Photons and Neutrinos Originating from Accelerated Protons in GRBs

1
Photons and Neutrinos Originating from
Accelerated Protons in GRBs

• Katsuaki ASANO
• (National Astronomical Observatory of Japan)

Collaborators S.Inoue, S.Nagataki, F.Takahara
2
Abstract
We show results of our Monte Carlo Simulation.

• There are many ambiguous points in the standard
  GRB model Emission mechanisms, proton
  acceleration efficiency etc.
• Future observations of gamma-rays and neutrinos
  from mesons will justify the standard model, and
  determine the proton acceleration efficiency.

3
Gamma-Ray Burst
4
Time Profile
?T
dT
5
Energy Budget
Shock Dissipated Energy
?
Magnetic Field
Acc. Electrons
Acc. Protons
Synchrotron
Gamma-Rays
6
Standard Picture of Electron Acceleration
Thermal Electrons
Electron number
Non-thermal
Energy
7
Electron-acceleration in the GRB Standard Model
Protons possess most of internal energy
Energy transport and electron-acceleration

• The energy transport process is unknown.
• No thermal electrons!!

Thermal
8
Break Energy
Break
9
Observed Break Energy
BATSE Data
10
Problems in the Theory

• Compactness problemTime Profile
• Internal Shock Model is required.
• Energy efficiency
• Large dispersion in G is required.

But, there are following problems

• Break energy problem
• Lower-energy spectra
• Energy transport
• Particle acceleration

11
In order to justify the model

• There are some serious problems in the standard
  model.
• We want to justify the assumed physical
  situation the size, G, magnetic field etc.
• If electrons are accelerated, protons should be
  also accelerated!!

(see Asano Takahara 2003)
12
Maximum Energy of UHECRs
Maximum energy of protons may be limited by The
following condition

• Larmor radius should be smaller than the size of
  the shocked region.
• The cooling time(Synchrotron) should be longer
  than the acceleration time scale.

13
Physical Condition in a Shell
?RR/G2
R
Photons Luminosity L
In the comoving frame Energy Density
Magnetic Field
14
Time Scales
Let us consider a proton of 1019eV
In the comoving frame,
Acceleration Time Scale
Dynamical Time Scale
Cooling Time Scale
GRBs can produce UHECRs!
15
Ultra-high energy cosmic ray(UHECR)
If Up above 1019 eVUe, it can explain the
flux of UHECRs.
Waxman 1995
41044erg Mpc-3 yr-1
16
Neutrino
The assumption UeUp is checked with neutrino
observations.
p??np ?pp0
p?µ ?µ
µ ?e ?µ ?e
Note Even if protons are accelerated, there are
cases that protons cool down via photo-pion
production.
17
Esh1051erg, R1013cm
Asano 2005
18
Esh1051erg, R1013cm
19
Neutrino Spectra
Pion-decay time and cooling time-gt
l1010cm
High Energy cut-off ?l0.5 R Low Energy cut-off
?R
20
More detailed simulation
E 1054erg, N1000,
G1000
R1013 cm
Magnetic Energy Density
UB0.1U
GRB photon field
n(e)?e-1 for 1 eVltelt1 keV
n(e)?e-2.2 for 1 keVltelt10 MeV
21
Mesons
Asano Nagataki 2006
See also Ando Beacom
22
Neutrino Spectra
23
Detection number of neutrinos
GRB at 30Mpc 1km2-detector
24
EUSO case
Neutrinos detected with EUSO may come from kaons!
gt1019eV detector
25
GLAST Era

• Practically, it is very hard to observe neutrinos
  from each event.
• Future gamma-ray observations with GLAST may
  bring us information on accelerated protons.

