Cyberinfrastructure Technologies and Applications

1
Cyberinfrastructure Technologies and Applications

• Summit on Cyberinfrastructure Innovation At Work

• Banff Springs Hotel
• Banff Canada October 11 2007
• Geoffrey Fox
• Computer Science, Informatics, Physics
• Pervasive Technology Laboratories
• Indiana University Bloomington IN 47401
• http//grids.ucs.indiana.edu/ptliupages/presentati
  ons/
• gcf_at_indiana.edu http//www.infomall.org

2
e-moreorlessanything

• e-Science is about global collaboration in key
  areas of science, and the next generation of
  infrastructure that will enable it. from its
  inventor John Taylor Director General of Research
  Councils UK, Office of Science and Technology
• e-Science is about developing tools and
  technologies that allow scientists to do faster,
  better or different research
• Similarly e-Business captures an emerging view of
  corporations as dynamic virtual organizations
  linking employees, customers and stakeholders
  across the world.
• This generalizes to e-moreorlessanything
  including presumably e-AlbertaEnterprise and
  e-oilandgas, e-geoscience .
• A deluge of data of unprecedented and inevitable
  size must be managed and understood.
• People (see Web 2.0), computers, data (including
  sensors and instruments) must be linked.
• On demand assignment of experts, computers,
  networks and storage resources must be supported

2
3
What is Cyberinfrastructure

• Cyberinfrastructure is (from NSF) infrastructure
  that supports distributed science (e-Science)
  data, people, computers
• Clearly core concept more general than Science
• Exploits Internet technology (Web2.0) adding (via
  Grid technology) management, security,
  supercomputers etc.
• It has two aspects parallel low latency
  (microseconds) between nodes and distributed
  highish latency (milliseconds) between nodes
• Parallel needed to get high performance on
  individual large simulations, data analysis etc.
  must decompose problem
• Distributed aspect integrates already distinct
  components especially natural for data
• Cyberinfrastructure is in general a distributed
  collection of parallel systems
• Cyberinfrastructure is made of services
  (originally Web services) that are just
  programs or data sources packaged for distributed
  access

3
4
Underpinnings of Cyberinfrastructure

• Distributed software systems are being
  revolutionized by developments from e-commerce,
  e-Science and the consumer Internet. There is
  rapid progress in technology families termed Web
  services, Grids and Web 2.0
• The emerging distributed system picture is of
  distributed services with advertised interfaces
  but opaque implementations communicating by
  streams of messages over a variety of protocols
• Complete systems are built by combining either
  services or predefined/pre-existing collections
  of services together to achieve new capabilities
• As well as Internet/Communication revolutions
  (distributed systems), multicore chips will
  likely be hugely important (parallel systems)
• Industry not academia is leading innovation in
  these technologies

5
Service or Web Service Approach

• One uses GML, CML etc. to define the data
  structure in a system and one uses services to
  capture methods or programs
• In eScience, important services fall in three
  classes
• Simulations
• Data access, storage, federation, discovery
• Filters for data mining and manipulation
• Services could use something like WSDL (Web
  Service Definition Language) to define
  interoperable interfaces but Web 2.0 follows old
  library practice one just specifies interface
• Service Interface (WSDL) establishes a contract
  independent of implementation between two
  services or a service and a client
• Services should be loosely coupled which normally
  means they are coarse grain
• Services will be composed (linked together) by
  mashups (typically scripts) or workflow (often
  XML BPEL)
• Software Engineering and Interoperability/Standard
  s are closely related

6
Computing and Cyberinfrastructure TeraGrid
TeraGrid resources include more than 250
teraflops of computing capability and more than
30 petabytes of online and archival data storage,
with rapid access and retrieval over
high-performance networks. TeraGrid is
coordinated at the University of Chicago, working
with the Resource Provider sites Indiana
University, Oak Ridge National Laboratory,
National Center for Supercomputing Applications,
Pittsburgh Supercomputing Center, Purdue
University, San Diego Supercomputer Center, Texas
Advanced Computing Center, University of
Chicago/Argonne National Laboratory, and the
National Center for Atmospheric Research.
Grid Infrastructure Group (UChicago)
UW
PSC
UC/ANL
NCAR
PU
NCSA
UNC/RENCI
IU
Caltech
ORNL
USC/ISI
SDSC
TACC
Resource Provider (RP)
Software Integration Partner
7
Data and Cyberinfrastructure

