Radiologiclal Investigations

1
Radiodiagnosis - An overview
Dept of Radio-Diagnosis Imaging, Father Muller
Medical College , Mangalore
2
Discovery of X-Rays

• Wilhelm Conrad Roentgen,a German physicist,
  discovered x rays on Nov.8,1895.
• In recognition of his outstanding contribution to
  science, he was awarded the first Nobel prize for
  physics in 1901.

3
The picture that caught the scientific world by
storm was the X-ray photograph of his wifes
hand, taken on December 22, 1895. It clearly
showed the structure of the bones and the ring
she was wearing.
4
Conventional Radiology

• Conventional X rays
• Barium studies of GIT
• IVU,MCU, ACU
• HSG
• Myelogram
• Sialography
• T-tube cholangiography

5
Conventional x-ray units fluoroscopy
6
COMPUTERISED RADIOGRAPHY
7
(No Transcript)
8
Chest radiographs
9
Abdominal radiographs
10
(No Transcript)
11
Musculoskeletal Radiographs
12
Spine
13
Skull radiograph
14
Pediatric radiographs
15
limitations of Chest Radiography

• Some medical conditions of the chest will not
  show up on the image. Therefore, a normal chest
  x-ray does not necessarily rule out all problems
  in the chest.
• For example, patients with asthma exacerbations
  can have a normal chest x-ray. There are some
  cancers that are too small or are difficult to
  visualize and may not be identified.
• Blood clots to the lungs (pulmonary embolism)
  cannot be seen on chest x-rays and require
  additional study.
• A chest CT may be requested to further clarify a
  finding seen on the chest x-ray or to look for an
  abnormality not visible on a chest x-ray in order
  to answer the clinical problem.

16

• The degree of involvement of the lung, as well as
  the distribution of disease, and anatomic
  location may be better evaluated with chest CT,
  helping aid the diagnosis.
• Some diseases, such as chronic lung disease, are
  frequently evaluated with HRCT (high-resolution
  CT).
• The chest x-ray and the physical examination
  should be correlated. The information each
  procedure provides can give the physician a
  clearer understanding of the patient's health.

17

• X-rays are a type of electromagnetic radiation,
  are invisible and create no sensation when they
  pass through the body.
• The chest x-ray is one of the lowest radiation
  exposure medical examinations performed today.
• Special care is taken during chest x-ray
  examinations to ensure maximum safety for the
  patient by paying attention to correct x-ray beam
  energies.

18

• Shielding the abdomen and pelvis with a lead
  apron helps reduce unnecessary radiation to the
  abdomen and pelvis.
• Women should always inform their doctor or x-ray
  technologist if there is any possibility that
  they are pregnant.
• The effective radiation dose from this procedure
  is about 0.1 mSv, which is about the same as the
  average person receives from background radiation
  in 10 days

19
INTRAVENOUS UROGRAM (IVU)

• Radiographic examination of urinary tract
  including renal parenchyma, calyces and pelvis
  after iv inj. Of contrast media
• There has been decline in IVU in past 10 years
  due to
• Development of new modalities like CT, USG
• Cost containment
• Adverse effect of contrast media

20
IVU
21
ASCENDING CYSTO URETHROGRAM (ACU)
22
MICTURATING CYSTOURETHROGRAM(MCU)

• Demonstrate the lower urinary tract and helps to
  detect the existance of any vesico-urethral
  reflux, bladder pathology and congenital and
  acquired anomalies of bladder outflow tract

23
BARIUM STUDIES

• BARIUM SWALLOW
• BARIUM MEAL
• BARIUM MEAL FOLLOW THROUGH
• ENTEROCLYSIS
• BARIUM ENEMA

24
BARIUM SULPHATE

• Ba has high atomic number 56
• Non absorbable /non toxic
• Insoluble in water/liquid
• Inert to tissues
• Can be used for double contrast studies

25
BARIUM SWALLOW

• Contrast study from oral cavity upto the fundus
  of stomach

26
(No Transcript)
27
Barium meal

• Radiological study of oesophagus, stomach,
  duodenum and proximal jejunum

28
BARIUM MEAL FOLLOW THROUGH

• To study the suspected small bowel
  abrormalities
• Major methods
• Small bowel follow through examination
• Dedicated small bowel follow through examination
• Enteroclysis
• Peroral pneumocolon
• Retrograde small bowel examination

29
BMFT
30
Enteroclysis

• Radiological study of small bowel from jejunum
  to IC junction and instillation of contrast
  through the tube

31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
Barium enema

• Study of large bowel by administration of
  contrast through rectum

35
(No Transcript)
36
(No Transcript)
37
HYSTEROSALPINGOGRAPHY(HSG)

