Software Aspects of Strategic Defense Systems

1
Software Aspects of Strategic Defense Systems

• Team Turkey
• Joe
• Kim
• Senthil
• Smitha

2
President Reagans SDI

• In March 1983, President Reagan called
  for a Strategic Defense Initiative (SDI).
• I call upon the scientific community to
  give us the means of rendering these
  nuclear weapons impotent and obsolete.
• The SDI program came to be popularly
  called Star Wars.

3
Parnas Background

• Doesnt object to weapons development in general
• 8yrs experience working on military aircraft
• 20yrs in the software engineering field
• June 28, 1985 - Parnas resigns from the 1,000 /
  day panel

4
Reasons for resignation

• Software is unreliable
• Unattainable goal due to SDI properties
• Software techniques inadequate
• SE improvements will be insufficient
• AI and Automatic Programming wont help
• Problems with Proofs
• Research is inefficient and ineffective

5
Software is Unreliable

• Software often produced with bugs
• Problems persist for several versions and
  sometimes worsen with upgrades
• Digital computers have large of states but made
  from redundant subsystems (which can be
  exhaustively tested but the whole system cant)
• of possible states too high in Software
• Functions describing their behavior not
  continuous and cant be mathematically verified
• Logical expressions often harder to understand
  than the program itself
• Most Programmers dont know the tools of the trade

6
Cant Trust that SDI Character

• Target and decoys have unknown characteristics,
  (need to identify, track, and direct weapons
  towards them)
• Fatal errors will occur if developed without
  knowledge of characteristics or with
  characteristics that can be changed by an
  attacker on day of battle
• Attackers countermeasures make network of sensors
  and weapons unreliable
• Fail-soft only successful when failures
  predicted from past history, component failures
  unlikely and statically independent, system has
  excess capacity, real-time deadlines can be
  missed
• None true for SDI system
• Impossible to test under real conditions
• No faith without extensive tests

7
Most massive, costly software ever attempted

• Service period too short for humans to debug and
  modify programs
• Debuggers notes on army truck in Vietnam not
  possible in 30-90 minute war
• Real-time computation deadlines worst case
  amount of resources cant be predicted
• Efficiency and predictability require some
  preruntime scheduling, need worse case real-time
  schedule
• Large variety of sensors and weapons each
  requiring complex software, suite will grow
  during development and after deployment (subject
  to independent modification)
• Difficulties increase with size of the system,
  of independent subsystems, and of interfaces

8
One Shot at the Title

• Flow chart approach think like a computer
• Improved with larger steps
• Leads to confusion as data has different meaning
  under different circumstances
• Concurrency program appear to be doing more
  than one thing at a time
• Multiprocessing program DOES more than one
  thing at a time
• Yes, Professional Programmers use this
  conventional approach
• Trial and Error software released when rate of
  finding new errors slows down

9
New SE Techniques

• Research aimed at reducing amount of information
  needed to test and maintain
• Structured programming and formal program
  semantics
• Use of formally specified abstract interfaces
  (information hiding)
• Use of cooperating sequential processes
• Gap between theory and practice
• Good software engineering can be done, its just
  far from easy
• It reduces, NOT ELIMINATES, errors thus there is
  still a need testing

10
Improvements in SE

• New languages and environments will help but they
  are not a major impediment to our work.
• AI makes big claims but can offer no help
• Automatic Programming is just a euphemism for
  programming in a higher-level language.
• Still need to specify an algorithm
• No breakthroughs
• The fault lies not in our tools but in ourselves
  and in the nature of our product.

11
Artificial Flowers and Intelligence

• AI-1 - Solving problems which previously could
  only be done with human intelligence
• This definition changes over time
• Best work in this area makes no attempt to mimic
  peoples problem solving techniques
• Mostly problem specific, requires abstraction and
  creativity to transfer the work
• AI-2 - Heuristic or Rule Based Programming/Expert
  Systems
• Approach is dangerous and misleading
• Rules obtained are inconsistent, incomplete, and
  inaccurate
• Evolutionary approach results in poorly
  understood behavior which is hard to predict
• Spectacular behavior on small of obvious cases