26
Physical Condition
In the standard model
But, there is possibilities of
So, we consider various cases without prejudice.
27
Microphysics in Our Simulation

• Photo-pion production
• Pion-decay
• Muon-decay
• Synchrotron radiation from electron, positron,
  muon, pion, and proton
• Photon scattering (Inv. Compton) with electron,
  positron, muon, pion, and proton
• Electron-positron pair creation
• Synchrotron self-absorption

28
Assumption

• Totally 1053erg burst
• Redshift z0.1
• Electron power-law index3 (2.5 for photon)
• ?e,m is chosen to be Ebreak300 keV

29
UeUBUp
40 amplified by protons
30
UeUBUp
GeV Observation will determine G!
31
UeUBUp, G300
E1051erg x 100 shells R1015 cm
Inv. Compton dominates above GeV.
32
UeUBUp, More Luminous Case
Target with Cherenkov Detectors
33
Magnetic Field and Cascade
Strong magnetic field enhances the cascade
processes!
34
Magnetic Field and GeV Photons
35
Muon Synchrotron
36
Proton Synchrotron
37
Other Interesting Feature
Heating Effect due to Self absorption
38
Other Interesting Feature 2
B250 G
tcoolgttdyn
Proton Synchrotron
39
Conclusion

• Future observations in neutrinos and GeV photons
  will be important to determine the model
  parameter.
• If protons are accelerated sufficiently,
  characteristic feature, such as muon or proton
  synchrotron etc., may be observed.

40
??????
41
The standard Model
Lorents factor of the shock
Proton temperature
Electron Temperature
Number fraction of non-thermal electrons
Energy fraction of non-thermal electrons
Energy fraction of magnetic field
Average energy of non-thermal electrons
42
f1 is the most efficient case.

• If f1, efficient gamma-ray production from the
  dissipated kinetic energy of outflows is
  realized.
• fltlt1 is natural, but there is huge amount of
  unobserved energy(EEobs/f) in this case.

43
Compactness Problem
If gamma-rays are emitted isotropically, the
fireball becomes optically thick because of
electron-positron pairs created via photon-photon
collision.
?Inconsistent with obs.
We need a Lorentz factor more than
100
X-ray
In the comoving frame
No high energy photons
44
Multiple Shells
Multiple shells emit independetly of each other
?Internal Shock Model
45
Fermi Acceleration
v
Shocked Region
Magnetic Field
u
GRBs are also considered to be emission from
non-thermal electrons
Particle
Shock Front
46
Degeneration of the parameters
Eichler Waxman ApJ 627, 861
If
Total Energy
Density of ISM
Observables are same as the case of f1.
47
Kinematics
Shock propagation Blandford-McKee(1976)
Shell width
If E/n is constant, the kinematics is conserved.
48
Spectrum
Energy Transport from protons to non-thermal
electrons
In case of f1
In case of flt1
is constant
The 1st in LHS is neglected ?
Magnetic Field
In order to keep the magnetic field
49
Energy Efficiency
Collision of a rapid shell and a slow shell
Internal Energy
Energy Conservation
Momentum Conservation
If equal masses
50
Energy Efficiency(2)
Efficiency
equal mass
If ?f0.057 ?f0.43
Large G-dispersion is required!
51
Expected Break Energy
Synchrotron
so that
Break Energy may have large dispersion.
52
Small variation of break energy
53
In numerical simulations
Asano Kobayashi 2003
54
Problems

• Fundamental physical processes
• Energy efficiency
• Break energy
• Spectra in the lower energy band

55
Many soft bursts should be observed
Similar Gs of the two shells lead to a soft burst.
Asano Kobayashi 2003
56
Each pulse is independent?
Borgonovo and Ryde(2000)
57
Spectra in the lower energy band
Emission from cooled enectrons may dominate in
the lower energy band.
Synchrotron spectra cannot be flatter than
Theoretical Prediction
Limit from synch.-theory
58
Observer???
?
(???
)
???Ultra-Rela (?gt100)???
59
Typical Electron Energy
Number Density
Energy Density
60
Shell????????
1/?
Observer
?????????
dT?T???????
61
?gt100????????????
?
Photon
Observer
R
c?T
62
???????????
????
63
??????????
?????????
???????? ???????
Smith Epstein(1993)
Compactness?????
??????????
???????????
64
?????????
???????
?????????
???????????????
???????Optical Depth
????
f?????????????????? f??????????????????
65
??
GRB 990123
X-ray
Optical
66
Jump Condition
Shell???L???M? shell???????????G? ?????????????
??
Shocked???????
?????????
