Lightweight Federation of Interoperable Digital Libraries

1
Lightweight Federation of Interoperable Digital
Libraries

• Ph.D. Dissertation Defense
• Rong Shi
• Department of Computer Science
• Old Dominion University
• November, 2004

2
Overview

• Introduction problem statement/motivation
• Background and related work
• Lightweight Federated Digital Library (LFDL)
  system architecture
• Design and implementation
• Conclusion and future work
• Demo

3
Why Digital Libraries

• Proliferations of digital information
• Digital Library digitized, organized, universal
  accessible collection of information
• DL vs. WWW/Web search engine
• Search spectrum
• Contents and management
• User interface and service

4
Motivation - why DL interoperability

• Digital libraries are important tools used by a
  large number of people everyday
• Search interfaces of digital libraries vary
  greatly and can lead to confusion
• Redundant work needs to be done when searching
  multiple digital libraries
• Most digital libraries are unable to interact
  with each other
• Many digital libraries have proprietary
  architecture and wont change it to
  interoperate with other libraries

5
Objectives

• Goal of interoperability
• Interoperability among non-cooperating DLs
• Federated search service
• Existing DL systems intact
• User transparency when add, delete, modify
  participants
• Lightweight, dynamic, flexible
• Service quality, usability, performance, and
  scalability
• Solution
• LFDL lightweight Federated Digital Library, or
  InterOp

6
Framework
7
Addressed Issues

• The feasibility of interoperability of
  non-cooperating DLs
• The architecture of building a federation service
• The quality and usability of the federated
  service
• System performance and robustness

8
Background

• General approaches
• Distributed search
• accurate fresher results, but
• joint protocol required, performance, reliability
  and scalability issues
• Models and sample solutions
• Fully cooperative federation NCSTRL/NCSTRL,
• Protocol exchange Z3950, STARTS, SDLIP, SDARTS,

• Results Gathering meta web search engines,
  SearchLight,
• Metadata harvesting
• Better scalability and enhanced value-added
  services, but
• Update overhead and synchronization for data
  freshness, harvesting protocol required

9
Distributed Search Fully Cooperative
Federation NCSTRL

• Dienst, Distributed search, UI,
• High cost
• Install and run same software
• Inflexible
• Software update?
• Internal structure change?
• Most suitable for each participant?
• Performance, reliability, scalability
• Only returns after all sites have responded, or
  timeout occurs
• Response time worst case
• Only as good as its weakest link, not scalable

10
Distributed Search Protocol Exchange SDLIP

• By Andreas Paepcke, etc. from Stanford
• Protocol between client and LSP
• LSP Library Service Proxy - Wrapper for
  information sources

11
SDLIP Review

• API or middleware toolkit, not for end user and
  DL
• Need to code both client side and DL LSP
• Non-flexible Proxy
• For each DL need to code LSP
• Hard coded access rules, results parsing rules
• Add DL or change DL? Change code, recompile,
  restart
• Not so lightweight
• Too comprehensive and complicated, detailed to
  low level
• need to install software or follow API to fully
  compliant with SDLIP
• Non-efficient interface
• Not really unified UI, non-simultaneous search

12
Distributed Search Results Gathering
SearchLight

• California Digital Library initiatives
• Similar to meta web search engine
• Simple search interface
• Search multiple DLs at the same time
• Problem
• Same as meta web search engine
• Simple UI only keyword search, inaccurate query
  mapping, irrelevant results
• Non-uniformly results displaying no results
  parsing, processing, or merging, only show
  returned hits, search DL again for a result doc
• Inflexible resource changes?
• Inefficient performance suffering, wait for all
  results back

