Title: Local Area Networks Yerel Alan Aglari


1
Local Area Networks(Yerel Alan Aglari)
2
Network classification
  • Local Area Networks (Yerel Alan Aglari)
  • Room, building, campus
  • Metropolitan Area Networks (Metropol Alan Aglari)
  • City cable TV
  • Wide Area Networks (Genis Alan Aglari)
  • Country, continent

3
Network topologies
  • Mesh (Örgü)
  • Star (Yildiz)

Fully connected mesh topology contains N(N-1)/2
connections between nodes
All communication passes through Central node
4
Network Topologies
  • Ring (Halka)
  • Tree (Agaç)

One path between two nodes
Whose turn is it to transmit?
5
Network Topologies
  • Bus (Veriyolu)

Broadcast
6
Multiple Access Protocols
  • ALOHA
  • Carrier Sense Multiple Access Protocols
  • Collision-Free Protocols
  • Limited-Contention Protocols
  • Wavelength Division Multiple Access Protocols
  • Wireless LAN Protocols

7
Pure ALOHA
  • In pure ALOHA, frames are transmitted at
    completely arbitrary times.

8
Pure ALOHA (2)
  • Vulnerable period for the shaded frame.

9
Pure ALOHA (3)
  • Throughput versus offered traffic for ALOHA
    systems.

10
Persistent and Nonpersistent CSMA
  • Comparison of the channel utilization versus load
    for various random access protocols.

11
Ethernet (IEEE 802.3)
  • Ethernet Cabling
  • Manchester Encoding
  • The Ethernet MAC Sublayer Protocol
  • The Binary Exponential Backoff Algorithm
  • Ethernet Performance
  • Switched Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
  • IEEE 802.2 Logical Link Control
  • Retrospective on Ethernet

12
Ethernet Cabling
  • The most common kinds of Ethernet cabling.

13
Ethernet Cabling (2)
  • Three kinds of Ethernet cabling.
  • (a) 10Base5, (b) 10Base2, (c) 10Base-T.

10Base5 Vampire tap
10Base2 Passive T junction
10BaseT Hub (kablo göbegi)
14
Ethernet Cabling (3)
  • Cable topologies. (a) Linear, (b) Spine, (c)
    Tree, (d) Segmented.

Single pathgtNo interference
15
Encoding types
  • Unipolar
  • One nonzero voltage level for 1 bit
  • Polar
  • One positive, one negative voltage level
  • NRZ (Non return to zero)
  • NRZ-L ve stands for 0 bit, -ve for 1 bit
  • NRZ-I Voltage inversion indicates 1 bit
  • RZ (Return to zero)
  • ve to zero transition indicates 1 bit, -ve to
    zero indicates 0 bit
  • Manchester high to low transition indicates 1
    bit, low to high indicates 0 bit - Enables better
    synchronization
  • Differential Manchester transition indicates 0
    bit, lack of transition indicates 1 bit Better
    noise immunity
  • Bipolar
  • Zero voltage for 0 bit, alternating ve and ve
    voltages for 1 bits

16
Ethernet Cabling (4)
  • (a) Binary encoding, (b) Manchester encoding,
    (c) Differential Manchester encoding.

17
Ethernet MAC Sublayer Protocol
  • Frame formats. (a) DIX Ethernet, (b) IEEE 802.3.

Preamble (64 bits) 10101010....10101010 for
synchronization Destination address 1 in MSB
indicates multicast, all 1s indicates
broadcast Half of the addresses are local, the
other half are global
18
Ethernet MAC Sublayer Protocol (2)
Minimum frame length should be So that
transmitter has not finished transmission by the
time noise burst generated by B arrives at A
19
CSMA/CD
  • At time 0 A senses the channel as empty and sends
    out a frame
  • Packet propagates
  • Before As packet arrives at B, B senses the
    channel as empty and sends out its own frame
  • Collision occurs
  • B receives more power than it sent out, transmits
    a noise burst to jam channel
  • A detects collision after it sent out
    first bit and aborts transmission.
  • Both A and B apply binary exponential backoff to
    repeat transmission

