Designing and Implementing RESTful Web Services with JAXRS

1
Designing and Implementing RESTful Web Services
with JAX-RS
Eben HewittBangaloreNovember 3-4, 2009
2
goals

• Understand principles of REST
• Survey RESTful tools and protocols
• Learn how to implement RESTful services with
  JAX-RS

3
who i am

• Architect at a multi-billion dollar, 50 year-old
  US retailer
• Speaker on SOA at JavaOne, others
• Interviewed on SOA by InfoQ
• Author of 5 books including Java SOA Cookbook
  (OReilly, 2009)
• Contributor to 97 Things Every Software Architect
  Should Know (OReilly, 2009)
• Other contributors include Gregor Hohpe, Bill de
  hÓra, Neal Ford, editor Richard Monson-Haefel.
• Many certifications in Java, Web Services, TOGAF
• I kitties

4
REST Overview

• REpresentational State Transfer
• http//www.ics.uci.edu/fielding/pubs/dissertation
  /top.htm (Fielding, 2000)
• Web Architecture
• Components user agent, intermediary, server,
  browser, spider, gateway
• Connectors HTTP, HTTPS, FTP
• Data URI referring to HTML, XML, RSS

5
REST is an architectural style

• WWW is based on these principles
• Starting from the null style, a set of
  constraints
• Separation of Concerns
• Statelessness
• Scalability
• Cacheable
• Reduce latency, reduce payload
• Uniform Interface
• Decouples, improves visibility, independently
  evolve
• Information Hiding
• Simplified clients, legacy encapsulation, load
  balancing
• Allow Code-on-Demand
• Applets, JavaScript

6
REST in a Nutshell

• REST services are built around Resources
• REST services are Stateless
• REST uses a Uniform Interface
• Resources are manipulated through Representations
• Messages are Self-Describing
• Hypermedia As The Engine Of Application State

7
Uniform Resources

• Resources are domain interests
• Universal Semantics
• Operations mean the same thing for every resource
  (GET, DELETE)
• All Resources are identified by a single
  mechanism (URI)
• Manipulate resources by exchanging Representations

8
Uniform Methods

• URI is sufficient for working with resources
• Dont need a separate Resource Description
  Language
• Intermediaries can take advantage of caching, can
  better anticipate behavior

9
Hypermedia as the Engine of Application State

• Responses are Representations
• They carry or point to current state of
  application
• They may contain links to transition to a new
  state
• No application state is kept on the server
• Hypertext doesnt need to be HTML in a browser

10
REST Noun (Resource) Oriented

• About resources
• The operations are standard via HTTP
• Resources can be cached, bookmarked, saved via
  standard mechanisms
• Customer
• http//example.com/customer/123
• http//example.com/order/555/customer
• POST, GET, DELETE

11
The Tipping Point

• March 1, 2005 Yahoo! Launches REST API
• On December 5, 2006, Google stopped accepting new
  signups for SOAPSearch
• Public REST APIs

12
Atom vs RSS

• Atom intended as a replacement for RSS, published
  under IETF
• Clarify ambiguities
• Unify
• Extend capabilities

13

• https//rome.dev.java.net
• Make it easy to work with RSS and Atom in Java
• Includes parsers and generators for a variety of
  feeds
• Get Java objects representing specific feed types
• Or, work normalized objects (SyndFeed)

14
Root Representations

• Publish a well-known root representation
• Dont require extensive documentation
• Let clients discover all others from this root
  (like index.html)
• Adds clarity for client-side library author
• Ensures only valid state transitions
• Cant Check Order until you have placed it

15
JAX-RS

• Java API for RESTful Web Services
• Helps developers quickly write RESTful
  applications
• API Expressed in Annotations
• To become part of Java EE 6

16
REST and SOAP

• With REST, the semantics are specified entirely
  by the URI
• The SOAP envelope is the beginning
• Its the extension point for a variety of specs
  (addressing, security, transactions, MTOM, WS-RM)

• With REST, the URI is the end

17
Orientation

• SOAP oriented around verbs
• (RPC, actions)
• REST oriented around nouns
• Resources

18
SOAP Verb (Operation) Oriented

• A SOAP interface defines verb/noun combinations,
  after RPC
• Its about a variety of operations
• addCustomer
• updateCustomerAddress
• getCustomer

19
JAX-RS
20
Resources

• In JAX-RS, a Resource is a POJO
• No interface to implement
• Just express the matching URI
• _at_Path
• The value is a relative path
• The base URI is provided by the either
• Deployment Context
• Parent Resource

21
JAX-RS Methods

• If your method returns void, JAX-RS returns a 204
  (successfully processed, no message body)
• Automatic encoding
• _at_Path("product list") is identical to
  _at_Path("product20list).