• DIKW Data ? Information ? Knowledge ? Wisdom
  transformation
• Applies to e-Science, Distributed Business
  Enterprise (including outsourcing), Military
  Command and Control and general decision support
• (SOAP or just RSS) messages transport information
  expressed in a semantically rich fashion between
  sources and services that enhance and transform
  information so that complete system provides
• Semantic Web technologies like RDF and OWL might
  help us to have rich expressivity but they might
  be too complicated
• We are meant to build application specific
  information management/transformation systems for
  each domain
• Each domain has Specific Services/Standards (for
  APIs and Information such as KML and GML for
  Geographical Information Systems)
• and will use Generic Services (like R for
  datamining) and
• Generic Standards (such as RDF, WSDL)
• Standards made before consensus or not observant
  of technology progress are dubious

8
Information and Cyberinfrastructure
Raw Data ? Data ? Information ?
Knowledge ? Wisdom
AnotherGrid
Decisions
AnotherGrid
SS
SS
SS
SS
FS
FS
OS
MD
MD
FS
Portal
FS
OS
OS
OS
OS
Inter-Service Messages
FS
FS
FS
FS
AnotherService
FS
MD
MD
OS
MD
OS
OS
FS
Other Service
FS
FS
FS
FS
OS
MD
OS
OS
FS
FS
FS
MD
MD
FS
Filter Service
OS
FS
MetaData
AnotherGrid
FS
FS
FS
MD
Sensor Service
SS
SS
SS
SS
SS
SS
SS
SS
SS
SS
AnotherService
9
Information Cyberinfrastructure Architecture

• The Party Line approach to Information
  Infrastructure is clear one creates a
  Cyberinfrastructure consisting of distributed
  services accessed by portals/gadgets/gateways/RSS
  feeds
• Services include
• Computing
• original data
• Transformations or filters implementing DIKW
  (Data Information Knowledge Wisdom) pipeline
• Final Decision Support step converting wisdom
  into action
• Generic services such as security, profiles etc.
• Some filters could correspond to large
  simulations
• Infrastructure will be set up as a System of
  Systems (Grids of Grids)
• Services and/or Grids just accept some form of
  DIKW and produce another form of DIKW
• Original data has no explicit input just output

10
Virtual Observatory Astronomy GridIntegrate
Experiments
Radio
Far-Infrared
Visible
Dust Map
Visible X-ray
Galaxy Density Map
11
(No Transcript)
12
CReSIS PolarGrid

• Important CReSIS-specific Cyberinfrastructure
  components include
• Managed data from sensors and satellites
• Data analysis such as SAR processing possibly
  with parallel algorithms
• Electromagnetic simulations (currently commercial
  codes) to design instrument antennas
• 3D simulations of ice-sheets (glaciers) with
  non-uniform meshes
• GIS Geographical Information Systems
• Also need capabilities present in many Grids
• Portal i.e. Science Gateway
• Submitting multiple sequential or parallel jobs
• The need for three distinct types of components
  Continental USA with multiple base and field
  camps
• Base and field camps must be power efficient
• Terrible connectivity from base and field camps
  to Continental subGrid

13
CICC Chemical Informatics and Cyberinfrastructure
Collaboratory Web Service Infrastructure
Portal Services RSS Feeds User
Profiles Collaboration as in Sakai
Core Grid Services Service Registry Job
Submission and Management Local Clusters IU
Big Red, TeraGrid, Open Science Grid
14
Process Chemistry-Biology Interaction Data from
HTS (High Throughput Screening)
Percent Inhibition or IC50 data is retrieved from
HTS
Scientists at IU prefer Web 2.0 to Grid/Web
Service for workflow
Grids can link data analysis ( e.g image
processing developed in existing Grids),
traditional Chem-informatics tools, as well as
annotation tools (Semantic Web, del.icio.us) and
enhance lead ID and SAR analysis A Grid of Grids
linking collections of services atPubChem ECCR
centers MLSCN centers
Workflows encoding plate control well
statistics, distribution analysis, etc
Question Was this screen successful?
Workflows encoding distribution analysis of
screening results
Question What should the active/inactive cutoffs
be?

