DATA TRANSMISSION

1
MECHANICAL MEASUREMENTS
Prof. Dr. Ing. Andrei Szuder Tel.
40.2.1.4112604 Fax. [phone] www.labsmn.pub.
ro szuder_at_labsmn.pub.ro
2
DATA TRANSMISSION
3
DATA TRANSMISSION

• An ideal data transmission system gives an output
  which is identical to the input Three problems in
  data transmission
• noise
• attenuation
• distortion.

4
Noise

• A variation in output not caused by a variation
  in the measurand is noise
• It gives an error in the measurement unless it
  is removed
• It is quantified as the signal-to-noise ratio
  (SNR)

5
Attenuation

• Energy losses in the transmission medium mean
  that the amplitude of the signal is reduced
• Reduces the SNR
• Reduces the signal level

6
Distortion

• Arises when the frequency response of
  transmission system is inadequate to deal with
  the frequencies in the signal.

7
Analogue data transmission

• Generally done by using conducting wires to feed
  the transducer output to the signal processing,
  recording and/or display unit.
• Wires may be simple single strand conductors, or
  may be co-axial cables.
• Co-axial cables consist of
• inner conductor
• insulating layer
• outer earthing and screening conductor
• final insulating layer outside.

8
Analogue data transmission

• Thickness and purity of both conductors and
  insulators vary the cost varies accordingly.
• Reduction of attenuation and noise mean
  increased cost.

9
Effect of noise on transmitted analogue data

• Low levels of noise enable the signal to be
  detected with very small errors
• High levels of noise may totally obscure the
  signal.
• Noise arises from
• external sources
• noise generated in the conductor itself.

10
Effect of noise on transmitted analogue data

• Coaxial cables reduce these problems compared
  with single wires
• Internal noise is related to the size, length
  and quality of the conductors.
• Isolation from external pickup reduces with
  thicker, better quality insulation

11
Effect of attenuation on transmitted analogue
data

• Attenuation is determined by the thickness and
  quality of the conductor in the cable.
• Also determined by distance (length of cable)

12
Effect of distortion on transmitted analogue data

• Distortion effects are related to frequency
  response
• The transmission system deals adequately with the
  low frequency
• A higher frequency is, however, barely
  transmitted.
• The frequency response of co-axial cable varies
  with cost.

13
Transmission distance

• The greater the distance, the more serious all
  these problems are
• Simple conducting wires may be adequate to carry
  a signal over a distance of a metre
• More expensive coaxial cable will be required to
  carry the same signal to the same display system
  over a longer distance.

14
Serial data transmission

• Signal sent as a series of pulses
• '1' represented by pulses at one voltage level
• '0' represented by pulses at different voltage
  level. The received signal is converted back to
  the original binary number
• A pulse is recognised as either '0' or '1' when
  it falls within prescribed limits.

15
SERIAL TRANSMISSION
TRANSDUCERS
COMUTATION
DATA TRANSMISSION
DISPLAY RECORDING
MEASURAND
CYCLE
TRANSDUCERS
16
Serial data transmission

• If the noise and distortion are below specific
  amounts, the received signal is exactly equal to
  transmitted signal
• Transfer of data is controlled by various signals
  to indicate the start and finish of individual
  numbers
• Various methods for checking the data used
• Standard serial transmission line are available,
  e.g. RS232.

17
PARALLEL TRANSMISSION
DISPLAY RECORDING
UTILIZATION
TRANSDUCER
SIGNAL TRANSMISSION
MEASURAND
SINCHRONIZATION
18
PARALLEL TRANSMISSION

• Separate cables for each measurand
• Faster than serial
• More complex
• Communication systems between computers and other
  systems - Standards IEEE, S-100, CAMAC.

19
Parallel data transmission

• The individual bits of the binary number are sent
  in parallel along separate lines.
• It is faster than serial transmission for a given
  rate of bit transfer
• It is more complex.
• A variety of such systems have been developed
  for communication between computers and other
  systems - IEEE, S-100, CAMAC.