20
Typical calculation
  • 500mx5segments2500 meters distance between two
    ends
  • 50 roundtrip propagation time
  • 10Mbps Ethernet gt frame sizegt 500bits
  • Rounded to 512bits64bytes
  • 1Gbps Ethernet,2.5kmgtframe sizegt6400bytes
  • 1Gbps Ethernet,0.25kmgtframe sizegt640bytes

21
CSMA with Collision Detection
  • CSMA/CD can be in one of three states
    contention, transmission, or idle.

22
Binary exponential backoff(Ikili üssel geri
çekilme)
  • After a collision divide time into slots of
    length
  • After i consecutive collisions wait a random
    number of slots.
  • After 16 collisions inform the higher layer
    (network layer) process
  • When number of users is large choose a large
    randomization interval
  • When number of users is small choose a small
    randomization interval

23
Switched Ethernet
  • A simple example of switched Ethernet with 4
    plug-in cards.

Either each card has its own collision domain or
each port has its own collision domain.
24
Fast Ethernet (IEEE 802.3u)
  • Fast Ethernet is faster, but backward compatible.

Hubs and switches, but no vampire taps or BNC
connectors 100Base-T4 25Mhz signalling in 4
twisted pairs one upstream, three
downstream downstream total log2(33)4bits/cycle
100Base-TX 125Mhz signalling in 2 twisted
pairs One upstream, one downstream 4B/5B coding
yields 100Mbps for data 100Mbps for control
25
Gigabit Ethernet (IEEE 802.3z)
Also backward compatible
  • (a) A two-station Ethernet. (b) A multistation
    Ethernet.

26
Gigabit Ethernet
  • Modes of operation
  • Full duplex Computer to switch, no contention,
    all lines buffered
  • Half duplex Computer to hub, contention,
    CSMA/CD. Distance gt25m.
  • Carrier extension Pad to 512 bytes by hardware
  • Frame bursting Concatenate multiple frames in a
    single transmission
  • Flow control to prevent fast transmission from
    overflowing buffers
  • PAUSE frames

27
Gigabit Ethernet (2)
  • Gigabit Ethernet cabling.

1Ghz signalling possible with lasers (no
LEDs) (1.3 microns and 0.85microns
lasers) 1000BaseSX/LX encoding 8B/10B each 8bits
encoded as 10 bits with codeword rules to balance
1s and 0s (ensure 0 DC) 1000Base T encoding
Five voltage levels (2 data bits) for each of 4
twisted pairs at 125Mhz.
28
Services and Ethernet
  • Ethernet is connectionless (best efforts)
    protocol
  • IP is a connectionless protocol, IP packets can
    just be pluged into 802 payload field
  • ATM is connection oriented and much less
    interoperable with IP
  • For enabling connectionless service at DLL level
    LLC which fits on top of 802 MAC can be used. LLC
    provides flow control.

29
IEEE 802.2 Logical Link Control
  • (a) Position of LLC. (b) Protocol formats.

30
Wireless LANs
  • The 802.11 Protocol Stack
  • The 802.11 Physical Layer
  • The 802.11 MAC Sublayer Protocol
  • The 802.11 Frame Structure
  • Services

31
The 802.11 Protocol Stack
  • Part of the 802.11 protocol stack.

11Mbps
54Mbps
54Mbps
1-2Mbps
32
The 802.11 Physical Layer
  • Infrared Not line of sight, 4bits encoded as 16
    bits codeword or 2 bits encoded as 4 bits
    codeword (Gray code 0001,0010,0100,1000)
  • FHSS psedo random hopping from frequency to
    frequency on 79 1Mhz channels in 2.4 Ghz ISM band
  • Security and insensitivity to interference
  • DSSS Similar to CDMA, 1 Mbaud phase shift
    modulation with 1bit/baud or 2bits/baud
  • OFDM Multiple narrow frequency bands in
  • 5Ghz ISM band, 802.11a
  • 2.4 Ghz ISM band 802.11g
  • HR-DSSS 11million chips/sec.
  • 1 Mbaud 1 bit/baud, 2 bit/baud
  • 1.375 Mbaud 4bit/baud, 8bit/baud

33
The 802.11 MAC Sublayer Protocol
Differences from Ethernet
  • (a) The hidden station problem. (C transmits to
    B)
  • (b) The exposed station problem.(B transmits to
    D)
  • (c) Can not transmit and listen at the same time.