Question What can we learn about the target
protein or cell line from this screen?
Workflows encoding statistical comparison of
results to similar screens, docking of compounds
into proteins to correlate binding, with
activity, literature search of active compounds,
etc
Compound data submitted to PubChem
CHEMINFORMATICS
PROCESS
GRIDS
15
People and Cyberinfrastructure Web 2.0

• Web 2.0 has tools (sites) and technologies
• Technologies (later) are competition for Grids
  and Web Services
• Sites (below) are the best way to integrate
  people into Cyberinfrastructure
• Kazaa, Instant Messengers, Skype, Napster,
  BitTorrent for P2P Collaboration text,
  audio-video conferencing, files
• del.icio.us, Connotea, Citeulike, Bibsonomy,
  Biolicious manage shared bookmarks
• MySpace, YouTube, Bebo, Hotornot, Facebook, or
  similar sites allow you to create (upload)
  community resources and share them Friendster,
  LinkedIn create networks
• http//en.wikipedia.org/wiki/List_of_social_networ
  king_websites
• Writely, Wikis and Blogs are powerful specialized
  shared document systems
• Google Scholar and Windows Live Academic Search
  tells you who has cited your papers while
  publisher sites tell you about co-authors

16
Best Web 2.0 Sites -- 2006

• Extracted from http//web2.wsj2.com/
• Social Networking
• Start Pages
• Social Bookmarking
• Peer Production News
• Social Media Sharing
• Online Storage (Computing)

16
17
Web 2.0 Systems are Portals, Services, Resources

• Captures the incredible development of
  interactive Web sites enabling people to create
  and collaborate

18
Web 2.0 and Web Services I

• Web Services have clearly defined protocols
  (SOAP) and a well defined mechanism (WSDL) to
  define service interfaces
• There is good .NET and Java support
• The so-called WS- specifications provide a rich
  sophisticated but complicated standard set of
  capabilities for security, fault tolerance,
  meta-data, discovery, notification etc.
• Narrow Grids build on Web Services and provide
  a robust managed environment with growing
  adoption in Enterprise systems and distributed
  science (so called e-Science)
• Web 2.0 supports a similar architecture to Web
  services but has developed in a more chaotic but
  remarkably successful fashion with a service
  architecture with a variety of protocols
  including those of Web and Grid services
• Over 500 Interfaces defined at http//www.programm
  ableweb.com/apis
• Web 2.0 also has many well known capabilities
  with Google Maps and Amazon Compute/Storage
  services of clear general relevance
• There are also Web 2.0 services supporting novel
  collaboration modes and user interaction with the
  web as seen in social networking sites, portals,
  MySpace, YouTube,

19
Web 2.0 and Web Services II

• I once thought Web Services were inevitable but
  this is no longer clear to me
• Web services are complicated, slow and non
  functional
• WS-Security is unnecessarily slow and pedantic
  (canonicalization of XML)
• WS-RM (Reliable Messaging) seems to have poor
  adoption and doesnt work well in collaboration
• WSDM (distributed management) specifies a lot
• There are de facto standards like Google Maps and
  powerful suppliers like Google which define the
  rules
• One can easily combine SOAP (Web Service) based
  services/systems with HTTP messages but the
  lowest common denominator suggests additional
  structure/complexity of SOAP will not easily
  survive

