due to the variances in applications and
  environment, it is difficult to determine what is
  normal and what is abnormal for a particular
  customer.
• Gathering benchmark data prior to encountering a
  problem allows for the isolation of problems

38
Basic Performance Troubleshooting

• Isolation query issues from system issues
• Optimizer issue, blocking issue, or resource
  issue?
• Gather data over time
• Establish baselines for all levels of activity
• Understand typical system loads at various times
• Look for trends
• Avoid tuning based on a single 5 minute sample
• Understand what you are changing
• Read documentation before tuning anything
• Document what you did and why you did it
• Dont ever turn on a trace flag until you know
  what it does and what the side effects are!

39
Tools to Consider for General Problems

• sp_sysmon
• Very good at giving an overall view of what the
  server is doing.
• Not so good at narrowing down to specific users,
  queries, etc.
• Well documented and easy to use, but can be
  difficult to find meaningful data.
• Monitor and historical servers
• Provides data sp_sysmon cant
• Better at monitoring specific users, queries,
  objects, etc.
• Requires separate setup, but this is trivial
• Can serve client apps written with the Monitor
  Client Library, such as Sybase central plug-in
• Shipped as part of ASE, no separate licenses
  required
• DBXray
• New optional feature for ASE 12.5.0.3
• Provides real-time, graphical monitoring of ASE
• Other external tools
• OS level tools such as iostat, vmstat, sar, etc.
• In extreme cases, tools such as truss can be used
  to determine the amount of time spent in
  individual system calls, but this adds a lot of
  overhead.

40
Guidelines for Using sp_sysmon

• Archive your output
• If performance drops off, archived output will be
  very useful
• Run sysmon prior to major changes
• Hardware
• Application
• Configuration parameters
• Run sysmon for short periods of time
• Dont overflow monitor counters (unsigned int)
• A sample that includes both busy and idle time
  may reveal neither.
• Look at per second and per transaction numbers
• Better than raw numbers for making comparisons
• Be careful of conflicts
• Monitor and historical server share counters with
  sysmon
• Run only a single sysmon at a time
• Be careful of automated recommendations
• Newer versions make recommendations
• Look at the system over time and consider
  implications prior to following any of them.

41
Locking / Blocking Tempdb Contention
As the overall scalability of ASE dramatically
improved, tempdb became a bottleneck

• Why is this a problem?
• Creating and dropping tables requires exclusive
  locks on system catalogs
• High throughput environments create / drop many
  temp tables
• This is normally fast, but having to do physical
  IO while holding these locks can queue up other
  processes
• Becomes a point of serialization in a high
  throughput environment

42
Tempdb Contention, Continued
Types of temporary tables

• Procedural tables
• Created inside of a stored procedure
• Visible only to that procedure and sub procedures
• Automatically dropped when proc exists
• Session tables
• Created outside of a proc using tablename
• Visible only to that session
• Automatically dropped when that session exists
• Shareable tables
• A regular table that lives in tempdb
• Visible to all users
• Will not be automatically dropped (except for ASE
  reboot)

Contention
43
Tempdb Contention, Continued
Some things to try

• On the application side, reduce the number of
  tables created
• Replace procedural tables with session tables
• proc can truncate the table at entry
• Have multiple sessions share the same regular
  table
• Row lock this table
• Requires additional logic at the application
  level
• One the server side, reduce latency while holding
  locks
• Place tempdb on a ramdisk
• Use named caches to take load out of default data
  cache

44
Tempdb Contention, Continued
Common Misconceptions

• Performing create followed by insertselect is
  better than doing select into
• Based on the belief that ASE holds the system
  table locks for duration of select into
• Reality is select into releases catalog locks
  prior to inserting rows
• Select into also faster due to reducing logging
• Truncating a table prior to dropping it reduces
  time locks are held
• This is absolutely true. During drop we must
  deallocate all extents while holding the system
  table locks.
• However, ASE already truncates temp tables prior
  to grabbing system table locks (introduced in
  11.9.2)
• Traceflag 3703 disables this, and it can increase
  contention. A common misconception is that it
  will reduce contention.

45
Tempdb Contention, Continued
Big Improvements in 12.5.0.3

• Multiple tempdbs spread the load
• 12.5.0.3 allows DBAs to create and assign
  multiple tempdbs, based on application, login,
  etc.
• Spreads the load and dramatically improves
  throughput
• Lazy log writing reduces physical IO
• Log buffers are not flushed to disk during commit
  processing in temporary databases
• Data buffers not flushed to disk at end of select
  into where target table is in a temporary
  database

46
Deadlocks

• Deadlocks are almost always an application issue.
• Get details by turning on print deadlock
  information
• sp_configure option
• Replaces the older 1204 traceflag for every day
  troubleshooting
• Traceflags can provided additional details
• 1204 prints deadlock chains (similar to print
  deadlock information above). This is required
  for other deadlock traceflags, so it should only
  be used when the trace flags below are required.
• 1205 prints a stack trace for each task in the
  deadlock chain. Tech support may request this in
  rare circumstances (requires the use of trace
  1204)
• 1218 prints the query plan (showplan) upon a
  deadlock. (requires the use of trace 1204)
• My favorite way to understand deadlocks is to
  diagram them.
• Note 12.5.0.3 MDA tables also contain deadlock
  information

