Chapter 3B

1
Chapter 3B

• Recombinant DNA

2
Plasmids

• Berg worked with chromosomal DNA
• Cohen worked with small circular pieces of DNA
  known as plasmids
• Found in bacteria
• Extrachromosomal DNA in cytoplasm
• Small range from 1,000 to 4,000 bp in size
• Self-replicating
• Plasmid are used as vectors
• Vectors are pieces of DNA that can accept, carry,
  and replicate other pieces of DNA

3
Plasmids

• Some plasmids are represented by 10 to 100 copies
  per host cell high copy number plasmids
  (relaxed plasmids)
• Some maintain 1 to 4 copies per cell low copy
  number plasmids (stringent controlled)
• Naturally occurring plasmids unmodified and
  unengineered plasmids often lack several
  important features that are required for a
  high-quality cloning vector

4
Types of Plasmids

• Some plasmids are represented by 10 to 100 copies
  per host cell high copy number plasmids
  (relaxed plasmids)
• Some maintain 1 to 4 copies per cell low copy
  number plasmids (stringent controlled)
• Naturally occurring plasmids unmodified and
  unengineered plasmids often lack several
  important features that are required for a
  high-quality cloning vector

5
DNA Ligase

• Cut plasmids can be joined together using DNA
  ligase to create new hybrid (recombinant)
  plasmids
• How does DNA ligase work?
• Catalyses the formation of phosphodiester bonds
  between nucleotides
• Join cohesive ends and blunt ends of DNA
• First plasmid vector was pSC101 contained a gene
  for tetracycline resistance and restriction sites
  for several enzymes

6
(No Transcript)
7
Cloning vector

• Cohen and Boyer created the first DNA cloning
  vector
• For the insertion and replication of DNA
• Patents received in 1980
• 1974, gene cloning pioneers and cloning critics
  voiced concerns about the safety of genetically
  modified organisms.
• What if it leaves the lab?
• National Institutes of Health formed the
  Recombinant DNA Advisory Committee (RAC) to
  evaluate the risk of recombinant DNA technology.
  Set guidelines in 1976

8
Transformation of Bacterial Cells and Antibiotic
Selection

• Cohen made another important contribution to gene
  cloning
• His laboratory demonstrated transformation
• What is transformation?
• A process of inserting foreign DNA into bacteria
• Treated bacterial cells with calcium chloride
• Added plasmid DNA to cells chilled on ice
• Briefly heated cells and DNA mixture
• Plasmid DNA entered bacterial cells
• Replicate with no problem
• Can also use electroporation (brief pulse of high
  voltage electricity to create holes in bacteria

9
Transformation and Selection

• Uptake of E.coli of cloned DNA is transformation
• A cell that is capable of taking up DNA is
  competent
• Natural transformations DNA binds to cell wall,
  DNA enters inner compartment that is protected by
  nuclease, linear integrates in host genome,
  circular stay in cytoplasm

10
How do you make cells competent?

• Electroporation, needles, and chemicals
• Treat cells to enhance the acquistion of DNA by
  the cell
• Calcium chloride (CaCL2) and heat at 42C
• Adhesion zones or pores in growing cells
• Cold crystallizes the fluid cell membrane,
  stabilizing the charged phosphates. The cations
  form complexes with exposed phosphate groups,
  shielding negative charges- ionic shield so
  plasmid can move through the adhesive zone

11
(No Transcript)
12
Electroporation

• To insert large circular DNA molecules into host
  cells
• Mix cells and vector together in a chamber and
  apply a pulse of electricity across the chamber.
• Change the electrical properties of the cells and
  the DNA enters
• Insert up to 1 million base pairs (cosmids,
  bacteriophages, etc)
• Used with a wide variety of host cells (fish,
  frogs, etc).

13
(No Transcript)
14
Screening to find vectors

• How do distinguish nontransformed bacteria and
  bacteria containing the plasmid?
• Use a process called selection
• Selecting for recombinant bacteria while
  preventing the growth of nontransformed bacteria
  and bacteria that contain plasmid without DNA
  insert
• Antibiotic Selection
• Cells are plated with different antibiotics for
  selection

15
Blue-white selection procedure

• Plasmid contains AMPr site and Restriction sites
• DNA is cloned into a restriction site in the lacZ
  gene
• LacZ gene encode beta-galactosidase and enzyme
  that degraed lactose into glucose and galactose
• When gene is disrupted, lacZ gene is incapable of
  producing function beta-galactosidase

