My Business GPS powered by TOC Engine'

1
My Business GPS powered by TOC Engine.
Reliable and focussed decision support in my
(complex) business environments.
2
My Business GPS
My GPS supports my decisions

• Planning
• Goal
• Position
• The best route
• Time estimation

• Execution
• Current Position
• Traffic-information
• Warnings of critical points
• New estimated arrival time

3
My Decision Tools
OUR ORGANISATION Operational Constraints
MARKET Market constraints
SUPPLY CHAIN Supply constraints
GPS4 Marketing Sales
GPS4OPERATIONS
GPS4PROJECTS
My Business GPS
The real challenge Be beter/faster than my
competitor..
4
OPERATIONS
OUR ORGANISATION Operational Constraints
MARKET Market constraints
SUPPLY CHAIN Supply constraints
GPS4OPERATIONS
GPS4 Marketing Sales
GPS4PROJECTS
My Business GPS
A complex and crucial part of my
business OPERATIONS!
5
GPS4Operations
My GPS for Operations also integrates the current
techniques like

Lean Elimination of waste 6 Sigma Measure
and improve. TOC THE ENGINE
6
GPS4Operations
Operational planning I make my commitment to
my customer. I have to commit on a reliable due
date, while taking into account Limited
resources, (people, machines) Limited money and
inventories Limited time Complex environment
interfering with internal and external
constraints.
7
GPS4Operations

• Execution.
• Current position gt Not always as planned.
• Too late start waiting for suppliers,
  customer-info...
• Traffic and queue information gt Bottlenecks.
• Queues at the critical resources.
• Warnings
• What is next? What priority? - How urgent.
• New estimated time of arrival. gt What is my
  probability for on-time delivery?
• Do I still have enough buffer?

8
GPS4Operations

• OK, Now we have
• Planning
• Execution
• Is this sufficient to be and to stay in a good
  competitive position? HOW to improve ?

Income
Expenses
How do I secure the profit growth?
9
GPS4Operations
Is this sufficient to be and to stay in a good
competitive position? HOW to improve ?
Income
Expenses
Profit Growth is not happening by luck, it is the
effect of well secured and on-going PROCESS.
10
The Money - flow
SALES (paid invoices)
Purchase
Throughput
OUR ORGANISATION Operational Constraints
Vendors Vendor constraints
MARKET Market constraints
OE Operating Expenses
How do I secure the profit growth?
Profit
OE
11
GPS4Operations
OUR ORGANISATION Operational Constraints
How do I secure the operational profit growth
while having so many operational constraints?
12
SYSTEM APPROACH TO IMPROVEMENT
Fact/ Very Few factors govern the performance of
the Physical and Logical parts of a system at any
point in time (the law of the weakest link
significant few)
Physical View of System
Logical View of System
Effect
Effect
Effect
Flow of Cause-Effect ?
Effect
Effect
20
12
15
16
10
Weakest Link
Cause
Root Cause
Flow of Goal units ?
The TOC- System approach should assist my
management to find the few physical and logical
leverage point(s) of the system (organisation)
where an improvement can cause a quantum
improvement for the system as a whole. I do
not want my managers to waste precious management
time and money in chasing symptoms.
13
Those nice TOC-techniques are now embedded in
MyGPS4Operations! BUT...A different vehicles
needs different GPS-options ...
GPS4Operations
In the same way my specific environment will need
different GPS4Operations options.
14
GPS4OperationsOptions

• .

• .
• CDS DBR (Make To Order)

. 2. CDS Make to Stock Replenishment .
. 3. Combined Make to Stock Make to Order
4. Combined Critical Chain DBR (Single pieces
Project type)
15
CDS The Main modules

• .
• Manufacturing Logistical database. Can be used
  as the backbone for your operations or can be
  interfaced with the availbale ERP data.
• 2. Replenishment logic. High sevice levels with
  optimized inventory management. Reliable VMI
  support!
• 3. Master Schedule. (Capacity driven). The basis
  for commitment to your customer and for planning
  internal and external ressources and supplies.
• 4. Execution Buffermanagement and
  sequencing.Flexibel priority system and detailed
  sequencing of all the resources and supplies.
• 5. POOGI Process Of On-Going Improvement.
• Corrective actions, perfomance measurements and
  improvements

CDS Database
.
16
1. Manufacturing Logistical database

• Creation Updates - Maintenance Consistency
  checks on
• Product data including stock-keeping and
  logistical parameters
• Bill Of Material Routing structure.
• Resource definitions maintenance.
• Calendars global and per resource.
• Orders Customer orders and prodcution/stock
  orders.
• Template architecture facilitates automatic
  creation.
• Active structure can be adapted on-the-fly.
• Includes facilites for sub-contracting and
  material management.

CDS Database
17
1. Manufacturing Logistical Database Common
Modules

• Creation Updates Maintenance.
• All the data and structures needed for the
  manufacturing and logistical database can be
  obtained by direct Input or by download or
  up-to-date refresh from your main ERP.

CDS Database

• Oracle and SQL Server compatible.
• Specific interfaces. (like AS-400, SAP, Navision)
• Web interfaces.

Multi user client/ server applications. User
administration. Customization to your needs.
Company Database
18
1. Manufacturing Logistical Database Options
CDS Database
19
1. Manufacturing Logistical Database Common
Modules

• Creation Updates Maintenance.
• Product data
• Generic and extended data fields.
• Logical checks Product families and LT
  classes etc.
• Resource definitions maintenance.
• Internal and external resources
• Link to specific calendar (shifts)
• Default setting (drum)
• Calendars
• Global and per resource

20
1. Manufacturing Logistical Database Common
Modules

• Creation Updates Maintenance.
• Bill Of Material
• Parent-component relations by drag-and-drop
  feature.
• Unlimited number of levels Assemblies
• Units/per Material needs - Scrap calculation
• Routing structure. (Including BOM)
• Creation by drag-and-drop feature.
• Coherence checks on items, resources, duplicates.
• Timing as pcs/hr or min/pc or time per batch..
• Set-up default or individual.
• Links with suppliers and sub-contractors.