20
Applications, Infrastructure, Technologies

• The discussion is confused by inconsistent use of
  terminology this is what I mean
• Multicore, Narrow and Broad Grids and Web 2.0
  (Enterprise 2.0) are technologies
• These technologies combine and compete to build
  infrastructures termed e-infrastructure or
  Cyberinfrastructure
• Although multicore can and will support
  standalone clients probably most important
  client and server applications of the future will
  be internet enhanced/enabled so key aspect of
  multicore is its role and integration in
  e-infrastructure
• e-moreorlessanything is an emerging application
  area of broad importance that is hosted on the
  infrastructures e-infrastructure or
  Cyberinfrastructure

21
Some Web 2.0 Activities at IU

• Use of Blogs, RSS feeds, Wikis etc.
• Use of Mashups for Cheminformatics Grid workflows
• Moving from Portlets to Gadgets in portals (or at
  least supporting both)
• Use of Connotea to produce tagged document
  collections such as http//www.connotea.org/user/c
  rmc for parallel computing
• Semantic Research Grid integrates multiple
  tagging and search systems and copes with
  overlapping inconsistent annotations
• MSI-CIEC portal augments Connotea to tag a mix of
  URL and URIs e.g. NSF TeraGrid use, PIs and
  Proposals
• Hopes to support collaboration (for Minority
  Serving Institution faculty)

22
Use blog to create posts.
Display blog RSS feed in MediaWiki.
23
Semantic Research Grid (SRG) Architecture
8/3/2018
23
24
MSI-CIEC Portal
MSI-CIEC Minority Serving Institution
CyberInfrastructure Empowerment Coalition
25
Mashups v Workflow?

• Mashup Tools are reviewed at http//blogs.zdnet.co
  m/Hinchcliffe/?p63
• Workflow Tools are reviewed by Gannon and Fox
  http//grids.ucs.indiana.edu/ptliupages/publicatio
  ns/Workflow-overview.pdf

• Both include scripting in PHP, Python, sh etc. as
  both implement distributed programming at level
  of services
• Mashups use all types of service interfaces and
  perhaps do not have the potential robustness
  (security) of Grid service approach
• Mashups typically pure HTTP (REST)

25
26
Grid Workflow Datamining in Earth Science

• Work with Scripps Institute
• Grid services controlled by workflow process real
  time data from 70 GPS Sensors in Southern
  California

NASA GPS
Earthquake
26
27
Grid Workflow Data Assimilation in Earth Science

• Grid services triggered by abnormal events and
  controlled by workflow process real time data
  from radar and high resolution simulations for
  tornado forecasts

Typical graphical interface to service composition
28
Web 2.0 uses all types of Services

• Here a Gadget Mashup uses a 3 service workflow
  with a JavaScript Gadget Client

28
29
Web 2.0 Mashups and APIs

• http//www.programmableweb.com/apis has (Sept 12
  2007) 2312 Mashups and 511 Web 2.0 APIs and with
  GoogleMaps the most often used in Mashups
• The Web 2.0 UDDI (service registry)

30
The List of Web 2.0 APIs

• Each site has API and its features
• Divided into broad categories
• Only a few used a lot (49 APIs used in 10 or
  more mashups)
• RSS feed of new APIs
• Amazon S3 growing in popularity

31
Grid-style portal as used in Earthquake Grid

• The Portal is built from portlets providing
  user interface fragments for each service that
  are composed into the full interface uses OGCE
  technology as does planetary science VLAB portal
  with University of Minnesota

Now to Portals
31
32
Portlets v. Google Gadgets

• Portals for Grid Systems are built using portlets
  with software like GridSphere integrating these
  on the server-side into a single web-page
• Google (at least) offers the Google sidebar and
  Google home page which support Web 2.0 services
  and do not use a server side aggregator
• Google is more user friendly!
• The many Web 2.0 competitions is an interesting
  model for promoting development in the world-wide
  distributed collection of Web 2.0 developers
• I guess Web 2.0 model will win!