12
Prove it

• Cant use exhaustive case analysis
• No prolonged, realistic, testing
• Use Mathematical analysis
• Dont have exact specifications to which one can
  apply a proof
• Proofs themselves may contain errors
• Concurrency adds difficulty to proofs
• No techniques to prove programs robust enough to
  operate with unknown hardware failures or input
  errors

13
Getting what youve paid for

• Those who make purchasing decisions dont know
  what theyre buying
• Most difficult and crucial step in research is to
  identify and define the problem
• Practical considerations restrict important
  theoretical problems
• Research should be judge by teams of successful
  researchers and experienced system engineers
• These people considered to valuable to spend time
  reviewing proposals

14
Some other perspectives on SDI

• A Debate on the feasibility of SDI was sponsored
  by CSPR MIT in 1985
• The debate was moderated by Michael L. Dertouzos
  PhD '64 of MIT
• Parnas and Joseph Weizenbaum of MIT against SDI
• Charles L. Seitz '65 of Caltech and Danny Cohen
  of the University of Southern California USC
  spoke in for SDI.
• Parnas presented his argument based on the
  papers he has submitted to SDIO at the time of is
  resignation from the panel.

15
Parnas Argument

• Since
• Specifications not known in advance,
• Realistic testing is not possible,
• No chance to fix software during use,
• No foreseeable technology changes this,
• Therefore
• It is not possible to construct SDI
• software that you could trust to work.

16
Seitz Argument

• Since
• A hierarchical architecture seems best,
• (because more natural, used in nature,
  understood by military, allows abstraction up
  levels )
• Physical organization should follow logical
  organization, (simplest choice, natural)
• Tradeoffs to make software problem tractable
  are in the choice of system architecture
  (not in new / radical methods) this makes
  software problems tractable.

17
Seitz Argument

• Loose coordination allows us to infer
  system performance
• (assume stat. independence, ) allows system
  reliability estimates.
• Therefore it is possible to create reliable SDI
  battle management software.

18
From the debate

• Parnas says We cant test it
• Seitz then replies We can build it.
• Cohen mentions the space shuttle as an example of
  a system requiring large and complex software.
• Parnas response is that whereas NASA can delay
  a launch up until the last second, the president
  cannot call up the USSR to delay a nuclear war.

19
From the debate

• Seitz argues that SDI will be much better than
  the existing ABM systems. In essencnce he says
  something useful could be built but doesnt really
  address the issue of testing it.
• Parnas argues that it doesnt make any difference
  what is built or how it is built, because there
  wont be any means of testing that it meets
  requirements.
• While people for SDI keep coming with arguments
  to support SDI, they fail to provide anwers to
  the specific issues raised by Parnas

20
Patriot Missile performance in the Gulf war

• The Patriot system has 7.4 ft long missile
  powered by a single stage solid propellant rocket
  motor that runs at mach 3 speeds
• The missile weighs 2200 lbs and its range is 43
  miles
• The patriot is armed with a 200 lb high explosive
  war head detonated by a proximity fuse that
  causes shrapnel to destroy the intended target
• The system is built around radar and fast
  computers

21
Operation

• The missile is launched and guided to the target
  in three phases
• First, the missiles guidance system turns the
  patriot toward the incoming missile as the
  missile flies into the Patriots radar beam
• Then the Patriots computer guides the missile
  toward the incoming scud missile
• Finally, the patriot Missiles internal radar
  receiver guides it toward the interception of the
  incoming missile
• During the Gulf war the Patriot was assigned to
  shoot down incoming Iraqi Scud or Al-Hussein
  missiles launched at Israel and Saudi Arabia

22
Statistical analysis of the Patriots performance
during the Gulf war

• The U.S. Army which was in charge of the Patriot
  claimed an initial success rate of 80 in Saudi
  Arabia and 50 in Israel
• Those claims were scaled back to 70 and 40
  respectively
• Part of the reason the success rate was 30
  higher in Saudi Arabia than in Israel is that in
  Saudi Arabia the patriots merely had to push the
  incoming scud missile away from military targets
  in the desert or disable the war head
• In Israel the scuds were aimed directly at cities
  and civilian populations (Lager targets)

23
Analysis continued

• The Patriots success rate in Israel was examined
  by the Israel Defense Forces (I.D.F)
• The IDF counted any scud that exploded on the
  ground (regardless of whether or not it was
  diverted) as a failure of the patriot
• A 10 month investigation by the House Government
  Operations subcommittee on legislation and
  national security concluded that there was little
  evidence to prove that the Patriot hit more than
  a few Scuds