16

• Transformed bacteria are plated on agar
  containing ampicillin
• Nontransformed bacteria can not grow on plates
• Agar also contains chromogenic substrate for
  B-gal called X-gal turns blue when cleaved by
  B-gal
• Nonrecombinant bacteria that contain the plasmid
  but not the insert have a functional B-gal gene-
  Blue
• Recombinant bacteria with insert do not have a
  functional gene- cannot metabolize X-gal - White

17
pUC19

• 2686 base pairs, Amp r gene
• Regulatable segment of ?-galactosidase gene (Lac
  Z) of lactose operon of E. Coli.
• Lac I gene that produces a repressor protein that
  regulates the expression of lac Z gene
• Many unique cloning sites multiple cloning
  sites
• Origin of replication

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
What makes a Good Vector

• Number of different vectors
• Plasmids are the most popular
• First widely used plasmid DNA vector is pBR322
• Designed to have genes for ampicillin and
  tetracyclin resistance

23
Plasmid pBR322

• General purpose plasmid cloning vector
• 4,361 bp
• Two antibiotic resistance genes
• Origin of replication for E. Coli
• High copy number

24
Practical Features of DNA Cloning Vectors

• Modern plasmid DNA cloning vectors
• Size small enough to be easily separated from
  chromosomal DNA
• Origin of replication (ori) allows plasmids to
  replicate
• Mulitple cloning site (MCS) restriction sites
• Selectable marker genes ampR or lacZ genes
• RNA polymerase promoter regions important for
  transcription
• DNA sequencing primers for sequencing

25
(No Transcript)
26
Phage library

• Isolate DNA, cut with RE to generate large pieces
  (partial cut). Use centrifugation to select
  large pieces 20 kb or separate by gel and
  extract.
• Ligate with phage (library), package in E. Coli.
• Phage injects its genetic material into E. Coli
  cell, replicated. Remember phage encodes a
  protein needed to package new viral particles.
• DNA packaged into viral particles and cells lyse
  - E. coli dies-plaque or clear spot is created
  on the surface of the plate (lytic phase)
• Each plaque originates from a single infected
  cell isolate the plaque

27
(No Transcript)
28
(No Transcript)
29
Two important feature of lambda vectors

• Bacteriophage ? vectors-M13 libraries sometimes
  contain large pieces of DNA- can carry up to 25kb

• Makes the job of screening more manageable
• Introducing recombinant DNA into E. Coli by phage
  infection is more efficient than transforming E.
  Coli with plasmids

30
Southern Blotting

• Used to determine gene copy number
• Developed by Ed Southern in 1975
• Begins with digesting chromosomal DNA into small
  fragments with restriction enzymes
• DNA fragments are separated by agarose gel
  electrophoresis
• Southern blotting is used to visualize specific
  fragments of interest
• Gel is treated with alkaline solution to denature
  DNA
• Fragments transferred to membrane (blotting)

31
(No Transcript)
32
Setting up the gel sandwich

• Gel is placed under the nylon or nitrocellulose
  membrane, filter paper, paper towels, and weight
  allowed for wicking the salt solution through gel
• DNA is transferred from the gel to the filter by
  capillary action or by current
• Blot is then incubated with nonradioactive or
  radioactive probe.

33
Polymerase Chain Reaction

• More rapid approach to identify gene of interest
• Kary Mullis 1980 Nobel Prize in Chemistry for
  his invention.
• Technique for making copies or amplifying a
  specific sequences of DNA in a short period of
  time
• Things you need target DNA to be amplified,
  deoxyribonucleotides, buffer, DNA polymerase, and
  set of primers

34
Primers

• Short single-stranded DNA oligonucleotides (20-30
  nucleotides long)
• Complementary to nucleotides flanking opposite
  ends of the target DNA to be amplified.
• Reaction tube place in thermal cycler
• Sophisticated heating block that is capable of
  rapidly changing temperature over very short time
  intervals.
• You go through a series of reactions called the
  PCR cycle

35
PCR cycle

• Each cycle consist of three stages
• Denaturation
• Reaction tube is heated to 94-960C causing
  separation of the target DNA into single strands
• Hybridization (Annealing)
• Tube is cooled slightly to 60-650C, which allows
  the primers to hydrogen bond to complementary
  bases at opposite ends of the target sequences
• Extension (Elongation)
• Temperature is raised slightly to 70-75C and
  DNA polymerase copies the target DNA by binding
  to the 3end of each primer.
• At the end of one cycle- target DNA has doubled
  usually run about 30-40 cycles.
• http//www.dnalc.org/ddnalc/resources/pcr.html

36
PCR DNA DNA polymerase Primers Denaturation
stage Hybridization/Annealing stage Extension
stage
37
Type of DNA polymerase important

• Must use an enzyme that is suitable for the
  various temperature changes.
• Most popular is Taq DNA polymerase. Isolated
  from archaea called Thermus aquaticus, a species
  that is adjusted to hot temperature.
• Named the molecule of the year by the Journal
  Science in 1989.

