Capabilities and Advantages of Fiber to the Home
2
Fiber to the Home Solution

• Fiber optics all the way to the subscribers
  premises

• Services
• Better quality voice services
• Higher quantity and quality video services than
  capable over copper network. Both IP and RF video
• Ultra-high speed data services in both directions
• Extensive two-way broadband services and
  applications only enabled with a FTTH network

3
Greenfield Developments

• Developers driving requirement to transition from
  HFC to FTTH
• Creates market advantage Create smart
  neighborhood
• Community wide Local Area Network
• Local Community Server (on-site to provide
  customized local content)
• Bulletin Board Services (BBS)
• Home Video Access to Association Meetings
• Group and Community Calendaring
• Personal and Group Home Pages
• Create smart home
• Whole house control
• Remote access
• Video Security

4
Telemedicine / Teleradiology

• Interactive virtual office visits
• Real-time monitoring of vital signs
• Instantaneous data to labs and off-site experts
• Digital archiving
• Fiber will radically improve the way you do
  healthcare
• Local clinics
• Comfort of your own homes

Hospital
Shared X-ray
Medical Specialist at his Office or Home
5
Distance Education
Local College

• Students can sit in a virtual classroom and
  interact with classes in local universities as
  well as with guest lecturers in distant
  institutions
• Virtual parent / teacher conferences for K-12
• Full-time employees with challenging schedules
  can enroll in customized educational programs

Harvard Law School
6
Residential Broadband Services

• Work-at-Home
• Increased efficiency and corporate profitability
• Improve employee satisfaction
• On-line Game Playing
• Connect with others around the world in
  graphics-intensive multiplayer games
• Personal Pictures / Videos
• Sharing high-quality digital pictures and home
  videos
• Real-time videophone

7
Residential Broadband Services

• Video Surveillance
• Nanny-cam / babysitter-cam
• Safety
• Swimming pool monitoring
• Peace of mind when only one person is at home
• Property management
• Small business web servers
• Welcome high end users to your network and
  generate revenue

8
Explosive Growth of Unicast Video

• Proliferation of high definition content
• Bandwidth intensive
• Video on Demand
• Consumers are becoming used to accessing content
  when they want it
• Digital video recording
• Web-connected video players
• Apple TV, iPOD, X-BOX
• Internet video shift from PCs to living room TVs
• Internet video distribution
• NBC will stream 1,000 hours of live Olympic
  coverage
• Broadcasters studios providing direct content

9
Explosive Growth of Upstream Video

• User-generated video rapidly increasing
• Google 1.65 BN purchase of YouTube
• Place-shifting Video
• If TiVo time-shifts video, Sling Box redirects
  or place-shifts video to a remote PC
• Continued pressure on the limited upstream
  bandwidth of HFC networks

Everything You Need to Know to shoot, edit and
post your own Internet Productions and Movies
10
Network Capacity
Standards based PON compared to HFC based network
. . .
Frequency
TV
TV
TV
TV
Data
TV
Tele
TV
Up to1Ghz
Limited upstream pipe
30 MHz
. . .
Frequency
TV
TV
TV
TV
TV
TV
TV
TV
TV
Up to1Ghz 100 video
Plus...
Data
Tele
Data
Data
Data
Data
Tele
Time
Huge symmetrical pipe 1.25 Gbps
11
Typical PON Network
12
Network Upgrade
Replace HFC node with all passive network
Central Office
Core Router
13
Network Upgrade
Utilize Remote OLT where fiber limited
Central Office
Upgrade to FTTP
Core Router
Remote OLT
Connect to Core Router with GigE or 10 GigE links
GPON GE-PON
14
Analog RF Return
Non-Standard 4 Wavelength PON

• Analog RF Optical Return
• Non-standard RF solution with separate node
• Reduced reliability
• Increase install cost
• Complicated network
• Cost prohibitive
• Noise funneling limits combining
• Susceptible to RF ingress
• Amateur radio, electrical interference

• WDM Optical Receiver per PON
• Non-standard
• Reduced loss budget
• Increase maintenance
• Increase space requirements cost

15
Digital RF Return

• All digital
• Eliminates noise funneling
• Immune to interference
• Plug-n-Play, no maintenance
• IP from ONT
• Combine 10ks of set tops from multiple sites
• Standard PON wavelengths

Analog
Digital
16
Trident7 Per Sub Cost
Trident7 PON
HFC
30
110
Less or equal to HFC
350
490
17
OPEX Advantages
OLT replaces complex RF combining and reduces
equipment
All passive no maintenance

• Simplified network
• All dielectric fiber very reliable requires no
  maintenance
• OLT replaces HFC optical transmission equipment,
  CMTS
• Eliminate headend and field equipment level
  adjustments and maintenance
• Eliminate CLI monitoring and reporting

• Centralized provisioning management
• Truck rolls for service termination / activation
  reduced
• No OSP powered devices
• Utility bills eliminated
• Power supply battery maintenance
• RF line gear repair

18
PON Advantages

• PON Enables
• Symmetrical bandwidth, no bottlenecks
• Support any bi-directional application
• Plug-n-play network with centralized provisioning
  and management
• Support of both RF and IP video
• Routing without physical multiplexing
• Additional revenue generation
• Reduced operating expenses
• Guarantees network product longevity

• PON Eliminates
• Active electronics in OSP
• Interference from EMI, variance in RF power
  levels
• Lightning and power related outages
• Upstream bandwidth limitation
• RF multiplexing to target services
• Complexity maintenance
• HFC requires careful attention to proper system
  alignment
• CMTS concentration
• Modems MTAs
• The Upgrade Cycle