• Contrast is injected in the uterus to study the
  uterine cavity and fallopian tubes

38
(No Transcript)
39
Sialography

• Study to demonstrate the parotid or
  submandibular glands by injection of contrast
  medium into duct system

40
T-tube cholangiography

• To study the CBD in post operative period prior
  to removial of T-tube

41
MYELOGRAM

• Injection of contrast medium in spinal
  subarachnoid space to study the stuctural details
  of spinal cord, conus medullaris nerve roots
  spinal canal

42
MYELOGRAM
43
Mammography
44
Indications for mammography

• Screening for CA in symptomatic women aged 50
  years and over
• Women above 35 years with high risk (family h/o
  breast CA)
• Symptomatic women with breast lump
• Surveillance of the breast following local
  excision of breast CA

45
Ultrasonography

• Grey scale ultrasound
• Colour Doppler
• Musculoskeletal USG
• 3D/4D ultrasound
• USG guided procedures

46
ULTRASONOGRAPHY

• Important technique for tomographic imaging of
  soft tissues
• Provides real time images
• Major application in heart, abdomen, pelvis,
  neck, breast, peripheries neonatal brain.
• Most imp application in obstetrics due to
  combination of safety and tomographinc imaging of
  fetus has rendered it indispensable

47

• LIMITATIONS ultrasound doesn't cross tissue-gas
  or tissue-bone boundary ? poor window
• ADVANTAGE just a light pressure on the skin
  non invasive
• Preparation is minimal
• Ideally fasting and full bladder is required

48
Doppler
49
(No Transcript)
50
Comuterised Tomography (CT)
51
Clinical application of spiral CT

• General survey
• Vascular studies CT angiography
• Imaging of trauma
• Pediatric studies
• Oncology- radiotherapy treatment planning
• Gastrointestinal studies- CT enteroclysis
• Newer tech- cardiac ct, VRT, MIP, virtual
  endoscopy
• Biopsy and drainage procedures

52
(No Transcript)
53
MAGNETIC RESONANCE IMAGING (MRI)
54
Clinical application of MRI

• MRI provides information that differs from other
  imaging modalities.
• Its major technological advantage is that it can
  characterize and discriminate among tissues using
  their physical and biochemical properties (water,
  iron, fat, and extravascular blood and its
  breakdown products).
• Blood flow, cerebrospinal fluid flow, and
  contraction and relaxation of organs, both
  physiologic and pathologic, can be evaluated.
• Because calcium emits no signal on spin echo
  images, tissues surrounded by bone, such as the
  contents of the posterior fossa and the spine,
  can be imaged.

55
Continued

• MRI produces sectional images of equivalent
  resolution in any projection without moving the
  patient.
• The ability to obtain images in multiple planes
  adds to its versatility and diagnostic utility
  and offers special advantages for radiation
  and/or surgical treatment planning.
• Excellent delineation of anatomic structures
  results from inherent high levels of contrast
  resolution.

56

• MRI acquisitions can be programmed to encode for
  various physiological phenomena including
  velocity of moving tissue or blood, diffusion of
  water (useful in detecting stroke)
• MR image acquisition does not use ionizing
  radiation.
• Because it requires little patient preparation
  and is noninvasive, patient acceptability is
  high.
• MRI contrast agents are very well tolerated and
  are much less likely than x-ray contrast agents
  to cause allergic reactions or alter kidney
  function.

57
Limitations of MRI

• Because of the small bore of the magnet, some
  patients experience claustrophobia and have
  difficulty in cooperating during the study. Some
  obese patients cannot be examined.
• Some patients, particularly acutely ill patients,
  cannot cooperate and movement artifacts may
  result.
• Patient throughput is slow compared with other
  imaging modalities.

58

• Patients with pacemakers and certain
  ferromagnetic appliances cannot be studied.
• MRI units require careful shielding.
• Greater technological expertise is required for
  utilization of MRI than for most other imaging
  modalities.
• MRI equipment is expensive to purchase, maintain,
  and operate

59
(No Transcript)
60
(No Transcript)
61
Interventional procedures

• FLUROSCOPY GUIDED-
• USG GUIDED -
• CT GUIDED-
• ANGIOGRAPHY AND INTERVENTIONAL PROCEDURES

62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
Current trends in Radio Diagnosis.
68
MDCT
Multi Detector CT. (MDCT) Presently 64 and 128
slice Head to toe in just 4 sec.
69
SUPERCON MRI

• 1.5 3 Tesla
• MR spectroscopy
• Functional MRI

70
PACS AND TELERADIOLOGY
71
Digital Radiography
72
Positron Emission Tomography PET CT fusion
73
Thank You