38
Advantage of PCR

• Amplify millions of copies of target DNA from a
  very small amount.
• After 20 cycles approximately 1 million copies
  are produces -2 20
• Real-time PCR used primers with fluorescent dyes
  to quantify amplification reactions.

39
Probe

• General Rule sequence of 16 nucleotides or
  longer is likely to be unique in the human
  genome. (exception- repetitive sequence for some
  genes)
• Probe around 100 400 bases is very good
• Complementary base pairing provides the most
  powerful tool for a probe. DNA/RNA and DNA/DNA
• Remember definition of denaturation heat above
  90C and pH above 10.5 (alkaline)
• Renaturation-reduce temperature and pH
• Hybridization annealing

40
Properties of probe

• Labeled
• Sequence complementary to gene of interest
• Must be incubated with denatured DNA
• Added in excess to increase the likelihood of the
  gene hybridizing with the probe instead of its
  complementary strand

41
Making a probe

• Requires a purified DNA sequence complementary to
  the gene of interest
• In order to identify your target gene, you need
  to already have a piece of that gene or no
  something about the conserved sequence.
• mRNAs within a cell are somewhat unique. mRNA is
  complementary to the DNA sequence of the gene
  from which it was transcribed

42
Probe

• Radioactive or nonradioactive probe
• Wash away unbound probe.
• Use photographic film to identify clones with
  gene.
• Autoradiography radioactivity or light
  (chemiluminescence) will expose silver grains on
  the film.
• Compare to original plate to identify clones
• Labeled with a dye

43
(No Transcript)
44
Genomic Library vs cDNA library

• Goal of Biotechnology is to make protein for
  numerous applications
• Prokaryotes structural gene form a continuous
  coding domain in genomic DNA( rarely have
  introns)
• Eukaryotes structural genes have coding regions
  (exon) separated by noncoding regions (introns)
• Use different strategies to clone these genes
• How would you make a cDNA library

45
(No Transcript)
46
Prokaryote

• Target gene 0.02 of total chromosomal DNA
• Cut the complete DNA with RE
• Each fragment is inserted into a vector
• Identify specific clone that carries the target
  DNA, isolate, and characterize the gene
• The process of subdividing DNA into clonable
  elements and insertion into host is called
  creating a library (gene bank, clone bank)
• A complete library, by definition, contains all
  the genomic DNA of the source organism.

47
Techniques

• Prokarytoes 4 cutter RE 256 bps generated
• Set conditions to give incomplete cuts to
  generate all the possible fragment sizes
• Low concentration of RE
• Shorten incubation time
• Sum of clone 3X more than the amount of genome
• 4 x 10e6 bp size for prokaryotic genome.
  Approximate size per piece 1000 by
• 3 ( 4 x 10e6 bp)/ 1000 12,000 clones

48
Eukaryotic genome

• 3.3 x 10 9 bp
• Large pieces bacterial artificial chromosome
  clones
• 80,000 clones each with 150,000 bp insert

49
Vectors for Cloning Large Pieces of DNA

• Bacteriophage ? vectors libraries sometimes
  contain large pieces of DNA
• E. Coli virus engineered to be a vector for
  inserts in the range of 15 to 20 kb. Replacing
  20 kb of cloned DNA with 20 kb of lambda DNA

50
(No Transcript)
51
Cosmids, YACS, and BACS

• Cosmids
• Carry about 45kb of cloned DNA and maintained as
  plasmids in E. Coli.
• Combine the properties of plasmids and
  bacteriophage lambda vectors
• pLFR-5 has two cos sites, RE site, MC site, etc
• YACS-yeast artificial chromosome, accepts 1000kb
  inserts
• BACS-bacterial artificial chromosomes, accepts
  1000kb inserts

52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
Southern Blotting and PCR

• http//highered.mcgraw-hill.com/olcweb/cgi/pluginp
  op.cgi?itswf535535/sites/dl/free/0072437316
  /120078/bio_g.swfSouthernBlot
• http//www.sinauer.com/cooper/4e/animations0411.ht
  ml
• http//www.maxanim.com/genetics/PCR/PCR.htm