21
2. Single Piece Project Logic

• A different environment needs a different GPS!
• Engineering
• Projects
• Prototyping
• Single piece mfg.
• Small series

Critical Chain!
22
2. Single Piece Project Logic

• The combination of all the advantages of the
  Critical Chain logic with DBR resource
  scheduling.
• Transformation of regular BOM Routing into
  Critical Chain logic.
• Calculation and positioning of the project buffer
  and feeding buffers.
• Build in checks with requested lead-time.
• Capacity checks on critical resources and drum
  algorithm.
• Full buffer management that supports execution
  schedules.

23
3. Make to Stock Logic

• A different environment needs a different GPS!
• Finished goods inventories
• Raw materials availability
• Intermediate stocks
• Vendor Managed Inventories

24
3. Replenishment Logic

• Based on the TOC- replenishment technique.
  More...

• High sevice levels with optimized inventory
  management. Reliable VMI support!

• Dynamic replenishment levels.
• Suggested or automated correction of the
  replenishment and alarm levels.
• Pro-active warnings and priorities.
• Risk analysis.

25
3. Replenishment Logic



Selective alarms on suggested productions. priorit
ies - risks proposed quantities.
Detail per item.
The best view on reality for understanding the
requests, the alarms and the suggestions.
The stock transactions and the complete history
26
3. Replenishment Logic

• The global inventory value (expressed in units or
  ) is permanently monitored within a selectable
  time window.


27
3. Replenishment Logic


• FOCUSSING on the right priorities.
•  .
• The calculation for replenishing the stock from
  production or supplier of by shipping from
  another warehouse, is taking in account
•
• The inventory on-hand.
• The inventory under way. (or in WIP for
  production)
• The lead-time for transport.
• The lead-time for production.
• The minimum order quantity.Priorities
• The packing quantity.



Priorities

28
4. Master Schedule

• The objective Do promise what you can deliver.
• Feasibility check
• Is the customers date far enough to meet our
  regular lead-time?
• Will we have the necessary capacity at that
  moment?
• What is the impact on other (already commited on)
  orders IF we take this additional one?
• Do we have all the necessary components? In
  stock/ or deliverd on-time?
• Do we have enough protection??
• COMMIT after checking keep your promises keep
  the protection on your side!

29
4. Master Schedule

• The objective Do promise what you can deliver.
• Is the customers date far enough to meet our
  regular lead-time, taking in account the complete
  process?

OR...
30
4. Master Schedule

• The objective Do promise what you can deliver.
• Will we have the necessary capacity on the
  critical resource at that moment?

Our critical resource is loaded to 98!
No regular gap before Nov 26 !
31
4. Master Schedule

• The objective Do promise what you can deliver.
• What is the impact on other (already commited on)
  orders IF we push this additional one earlier?

32
4. Master Schedule

• The objective Do promise what you can deliver.
• Do we have enough protection??

33
4. Master Schedule
The objective Do promise what you can deliver.
COMMIT after checking keep your promises
keep the protection on your side!
34
5. Execution

• The objective Execute what you promised.
• .
• The Launching dilemma
• Too early gt High WIP and Stocks.
• Difficult to comply with last minute changes.
• Too late gt Delivery risks.
• gt Urgencies, additional costs...

35
5. Execution
The objective Execute what you promised. Do not
launch too early
36
5. Execution
The objective Execute what you promised. .Do not
launch too late
Pragmatic risk management! The more buffer
penetration gt the higher the priority
37
5. Execution
The objective Execute what you promised. Keep
the global chain synchronized!
My department
My responsibility
Coherent priorities through the global
organization
38
6. POOGI Process Of On-Going Improvement.
The objective Do not waste time and money by
solving the symptoms!
Physical View of System
Logical View of System
Effect
Effect
Effect
Flow of Cause-Effect ?
Effect
Effect
20
12
15
16
10
Weakest Link
Cause
Root Cause
Flow of Goal units ?

• The embedded mechanisms for identifying the core
  problems is transforming data into information!!!
• Objective quantified information.
• Automaticcaly generated.

39
6. POOGI

• The embedded mechanisms for identifying the core
  problems is transforming data into information!
• Inputs from daily operational problems
• Detected by buffermanagement.
• Supported by structured operational
  cause-reporting.
• Measuring the operational damage.
• (Late deliveries, lost Throughput excess
  expenses)

40
6. POOGI

• The embedded mechanisms for identifying the core
  problems is transforming data into information!
• 6 sigma analysis and S-curves are automatiqualy
  generated for
• Warnings of process-deteriorations
• Monitoring of the improvements
• Revealing available flexilibity and identifying
  the leaning possibilities.
• Identifying the most powerful leverage points !

41
6. POOGI
The embedded mechanisms for identifying the core
problems is transforming data into
information! It is a powerful decision-tool for
supporting your organization in managing the
profit improvement process.
42

• For implementation you can rely on
• Certified Application Experts Audit by TOC-Sr
  TOC- Experts
• Direct link to the Goldratt WW- network, which
  guarantees on-going update and and new
  developments.
• 20 years of local experience.
• www. goldratt.be
• www.gig-europe.eu
