Classes and Inheritance

1
Classes and Inheritance
2
Recall Structs

• Many programming languages support user-defined
  types that are aggregations of other objects.
• supported in C with the struct construct
• supported in C with the class construct
• The aggregation allows several variables to be
  treated as a unit
• allocated together
• passed as parameters/return values together.

3
Implementation of Structs

• Compiler determines a size of the aggregate
  object.
• size of the field
• some adjustments for address alignment
• Compiler determines an offset for each field.
• The . operator is implemented simply by adding
  the offset of the named field to the address of
  the aggregate.

4
Type Rules in C

• Structs in C are legitimate types and can be
  use exactly like any base types.
• can be parameters, global/local variables or
  return types
• can be fields in other structs
• derived types (pointer reference) can be based on
  structs.
• Struct assignment is permitted in C. The
  default behavior is to use the default
  assignment/copy rules for each individual field.
• Custom behavior can be defined using operator()
• Strong/static type checking is used.

5
Member Functions

• The next step up on the evolutionary ladder above
  structs is ADTs.
• An Abstract Data Type is a software module
  consisting of a struct (data layout) plus a set
  of functions for operating on that struct.
• These functions (obviously) require that one of
  their parameters be a pointer or reference to the
  struct that they are to manipulate.
• Member functions support ADTs by
• merging the source code for the data layout and
  function declarations.
• passing the struct pointer implicitly to member
  functions

6
C and this

• The this pointer is a parameter. For a member
  function in class T, the
• declared T const this
• The this pointer is passed implicitly (does not
  appear in the parameter list).
• The implicit this pointer is the only
  implementation difference between a member
  function and a regular function!
• The only other differences relate to
  type-checking rules (scoping and access control).

7
Pop Quiz

• int x 0
• class A
• void doit(void) x 1 doit()
• // no data members
• class B
• double a,b,c // 24 bytes of data members
• void doit(void) x 1 doit()
• Does either function run indefinitely? Which
  program runs longer (increments x more times)
  before crashing? Adoit() or Bdoit()?

8
Inheritance

• The terminology of object-oriented programming is
  somewhat ambiguous (at least in conventional
  usage).
• The C inheritance mechanism does at least two
  very distinct things.
• Allows a new type to be defined as an extension
  of an existing type.
• Creates a subtype/supertype relationship.
• Ill refer to 1 as inheritance and as 2 as
  subtyping.

9
Inheritance for Reuse

• Remember that the goal for object-oriented
  programming was to achieve greater/more flexible
  code reuse.
• Imagine we have a class that provides some useful
  function, but that we wish to improve, e.g.,
  adding range checking to the standard vector
  container.

10
Defining an Inheritance Relationship

• class Derived public Base
• // changes from Base class
• Public inheritance makes all of Bases public
  members available to users of Derived (public in
  base becomes public in Derived).
• The body of Derived describes changes from Base
• Except as explicitly changed, all of Base is
  inherited into Derived.

11
Restrictions and caveats on Inheritance

• Constructors cannot be inherited. Must use ugly
  syntax for constructors.
• DerivedDerived(derived_args)
• Base(base_args)
• Assignment operator (and other operators) are
  inherited. Can lead to some confusion with
  return types. More on this in later examples.
• Destructor is not inherited.
• Base constructor is invoked FIRST, base
  destructor is invoked LAST.

12
Checked Vector Example

• template lttypename Tgt
• class CheckedVector public vectorltTgt
• public
• explicit CheckedVector(int sz 0)
• vectorltTgt(sz)
• CheckedVector(const CheckedVectorltTgt other)
• vectorltTgt(other)
• CheckedVectorltTgt operator(const
  CheckedVectorltTgt other)
• (void) vectorltTgtoperator(other)
• return this
• Note the syntax to call the operator function
  from the base class.

13
Specifying Changes

• For our checked vector we want to inherit almost
  all of the functionality from vector. operator
  is about the only thing that should change.
• T operator(unsigned k)
• if (k gt size()) abort()
• return vectorltTgtoperator(k)
• We need to watch out! Changes are based on the
  NAME of the method, not the signature.