22
HTTP Methods
23
Hello Jersey!

• import javax.ws.rs.Path
• import javax.ws.rs.GET
• import javax.ws.rs.ProduceMime
• _at_Path("/helloRest")
• public class HelloRest
• _at_GET
• _at_ProduceMime("text/html")
• public String sayHello()
• return "lthtmlgtltbodygtlth1gtHello from
  Jersey!lt/bodygtlt/h1gtlt/htmlgt"

24
Modify web.xml to Use Adapter Servlet

• ltweb-app version"2.5" xmlns"http//java.sun.com/
  xml/ns/javaee"
• xmlnsxsi"http//www.w3.org/2001/XMLSchema-instan
  ce"
• xsischemaLocation"http//java.sun.com/xml/ns/jav
  aee
• http//java.sun.com/xml/ns/javaee/web-app_2_5.xsd"
  gt
• ltservletgt
• ltservlet-namegtServletAdaptorlt/servlet-namegt
• ltservlet-classgt
• com.sun.jersey.spi.container.servlet.ServletContai
  ner
• lt/servlet-classgt
• ltload-on-startupgt1lt/load-on-startupgt
• lt/servletgt
• ltservlet-mappinggt
• ltservlet-namegtServletAdaptorlt/servlet-namegt
• lturl-patterngt/resources/lt/url-patterngt
• lt/servlet-mappinggt

25
Uniform Interface

• Annotate methods
• _at_GET, _at_PUT, _at_POST, _at_DELETE, _at_HEAD
• JAX-RS forwards to correct method based on
  request method

26
URI Templates

• At class level, assign a Root Resource with _at_Path
• Dynamic resources assigned using
  _at_PathParam(paramName)
• Can use Regular Expressions to match
• _at_Path("products/ida-zA-Za-zA-Z_0-9"
• Non-matches return 404

27
URI Template Example

• _at_Path("/products/id")
• public class ProductResource
• _at_Context
• private UriInfo context
• / Creates a new instance of ProductResource /
• public ProductResource()
• _at_GET
• _at_ProduceMime("text/plain")
• public String getProduct(_at_PathParam("id") int
  productId)
• switch (productId)
• case 1 return "A Shiny New Bike"
• case 2 return "Big Wheel"
• case 3 return "Taser Toddler Edition"
• default return "No such product"

28
Variable Resources of the Same Type

• Map path elements using _at_PathParam
• _at_Path(customer/name")
• public class Customer
• _at_GET
• String get(_at_PathParam("name") String name)
• _at_PUT
• Void put(_at_PathParam(name) String name, String
  value)

29
Regular Expressions in URI Template

• _at_Path("/products/id \\d3")
• public class ProductResource
• public ProductResource()
• _at_GET
• _at_Produces("text/plain")
• public String getProductPlainText(_at_PathParam("id")
  int productId)
• return "Your Product is " productId
• //constrained to 3 digits
• http//localhost8080/jrs/resources/products/555
• works
• http//localhost8080/jrs/resources/products/7
• returns 404

30
Accessing Query Parameters

• Use _at_QueryParam on your method parameter
• Optionally include _at_DefaultValue
• _at_GET
• _at_Produces("text/xml")
• public String getProducts(
• _at_PathParam("id") int productId,
• _at_QueryParam("results")
• _at_DefaultValue("5") int numResults)
• ///resources/products?results3

31
Accessing Request Headers

• _at_GET public String doGet(_at_Context HttpHeaders
  headers)
• //list all incoming headers
• MultivaluedMapltString,Stringgt h
  headers.getRequestHeaders()
• for (String header h.keySet())
• System.out.println(header "" h.get(header))

