Casting

• By Jeffrey Wu

2
Definition Casting is a process by which a
material is introduced into a mold while it is
liquid, allowed to solidify in the shape inside
the mold, and then removed producing a fabricated
object, part, or casing. Molding is the process
of manufacturing by shaping pliable raw material
using a rigid frame or model called a mold.
3

• Four main parts
• Pattern
• Mold
• Cores
• Part

An example of an art work that can be produced by
casting.
4
Expendable Mold Casting - Needs non-reusable
molds
Non-Expendable Mold Casting - Can re-use the molds
Sand Casting Investment Casting Plaster Casting
Die Casting Permanent Mold Casting Centrifugal
Casting
5

• Sand Casting
• Traditional
• Damp sand and clay wax mix to produce a hollow
  mold
• Oldest and best understood

• Die Casting
• Forces the fluid into a steel mold under
  pressure
• Less work
• More quickly and economically
• Precise

6
This is a hand truck casting
7
Silicon Bronze Sink
8
Reference http//en.wikipedia.org/wiki/Casting h
ttp//www.kineticdiecasting.com/index.html http//
www.efunda.com/processes/metal_processing/sand_cas
ting_intro.cfm