32
33
Typical Google Gadget Structure

• Lots of HTML and JavaScript lt/Contentgt lt/Modulegt

Portlets build User Interfaces by combining
fragments in a standalone Java Server Google
Gadgets build User Interfaces by combining
fragments with JavaScript on the client
34
Web 2.0 v Narrow Grid I

• Web 2.0 and Grids are addressing a similar
  application class although Web 2.0 has focused on
  user interactions
• So technology has similar requirements
• Web 2.0 chooses simplicity (REST rather than
  SOAP) to lower barrier to everyone participating
• Web 2.0 and Parallel Computing tend to use
  traditional (possibly visual) (scripting)
  languages for equivalent of workflow whereas
  Grids use visual interface backend recorded in
  BPEL
• Web 2.0 and Grids both use SOA Service Oriented
  Architectures
• System of Systems Grids and Web 2.0 are likely
  to build systems hierarchically out of smaller
  systems
• We need to support Grids of Grids, Webs of Grids,
  Grids of Services etc. i.e. systems of systems of
  all sorts

34
35
Web 2.0 v Narrow Grid II

• Web 2.0 has a set of major services like
  GoogleMaps or Flickr but the world is composing
  Mashups that make new composite services
• End-point standards are set by end-point owners
• Many different protocols covering a variety of
  de-facto standards
• Narrow Grids have a set of major software systems
  like Condor and Globus and a different world is
  extending with custom services and linking with
  workflow
• Popular Web 2.0 technologies are PHP, JavaScript,
  JSON, AJAX and REST with Start Page e.g.
  (Google Gadgets) interfaces
• Popular Narrow Grid technologies are Apache Axis,
  BPEL WSDL and SOAP with portlet interfaces
• Robustness of Grids demanded by the Enterprise?
• Not so clear that Web 2.0 wont eventually
  dominate other application areas and with
  Enterprise 2.0 its invading Grids

36
Web 2.0 v Narrow Grid III

• Narrow Grids have a strong emphasis on standards
  and structure Web 2.0 lets a 1000 flowers
  (protocols) and a million developers bloom and
  focuses on functionality, broad usability and
  simplicity
• Semantic Web/Grid has structure to allow
  reasoning
• Annotation in sites like del.icio.us and
  uploading to MySpace/YouTube is unstructured and
  free text search replaces structured ontologies
• Portals are likely to feature both Web and
  desktop client technology although it is
  possible that Web approach will be adopted more
  or less uniformly
• Web 2.0 has a very active portal activity which
  has similar architecture to Grids
• A page has multiple user interface fragments
• Web 2.0 user interface integration is typically
  Client side using Gadgets AJAX and JavaScript
  while
• Grids are in a special JSR168 portal server side
  using Portlets WSRP and Java

36
37
The Ten areas covered by the 60 core WS-
Specifications
WS- Specification Area Typical Grid/Web Service Examples
1 Core Service Model XML, WSDL, SOAP
2 Service Internet WS-Addressing, WS-MessageDelivery Reliable Messaging WSRM Efficient Messaging MOTM
3 Notification WS-Notification, WS-Eventing (Publish-Subscribe)
4 Workflow and Transactions BPEL, WS-Choreography, WS-Coordination
5 Security WS-Security, WS-Trust, WS-Federation, SAML, WS-SecureConversation
6 Service Discovery UDDI, WS-Discovery
7 System Metadata and State WSRF, WS-MetadataExchange, WS-Context
8 Management WSDM, WS-Management, WS-Transfer
9 Policy and Agreements WS-Policy, WS-Agreement
10 Portals and User Interfaces WSRP (Remote Portlets)
38
WS- Areas and Web 2.0
WS- Specification Area Web 2.0 Approach
1 Core Service Model XML becomes optional but still useful SOAP becomes JSON RSS ATOM WSDL becomes REST with API as GET PUT etc. Axis becomes XmlHttpRequest
2 Service Internet No special QoS. Use JMS or equivalent?
3 Notification Hard with HTTP without polling JMS perhaps?
4 Workflow and Transactions (no Transactions in Web 2.0) Mashups, Google MapReduce Scripting with PHP JavaScript .
5 Security SSL, HTTP Authentication/Authorization, OpenID is Web 2.0 Single Sign on
6 Service Discovery http//www.programmableweb.com
7 System Metadata and State Processed by application no system state Microformats are a universal metadata approach
8 ManagementInteraction WS-Transfer style Protocols GET PUT etc.
9 Policy and Agreements Service dependent. Processed by application
10 Portals and User Interfaces Start Pages, AJAX and Widgets(Netvibes) Gadgets
39
Too much Computing?