14
Implementing Inheritance

• The compiler has two responsibilities with
  inheritance.
• Extend the struct by adding any new fields (note,
  it is not possible to remove or eliminate old
  fields)
• Support inheritance by allowing the old methods
  to be invoked on the new object WITHOUT
  RECOMPILATION.

15
Extending the Struct

• With single inheritance, this support is fairly
  simple. All of the new fields are appended to
  the end of the old object.
• We will talk about this in terms of A Derived
  object has a Base inside it.
• To invoke a Base function, nothing special is
  required, just pass this as we normally would
  (with single inheritance).
• All the original fields are accessed using their
  original offsets!

16
The Implied Subtype Relationship

• This simple implementation trick means that a
  Derived object can be used any place that a Base
  object was expected (their this pointers are the
  same).
• C provides a subtype (the isa) relationship
  a Derived is a Base
• Note the reverse relationship would not hold (all
  base objects may not be derived).
• During type checking, a subtype (derived) can be
  used whenever a supertype is expected (even on
  the right hand side of an equals!)

17
Truncating objects

• The last bullet on the previous slide had a very
  important point. A base object can be assigned
  (copied) from a derived object.
• However, the newly created object will only have
  the base part of the original object.
• Any additional fields will NOT be copied.
• Pass by value parameters are a common place to
  run into this problem (well see this again
  later).

18
Multiple Inheritance (yuck)

• There are two distinct problems with multiple
  inheritance.
• A potential ambiguity arises as a natural result
  of inheriting members from two (or more) base
  classes.
• The C compilation technique does not elegantly
  support multiple inheritance (like it does for
  single inheritance).

19
Ambiguities with Multiple Inheritance

• class Base1
• void doit(void) cout ltlt Im number 1\n
• class Base2
• void doit(void) cout ltlt nope, number 2\n
• class Derived public Base1, Base2
• Derived d
• d.doit() // what happens?
• Programmer must explicitly state which doit is to
  be used.
• d.Base1doit() d.Base2doit()

20
More Ambiguities and Virtual Inheritance

• class Counter
• public
• static int x
• Counter(void) x 1
• int Counterx 0
• class B1 public Counter
• class B2 public Counter
• class D public B1, B2
• D d // how many times is x incremented?
• Every D object has two Counters! (x 2).
• Instead, use virtual inheritance
• class B1 public virtual Counter
• class B2 public virtual Counter

21
Implementation Nightmares,Fudging this

• Besides the potential for confusion, multiple
  inheritance greatly complicates the C
  implementation.
• Lets assume we have two base classes B1 and B2
  in derived class D.
• B1s inherited fields will come first in object D
• B2s inherited fields will come second
• Ds new fields will be third.
• If we invoke an inherited B1 method on D, the
  this pointers are the same. BUT if we invoke
  an inherited B2 method, we need to change this!

22
Implementation Pop Quiz

• Explain what it would take to implement a pointer
  to a member function?
• First, we must accept that pointers to member
  functions must be kept distinct from pointers to
  functions.
• The implicit parameter must be passed to member
  functions.
• Next we need to consider the possibility that the
  pointer to the function could point to an
  inherited function.
• in the case of multiple inheritance, we might
  have to fudge this to call that function!

23
Other Inheritance Stuff

• nested types are inherited
• CheckedVector inherits vectorltTgtiterator
• can be overridden.
• A base class can be an instantiation of a
  template (duh, weve done this already).

24
Putting Inheritance to good use

• The iterator base classes
• it is tedious to have to define all the umpteen
  different nested types (value_type,
  iterator_category, pointer, reference, etc.) for
  your user-defined iterators.
• Instead, inherit them!
• class iterator
• public iteratorltforward_iterator_tag, Tgt

25
Protected Members

• To a first approximation, a protected member
  (function or data) is accessible by the class and
  any derived classes.
• class B
• protected
• int x
• class D public B
• int value(void) return x
• Fields are often made protected (rather than
  private).