34
MAC Modes of operation
  • DCF (Distributed Coordination Function)
  • Mandatory
  • CSMA/CA (Collisions can occur)
  • Physical channel sensing Similar to Ethernet
  • Virtual channel sensing ARQ and Internal NAV
    issued upon hearing RTS/CTS and information it
    contains
  • Frame fragmentation to keep frame error rates low
    in a noisy environment
  • PCF (Point Coordination Function)
  • Polling by base station (No collision occurs)

35
The 802.11 MAC Sublayer Protocol (2)
  • The use of virtual channel sensing using CSMA/CA.

36
The 802.11 MAC Sublayer Protocol (3)
  • A fragment burst.

37
PCF and DCF coexistence
  • Prioritization by time elapse After an ACK for a
    fragment
  • Allow the sender to send the next fragment
  • if not allow the base station to send its frame
    or fragment sequence
  • if not allow a new station to send a new frame
  • if not allow an error to be reported

38
The 802.11 MAC Sublayer Protocol (4)
  • Interframe spacing in 802.11.

39
The 802.11 Frame Structure
Version a, b or g Type data, control,
management Subtype RTS/CTS To DS/ From DS Going
to/coming from distribution system type MF More
frames W Encryprion used O Order of
transmission important Duration FrameACK
roundtrip time Addresses Source station,
destination station. Source base
station, destination base station (except
management and control) Sequence Frame no.
0-4095, fragment no. 0-15 (Except control)
40
802.11 Services
Distribution Services
  • Association(Connection setup upon entry into
    cell, announce id, capabilities
  • Disassociation (Either mobile station or base
    station breaks down connection)
  • Reassociation (Smooth handover to another base
    station)
  • Distribution (Base station to destination)
  • Integration (Translation to non 802.11 format)

41
802.11 Services
Intracell Services
  • Authentication (Check for authorization/possession
    of secret key)
  • Deauthentication (Leaving the network)
  • Privacy (Encryption)
  • Data Delivery(Best effort transmission)

42
Token Ring (IBM Zurich-IEEE802.5)
  • 4Mbps (1985)-16Mbps (1989)
  • Shielded twisted pair
  • Differential Manchester encoding
  • Stations are connected to the ring via network
    adapters
  • Token is a short frame that consists of a unique
    sequence of bits (three bytes)
  • Token has two states
  • Free no data is attached, frame consists of
    token only
  • Busy token is followed by data (payload)

43
Token Ring
  • Network Adapter

44
Token Ring
  • A free token may be captured by a station that
    wishes to transmit
  • A station that captures the free token attaches
    its data to it and fills the source and
    destination addresses and sends out a busy token
  • Busy token circles the ring and data is read off
    by the destination station
  • Busy token is converted to free token when it
    arrives back at the sending station
  • Upon a transmission error, no token or multiple
    tokens Active Monitor detects and removes or
    reinserts tokens as necessary
  • Active Monitor also ensures synchronization of
    signal for stations and sufficient delay for the
    token to sit on the ring.

45
Token Ring Free/Busy Token Formats
  • Busy
  • token
  • SD (Start Delimiter)8 bit start of frame marker
    (via code violations)
  • AC(Access Control)Specifies priority, busy/free,
    monitored
  • FC(Frame Control)Specifies data/control, if
    control type
  • DA(Destination Address), SA(Source Address)
  • ED(End delimiter) 8bit end of frame marker (via
    code violations)
  • FS (Frame Status) Primitive ACK on whether frame
    was correctly received
  • Free token
  • Abort
Write a Comment
User Comments (0)
About PowerShow.com