13
Metadata Harvesting OAI

• Meta-data harvesting protocol
• Data Providers documents and archives manager
  and maintainer
• Service Providers end-user service to access
  archives
• OAI protocol OAI-PMH (Protocol for Metadata
  harvesting)
• Defines metadata harvesting framework, de-facto
  standard
• Syntax
• HTTP URL request and XML response
• Validated using XML Schema
• Metadata format Dublin Core
• OAI review
• For data providers
• Agreement on how to publicize metadata
• Easier to participate, but
• Still need to stick to some convention like in
  federation
• For service providers
• Agreement on how to utilize metadata
• Can provide scalable, efficient service but
• Need to follow convention like in federation,
  data synchronization, server availability

14
Summary of Current Approaches
15
LFDL Introduction

• General principal
• Distributed search results gathering
• Lightweight no work for data providers to join
• Basic solution
• Dynamic DL specification registration
• Dynamic universal interface
• Dynamic Query mapping
• Efficient system management
• Local repository

16
LFDL Basic Approach
17
LFDL Architecture
18
Data-centered specification- based LFDL Federation
19
LFDL Design DL specification

• DLDL in XML
• Structure
• General info on a digital library
• Search URL
• Search method
• Query Mapping rules
• Access methods of the digital library
• Search interface definition
• Mapped to LFDL universal interface
• Results retrieval and parsing rules
• Information to be retrieved from the digital
  library
• Specification DTD

20
DL Specification - sample

• Specification for NEEDS
• Access information
• ltSEARCHDATA Title"Search Info"gt
• ltSEARCH-METHOD Title"Search
  Method"gtPOSTlt/SEARCH-METHODgt
• ltSEARCH-URL Title"Search
  URL"gthttp//www.needs.org/needs/public/search/sea
  rch_results/index.jhtml?_DARGS/needs/public/searc
  h/index_body.jhtmllt/SEARCH-URLgt
• Search interface
• ltFORMFIELDgt
• ltINPUTNAMEgt
• ltINPUTNAME_VALUE Title"Internal Form
  Name"gt/smete/forms/FindLearningObjects.keywordlt/I
  NPUTNAME_VALUEgt
• ltINPUTNAME_MAPPING Title"Mapped UI
  Field Name"gtUI_keywordlt/INPUTNAME_MAPPINGgt
• lt/INPUTNAMEgt
• ltINPUTTYPE Title"Form Type"gttext
  inputlt/INPUTTYPEgt
• ltINPUTVALUE/gt
• lt/FORMFIELDgt
• Simulated search interface from specification

21
DL Specification sample cont.

• Results matching
• ltOVAR-TAG Title"Output Tag"gtAlt/OVAR-TAGgt
• ltOVAR-MATCH Title"Output Match"gtneeds/public/sea
  rch/search_results/learning_resource/summarylt/OVAR
  -MATCHgt
• ltCOMMENT-MATCH-START Title"Comment match
  start"gt, lt/COMMENT-MATCH-STARTgt
• ltCOMMENT-MATCH-END Title"Comment match
  end"gt/pgtlt/COMMENT-MATCH-ENDgt
• Multiple results page
• ltMULTIPAGE Title"Multi Page Information"gt
• ltMULTI-PAGE Title"MultiPage"gtyeslt/MULTI-PAGEgt

• ltHAS-NEXT Title"Contains Next
  Link"gtnolt/HAS-NEXTgt
• ltNEXT-URL Title"Matching String"gtnulllt/NEXT
  -URLgt
• ltLINK-URL Title"Matching String"gt/needs/pub
  lic/search/search_results/index.jhtml?queryIdlt/LI
  NK-URLgt
• ltURL-ADDITIONAL-MATCHgtpagelt/URL-ADDITIONAL-M
  ATCHgt
• ltPAGE-HIT Title"No. of hits per
  page"gt10lt/PAGE-HITgt
• lt/MULTIPAGEgt

22
Query Mapping Samples
23
Specification Issues

• Interface capture and query mapping
• Semantics mapping
• Non-web form based proprietary interface
• Java applet
• Multimedia
• Search behavior simulation and specification
• Access control
• Multi-steps search