26
The technical definition

• class B
• protected int x
• void bFun(D d)
• class D public B
• void dFun(B b)
• The variable used to access x must be a subtype
  of the method where the function is called.
• BbFun(D d)
• this-gtx // OK
• d.x // OK
• DdFun(B b)
• this-gtx // OK
• b.x // ERROR

27
Dynamic Binding

• Recall that the C inheritance mechanism creates
  a subtype relationship
• Any object of the derived type can be passed to a
  function that expects a parameter of the base
  type.
• Note that type checking is still static, and the
  function-call mechanism is still 100 compile
  time.
• In C we use virtual functions to get run-time,
  type-specific behavior.

28
The virtual function

• non-static member functions can be declared
  virtual.
• any function with the same signature in derived
  classes must have the same return type.
• when a virtual function is invoked through a
  pointer or reference to a base type object, the
  correct (inherited or overridden) function is
  executed on the derived object.
• the determination of which function to invoke is
  made at run time.

29
virtual example

• class B
• public
• //virtual
• void doit(void) cout ltlt "base\n"
• class D public B
• public
• void doit(void) cout ltlt "derived\n"
• void foo(B b)
• b.doit() // if doit is virtual, prints derived
• int main(void)
• D d
• foo(d)

30
Style Suggestions with Virtual

• the keyword virtual is only required in the base
  class.
• use virtual in class definition for every derived
  class.
• virtual-ness applies to the signature, not the
  name.
• avoid confusion by not overloading virtual
  functions

31
Implementation of Virtual

• The compiler produces machine code that calls the
  appropriate function using a pointer to the
  function.
• The pointer is taken from a table.
• each derived class has a distinct table.
• Every object has a pointer to the correct table.

32
Implications of Implementation

• The size of the vf table is linear in the number
  of virtual functions. (e.g. 4X bytes or 8X bytes
  where there are X virtual functions).
• There is only one table per class. There is one
  pointer (to a table) inside each object. Thus
  the objects are made 4 bytes larger when there is
  a virtual function.
• The virtual function table provides us the
  ability to determine the type of an object at
  runtime.

33
Replacing Switch Statements with Virtual Functions

• A switch statement is inconsistent with the
  principles of object-oriented programming.
• Instead of
• switch(x-gttype)
• case A
• a_operation() break
• case B
• b_operation() break
• Create derived types A and B, and virtual
  function operation in base class (x is ptr to
  base class).
• x-gtoperation()

34
Functions invoked using this get dynamic binding

• Functions inherited from the base class can call
  virtual functions from the derived class.
• class B
• public
• virtual const char name(void)return "base"
• void display_info()
• cout ltlt "this is the " ltlt name() ltlt "
  class\n"
• class D public B
• public
• virtual const char name(void) return
  "derived"

35
Virtual Destructors

• The rule of thumb for C is to make your
  destructor virtual if you have at least one
  virtual function.
• Virtual destructors are important only if you use
  new/delete.
• When you call delete the destructor is invoked.
• If you delete a Base pointer that points to a
  Derived object, we still want the derived
  destructor to be called.

36
A C Gotcha with Destructors

• Once upon a time I wrote a class that did not
  need a destructor. I created a derived class
  that also did not need a destructor.
• I created instances of the derived class using
  new, and used pointers of the base class to
  reference these objects.
• I deleted the objects using the pointers I had
  but was surprised to discover a memory leak.
• I fixed the memory leak by writing a virtual
  destructor in the parent class with an empty body
  . The derived class still did not need a
  destructor.

37
Abstract Functions

• In object oriented design it is common to have a
  base type which is so general it is abstract.
  i.e., youd never really have an object that was
  just that type. For example, Shape (you could
  have a Circle or a Triangle which might be
  subtypes of Shape).
• It may not make sense or be possible to implement
  all of the functions in this abstract class.
• A function is pure virtual if it has no
  implementation.

38
Pure Virtual Syntax and Semantics

• Syntax
• class Shape
• public
• virtual void draw(void) 0
• If any virtual function is pure virtual, then the
  class is abstract. You cannot have a variable,
  or return value declared an abstract type.
• Any derived type must override the pure virtual
  function or else it too will be abstract.

39
When Should a Function be Abstract

• Keep in mind the consequences if any one
  function is abstract, then the class is abstract
• If there is no reasonable default implementation
  for the function, or
• if every subclass should be required to implement
  this function.