24
Patriot missile software problem

• As reported by the U.S. General Accounting
  office, On 02/25/1991, a Patriot failed to track
  and intercept a Scud missile because of a
  software problem in the systems weapons control
  computer, the scud subsequently hit an Army
  barracks, killing 28 Americans
• This problem led to inaccurate tracking
  calculation that became worse the longer the
  system operated
• The patriot had never before been used to defend
  against Scud missiles nor was it expected to
  operate continuously for long periods of time

25
A look at current missile defense scenario

• Some dreams never die. Do they?
• SDI , which was envisioned by President Regan
  continues to live.
• The concept of missile defense remains the same
  but the bounds of the dream keeps changing.
• This can be attributed to the change in the
  sophistication and the geographical location of
  the hypothesized enemy.

26
A look at current missile defense scenario

• In the early 90s SDI gets reincarnated, but this
  time with a new name BMD
• BMDO unlike SDIO has a string of projects with
  relatively smaller goals.
• The projects under BMDO can be classified broadly
  under these categories,
•  Terminal Defense
• Midcourse Defense Segment
•  Boost Defense Segment

27
A look at current missile defense scenario
28
A look at current missile defense scenario

• Further classification of these categories
• Terminal Defense Segment
• THAAD, NTMD, PATRIOT PAC3, etc..
• Midcourse Defense Segment
• NMD GMD, SMD, etc
• Boost Defense Segment
• Airborne Laser, Space Based Laser, etc ..

29
A look at current missile defense scenario

• Well how is the BMD Doing?
• An estimated amount of 100 billion dollars have
  been spent on Missile defense.
• The goals of each of the subsystem is small
  compared to SDI due to the current scenarios
• This is a sharp change from the Reagan years,
  perhaps because the technology used is closer at
  hand and the threats are smaller.
• (Mosher, page 39, IEEE Spectrum, 1997)

30
A look at current missile defense scenario

• Smaller anticipated mission
• protect the U.S. against an attack by a rogue
  state using a handful of warheads outfitted with
  simple countermeasures.
• also provide protection against an accidental
  launch of a few warheads by Russia or China.
• no more than 100 hit-to-kill interceptors
  based at old ABM site near Grand Forks, ND.
• (Mosher, page 37, IEEE Spectrum, 1997)

31
A look at current missile defense scenario

• How do these smaller anticipated missions affect
  Parnass argument about SDI wont be able to
  produce a trustworthy missile defense software?
• Fundamentally not as you can see from the Test
  facts below,
• In the last 15 years, the U.S. has conducted 20
  hit-to-kill intercepts, . Six intercepts were
  successful 13 of those test were done in the
  last five years, and among them three succeeded.

32
Test Facts

• No real attempts have been made to intercept
  uncooperative targets those that make use of
  clutter, decoys, maneuver, anti-simulation, and
  other countermeasures.
• (Mosher, page 39, IEEE Spectrum, 1997)
• In 1996, ex TRW engineer Nira Schwartz filed a
  False Claims Act suit, alleging that results of
  tests to distinguish warheads and decoys were
  falsified by TRW.
• (featured on 60 Minutes II in January 2001)

33
Test Facts

• Lt. General Kadish Right now, from what I see,
  there is no reason to believe that we cant make
  this work. But theres a lot more testing to be
  done.
• Secretary of Defense Donald Rumsfeld said,
• We are going to deploy a minimal Missile
  Defense System, in the near future even if the
  system has not been tested completely.

34
Conclusions

• A trustworthy SDI Software seems highly
  impossible.
• The arguments by others supporting SDI doesnt
  seem to answer the issues raised by Parnas.
• The newer scenarios of missile defense does not
  change Parnass argument fundamentally
• The systems for limited mission seems to be more
  tractable than SDI

35
References

• http//www.cse.nd.edu/kwb/nsf-ufe/star-wars/
• Broad, W.J., "Scientist at work Philip E. Coyle
  III words of caution on missile defense", New
  York Times, January 16, 2001.
• DOD Ballistic Missile Defense Organization
  (BMDO). Web site http//www.acq.osd.mil/bmdo/
• http//www.clw.org/nmd/bmdfuzzylogic.html