24
LFDL Prototype Universal Search Interface
25
LFDL Search Service
26
LFDL Search Service User-centered Dynamic Search

• Keyword-driven dynamic interface
• Base on keyword-hit set of each DL
• Generating keyword-hit set for each DL
• Source of base keyword set from OAI test-bed
• Data from Arc metadata database
• Data from user search logs
• Generate keyword-hit set
• Calculate hits from Arc metadata database
• Query remote DL based on base keywords, parse
  results
• DL specification add parsing rules
• ltDOCHIT Title"Doc hits match string"gt
• ltMATCHSTRING Title"Output Match"gttotal
  resultslt/MATCHSTRINGgt
• ltBEFORESTRING Title"before
  string"gtoflt/BEFORESTRINGgt
• ltAFTERSTRING Title"after string"gttotal
  resultslt/AFTERSTRINGgt
• lt/DOCHITgt

27
Keyword-hit - from Arc DB and remote DL
28
Populating Keyword-hit for a DL
29
Dynamic Interface- Design

• Interface generation
• Generic universal interface
• Based on Dublin Core
• Complete DL specification in DLDL
• Filter field type, name, values
• Mapping with UI field
• Allow DL unique features (no mapping)

30
Interface Generation Algorithm

• Factors
• Input keyword
• Generic base UI
• DL keyword-hit
• DL specification
• Algorithm
• Weight based DL features selection
• DL weight determined by keyword-hit
• Absolute feature weight within UI
• Relative feature weight within a DL
• User behavior from user features selection log
• Algorithm
• balance all weights
• select features with highest weight

31
Universal Search Interface Based on DC Element
32
Enhanced DLDL and Specification

• ltFORMFIELDgt
•   ltREQUIRED Title"Required Field or
  not"gtYlt/REQUIREDgt
•   ltWEIGHT Title"Weight of Field"gt1lt/WEIGHTgt
•   ltTYPE Title"Search Criteria or Display
  Option"gtSearch Criterialt/TYPEgt
•   ltLABEL Title"Displayed Field
  Name"gtKeywordslt/LABELgt
•   ltLENGTH Title"Field Length"gt35lt/LENGTHgt
• - ltINPUTNAMEgt
•   ltINPUTNAME_VALUE Title"Internal Form
  Name"gtkeywordslt/INPUTNAME_VALUEgt
•   ltINPUTNAME_MAPPING Title"Mapped UI Field
  Name"gtUI_keywordlt/INPUTNAME_MAPPINGgt
•   lt/INPUTNAMEgt
•   ltINPUTTYPE Title"Form Type"gttext
  inputlt/INPUTTYPEgt
•   ltINPUTVALUE /gt
•   lt/FORMFIELDgt

33
Experimentation and Implementation Interface
for keyword html
34
Experimentation and Implementation Interface
for keyword university
35
Experimentation and Implementation Interface
customization
36
Results Presentation Service Automatic Metadata
Extraction

• Metadata is key
• Service usability present rich , interactive,
  and dynamic search results consistently
• Performance and robustness local repository and
  intelligent cash
• Available metadata sources
• List page of search results
• Detail page of a selected document/record
• Metadata retrieval approach
• Define specification on how metadata are
  presented in those pages
• Use Dublin Core as common metadata mapping set
• Develop metadata parser to extract metadata
• Store parsed metadata in local repository
• Build up metadata repository
• Proactive
• Passive or piggyback

37
Metadata Extraction Approach
38
(No Transcript)
39
Metadata Retrieval and Parsing Workflow
40
Metadata Parsing Rules Definition

• Extended DLDL
• Two levels list page and record page
• String parsing separate raw string to segments
  corresponding to metadata fields

