Tutorial:IS 11179 Part 3 Basic attributes of data elements

1
TutorialIS 11179 Part 3 Basic attributes of
data elements

• Joe Christensen
• Head, National Information Development Unit
• Australian Institute of Health and Welfare

2
Part 3 Basic attributes of data elements
Defines a set of basic attributes for specifying
data elements A number of attributes have to be
specified to facilitate a common understanding
between users and owners
3
Part 3 Basic attributes of data elements

• Defines a set of basic attributes for specifying
  data elements
• A number of attributes have to be specified to
  facilitate a common understanding between users
  and owners

4
Uses

• the definition, specification and contents of
  data element dictionaries
• the design and specification of
  application-oriented data models, databases and
  message types for data interchange
• the actual use of data in communications and
  information processing systems
• interchanging or referencing among various
  collections of data elements.

5
Definitions
General descriptors Descriptors that enable
data elements to be registered and controlled in
a standard way - in order to achieve
consistency in the exchange of information on
data elements among data element
dictionaries - to enable the comparison of data
elements used in different data management
environments. Basic attributes A
specification of a data element consists of a set
of attributes. Part 3 of the International
Standard specifies a set of basic attributes.
6
General descriptors
descriptor of attribute obligation -
name M - definition M - obligation
M - condition C - maximum occurrence
O - datatype M - maximum size O -
character set C - language C - comment
O
7
Category Attribute obligation
________________________________________________
______________________ Identifying - Name
M - Identifier C - Version C -
Registration Authority C - Synonymous
name O - Context C _____________________
_________________________________________________
Definitional - Definition M
________________________________________________
______________________ Relational -
Classification scheme O - Keyword(s) O -
Related data reference O - Type of
relationship C ________________________________
______________________________________ Represen
tational - - Representation category M -
Form of representation M - Datatype of data
element values M - Maximum size of data
element value M - Minimum size of data element
value M - Layout of representation C -
Permissible data element values M ______________
__________________________________________________
______ Administrative - Responsible
organization O - Registration status C -
Submitting organization O - Comments O
8
Obligations

• mandatory always required
• conditional required to be present under certain
  specified conditions
• optional allowed but not required.(in context
  of your data of your own registry)

9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
Categories of basic attributes

• Identifying
• Relational
• Representational
• Administrative

• Attributes that are applicable for the
  identification of a data element.
• Attributes that describe associations among data
  elements and/or associations between data
  elements and classification schemes, data element
  concepts, objects, entities.
• Attributes that describe associations among data
  elements and/or associations between data
  elements and classification schemes, data element
  concepts, objects, entities.
• Attributes that describe management and control
  aspects of a data element.
