Introduction to Sequence Alignment

1
Introduction to Sequence Alignment
2
(No Transcript)
3
Why Align Sequences?

• Find homology within the same species
• Find clues to gene function
• Practical issues in experiments
• Find homology in other species
• Gather info for an evolutionary model
• Gene families

4
The Most Visual Way of Aligning Two Sequences
5
Dot Matrix Alignment
CACTAGGC AGCTAGGA
Gibbs McIntyre (1970)
6
Dot Matrix Alignment
7

• Has many variations
• Can be used to find sequence repeats
• Find self-complimentary subsequences of RNA to
  predict secondary structure
• Still used today

8
Alignment using Dynamic Programming
9
An Example

• GCGCATGGATTGAGCGA
• TGCGCCATTGATGACCA
• A possible alignment
• -GCGC-ATGGATTGAGCGA
• TGCGCCATTGAT-GACC-A

10

Alignments

• -GCGC-ATGGATTGAGCGA
• TGCGCCATTGAT-GACC-A
• Three elements
• Perfect matches
• Mismatches
• Gaps

11
Choosing Alignments

• There are many possible alignments
• For example, compare
• -GCGC-ATGGATTGAGCGA
• TGCGCCATTGAT-GACC-A
• to
• ------GCGCATGGATTGAGCGA
• TGCGCC----ATTGATGACCA--
• Which one is better?

12
Scoring Rule

• Example Score
• ( matches) ( mismatches) ( gaps) x 2

13
Example

• -GCGC-ATGGATTGAGCGA
• TGCGCCATTGAT-GACC-A
• Score (1x13) (-1x2) (-2x4) 3
• ------GCGCATGGATTGAGCGA
• TGCGCC----ATTGATGACCA--
• Score (1x5) (-1x6) (-2x11) -23

14
Optimal Alignment

• Optimal alignment is achieved at best similarity
  score d, thus is determined by the scoring rule

15
Finding the Best Alignment Score

• The additive form of the score allows to perform
  dynamic programming to find the best score
  efficiently
• Guaranteed to find the best alignment

16
Assume that an Optimal Score Exists

• d(s,t) Optimal score for globally aligning s
  and t

17
The Idea

• The best alignment that ends at a given pair of
  bases the best among best alignments of the
  sequences up to that point, plus the score for
  aligning the two additional bases.

18
Dynamic Programming

• Consider the best alignment score of two
  sequences s, t at base/residue i1, j1,
  respectively

19
Dynamic Programming

• The best alignment must be in one of three cases
• 1. Last position is (si1,tj 1 )
• 2. Last position is (-, tj 1 )
• 3. Last position is (si 1,-)

20
Dynamic Programming

• The best alignment must be in one of three cases
• 1. Last position is (si1,tj 1 )
• 2. Last position is (-, tj 1 )
• 3. Last position is (si 1,-)

21
Dynamic Programming

• The best alignment must be in one of three cases
• 1. Last position is (si1,tj 1 )
• 2. Last position is (-, tj 1 )
• 3. Last position is (si 1,-)

22
Dynamic Programming
23
Dynamic Programming

• Of course, we first need to handle the base cases
  in the recursion

24
Dynamic Programming
A G C A A A C
We fill the matrix using the recurrence rule
25
Dynamic Programming
26
Dynamic Programming
Conclusion d(AAAC,AGC) -1
27
Reconstructing the Best Alignment
AAAC AG-C
28
More than one best alignment
AAAC A-GC
29
Complexity

• Space O(mn)
• Time O(mn)
• Filling the matrix O(mn)
• Backtrace O(mn)

30
Needleman Wunsch (1970)

• A General Method Applicable to the Search for
  Similarities in the Amino Acid Sequence of Two
  Proteins
• J. Mol. Biol. 48 443-453

31
Local Alignment

• We just introduced global alignment
• Now introduce local alignment
• A local Alignment between sequence s and sequence
  t is an alignment with maximum similarity between
  a substring of s and a substring of t.

32
Smith and Waterman (1981)

• Identification of Common Molecular Subsequences

• J. Mol. Biol., 147195-197

33
Best-aligned Subsequences
The best score or start over
34

• Note different scoring rule

35
(No Transcript)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
Best aligned subsequences
