NOTAM REALIGNMENT

1
NOTAM REALIGNMENT

• Overview and Progress

2
Overall Goals

• Improve the quality of NOTAMs
• Provide meaningful information
• Enhance NOTAM interpretation
• Graphical depiction necessary
• Improve reliability and accessibility
• Digital data exchange will enhance filtering and
  sorting
• Provide a single source for all NOTAMs
• One collection and distribution point for all
  information
• Consolidate inefficient legacy systems for
  improved customer service
• Conform to ICAO standards
• Balance diverse customer needs
• Airlines, ATC, General Aviation, International,
  Military
• Complete Digital Capture and Delivery
• Enable automated fusion of published and dynamic
  (NOTAM) data

3
Modernization Roadmap
4
Initial Policy Change

• Expanded definition of a Distant (D) NOTAM
• Adopted ICAO definition for aerodrome movement
  area
• Includes taxiways, ramps, aprons, lighting
• All D NOTAMs will be prefaced with a keyword
• Labeled unverified reports of hazards
• Information that meets NOTAM criteria but is
  unverified will be tagged with (U) and
  disseminated as D NOTAM
• Applicable only where letters of agreement exist
• Labeled other information that doesnt meet ICAO
  criteria
• Other information that may impact aircraft
  operations will be tagged with (O) and
  disseminated as D NOTAM

5
Effects of policy change

• Reclassified civil Local NOTAMs
• All current local civil NOTAMs become D NOTAMs
• Became effective January 2008
• Created keywords for all D NOTAMs for improved
  sorting and parsing
• AD AIRSPACE APRON COM
• NAV OBST (O) RAMP
• RWY SVC TWY (U)
• Enabled central distribution for all NOTAMs
• Standardized NOTAM policy and QA

6
Current Examples

• Runway condition
• !MIV 05/123 MIV RWY 10/28 CLSD 0709021200-07090216
  00
• Taxiway status
• !RDU 05/123 RDU TWY A CLSD BTWN A1, A2 TIL
  0709011600
• Ramp status
• !MEM 05/123 MEM RAMP PAEW FEDEX CARGO EAST
• Other status information
• !LOU 05/123 LOZ (O) CONTROLLED BURN 6.5SM NORTH
  TIL 0708302200

First word in the text area
7
NOW IN EFFECT
8
Implementation Activities

• NOTAM Realignment Working Group (NRWG)
• Stakeholder representatives from AIM, DoD, Flight
  Service, and USNOF
• Reviewing/modifying NOTAM Handbook
• Creating NOTICE for coordination and
  dissemination
• Safety Risk Management Panel
• Includes members from AFS, AOPA, ARP, ATA, AVN,
  Continental Airlines, DoD, En Route Service Unit,
  NBAA, Northwest Airlines, Sys Ops Service Unit,
  Tech Ops Service Unit, Terminal Service Unit, US
  Airways
• Aeronautical Information and Flight Service
  Station staff
• Reviewing proposed changes to policy proposed by
  NRWG
• Identifying hazards and potential mitigations
• Town Hall Meetings
• User Outreach!!!!
• Domestic (including Dispatchers)
• Military
• International (IATA, Canada)
• Help from our Partners

9
Digital NOTAMs

• Digital Capture
• NOTAMs Today
• Digital NOTAMs Concept of Operations
• NOTAM Origination
• NOTAM Delivery to Customers
• Convert Messages to Digital Packets
• A Common Aeronautical Model

10
Digital NOTAM Concept of Operations
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
Concept of OperationsNOTAM Origination
ORIGINATORAirport Authority
EVENTNOTAM trigger (e.g., Runway damage)

• Eliminate free form text
• Pre-populated data entry screens
• Direct submission to USNS without manual
  intervention
• Tracking data for NOTAM
• Creator
• For more information
• Chain of Custody through data chain

21
Concept of OperationsDistribution to customers
DATALINK
AI Database
Baseline Static Data
Change
VALIDATE Web
Service,Product Specs
PUBLISH Global AIM Net
Aeronautical Information Transactions
Change
Temporary Update (NOTAM)
Temporary Update (NOTAM)

• Consistent static and dynamic data
• Filter, Query and Sort
• Map and Display

22
Modernization Roadmap
23
Single Federal System

• Development underway for a federal system
  consolidation
• Joint development to compress Civil and Military
  systems and database into a single baseline
• Extend system capabilities
• ICAO Standardization
• Goal Single Federal system with full ICAO
  implementation by Late 2009
• Multiple Views of shared data
• Based on a Common International Model

24
Legacy verses ICAOComputer can create any output
from data
Common Data Model AIXM
Data
Views
25
A common aeronautical data model

• AI Common Themes
• Identification and Operation What
• Period of Validity When
• Geometry Where

