CELL STRUCTURE

1
CELL STRUCTURE FUNCTION
Dr. Michael C. Potter Department of Biology Paul
VI Catholic High School 2006
2
CELL STRUCTURE FUNCTION
HISTORY 1600S Anton van Leeuwenhoek 1665 Robe
rt Hooke 1838 Matthias Schleiden 1839 Theodor
Schwann 1855 Rudolph Virchow
3
CELL STRUCTURE FUNCTION
Anton van Leeuwenhoek
4
CELL STRUCTURE FUNCTION
Robert Hooke 1665
5
CELL STRUCTURE FUNCTION
Matthias Schleiden 1838
6
CELL STRUCTURE FUNCTION
Theodor Schwann 1839
7
CELL STRUCTURE FUNCTION
Rudolf Virchow 1855
8
CELL STRUCTURE FUNCTION

• CELL THEORY
• All living things are composed of cells
• Cells are the basic unit of structure
  function in living things
• New cells are produced from pre-existing cells

9
CELL STRUCTURE FUNCTION

• BASIC CELL STRUCTURE
• ALL CELLS HAVE
• Cell Membrane
• Cytosol

10
CELL STRUCTURE FUNCTION

• BASIC CELL STRUCTURE
• SOME CELLS HAVE
• Nucleus
• Cytoplasm

11
CELL STRUCTURE FUNCTION
CELL CATEGORIES EUKARYOTIC CELLS (Eukaryotes)
PROKARYOTIC CELLS (Prokaryotes)
12
CELL STRUCTURE FUNCTION
EUKARYOTES Contain nucleus Have Cell
Membrane Cytoplasm Organelles Plant, Animal,
Fungi, Many Microorganisms
13
CELL STRUCTURE FUNCTION
14
CELL STRUCTURE FUNCTION
15
CELL STRUCTURE FUNCTION
PROKARYOTES Smaller, Simpler Cells Cell
Membranes NO Nuclei ALL Bacteria are
Prokaryotes E. coli S. Aureus
16
CELL STRUCTURE FUNCTION
CELL SIZE Average Cell 5-50µm Surface Area
4pr2 Volume 4/3pr3 Cell Surface is interface
between internal and external environment