41
Part of DTD for DL parsing rules specification

• lt!ELEMENT RESULT-METADATA (MATCH-START,MATCH-END,E
  XCLUDE,REPLACE,DELIMITER,METADATA-FIELD)gt
• lt!ELEMENT RECORD-METADATA (MATCH-START?,MATCH-END?
  ,EXCLUDE,REPLACE,DELIMITER,METADATA-FIELD)gt
• lt!ELEMENT METADATA-FIELD (PCDATA)gt
• lt!ATTLIST METADATA-FIELD Title CDATA "information
  about a particular metadata field"gt
• lt!ATTLIST METADATA-FIELD order CDATA IMPLIEDgt
• lt!ATTLIST METADATA-FIELD multiple (true false)
  IMPLIEDgt
• lt!ATTLIST METADATA-FIELD delimeter CDATA
  IMPLIEDgt
• lt!ATTLIST METADATA-FIELD format CDATA IMPLIEDgt
• lt!ATTLIST METADATA-FIELD null_value_string CDATA
  IMPLIEDgt

42
Sample Specification for CogPrints

• ltRESULT-METADATA hasRecordLevel"true"gt
• ltMATCH-STARTgtnulllt/MATCH-STARTgt
• ltMATCH-ENDgtnulllt/MATCH-ENDgt
• lt/RESULT-METADATAgt
• ltRECORD-METADATAgt
• ltMATCH-STARTgtname"DC.title"lt/MATCH-STARTgt
• ltMATCH-END isLastIndex"true"gt"
  name"DC.creator"lt/MATCH-ENDgt
• ltEXCLUDEgt/gtltmeta content"lt/EXCLUDEgt
• ltREPLACEgt
• ltOLD-STRINGgt" name"DC.creator"lt/OLD-STRINGgt
• ltNEW-STRINGgt lt/NEW-STRINGgt
• lt/REPLACEgt
• ltMETADATA-FIELD order"1" multiple"true"
  delimeter" "gtCREATORlt/METADATA-FIELDgt
• lt/RECORD-METADATAgt

43
Results
44
Results Merging and Presentation

• Group results based on metadata field
• Can further tailor interface and format results
  using XSLT

45
Performance Improvement Intelligent Cache

• Search scenario
• Case 1 a query for keywordcomputer
• Case 2 a query for keywordcomputer AND
  date2002
• Results LFDL prototype caching
• Cache grouped by query string, so
• Case 1 no cache hits, distributed search request
  sent to DLs
• Case 2 no cache hits, distributed search request
  sent to DLs
• Intelligent Cache Enhanced LFDL caching
• Cache grouped by metadata, so
• Case 1 no cache hits, distributed search request
  sent to DLs
• Case 2 cache hits, search served locally

46
Local Metadata Repository

• All searches are served locally first
• A secondary in memory metadata cache for better
  performance and system reliability
• Cache grouped by metadata instead of query string
• Cache-based distributed search
• Display results from cache, at the same time
• Still send out query to DLs to update cache
• Transparent to end users

47
Metadata Cache and Repository
48
Cache Replacement Algorithm

• Replacement algorithm least used plus least
  recent used metadata
• Initial system-wide parameters cache size, cache
  keep safe size
• Runtime parameters per metadata record
  date_last_used, total_usage
• Algorithm implementation
• when first start load from db order by
  date_last_used, total_usage and pick based on
  cache size
• String orderBy " ORDER BY total_usage desc,
  date_last_used desc"
• String selectMetadata "SELECT internalID,
  identifier, archive, datestamp, title, creator,
  subject, description, publisher, publication,
  keyword, category contributor, type, format,
  source, language, status, date_last_used,
  total_usage FROM dc orderBy
• each time when user view a metadata, update
  date_last_used and total_usage
• if cache full, remove least used from cache and
  save to db(first sort by date_last_used, keep
  safe, then sort by total_usage)
• cache size and keep safe size can changed at
  runtime

49
Registration and Management service
50
Registration and Management

• Registration service
• Validate, add, update and remove a DLs
  specification
• Implementation
• LDAP-based
• Tightly-integrated
• Management service
• Real-time system monitoring
• Registered DL
• Average system response time
• Resource usage
• Search activities
• Real-time system reconfiguration and maintainence
• Turn on/off debug mode
• Reallocate system resources
• Update keyword-hits database