• Historically one has tried to increase computing
  capabilities by
• Optimizing performance of codes
• Exploiting all possible CPUs such as Graphics
  co-processors and idle cycles
• Making central computers available such as
  NSF/DoE/DoD supercomputer networks
• Next Crisis in technology area will be the
  opposite problem commodity chips will be
  32-128way parallel in 5 years time and we
  currently have no idea how to use them
  especially on clients
• Only 2 releases of standard software (e.g.
  Office) in this time span
• Gaming and Generalized decision support (data
  mining) are two obvious ways of using these
  cycles
• Intel RMS analysis
• Note even cell phones will be multicore
• There is Too much data as well as Too much
  computing but unclear implications

40
Intels Projection
41
RMS Recognition Mining Synthesis
Recognition
Mining
Synthesis
Is it ?
What is ?
What if ?
Find a model instance
Create a model instance
Model
Model-less
Real-time streaming and transactions on static
structured datasets
Very limited realism
Model-based multimodal recognition
Real-time analytics on dynamic,
unstructured, multimodal datasets
Photo-realism and physics-based animation
42
Recognition
Mining
Synthesis
What is a tumor?
Is there a tumor here?
What if the tumor progresses?
It is all about dealing efficiently with complex
multimodal datasets
Images courtesy http//splweb.bwh.harvard.edu800
0/pages/images_movies.html
43
Intels Application Stack
44
Multicore SALSA at IU

• Service Aggregated Linked Sequential Activities
• http//www.infomall.org/multicore
• Aims to link parallel and distributed (Grid)
  computing by developing parallel applications as
  services and not as programs or libraries
• Improve traditionally poor parallel programming
  development environments
• Can use messaging to link parallel and Grid
  services but performance functionality
  tradeoffs different
• Parallelism needs few µs latency for message
  latency and thread spawning
• Network overheads in Grid 10-100s µs
• Developing Service (library) of multicore
  parallel data mining algorithms

45
Microsoft CCR for Parallelism

• Use Microsoft CCR/DSS where DSS is
  mash-up/workflow service model built from CCR and
  CCR supports MPI or Dynamic threads
• CCR Supports exchange of messages between threads
  using named ports
• FromHandler Spawn threads without reading ports
• Receive Each handler reads one item from a
  single port
• MultipleItemReceive Each handler reads a
  prescribed number of items of a given type from a
  given port. Note items in a port can be general
  structures but all must have same type.
• MultiplePortReceive Each handler reads a one
  item of a given type from multiple ports.
• JoinedReceive Each handler reads one item from
  each of two ports. The items can be of different
  type.
• Choice Execute a choice of two or more
  port-handler pairings
• Interleave Consists of a set of arbiters (port
  -- handler pairs) of 3 types that are Concurrent,
  Exclusive or Teardown (called at end for clean
  up). Concurrent arbiters are run concurrently but
  exclusive handlers are
• http//msdn.microsoft.com/robotics/

45
46
Timing of HP Opteron Multicore as a function of
number of simultaneous two-way service messages
processed (November 2006 DSS Release)
DSS Service Measurements

