Linear Collider TPC R

1
Linear Collider TPC R D

• A sampling of this work by Ron Settles

2
Goal

• To design and build an ultra-high performance
• Time Projection Chamber
• as central tracker for the LC detector
• where excellent vertex, momentum and
• jet energy precision are wanted

3
LDC
4
GLD
TPC
5
The basic idea

• Cost-effective way of instrumenting a large
  volume
• With continuous tracking and a minimum of
  material
• Want the largest possible granularity
• -- i.e. 2 .109 voxels
• -- the best possible spoint resolution
• -- the best possible 2-track resolution

6
Why

• High granularity to ensure robust operation in
  presence of large backgrounds
• Continuous tracking to ensure good
  momentum-measuring precision and gt98
  pattern-recognition eff. in jets

7
ILC-TPC
A Large, High precision, High 3-D granularity
Time Projection Chamber operated
under a high magnetic field of 3 4 T

Unprecedented requirements to TPC especially for
granularity ? use of micro
pattern gas detector (MPGD) as a readout device
?
performance tests using prototypes
8
LCTPC/LP Groups (16 August 06)
Americas Carleton Montreal Victoria Cornell Indi
ana LBNL MIT Purdue Yale
Europe LAL Orsay IPN Orsay Saclay Aachen Bonn DES
Y UHamburg Freiburg Karlsruhe MPI-Munich Rostock S
iegen NIKHEF UMM Krakow Bucharest Novosibirsk PNPI
StPetersburg Lund CERN
Asia Tsinghua CDC Hiroshima KEK Kinki
U Saga Kogakuin Tokyo UAT U Tokyo U
Tsukuba Minadano SU-IIT
Other groups interested?
9
Examples of Prototype TPCs
Carleton, Aachen, Cornell/Purdue,Desy(n.s.) for
B0or1T studies Saclay, Victoria, Desy (fit in
2-5T magnets) Karlsruhe, MPI/Asia, Aachen built
test TPCs for magnets (not shown), other groups
built small special-study chambers
10
MPI-Munich prototype for Wires, Gem and
Micromegas test in 5T at Desyand in 1T in beam
at Kek
11
MWPC

• Very

12
Replace sensor (wire) gitter previous slide by
either GEM or Micromegas
GEM Two copper perforated foils separated by an
insulator The multiplication takes place in the
holes. Usually used in 2 or 3 stages
Micromegas a micromesh sustained by 50-100 mm -
high insulating pillars. The multiplication
takes place between the anode and the mesh One
stage

• Very

200 mm
13
GEM and Micromegas
S1/S2 Eamplif / Edrift
14
Due to the high value of wt and the low grid
transparency, does it work in a magnetic field?
-gt Simulations in Aachen
15
Prototype TPC
Field cage maximum drift length 260 mm
typical cathode H.V. - 6 kV
Readout plane effective area 100 mm100
mm MWPC GEMs
(3-stage) or
MicroMEGAS
16
Experimental setup
We have conducted a series of beam experiments at
KEK PS.

• Beam mostly 4 GeV/c pions (0.5-4 GeV/c hadrons
  electrons)
• Magnet super conducting solenoid
• without return yoke (max
  field 1.2 T)

KEK p2 Beam Line
JECCEE inner diameter 850 mm effective
length 1 m
17
Readout scheme and Gas
ALEPH TPC Electronics charge sensitive
preamp. shaper amp. (shaping time 500 ns)

digitizer (time bucket 80
nsec)