And Metadata
NOTAMTemporary change to aeronautical information
SNOWTAM, ASHTAMTemporary change to airspace and
surface conditions
Military AirspaceTemporary activation of
refueling and military operating areas
Route Availability / Traffic RestrictionTemporal
restriction on traffic flows and routing
AIM Aeronautical Information Management
26
Summary

• NOTAM Realignment
• Policy Change went into effective January 28,
  2008
• Customer Outreach
• Overall Goals
• Digital Capture
• Chain of Custody through NOTAM life cycle
• Automation
• Single Federal System in late 2009
• Digital NOTAMs
• Tower Lights
• Nav Outages
• Direct Airport Authority entry
• Legacy and ICAO
• Opportunities
• Assured Delivery to Facilities
• Runway Conditions and Military Airspace Management

27
Thank You !
For more information Gary.bobik_at_faa.gov 202-493-14
07 Nfdc.faa.gov/aimnews Pilotweb.nas.faa.gov Notam
s.jcs.mil Tfr.faa.gov Naco.faa.gov
28
Airports Conference
Submitting Airport Data Changes to FAA Future
Advisory Circular
Presented by Gary Bobik, FAA April 6-8,
2008 Tulsa, Oklahoma
28
29
Background of Airports AC

• Problem Description
• Airport operators may be unaware of the need to
  reportairport data changes to FAA in a
  consistent andtimely manner
• Airport data is published in navigation
  charts, databases and flight information
  publications
• Changes to certain airport data elements
  directly impact instrument approach and
  departure procedures, affecting the safety,
  utilization and efficiency of the airport

30
Background of Airports AC

• Solution
• Airports Division and Air Traffic Organization
  workingtogether to release guidelines on how to
  submit airport data changes to FAA
• These guidelines will be contained in an
  Airports Advisory Circular (AC)
• Anticipated release date for AC is July 2008

31
Purpose of Airports AC

• AC provides guidance on what, when and how to
  submit airport data changes to the Federal
  Aviation Administration (FAA)

32
Who the AC affects

• Assists operators of all airports listed in
  the Airport/Facility Directory (A/FD),
  Supplement Alaska, and Pacific Supplement in
  keeping their data up to date
• Compliance with the guidelines is highly
  recommended for operators of all public use
  airports
• Airport Improvement Program (AIP)
• Passenger Facility Charge (PFC) funds
• Operators of private use airports should
  follow guidelines

33
When to report data changes

• If a change has taken place, FAA needs to know
  about it
• Some data elements on or about the airport may
  require coordination with Regional or Airports
  District Office (ADO) and/or RAPT (Regional
  Airspace Procedures Team) prior to change
• AC will give guidelines on how/what to
  coordinate

Immediately!!!
34
How to report data changes now
Until AC is released http//nfdc.faa.gov

•

Important links
35
How to report data changes now

36
How to report data changes soon
When AC is released http//airports-gis.faa.gov

• FAA Airports Geographic Information System
  (GIS) is the primary entry point for
  requesting changes to airport data
• Airports GIS is designed
• as the foundation for airport data within FAA
• to interface with other FAA systems and
  processes to affect changes in those systems
  or initiate airspace studies as required
• AC will give guidelines on how/when to use
  Airports GIS

37
Questions? Contact Us

• Aeronautical Information Services (AIS) -
  National Flight Data Center (NFDC)
• E-mail     9-ATOR-HQ-AIS-AirportChanges_at_faa.go
  v
• Fax [phone]
• Phone [phone]

38
Airfield Conditions Reporting

• What is the requirement?
• Code of Federal Regulations (CFR), Title 14
  Aeronautics and Space, Federal Aviation
  Administration, Department of Transportation
• 14 CFR Part 139, Section 339, Airport condition
  reporting
• This section addresses the collection and
  dissemination of airport condition reporting to
  air carriers
• To comply with this section, the CFR states that
  the NOTAM system is to be used as appropriate,
  along with other systems and procedures.
• Indicates what information or airport conditions
  are to be reported or affect the safe operations
  of air carriers.
• Who is responsible?
• The airport operators are responsible for
  informing all applicable stakeholders
• What methods are being used to disseminate this
  information?
• United States NOTAM System (USNS)
• Airport Web pages
• Auto updates
• Electronic direct distribution to airport
  stakeholders

39
Example of a commercial Airport Operations
dashboard
40
Messages to Digital Packets
Message
Digital Packet
41
Global change AIS to AIM
Classical AIS - publish documents
AIM System - manage data
Managing Product
Managing Data
Document content and format is described by -
ICAO Annex 15, Appendix 1 AIP Content - ICAO
Annex 15, Appendix 6 NOTAM format -
Data managed in the system is described by
models - Aeronautical Information Exchange
Model (AIXM) - AIXM Conceptual Model (AICM) -
Electronic AIP (eAIP) on-line presentation
format

• Specifications
• Content
• Quality
• Metadata

EuroControl Slide
