Common Rocks and Minerals in Soil Parent Materials

1
Common Rocks and Minerals in Soil Parent Materials

• Laboratory 2

2
Objectives of the Lab

• Know the definition of a mineral and a rock.
• Recognize common minerals and rocks.
• Understand the general geology of North Carolina

3
Minerals

• Minerals are naturally occurring homogenous
  solids that were inorganically formed, having a
  definite chemical composition, and an orderly
  atomic arrangement.
• Most minerals have fairly definite physical
  properties such as crystal form, color, luster,
  hardness, specific gravity, and solubility.
• Minerals are classified as to their origin and
  chemical composition.

4
Types of Minerals

• Based on origin, minerals may be primary or
  secondary minerals.
• Primary minerals are formed when molten rock
  cools and solidifies.
• Secondary minerals are formed by the weathering
  of primary minerals.

5
Primary Minerals

• -Formed directly from molten rock

6
Quartz Si02

• Most common soil forming mineral
• Make up 13 of earth's crust and from 30 to 40
  of the average soil
• Commonly a translucent milky-white color
• Hard enough to scratch glass
• Resistant to weathering
• Present in granite absent from basalt
• Does not contribute plant nutrients to the soil

http//www.luc.edu/faculty/spavko1/minerals/quartz
/qa1.htm
7
Orthoclase Feldspar KAl1Si3O8

• Slightly harder than glass
• Commonly white, orange, or pink in color
• Fine wavy lines may occur within crystals
• Flat surfaces are common (intersecting at 88-90
  angles)
• The most abundant mineral in granite
• Is an important source of potassium

8
Plagioclase Feldspar

• Slightly harder than glass
• Common gray color (from almost white to dark
  bluish gray)
• Commonly has striations (flat faces within
  crystals seen as straight lines on surface)
• Flat surfaces are common (interesting at 87-89
  angles)
• Weathers more readily than orthoclase

http//www2.nature.nps.gov/GEOLOGY/usgsnps/rxmin/m
ineral.html
9
Horneblende

• Slightly harder than glass
• Black, dark brown, or dark green in color
• One of the dark-colored minerals in granite
• Weathers more rapidly than feldspar, but persist
  in soils as dark colored gravel

http//cmsc.minotstateu.edu/Labs/web20minerals/Ho
rnblende.html
10
Muscovite

• Easily spilt into thin flexible elastic plates
• Has shiny surface
• Present in granite, basalt, loess, and glacial
  till
• Is the Al mica and is colorless
• Contains more potassium than Biotite

http//www.cropsoil.uga.edu/soilsandhydrology/imag
es/Muscovite.jpg
11
Biotite

• Easily spilt into thin flexible elastic plates
• Has shiny surface
• Present in granite, basalt, loess, and glacial
  till
• Is the Mg, Fe mica and is black
• Has more iron and magnesium

http//www.pitt.edu/cejones/GeoImages/1Minerals/1
IgneousMineralz/Micas/BiotiteFlakes.JPG
12
Secondary Minerals

• -Formed from primary minerals

13
Gypsum - CaSO4 2H2O

• Forms from evaporating calcium sulfate-bearing
  waters
• Very soft and weathers fairly readily
• Accumulate in large quantities in semi-arid
  regions
• Can be both a primary and secondary mineral

http//dave.ucsc.edu/myrtreia/photos/gypsum.jpg
14
Calcite CaCO3

• Commonly found in limestone and Marble
• Much softer than glass harder than fingernails
• White or colored by impurities
• Slightly soluble in water
• Effervesces in dilute HCI (release bubbles of
  CO2)

http//www.beg.utexas.edu/mainweb/publications/gra
phics/calcite400.jpg
15
Dolomite - CaCO3 MgCO3

• Most common liming material in NC
• Similar to calcite
• Contains Mg

http//hyperphysics.phy-astr.gsu.edu/hbase/mineral
s/imgmin/dolomite.jpg
16
Iron Oxides