• Measurements of Axis 2 shows about 500
  microseconds DSS is 10 times better

46
47
MPI Exchange Latency in µs (20-30 µs computation between messaging) MPI Exchange Latency in µs (20-30 µs computation between messaging) MPI Exchange Latency in µs (20-30 µs computation between messaging) MPI Exchange Latency in µs (20-30 µs computation between messaging) MPI Exchange Latency in µs (20-30 µs computation between messaging) MPI Exchange Latency in µs (20-30 µs computation between messaging)
Machine OS Runtime Grains Parallelism MPI Exchange Latency
Intel8cgf12 (8 core 2.33 Ghz) (in 2 chips) Redhat MPJE (Java) Process 8 181
Intel8cgf12 (8 core 2.33 Ghz) (in 2 chips) Redhat MPICH2 (C) Process 8 40.0
Intel8cgf12 (8 core 2.33 Ghz) (in 2 chips) Redhat MPICH2 Fast Process 8 39.3
Intel8cgf12 (8 core 2.33 Ghz) (in 2 chips) Redhat Nemesis Process 8 4.21
Intel8cgf20 (8 core 2.33 Ghz) Fedora MPJE Process 8 157
Intel8cgf20 (8 core 2.33 Ghz) Fedora mpiJava Process 8 111
Intel8cgf20 (8 core 2.33 Ghz) Fedora MPICH2 Process 8 64.2
Intel8b (8 core 2.66 Ghz) Vista MPJE Process 8 170
Intel8b (8 core 2.66 Ghz) Fedora MPJE Process 8 142
Intel8b (8 core 2.66 Ghz) Fedora mpiJava Process 8 100
Intel8b (8 core 2.66 Ghz) Vista CCR (C) Thread 8 20.2
AMD4 (4 core 2.19 Ghz) XP MPJE Process 4 185
AMD4 (4 core 2.19 Ghz) Redhat MPJE Process 4 152
AMD4 (4 core 2.19 Ghz) Redhat mpiJava Process 4 99.4
AMD4 (4 core 2.19 Ghz) Redhat MPICH2 Process 4 39.3
AMD4 (4 core 2.19 Ghz) XP CCR Thread 4 16.3
Intel4 (4 core 2.8 Ghz) XP CCR Thread 4 25.8
48
Clustering algorithm annealing by decreasing
distance scale and gradually finds more clusters
as resolution improved Here we see 10 increasing
to 30 as algorithm progresses
49
Parallel Multicore Clustering (C on Windows)
Parallel Overheadon 8 Threads running on Intel 8
core Speedup 8/(1Overhead)
10 Clusters
Overhead Constant1 Constant2/n Constant1
0.05 to 0.1 (Client Windows) due to
threadruntime fluctuations
20 Clusters
10000/(Grain Size n points per core)
50
We use DSS as Service Framework as Integrated
with CCR Supporting MPI/Threading
51
Intel 8-core C with 80 Clusters Vista Run Time
Fluctuations for Clustering Kernel

• 2 Quadcore Processors
• This is average of standard deviation of run time
  of the 8 threads between messaging
  synchronization points

52
Intel 8 core with 80 Clusters Redhat Run Time
Fluctuations for Clustering Kernel

• This is average of standard deviation of run time
  of the 8 threads between messaging
  synchronization points

Standard Deviation/Run Time
Number of Threads
53
What should one do?

• i.e. How does one Cyberinfrastructure enable a
  given area/application XYZ
• As computing free, focus on identifying
  data/information/knowledge/wisdom needed (there
  is probably too much data but not so much wisdom
  in DIKW pipeline)
• Should we care just about original data or also
  about the whole pipeline DIKW?
• Scope out supercomputer/computer services needed
  and exploit OGF standards
• Identify services (filters, often data mining)
  needed by XYZ?
• Will we need parallel implementations of filters
  if so use multicore compatible frameworks
• Identify standards for application XYZ
• Set up distributed XYZ Services
• Use Web 2.0 (as it makes things easier) not
  current Grids (which makes things harder)
• Build a Programmable XYZ Web
• Emphasize Simplicity
• Is Secrecy important and in fact viable? Often
  important but hard
• What are synergies of XYZ to pervasive
  capabilities such as Web 2.0 sites, National
  resources like TeraGrid, and Personal aides in
  an information rich world (future of PC) ?