17
CELL STRUCTURE FUNCTION
18
CELL STRUCTURE FUNCTION
CELL STRUCTURES 1. CELL WALL Found in
Plants, Algae, Fungi and many
Prokaryotes Support Protection External
to Cell Membrane
19
CELL STRUCTURE FUNCTION
CELL STRUCTURES 1a. BACTERIAL CELL
WALL (peptidoglycan) CHARACTERISTICS Gram
Gram Encapsulated
20
CELL STRUCTURE FUNCTION
21
CELL STRUCTURE FUNCTION
22
CELL STRUCTURE FUNCTION
CELL STRUCTURES (contd) 1b. PLANT CELL
WALLS Primary Cellulose Green
Plants Secondary Lignin Woody Plants
23
CELL STRUCTURE FUNCTION
24
CELL STRUCTURE FUNCTION
CELL STRUCTURES (contd) 2. NUCLEUS Robert
Brown (1831) Chromatin/Chromosome Nucleoplasm
Nucleolus Nuclear Envelope
25
CELL STRUCTURE FUNCTION
Browns Microscope Robert Brown
26
CELL STRUCTURE FUNCTION
27
CELL STRUCTURE FUNCTION
28
CELL STRUCTURE FUNCTION
29
CELL STRUCTURE FUNCTION
30
CELL STRUCTURE FUNCTION
31
CELL STRUCTURE FUNCTION
CELL STRUCTURES (contd) 3. CYTOSKELETON a.
Microtubules- 25 nanometers Heterodimers of a
and ß tubulin MTOC ? tubulin
32
CELL STRUCTURE FUNCTION
33
CELL STRUCTURE FUNCTION
CELL STRUCTURES (contd) 3. CYTOSKELETON
Microtubules Plus End () Away from MTOC
(Toward Nucleus) Minus End (-)
Toward the MTOC
34
CELL STRUCTURE FUNCTION
35
CELL STRUCTURE FUNCTION
CELL STRUCTURES (contd) 3. Cytoskeleton
Microtubules Structural Role Movement of
Chromosomes Act as Tracks Structural
Component Of Cilia and Flagella
36
CELL STRUCTURE FUNCTION
37
CELL STRUCTURE FUNCTION
38
CELL STRUCTURE FUNCTION
39
CELL STRUCTURE FUNCTION
40
CELL STRUCTURE FUNCTION
INTRACELLULAR MOLECULAR MOTORS KINESIN Move
Organelles toward () end Kinectin DYNEIN M
ove Organelles toward (-) end Dynactin
Retrograde Transport
41
CELL STRUCTURE FUNCTION
42
CELL STRUCTURE FUNCTION
43
CELL STRUCTURE FUNCTION
b. Microfilaments (Actin) Long, thin fibers
(7nm) String of Pearls Concentrated in
Cortex Amoeboid Motion
44
CELL STRUCTURE FUNCTION
Microfilament Function Anchor Cytoskeleton
to cell membrane Determine consistency of
cytoplasm Interact with Myosin
45
CELL STRUCTURE FUNCTION
46
CELL STRUCTURE FUNCTION
47
CELL STRUCTURE FUNCTION
48
CELL STRUCTURE FUNCTION
49
CELL STRUCTURE FUNCTION
c. Intermediate Filaments 8-10 nm
diameter Most durable Rope-like
Structure Provide Structural Stability
(vimentin)
50
CELL STRUCTURE FUNCTION
Function of Intermed. Filaments Strengthen
Cell Stabilize Position organelles Stabilize
cell relative to other cells
51
CELL STRUCTURE FUNCTION
Proteins Associated with Int. Filaments a.
Lamins b. Desmins c. Vimentins d.
Cytokeratins
52
CELL STRUCTURE FUNCTION
Proteins of Intermed. Filaments e. Actin f.
Myosin
53
CELL STRUCTURE FUNCTION
54
CELL STRUCTURE FUNCTION
CELL MOVEMENT 1. Crawling Actin/Myosin Ge
l-Sol States Pseudopod Formation
55
CELL STRUCTURE FUNCTION
56
CELL STRUCTURE FUNCTION
Amoeba
57
CELL STRUCTURE FUNCTION
58
CELL STRUCTURE FUNCTION
59
CELL STRUCTURE FUNCTION
CELL MOVEMENT 2. Pinching Actin
filaments Animal cells Cytokinesis
60
CELL STRUCTURE FUNCTION
Cytokinesis of Animal Cell
61
CELL STRUCTURE FUNCTION
Actin filament causing cell separation
62
CELL STRUCTURE FUNCTION
CELL MOVEMENT 3. Prokaryote Flagella Protein
Structure (flagellin) Rotatory
Movement Molecular motor in cell wall Basal
Apparatus Hook Filament
63
CELL STRUCTURE FUNCTION
64
CELL STRUCTURE FUNCTION
65
CELL STRUCTURE FUNCTION
CELL MOVEMENT 4. Eukaryote Flagella Microtubul
ar Structure 92 Arrangement Basal Body
Origin 9 triplet structure Whip-like
motion
66
CELL STRUCTURE FUNCTION
92 arrangement microtubules
67
CELL STRUCTURE FUNCTION
68
CELL STRUCTURE FUNCTION
69
CELL STRUCTURE FUNCTION
CELL MOVEMENT 5. Cilia Short, often in
rows Multiple Internal structure of
flagella Multiple functions
70
CELL STRUCTURE FUNCTION
Structure Of Cilia
71
CELL STRUCTURE FUNCTION
Cilia of Unicellular Protist
72
CELL STRUCTURE FUNCTION
Function of cilia in Hearing
73
CELL STRUCTURE FUNCTION
Cilia present in lining of trachea
74
CELL STRUCTURE FUNCTION
Ciliated Protist
75
CELL STRUCTURE FUNCTION
Ciliated Protist with Food Vacuole
76
CELL STRUCTURE FUNCTION