20
Noise, attenuation and distortion in digital
transmission

• None of these are a problem unless '1's cannot be
  distinguished from '0's.
• Sampling rate must be high enough to 'see' all
  frequencies - Nyquist criterion

21
Optical fibres for data transmission

• Used only for digital data transmission.
• They have been extensively developed for use in
  telecommunications
• They operate at frequencies of many GHz.
• They have very low attenuation over long
  distances
• A major advantage is that they are not subject
  to interference from external EM sources.

22
Optical fibres for data transmission

• They are much lighter than copper cables
• They are better in hazardous environments where
  intrinsically safe equipment is required
  (explosive environments such as mines, chemical
  factories).
• They are much lighter than copper cables

23
Optical fibers for data transmission

• They are available with a variety of performance
  specifications
• The higher the specification, the more
  expensive.
• Currently more expensive than the equivalent
  conducting system
• May change as the raw material (sand) is much
  cheaper than copper or other metals.

24
Analogue vs. digital data transmission

• Analogue data transmission is simpler, therefore
  cheaper than digital data transmission.
• Normally the first choice if the signal has to
• travel a long distance
• go through an electrically noisy environment or a
  hazardous atmosphere
• is at a high frequency

25
Analogue vs. digital data transmission

• If the signal is to be input to a computer, it
  may be worth converting to it to digital form
  before transmission.

26
DATA TRANSMISSION SUPPORT

• FILAR CABLE
• COAXIAL CABLE
• OPTICAL FIBERS Eliminating noise, electrical
  insulation,
• optoelectronics
• RADIO
• Long distance
• Close distance (10-100 m) technology BLUETOOTH
• INTERNET
• INTRANET

27
Transmission of data using EM propagation

• Used for transmission
• over long distance
• through hostile environments
• The signal is superimposed on a radio wave at a
  much higher frequency (carrier wave) as either
• amplitude modulation (AM)
• frequency modulation (FM).

28
Transmission of data using EM propagation

• The radio wave is transmitted through the air
• It is picked up by a receiver
• It is then demodulated back into its original form

29
RADIOTRANSMISSION
30
RADIO TRANSMISSION
APLLICATIONS
RANGE
RANGE
Classic telephone
31
RADIO TRANSMISSION
32
Carrier wave
33
AM modulation
34
AM modulation
35
FM modulation

• Carrier frequency changes according to the level
  of the signal
• FM much less susceptible to noise and distortion
  and noise than AM

36
FM modulation
37
Fibrele optice pentru transmiterea datelor

• Utilizate pentru transmiterea digitala a datelor.

• Sunt utilizate in telecomunicatii
• Functioneaza la frecvente extrem de mari
• Atenuare foarte mica pe distante mari
• Nu sunt supuse interferentelor cu surse externe
• Sunt mai usoare decat cablurile de Cu
• Mai scumpe

38
TRANSMISIA DATELOR

• Intr-un sistem ideal de transmisie a datelor
  marimea de intrare este identica cu cea de iesire

• Probleme care apar la trensmiterea datelor
• zgomot
• atenuare
• distorsia semnalelor.

39

• Zgomot
• O variatie a marimii de iesire ne cauzata de o
  variatie a masurandului. Surse externe si
  interne. Calitatea izolatiei
• Produce o eroare de masuare daca nu este
  indepartat
• Se masoara prin raportul semnal - zgomot

• Atenuare
• Pierderile energetice in timpul transmisiei se
  manifesta prin reducerea amplitudinii semnalului.

• Reduce raportul semnal-zgomot si nivelul
  semnalului
• Calitatea si lungimea cablului

• Distorsia
• Se produce cand raspunsul in frecventa a
  sisstemului de transmisie este neadecvat cu
  frecventa semnalului. Depinde de calitatea
  cablului
• Mai mare la frecvente mare.

