Real-time Text Mining for the Biomedical Literature

1
Real-time Text Mining for the Biomedical
Literature a collaboration between Discovery Net
myGrid
Rob Gaizauskas Department of Computer
Science University of Sheffield
Moustafa M. Ghanem Department of
Computing Imperial College London
2
Outline

• Context
• Workflows, Services and Text Mining
• Discovery Net myGrid
• Aims and Objectives of New Project
• Architecture of New System
• Integration of Existing Components
• Approach to Text Mining
• Data Resources Evaluation
• Techniques for Go Tagging
• Interface and Results Presentation
• Lessons Learnt So far, Conclusions and Broader
  Applicability of Work

3
Workflows, Web Services and Text Mining for
Bioinformatics

• Workflows
• useful computational models for processes that
  require repeated execution of a series of complex
  analytical tasks
• e.g. biologist researching genetic basis of a
  disease repeatedly
• maps reactive spot in microarray data to gene
  sequence
• uses a sequence alignment tool to find
  proteins/DNA of similar structure
• mines info about these homologues from remote DBs
• annotates unknown gene sequence with this
  discovered info

4
Workflows, Web Services and Text Mining for
Bioinformatics

• Web services
• Processing resources that are
• available via the Internet
• use standardised messaging formats, such as XML
• enable communication between applications without
  being tied to a particular operating
  system/programming language
• Useful for bioinformatics where data used in
  research is
• heterogeneous in nature DB records, numerical
  results, NL texts
• distributed across the internet in research
  institutions around the world
• available on a variety of platforms and via
  non-uniform interfaces

5
Workflows, Web Services and Text Mining for
Bioinformatics

• Text mining
• any process of revealing information
  regularities, patterns or trends in textual
  data
• includes more established research areas such as
  information extraction (IE), information
  retrieval (IR), natural language processing
  (NLP), knowledge discovery from databases (KDD)
  and traditional data mining (DM)
• relevant to bioinformatics because of
• explosive growth of biomedical literature
• availability of some information in textual form
  only, e.g. clinical records

6
Workflows, Web Services and Text Mining for
Bioinformatics
7
Discovery Net myGrid

• Discovery Net An e-Science testbed for High
  Throughput Informatics
• 2.2M EPSRC Pilot Project
• Started Oct 01, Ended in March 05
• Service-based infrastructure/workflow model for
  Life Sciences, Environmental Modelling and
  Geo-hazard Modelling
• Infrastructure for mixed data mining / text
  mining
• Machine learning methods for text mining
• myGrid Directly Supporting the e-Scientist
• 3.5M EPSRC Pilot Project
• Started Oct 01, Ends June 05
• Service-based infrastructure/workflow model for
  Life Sciences
• Infrastructure for Text Collection Server, Text
  Services Workflow Server and Interface/Browsing
  Client
• Service-based Terminology Servers

8
myGrid

• Overall aim develop an e-biologists workbench
  a platform allowing biologists to execute,
  analyze, repeat multi-stage in silico experiments
  involving distributed data, code and processing
  resources
• Workflow model for composing/executing processing
  components
• Web services for distribution
• Problem how to integrate text mining into a
  biological workflow?
• Most text mining runs off-line and supports
  interactive browsing of results
• Most workflows run end to end with no user
  intervention
• What are the inputs to text mining to be?
• Solution tap off result of a workflow step and
  treat as implicit query

9
A myGrid example studying the Genetic Basis of
Disease

• Graves Disease
• an autoimmune condition affecting tissues in the
  thyroid and orbit
• being investigated using the micro-array methods
• micro-array shows which genes are differentially
  expressed in normal patients vs patients with
  the disease candidate genes
• sequence alignment search (e.g. BLAST) finds
  genes/proteins with similar structure
• function of these homologues may suggest
  function of candidate gene
• key step for text mining follows BLAST search
• for homologous proteins BLAST report contains
  references to proteins in SWISSPROT protein
  database
• Swissprot records contain ids of abstracts
  describing the protein in Medline abstract
  database
• abstracts can be mined directly or used as
  seed'' documents to assemble a set of related
  abstracts

10
myGrid Text Services Architecture
11
myGrid Text Services Architecture

• 3-way division of labour sensible way to deliver
  distributed text mining services
• Providers of e-archives, such as Medline, will
  make archives available via web-services
  interface
• Cannot offer tailored sevices for every
  application
• Will provide core, common services
• Specialist workflow designers will add value to
  basic services from archive to meet their
  organizations needs
• Users will prefer to execute predefined workflows
  via standard light clients such as a browser
• Architecture appropriate for many research areas,
  not just bioinformatics

12
myGrid Interface/Browsing Client
13
Discovery Net Adding text mining to e-Science
workflows

• DNet Workflow server executes DPML workflow and
  uses Discovery Nets InfoGrid data access and
  integration wrappers and web services

14
Text Mining in e-Science workflows

• Problem how to develop new distributed text
  mining applications using a workflow?
• Most text mining applications require the
  integration of a mixture of components (Services)
  for text processing tasks (e.g. parsing and
  cleaning), natural language processing (e.g.
  named entity recognition), statistics and data
  mining (e.g. classification, clustering, etc).
• There are many design alternatives and end users
  may want to prototype and compare alternative
  implementations.
• Once application developed, most workflows run
  end to end with no user intervention
• Solution Extend service infrastructure to allow
  composition of text mining services.