51
Major Contributions

• Scope
• provide service for non-cooperating DLs
• DLs like IEEE and ACM may continue to work
  independently without participating any
  interoperation
• Automatic metadata extraction from
  non-cooperating DLs
• Architecture
• lightweight, dynamic, data-centered, rule-driven
  architecture
• DL specification defines interoperability
  processing rules using DLDL, a human-readable and
  highly maintainable xml-based language
• Dynamic DL registration, removal, or modification
• Powerful federation engine enforces rules defined
  in specification and enable DLs to join
  federation in real-time no code change or
  restart system
• quickly forming a gathering service for a special
  community, just add specification of DL and that
  DL will be incorporated into service on the fly
  lots of work behind the scene come up a new
  language, develop a processing engine to process
  spec written in that language
• Can be used in other domain, like web robot,
  shopping agent, price comparison agent

52
Major Contributions

• Approach
• lies in between of distributed search with no
  caching (Dienst) and harvesting (Arc)
• so can achieve both advantages - data freshness
  from distributed search and rich service,
  reliability, performance from harvesting
• Service design
• Service quality and usability
• dynamic user-centered, keyword driven search
  interface
• can be applied to other DL applications, like
  archon, to design flexible interface based on
  archive and metadata
• Results processing and presentation for rich,
  user friendly service
• parse results, so that can display results
  uniformly without showing each DL native results
  page
• Automatic metadata parsing and retrieval can be
  used by other domains and applications such as
  metadata extraction from PDF files
• System performance, efficiency and robustness
• Local metadata repository and intelligent cache

53
Publications

• R. Shi, K. Maly and M. Zubair. Interoperable
  Federated Digital Library using XML and LDAP.
  Global Digital Library Development in the New
  Millennium, pages 277-286, May 2001.
• R. Shi, K. Maly and M. Zubair. Dynamic
  Interoperation of Non-cooperating Digital
  Libraries. In Proceedings of International
  Conference on Digital Library - IT Opportunities
  and Challenges in the New Millennium, Beijing,
  China, July 2002.
• R. Shi, K. Maly and M. Zubair. Automatic Metadata
  Discovery from Non-cooperative Digital libraries.
  In Proceedings of IADIS International Conference
  on e-Society 2003, Lisbon, Portugal, June 2003.
• R. Shi, K. Maly and M. Zubair. Improving
  Federated Service for Non-cooperating Digital
  Libraries. In Proceedings of International
  Conference on Digital Libraries, New Delhi,
  India, February 2004.
• M. Zubair, K.Maly, and R. Shi. Focus Research
  Libraries in Support of Active Learning. In
  Proceedings of International Conference on
  Information and Communication Technologies for
  Education, Vienna, December 2000.

54
Major Issues

• Scalability
• not easy to incorporate a large number of DL at
  one time
• cache size limit caching
• Resource intensive when serve query with large
  amount of results to process
• however, it is still useful for building service
  for special communities with limited number of
  DLs
• Incorporate DLs with complex or non web-based
  search interface
• DL specification generation not automatic
• DL behavior discovery still need to human
  intervene to find out if a DL change its
  searching and presenting mechanism
• Effective evaluation, measurement, usefulness
  testing

55
Conclusion and Future Works

• Federation service for non-cooperating DLs is
  possible
• Dynamic user-centered interface is practical to
  improve quality of service
• Locally harvested metadata improve service
  usability and performance
• Future works
• Complex interface mapping, access control
• Scalability, and performance
• Automatic specification generation
• DL behavior changes discovery
• Dynamic interface keyword relevance instead of
  hit (only user select that DL or DL has relevant
  results)
• Personalized portal customized interface and
  results displaying most often used search and
  remember search preference caching options for
  fresh data or fast results

56
Demo

• Steps http//www.cs.odu.edu/shi/interop/demo/doc
  /dissertation/demo/demo_steps.html
• Site http//128.82.7.868088/interop/demo/index.h
  tml