• Formed through chemical weathering
• Geothite (FeOOH) gives yellow color in soils
• Hematite (Fe2O3) responsible for red coloration
  in soils

http//www.uwrf.edu/wc01/mont-goet1.JPG
http//www.cst.cmich.edu/users/dietr1rv/hematite-b
.JPG
17
Clay Minerals

• Highly colloidal
• Formed primarily form chemical weathering of
  primary minerals
• Ability to adsorb or hold nutrient ions on their
  surfaces

18
Rocks

• Rocks are combinations of two or more minerals.
• There are three major groups of rocks igneous,
  metamorphic, and sedimentary.

19
The Rock Cycle
http//rst.gsfc.nasa.gov/Sect2/rock_cycle_800x609.
jpg
20
Igneous Rocks

• Formed when molten rock cools and solidifies.
• This is the most abundant group of rocks within
  the earth's crust.
• Classified on the basis of their chemical
  composition
• Acidic (Felsic)
• Usually light colored
• Basic (Mafic)
• Igneous rocks that have less than 50 SiO2
• Neutral
• Igneous rocks that have between 50 and 65 SiO2

21
Intrusive Igneous Rocks

• Rocks deep within the earth's crust were formed
  by relatively slow cooling process.
• Have coarse-grained (pea size) texture.
• Intrusive mode of occurrence.

http//epswww.unm.edu/facstaff/zsharp/103/Lecture
207,20rocks_files/image004.gif
22
Extrusive Igneous Rocks

• At or near the earth's surface the igneous rocks
  developed by rapid to very rapid cooling
  processes.
• They have fine grained (size of sugar crystals)
  or glassy textures.
• These are termed as extrusive in mode occurrence.

http//epswww.unm.edu/facstaff/zsharp/103/Lecture
207,20rocks_files/image004.gif
23
Examples of Igneous Rocks

• -Formed from molten rocks

24
Granite

• Are coarse-grained and light colored
• has quartz and orthoclase feldspar as principal
  minerals
• Acidic in chemical composition and intrusive in
  mode of occurrence

http//www.beg.utexas.edu/mainweb/publications/gra
phics/granite.htm
25
Syenite

• Relatively coarse-grained
• Contains large amounts of feldspar and hornblende

• Classified as neutral and intrusive

http//www.guilford.edu/geology/imagelibrary/MVC-0
26
Rhyolite

• Mineralogical and chemical composition are
  similar to granite
• Fine grained in texture
• It is acidic in chemical composition
• Extrusive in mode of occurrence

http//volcano.und.edu/vwdocs/vwlessons/rocks_pics
/rhyolite.jpg
27
Gabbro

• Dark colored
• Has a predominance of plagioclase feldspar,
  hornblende, and augite
• Basic
• Intrusive
• Coarse-grained

http//www.geo.umn.edu/mgs/virt_egg/gabbro.jpg
28
Basalt

• Same chemical and mineralogical composition as
  gabbro
• Fine-grained
• Basic in chemical composition
• Extrusive in mode of occurrence

http//itc.gsw.edu/faculty/tweiland/basalt.jpg
29
Obsidian

• Is volcanic glass
• Dark colored
• Acidic in chemical composition
• All volcanic rocks are extrusive in mode of
  occurrence

http//www.drexel.edu/coe/enggeo/rocks1/obsidian.J
PG
30
Sedimentary Rocks

• Result from the erosion and deposition of
  sediments
• Have two classifications clastics or
  precipitates.

31
Clastic Sedimentary Rocks

• Are sedimentary rocks which have been formed
  through physical or mechanical means.
• Vary in size.
• Cementing agents may be clay, iron oxide, silica,
  or calcium carbonate.

32
Precipitate Sedimentary Rocks

• Types of sedimentary rocks that have been
  produced by chemical or biochemical precipitation
  of ions from solution (biochemical precipitates
  usually involve marine animals and may be
  fossiliferous).

