Diapositiva 1

1
Laboratorio Subterráneo de Canfranc IN2P3 -
MICINN meeting Madrid, 12 January 2009
http//www.lsc-canfranc.es/
2
Map of LSC
3
Experimental halls A, B and C
600 m2 (40x15x12)
Hall A
150 m2 (15x10x7)
Hall B
Depth 800 m
Muons 0.47 m x 10-2 m m-2 s-1
Hall C
Ventilation 11.000 m3/h
4
Status of the reparation works

• January 2007 Signs of rocks instability
• March 2007 Rock fall in hall A
• August 2007 End of short range consolidation
  works (UZ)
• January 2008 Agreement on the project for
  safety improvement works
• February 2008 UZ sends project to GA for
  supervision
• July 2008 LSC Director requests to UZ,
  including
• Report on the status of the reparation works as
  done, and convergence measurements
• Programme of the future works including
  organisation, milestones and times
• December 2008 GA sends final supervision to UZ

5
Objectives
Create a world-class underground
multi-disciplinary laboratory with experiments
and observatories leading in

• Dark matter searches
• Neutrino nature (Majorana vs. Dirac) and mass
• Nuclear astrophysics
• Physics of system near absolute zero
• Extreme low background techniques
• Sub-surface geo-dynamics
• Environmental ultra-low background studies
• Life under extreme conditions

Consider options for long range development
(LAGUNA)
21/11/2009
A. Bettini. LSC
5
6
External building
Headquarters Administration Safety and Quality
Assurance 16 offices for scientific users 7
offices for LSC personnel 4 specialised
laboratories Mechanical workshop storage
room Meeting room Library Conference
room Exhibitions room 2 apartments
Surface 1.821 m2 (2.115 m2 built) Project
completed December 2008 Building completed
Autumn 2010 Cost of the building
2.830.403,27
7
Structures
Managed by 14 staff
8
Scientific ProgrammePhysics

• - Approved experiments on proposal of the
  International Scientific Committee.
• 3 years running. Milestones defined. Two referees
  appointed to each exp
• EXP-01-2008 (ANAIS) Dark Matter (NaI, Annual
  modulation)
• Direct check of DAMA/LIBRA result
• EXP-02-2008 (ROSEBUD) Dark Matter (Scintillating
  bolometers)
• Integrated in the European EURECA project
• EXP-03-2008 (BiPo) 0??? decay (extra-low surface
  background meas.)
• Ancillary to Super-NEMO
• EXP-04-2008 (ULTIMA) Super-fluid 3He physics
• To be screened by muon background
• EXP-05-2008 (NEXT) 0??? decay (Enriched 136Xe
  TPC)
• Majorana vs Dirac neutrinos
• CUP Consolider approved
• EoI-02-2005 (ArDM) EoI on Dark Matter (Liquid
  Argon TPC)
• In risk analysis phase

9
Dark Matter

• 95 of the Universe mass-energy is dark
• Status of the art. Calorimetric approach target
  of dark particles detector
• sensitive detector mass M several kg
• best background bO(103 kg1keV1 d1)
• To explore theoretical range need MO(1t) and bO
  (105 kg1keV1 d1)
• This levels may be reached in the next few years
  by noble liquids
• 10-100 kg Xe and Ar modules operational / under
  construction at LNGS
• Xe and Ar complementary, both in physics and
  technique. Both should be done
• Do not forget other techniques. Hunting for dark
  matter is extremely difficult
• Strong competition world wide
• DAMA positive evidence can be confirmed/rejected
  only by an annual modulation sensitive experiment
  with Iodine nuclei

10
EXP-01-2008 ANAIS
Search for the annual modulation Confirm/refute
DAMA evidence
Work on a series of prototype performed in the
old LSC using 14?10.7 kg NaI crystals stored
underground since 1988

• Contribution to background of internal
  contamination at 2-6 keV
• UTh lt 1/ (keV kg d) OK
• 40K several/(keV kg d) too large
• New crystals required
• Funded about 100 kg by MCINN Program
• Additional NaI procurementwith LSC funding under
  examination

11
EXP-02-2008 ROSEBUD
Develop cryogenic temperatures bolometers with
heat and scintillation light readout, focussing
on prototypes for EURECA (next-generation
European project for DM search with bolometers)
12
EoI-02-2005 ArDM
Ar two-phase TPC Tests on 1 t prototype going on
at CERN Preliminary LSC risk analysis stage
13
Neutrino-less Double beta decay

• Unlike the other particles neutrinos may be
  matter and antimatter at the same time
• Two approaches calorimetric and tracking
• Status of the art of calorimetric approach (two
  experiments _at_ LNGS)
• Exposure O (100 kg yr)
• Background bO(102 kg1keV1 y1)
• Complementary tracking approach necessary, on
  different isotopes, with similar sensitive masses
• Due to limited overburden of LSC ? tracking
  approach (calorimetry already covered by CUORE
  and GERDA)
• SuperNEMO _at_ 100 kg does not fit in LSC
• Extrapolates NEMO3 technology. However, much RD
  needed
• First steps BiPo and its prototypes
• Liquid Xe TPC. EXO 200 kg in the US
• Gas TPC with novel RD techniques
• Much RD needed. NEXT