47
Other Lock Troubleshooting Tips

• Traceflag 1202 will insert blocked lock requests
  into syslocks
• Normally blocked requests do not go to syslocks,
  and therefore are not displayed by sp_lock
• 1202 causes them to be displayed for additional
  troubleshooting
• Traceflags 1212 and 1217 provide extensive lock
  tracing
• 1212 traces every lock acquisition and release
• 1217 traces lock acquisition and release for user
  tables only (same as 1212, but doesnt display
  system table locks)
• Both of these traces provide A LOT of output, but
  may be helpful in isolated test and development
  environments
• May provide a better idea of how the locking
  system is handling your query

48
Low-Level Task Related Problems
Things that make your process go boom

• A task may be terminated due to some internal
  problems
• Time slice violations
• Operating system signals
• Stack and stack guard overflows
• Normally the task will be terminated and ASE will
  move on. However
• If the terminating task is holding a spinlock,
  ASE will shut itself down.
• Stack overflow issues will always result in an
  ASE shutdown

49
Low-Level Task Related Problems Time Slice
Time slice violations prevent a run-away task
from taking over your server

• ASE uses a non-preemptive scheduling algorithm
• Each scheduled task is responsible for
  voluntarily or automatically scheduling itself
  out.
• Every task is given a time quantum to run in,
  along with a grace time.
• If a task fails to yield after this grace time is
  exhausted, it will be killed.
• Tasks normally run for a very short time,
  yielding when
• The task must sleep for a resource, such a
  network or physical I/O
• Execution has completed and the task becomes idle
• They have exhausted their time quantum and are
  executing in the grace period. ASE code
  frequently checks to see if the time quantum has
  been exhausted and if the task should yield.
• Tasks may fail to yield within the grace period
  when
• The task is caught in a loop that does not
  contain any yield point
• A long code path is being executed that does not
  contain a necessary yield point
• An operating system call that was expected to
  take a short period of time takes a long time

50
Time Slice - Yielding
51
Time Slice Errors
52
Time Slice Errors, Continued
What should you do if you get a time slice error?

• Two sp_configure parameters are commonly
  referenced
• time slice -gt typically this should not be
  changed as it will have implications for every
  task.
• cpu grace time -gt this can be increased to give
  a task more time to execute before being killed.
  This will only impact processes that are running
  for an extremely long period of time.
• Tweaking parameters is easy, but not always
  fruitful
• The default grace time of 500 already gives a
  task 50 seconds to yield, which should be more
  than enough time.
• If it doesnt yield in 50 seconds, it probably
  wont yield in 75 or 100 seconds, and you will
  have tied up the engine for that much longer
• Finding a solution
• Try to isolate the behavior, i.e. errors occur on
  RPCs to a specific site.
• Pick good key words from the stack and check the
  solved cases database.
• Work with Sybase Tech Support to find the root
  cause. In some cases, a configured shared memory
  dump may help.

53
Low-Level Task Related Problems - Signals
ASE can survive most signals

• ASE tasks may receive fatal signals from the
  operating system.
• At boot time ASE installs handlers for many of
  these signals so that it can respond
  appropriately.
• ASE prefers not to dump core and exit. Rather,
  it will terminate its internal task that
  generating the signal and continue scheduling
  work on that engine.
• A message in the error log will read Current
  process infected with and a stack trace will
  be generated.
• Signals you may see
• Infected with (signal) 11 / Segmentation
  Violation an attempt was made to read or write
  memory outside of ASEs valid address space.
• Infected with (signal) 10 / Bus Error similar to
  signal 11, but may be related to a misaligned
  attempt to access memory.
• On the Windows platform, you would see a Storage
  Access Violation with code 0xC0000005

54
Signals, Continued
Dealing with signal problems

• Causes of fatal signals
• Coding error within ASE
• Operating system / hardware problem
• Improperly coded applications should not result
  in ASE performing illegal memory access.
• Be sure to see if this is a known problem
• Check solved cases and open bugs, using good key
  words from the stack trace.
• Consider a newer EBF is your release is
  significantly behind.
• Make sure your OS patches meet those required by
  the release bulletin, as well as those
  recommended by your OS vendor.
• Reproduce, reproduce, reproduce
• It is very difficult to develop a code solution
  to a signal without a reproduction.
• Use information such a the SQL Causing Error,
  application, and login to try to reproduce the
  problem.
• Tech support can and will assist without a
  reproduction, and their efforts will largely
  focus on developing a reproduction.
• Shared memory dumps are very common in these
  situations, and may help support in developing a
  reproduction.

55
Low-Level Task Related Problems Stacks
ASE must monitor its own stacks to look for
overflows

• ASE maintains stack space for its tasks
• The per-task allocation consists of space for the
  stack, followed by a guard word.
• The guard word allows a task to overflow its
  stack without affecting adjacent memory.
  Normally, it is empty space.
• If the guard word is not empty, or if it has been
  overflowed, ASE considers memory to be corrupt
  and panics, shutting itself down immediately.
• What to do
• The size of the stack and the guard word are
  independently configurable. If you must make an
  adjustment, change the stack size and not the
  guard word.
• Again, check OS patches. This is especially
  important on Solaris.
• A shared memory dump for the panic condition can
  be gathered. This allows support to examine the
  raw stacks.
• If this is a recurring problem, try to isolate
  specific queries.

56
Backup and Recovery Problems

• Validate your backups!!!
• Most major backup and recovery issues occur when
  a customer is forced to go to backup and then
  finds out their backups cannot be loaded.
• My advice do not consider you database backed-up
  unless you have successfully tested a load of the
  dump.
• This can be an expensive bit of overhead on VLDB
  systems, but it is a very good investment!
• There is very little that anybody can do to get a
  corrupted database or transaction dump to load.

57
Thank You

• Questions?