33
Examples of Sedimentary Rocks

• -Formed from erosion and deposition of sediments

34
Conglomerates

• Formed from rounded pebbles or boulders (gt2mm in
  diameter)
• Cemented together with finer-grained material
• Weather to a very coarse material-which-may forma
  gravelly soft

http//comp.uark.edu/sboss/rockbag35.jpg
35
Sandstone

• Consists of sand grains (0.5 to 2mm in diameter)
• Gives rise to sandy or sandy loam soil

http//www.beg.utexas.edu/mainweb/publications/gra
phics/sandstone400.jpg
36
Shale

• Composed of minute particles (lt0.005mm diameter)
  which are consolidated
• Predominant mineral is clay which is deposited in
  slowly moving water
• Soils derived by shales are clayey

http//csmres.jmu.edu/geollab/fichter/SedRx/rkimag
es/shale2-899.jpg
37
Limestone

• Usually fine-grained chemical precipitates.
• Principal minerals are Calcite and dolomite
• Durng weathering the carbonate minerals dissolve
  and leach away
• Remaining impurities determine the nature of the
  developed soil

http//www.dep.state.fl.us/geology/geologictopics/
rocks/miami_limestone.jpg
38
Metamorphic Rocks

• Form from igneous and sedimentary rocks exposed
  to extreme heat and/or pressure
• These are classified according to their structure
  and parent material, either as banded (foliated)
  or non-banded.

39
Banded (Foliated) vs. Non-banded Metamorphic Rock

• Banded metamorphic rocks have more or less
  parallel layers of different minerals and are
  usually uniformed in color or they alternate
  light and dark-colored layers.
• Non-banded metamorphic rocks have a random
  pattern of mineral crystals.

40
Examples of Metamorphic Rock

• -Formed from parent rock due to heat and/or
  pressure

41
Gneiss

• Banded (alternates light and dark bands)
• Derived primarily from acidic igneous rocks.
• Contains an abundance of feldspar

http//www.beg.utexas.edu/mainweb/publications/gra
phics/gneiss400.jpg
42
Schist

• Layered
• Fairly uniform in color
• These are metamorphosed shale, gneiss, or basic
  igneous rock.
• Newly formed minerals like mica, chlorite, and
  hornblende tend to predominate

http//ocw.mit.edu/ans7870/12/12.108/f04/imagegall
ery/lab2/images/lab2-5.jpg
43
Slate

• Layered
• Derived from shale
• Mineral grains are invisible
• Is more dense and compact than shale and cleaves
  into sheet

http//www.es.ucl.ac.uk/schools/Glossary/slate.jpg
44
Quartzite

• Non-layered metamorphosed sandstone
• Very hard
• Weathers extremely slowly
• The rock fractures through sand grains which are
  mainly quartz

http//www.es.ucl.ac.uk/schools/Glossary/quartzite
.jpg
45
Marble

• Is a recrystallized limestone with a random array
  of mineral grains
• Coarser-grained than parent limestone
• Weather more slowly than limestone
• The impurities determine the kind of soil.

http//www.drexel.edu/coe/enggeo/rocks2/marble.JPG
46
Physiographic Regions of NC

• There are 3 physiographic regions in North
  Carolina Coastal Plain, Piedmont, and Mountain
  region.
• In North Carolina, all 3 rock types are present.

http//nc.water.usgs.gov/projects/icons/Physio.gif
47
Coastal Plain Soils

• Coastal Plain soils are formed from weathered and
  eroded rock particles that are moved by water and
  may be alluvial or marine sediments (sedimentary
  rock).
• These sediments have similar minerals, so parent
  material differences are related to changes in
  the amounts of sand, silt, and clay.
• Properties of parent materials within the same
  landform vary if changes in texture occur.

48
Piedmont Mountain Soils

• The piedmont region consists of remnant
  metamorphic mountains with some sedimentary rock.
• The mountain region contains metamorphic rock
  with some igneous intrusions.

49
Questions??