14
EXP-03-2008 BiPo
?EFWHM/E _at_ 1MeV NEMO3 14-17 Best prototype so
far 8 Design figure 4 _at_3 MeV
Contamination of the (large) source foil BiPo
detectors for requested sensitivity 208Tl lt 20
µBq/kg ? lt2 µBq/kg 214Bi lt 300 µBq/kg ? lt10
µBq/kg
15
The ultimate background 2b?n
Case of 136Xe assuming T1/2(????)?1021 (measured
lower limit)
High pressure TPC Strong RD effort needed
EXO achieved
16
EXP-05-2008 NEXT

• High pressure gas TPC with enriched 136Xe
  Complementary to EXO
• Status. Initial RD phases. CUP Consolider
  (mainly NEXT) approved (5 M)
• Avoid charged background from surfaces by
  eliminating surfaces, based on 100 active,
  completely closed virtual fiducial surface
• Obtain fine topological information (unlike EXO)
• Tag signal by topology 2 balls at the end of the
  spaghetti
• Expected reduction of (dominant) gamma background
  gt 100
• FWHM resolution O(1) appears feasible with
  latest TPC R/O techniques
• Montecarlo evaluation of the tolerable
  radioactive contaminants in materials screening
  starting now

17
EXP-04-2008 ULTIMA100 µK superfluid 3He detector
Density of quasi-particles determined directly by
measuring the damping of micro vibrating wire
Originally proposed for dark matter direct search
via spin-dependent coupling Detector sensitive
mass very small (grams) The super-fluid phase of
the 3He-4He mixture might be observable at these
temperatures Signal is confused by cosmic muons
interference on the surface
18
Possible location of the experiments
Laboratory space is almost full
19
Strategic Plan 2010-2013

• Due by all the Spanish ICCs by 31/12/2008
• Built on the basis of the approved multi-annual
  LSC funding
• Invest in infrastructures residuals 2006-2008
• To be presented tomorrow

20
Scientific ProgrammeGeodynamics, Environment

• - Presented at the Scientific Committee,
  preliminary stage of discussion
• Canfranc Nuclear Astrophysics facility (CUNA)
• New dedicated hall Accelerator (5 MeV, to be
  funded separately)
• Develop synergic program with INFN LNGS
• Dedicated scientific Workshop in Barcelona 19-20
  Feb 2009
• Geodynamic facility (GEODYN)
• Integrate in the TOPO-IBERIA Consolider
• Integrate with LSC rock stability monitors
• Ultra-Low Level Lab for Environmental
  Radioactivity Monitoring (ULLERM)
• Groundwater, rainwater, air (inside outside)
  and soil characterisation
• Integrate in the general purpose
  ultra-low-background service

21
The astrophysical S-factor
Extrapolations by orders of magnitude not always
safe (resonances)
22
CUNA

• First Laboratory for Nuclear Underground
  Astrophysics (LUNA) at INFN LNGS. 1995..
• LUNA1 50 kV LUNA2 400 kV
• Beautiful measurements of the cross sections of
  nuclear reactions relevant for the Sun and stars
  d(p,?)3He, 3He(???)7Be, 14N(p,?)15O,
  25Mg(p,?)26Al
• Many other cross sections await for measurement
• 12C(???)16O, 13C(??n)16O, 22Ne(??n)25Mg
• (??n) on 15N, 14N, 18O
• Next phase requires higher energy (3-5 MeV)
  accelerator
• Needs separate hall due to neutron production
• LUNA3 proposal at LNGS 3-4 MeV
• Develop European program with two complementary
  sources
• Build a dedicated hall and associated facilities
  at LSC

23
GEODYN

• LSC is located underground in one of the most
  seismically active areas in Europe
• Ideal position for an advanced geodynamic
  observatory with
• two perpendicular LASER strainmeters
• borad-band and strong motion seismometers
• CGPS stations on the surface
• Integrate in the TOPO-IBERIA Consolider project
• Local phenomena
• measure seismic phase velocity
• Slow earthquakes
• Strain seasonal changes (charging and discharging
  of the aquifer,..)
• Tectonic deformation
• Global phenomena
• Siesmic core modes
• Free oscillations of the Earth
• Free core nutation

24
GIGS. Fast and slow quakes
Local normal quakes
1.5 µm
Michelson interferometer with asymmetric arms.
Longer one is 90 m
Quake at Giava superposed to a slow local quake
Slow (aseismic) quake
0.5 µm
25
Dark Life

• Microbiology
• How deeply in the earth does life extend?
• What makes life successful deep under the
  surface?
• What can life underground teach us about how life
  evolved?
• Status of art. Studies made by Henderson DUSEL
  project in US
• 2 new Phyla discovered at Henderson
• Cross-disciplinary work between biologists and
  geologists
• Do bacteria enter into the genesis of minerals
  and rocks?

No proposal yet
26
Thank you