15
Building text mining applications from workflows
Using workflow technologies to build text mining
applications and services using finer grain
components/services
Text Mining Pipelines
Features are summarized into vector forms which
are suitable for data mining
Results can be document characterization or
hidden relationship extraction
Pre-process documents to enhance the ease of
feature extraction
Retrieve and organize relevant documents
16
Simplified Document Classification Workflow
Predictive Accuracy of Relevance prediction,
using Support Vector Machine classification Ove
rall accuracy 84.5 Precision 78.11 Recall
73.40
17
Text Meta Data Model
Build Classifier training phase using workflow
co-ordinating distributed services Build
Prediction phase using workflow co-ordinating
distributed services Metadata Model Service
Interfaces only tell you how to invoke remote
service but it is up to you to decide what
information flows between services !
18
Aims Objectives of New Project

• Aim to develop a unified real-time e-Science
  text-mining infrastructure that leverages the
  technologies and methods developed by both
  Discovery Net and myGrid
• Software engineering challenge integrate
  complementary service-based text mining
  capabilities with different metadata models into
  a single framework
• Application challenge annotate biomedical
  abstracts with semantic categories from the Gene
  Ontology
• Deliverables
• D1 A GO Annotation Service
• D2 A Generic Shared Infrastructure for
  Grid-enabled Biomedical Document Categorization
• D3 Infrastructure for Semantic Document
  Annotation
• D4 A Detailed Case Study (analysing/evaluating
  the GO annotator)
• D5 Developing a common framework for
  representing exchanging information about
• 1. Data biomedical documents/doc collections
  metadata, biomedical dictionaries
• 2. Intermediate data Document indexes and
  Document feature vectors
• 3. Text Analysis Results

19
Go TAG A Novel Application

• The GO TAG Application Automatic Assignment of
  GO (Gene Ontology) Codes to Medline Documents

20
A Machine Learning Approach
21
Run-time System
22
GO Annotator Version 1

• Version 1a
• Direct search for GO Annotation descriptions and
  synonyms in document text
• If description is found, document is labelled
  with this GO Annotation
• Description is also marked-up in document
• Version 1b
• 1a search for gene names extracted from yeast
  genome DB
• If gene name found, document labelled with GO
  annotation(s) associated with gene in DB
• Gene name also marked up in document
• Termino web-service, hosted at Sheffield,
  provides lookup capability
• This is wrapped in a DiscoveryNet workflow to
  include PubMed query, results visualization and
  performance calculations
• Workflow is deployed as a web application for end
  users which includes applet to interactively
  browse results

23
GO Annotator Version 1Underlying Discovery Net
Workflow
24
GO Annotator Version 1Underlying Discovery Net
Workflow
Enter query and retrieve abstracts from PubMed.
25
GO Annotator Version 1Underlying Discovery Net
Workflow
Use Termino to mark-up abstracts with GO
Annotations when match for GO Annotation
description is found.
26
GO Annotator Version 1Underlying Discovery Net
Workflow
Tabulate GO Annotations by PMID.
27
GO Annotator Version 1Underlying Discovery Net
Workflow
Join PMIDs and matching GO Annotations with
abstracts and titles.
28
Workflow Deployment
29
GO Annotator Version 2

• Use Saccharomyces (Yeast) Genome Database as
  source of papers expertly curated with GO
  Annotations
• Train classifier using these papers
• Hierarchical classification
• Training data sufficient to classify over 2000 GO
  Annotations
• Classifier is then applied to assign unseen
  papers with GO Annotations
• Main Issues
• Choice of features to be extracted from the
  training documents
• Choice of feature reduction methods to produce
  accurate classification
• Choice of classification algorithm to be used?

30
GO Annotator Version 2Underlying Discovery Net
Workflow
31
GO Annotator Version 2Underlying DiscoveryNet
Workflow
Papers expertly curated with GO Annotations from
SGD database.
32
GO Annotator Version 2Underlying Discovery Net
Workflow
Generate vector of features (frequent phrases)
for each paper. This is used to train classifier.
33
GO Annotator Version 2Underlying Discovery Net
Workflow
Generate a Naïve Bayesian classification model.
34
GO Annotator Version 2Underlying Discovery Net
Workflow
Generate vector of features (frequent phrases)
for each paper in test data set. This is used to
test the classifier.
35
GO Annotator Version 2Underlying Discovery Net
Workflow
Apply classification model to test data to
evaluate classification accuracy.
36
Interface Results Presentation
37
Achievements to date

• Infrastructure Interoperability
• More than just remote web service invocation
  interoperable metadata models
• Mark 1 System Implemented
• Annotation based on terminology lookups
• 15 Recall 5 Precision (Exact matches for
  18,000 GO terms)
• Measures inadequate due to incompleteness of gold
  standard
• In process of Finalising Training Data Sets and
  Evaluation Metrics
• 4,922 papers referencing 2,455 GO Terms
• Mark 2 Systems in Progress
• Naïve Bayesian Approach
• 41 Recall and 27 Precision
• User Interfaces
• Mark 3, 4, Systems and Evaluation

38
Implementation Options

• Feature Vector Options
• Bag of words
• Frequent Phrases
• Key Phrases (Gene Names, Protein Names, MeSH
  terms, etc).
• Classifier Options
• Bayesian Classifiers
• Support Vector Machines
• Drag Push (a novel centroid based method)

39
Lessons Learnt and Challenges to Face

• Infrastructure
• Interoperability Issues
• Performance Issues
• Communication vs Persistence of remote server
• Off-line vs on-line feature extraction
• Text Mining
• Usability Issues
• Evaluation Issues