40
(No Transcript)
41
(No Transcript)
42
ETHERNET CONNEXIONS
10 Base - T
10 Base - 2
CABLURI TORSADATE 100 m 10Mbps
COAXIAL GROS 500 M MAX 10 Mbps
COAXIAL FIN 185 m 10 Mbps
HUB
100 Base - TX
COAXIAL
100 Base - FX
FIBRA OPTICA 2000 m 100 Mbs
CABLURI TORSADATE 100 m 100Mbps
43
INTERNET
GPRS - General Packet for Radio Services EGPRS -
Enhanced General Packet for Radio Services UMTS -
Universal Mobile Telecommunication System
SERVER WAP
BASE STATION
2001- GPRS si EGPRSPhoto E_ commerce Muzica
(MP3) Ziare Banca max 144si 384 Kbits/s F 900
si 1800 MHz
2002 - UMTS TV pictures Radio
Games Videophon max 2 Mbits/s F 2 GHz
1999 - GSM Voice Fax Mesages E_Mail max 9,6
Kbits/s F 900 si 1800 MHz
44
SATELITTE DATA TRANSMISSION
Satellite frequency (FS) 10,729 la 12,670 GHz
SATELLITE
PARABOLIC ANTENNA
LN C Oscillator frequency local (FOL) 9,75 GHz
13 or 18V (Polarization)
SATELLITE DEMUDALATOR 950 at 2150 MHz
TV
Frequency in cable (FC) 979 MHz at 2920 MHz FC
FS-FOL
45
PROTOCOLURI TCP / IP
Principiu - Comutarea pachetelor Mesajele
decupate in pachete Pachete trimise pe drumul cel
mai scurt Noduri terminal - calculatoarele care
schimba informatii Rutare dinamica - leagatura
pate fi facuta prin multiple intinerarii Transmis
ion Control Protocol - Controleaza integritatea
informatiei Internet Protocol - Transmterea
informatiei
Adresare logica - Placa retea. Numar
identificare calculator ID Rutare - citeste
adresle logice si orienteaza datele catre
destinatar Nume si adrese - Corespondenta dintre
adresa ID si Numele de Domeniu -DNS Controlul
erorilor si debitelor (data flow) Suportul de
aplicatie - Intrefata pentreu ca aplicatiile se
pe calculator sa poata accede la retea
46
PROTOCOLURI TCP / IP
MODULELE TCP / IP

• ACCES RETEA - INTERFATA CU RETEAUA
• Formateza datele dupa normele sub retelei tinând
  cont de adresele destinatarilor
• Controleaza erorile
• INTERNET - ADRESARE LOGICA
• Asigura rutarea datelor
• Evita aglomerarea datelor
• TRANSPORT - CONTROLUL FLUXULUI DE DATE
• Gestioneza si contoleaza erorile
• Interfata pentru aplicatii
• APLICATIE - FURNIZEAZA APLICATIILE PENTRU
  TRANSFERUL DE FISIERE
• APLICATIE PREZENTARE - FORMATAREA, CRIPTAREA SI
  COMPRESIA DATELOR SESIUNE - DESCHIDE SESIUNILE
  CARE LEAGA APLICATIILE PE
• CALCULATOARELE INTERCONECTATE

47
WAP - WIRELESS APPLICATION PROTOCOL
UTILIZAREA COMUNA A TELEFONIEI MOBILE SI A
INTERNETULUI
Comunicarile GSM - 9,6 Kbits / s , Internet 56,6
Kbits/ s47 Utilizarea standardelor de comunicare
internet in forma concisa Limbajul HTML -
WML ( Wireless Markup Language) 1997 Traducere
care ia timp. Viteza de transfer
redusa. Legatura infrarosu IrDA pentru
transferarea datelor pe calculator Consum mare
de energie (Autonomie max 6 ore)
48
BLUETOOTH
MODUL GESTIONARE asigura compatibilitatea între
protocolul BLUETOOTH si interfata utilizator
PC SISTEMACHIZITIE DATE
EMITATOR / RECEPTOR 2,4 GHz
MODUL CONTROL
Lungimea mesaj 625 ?s
Canale voce - 64 Kb/s Canal asincron 433,9 Kb/s
in mod sincron
49
COMPRESIA DATELOR
50
DECOMPRESIA DATELOR
51
ISDN
Services integration Transmssion voice, images,
data
Digital link duplex shared by independent
channels time multiplexed pe A Analogical
telephone channel -4 KHz B- Digital cable 64
Kbits/s (PCM- Pulse Code Modulation) C Digital
channel 8 or16 Kbits/s D - Digital channel 16
or64 Kbits/s for signalization
52
TRANSMISIA NUMERICA IN BANDA DE BAZA
53
TRANSMITEREA PRIN MODULAREA IMPULSURILOR
CODIFICATE
