Similarity based deduplication

1
Similarity based deduplication

• By Lior Aronovich, Ron Asher, Eitan Bachmat,
  Haim Bitner, Michael Hirsch , Tomi Klein

2
Deduplication

• There is a lot of redundancy in stored data,
  especially in backup data.
• Deduplication aims to store only the differences
  between different versions.

3
Different types of deduplication

• Inline or offline.
• Hash comparison or byte by byte.
• Similarity based or identity based.

4
Our initial design requirements

• Support for a petabyte of physical storage.
• A deduplication rate of at least 350MB/sec.
• Inline
• Byte to byte (B2B) comparison

5
Standard approach

• Break up the incoming data stream into segments,
  a few KB in size. The break up boundaries are
  computed using patterns in a rolling hash.
• Identify each segment using a long hash.
• Check if the hash belongs to a previous segment
• If so place a pointer to the segment.

6
Standard approach

• Can be fast, can be inline, however
• Doesnt scale to a physical Petabyte (because of
  KB sized segments)
• No B2B comparison

7
Our approach

• Break up incoming stream to chunks of a few MB
  size.
• Compute a similarity (not identity!) signature so
  that chunks which are alike (even only 50) will
  have signatures which are alike (could be only
  25).
• Do a B2B comparison between the incoming chunk
  and similar repository segments.
• Store differences based on the B2B.

8
Similarity signatures

• Compute a rolling hash (Karp-Rabin) to all blocks
  of the chunk.
• Three possibilities
• (Breen et al) Take k random block hashes
• (Broder, Heintze, Manbar) Take the largest k
  hashes
• (Our choice) Take k hashes of blocks which are
  close to those that produced the k largest hashes



9
Criteria for comparison

• Similarity checking speed
• Successful identification of similarity
  percentage
• Low probability of false positives
• Likelihood of finding the most similar match

10
Comparison of methods

• The first method (random block hashes) is slow
  and has many false positives, likelihood of
  finding best similarity is lower compared to the
  other methods
• The second method (k maximal hashes) is faster,
  but still has false positives
• The third method solves all issues

11
B2B phase

• Once similarity is detected, we know where in the
  repository the similar data is located and we
  have a few anchoring matches.
• The B2B comparison itself is completely decoupled
  from the similarity search ! We have the
  anchors and computed hashes to support the B2B.

12
Implementation

• The TS7650 from IBM, formerly from Diligent
• Has been available since 2005.
• Many clients managing many petabytes
• Very large installations

13
Did we achieve our goals?

• Up to 850MB/sec on a single system node
• Up to 1PB of physically usable storage with only
  12 GB of memory
• Inline
• B2B comparison

14
Some of the competition

• Data Domain 690 series
• An HP system, the DD4000 from 2008, academic
  paper in FAST 2009, the only other similarity
  based product, but with hash comparison, uses a
  variant of the second method.

15
How do we compare?
16
We are better !!
17
In more detail

• While our solution supports 1PB physical, Data
  domain supports at most 50TB and the HP product
  at most 10TB, we have actual installations which
  are far bigger than either of these numbers.
• Our solution is faster, somewhat faster than Data
  Domain, much faster than HP
• We still find time to do B2B comparison, they
  dont
• Our solution has faster reconstruction rate,
  remember thats when you have a data outage
  situation !

18
Customer site
19
401 dedupe ratio
20
Daily back-up fluctuations
21
throughput
22
Thanks !!