32
Accessing Other Parameter Types

• _at_FormParam
• Extracts from a request representation of MIME
  media type "application/x-www-form-urlencoded"
  and conforms to the encoding specified by HTML
  forms
• _at_MatrixParam
• Extracts from URL path segments
• _at_HeaderParam
• _at_CookieParam

33
Representation Formats

• Identified by media type
• text/xml, application/json
• Content negotiation is automatically handled by
  JAX-RS
• Annotate with _at_Produces or _at_Consumes to indicate
  static content capabilities
• _at_Path("/emps")
• public class EmployeeService
• _at_GET
• _at_Path("id")
• _at_Produces("application/xml")
• public Employee getEmployee(_at_PathParam("id") int
  empId)
• return emps.get(empId)
• //this example uses JAXB on the Employee POJO for
  XML
• _at_XmlRootElement(name"employee")
• public class Employee id, name

34
Produces/Consumes

• _at_Produces
• Specify the MIME media types of representations a
  resource can produce and send back to the client.
• Applied at Class or Method level
• _at_Consumes
• Specify MIME media types of representations a
  resource can consume that were sent by the client
• Applied at Class or Method level
• One method can consume more than one media type

35
Building a Response

• ResponseBuilder allows you to create a response
  that contains metadata instead of, or in addition
  to, an entity
• String type new MimetypesFileTypeMap().getConten
  tType(image)
• return Response.ok(image, type).build()

36
Using JAXB to Provide XML View of Java

• byte
• java.lang.String
• java.io.InputStream
• java.io.Reader
• java.io.File
• javax.activation.DataSource
• javax.xml.transform.Source
• javax.xml.bind.JAXBElement and application-supplie
  d JAXB classes (used for XML media types only)
• MultivaluedMapltString, Stringgt for form content
  only (application/x-www-formurlencoded)
• StreamingOutput

37
Different Representations of a Resource

• Typical HTTP Accept Request Header
• Accept text/html,application/xhtmlxml,applicatio
  n/xmlq0.9,/q0.8
• Use HTTP Commons Client library
• private static void getXml()
• HttpClient client new HttpClient()
• GetMethod get new GetMethod(RESOURCE_URL)
• get.setRequestHeader("Accept", "text/xml")
• try
• int httpStatus client.executeMethod(get)
• if (HttpStatus.SC_OK httpStatus)
• String xmlResponse get.getResponseBodyAsSt
  ring()
• System.out.println("Xml Response "
  xmlResponse)
• //

38
Responses

• UriInfo get information about deployment
  context, request URI and the route to the
  resource
• UriBuilder helps you construct resource URIs

39
Getting a Parameter Map with UriInfo

• _at_GET public String get(
• _at_Context UriInfo ui)
• MultivaluedMapltString, Stringgt q
  ui.getQueryParameters()
• MultivaluedMapltString, Stringgt p
  ui.getPathParameters()

40
UriBuilder

• Makes it easy to build new URIs or from scratch.
• Methods to work with all parts of URI Path,
  Fragment, Matrix Param, query param, scheme
• To create sitefaq
• UriBuilder.fromPath("arg1").fragment(
• "arg2").build(site", faq")

41
Adding Metadata to Responses

• Response response Response.noContent()
• .header("MY_KEY", "MY_VALUE")
• .cacheControl(cacheCtl)
• .expires(expy)
• .language(Locale.ENGLISH)
• .type(MediaType.TEXT_HTML)
• .build()
• HTTP/1.1 204 No Content
• Server Apache-Coyote/1.1
• Cache-Control no-store, no-transform,
  must-revalidate, max-age500
• Expires Sat, 10 Oct 2009 164149 GMT
• MY_KEY MY_VALUE
• Content-Language en
• Date Sat, 08 Nov 2008 164149 GMT

42
Security

• Available via the SecurityContext from _at_Context
• Same as security in HttpServletRequest
• _at_Path(cart")
• public ShoppingBasketResource get(_at_Context
  SecurityContext sc)
• if(sc.isUserInRole(GoldMember")
• //

43
Implementations

• Jersey
• Restlet
• JBoss RESTEasy
• Apache CXF
• Triaxrs
• Apache Wink

44
thank you
