Menuju Teknologi Cellular : 3G dan UMTS

1
Menuju Teknologi Cellular 3G dan UMTS

• Oleh
• Uke Kurniawan Usman,Ir,MT
• Dosen PNS Kopertis Wilayah IV
• Dpk di STT Telkom BANDUNG
• uku_at_stttelkom.ac.id
• www.stttelkom.ac.id/staf/UKU

2
Evolusi Technology Cellular

• 1G
• wireless

AMPS (Advanced Mobile Phone Service)
- Analog voice service - No data service
2G wireless
CDMA (Code Division Multiple Access) TDMA (Time
Division Multiple Access) GSM (Global System for
Mobile Communications) PDC (Personal Digital
Cellular)
- Digital voice service - 9.6K to 14.4K
bit/sec. - CDMA, TDMA and PDC offer one-way
data transmissions only - Enhanced calling
features like caller ID - No always-on data
connection
3G wireless
W-CDMA (Wide-band Code Division Multiple
Access) CDMA-2000
- Superior voice quality - Up to 2M bit/sec. -
always-on data - Broadband data services like
video multimedia - Enhanced roaming
3
Advanced Mobile Phone Service

• Pioneer of cellular telecommunications
• FDMA-based analog system
• Low capacity of subscriber per cell
• Unsecure
• Phone number can be scanned and copied
• Voice conversation is not encrypted

4
Global System for Mobile Communications

• The most popular of cellular technologies
• Supported in nearly all countries
• TDMA-based digital system
• 8 times capacity of AMPS per frequency band
• Secure
• All information exchange between Mobile Station
  (MS) and Base Station (BS) are encrypted

5
CdmaOne

• Newest cellular phone standard
• Developed by Qualcomm
• Supported mainly in the Americas and East Asia
• CDMA-based digital system
• Up to 18 times capacity of AMPS per frequency
  band
• Very Secure
• Listeners need the right descrambler key
• Optional encryption is also available

6
Evolution of Cellular Standards
7
Migration To 3G
8
Alasan adanya 3G Network
The Convergence

• Mobile telephony
• The internet technology
• Media business

3G Network
Kebutuhan akses informasi dimana saja
high speed mobile access with Internet Protocol
(IP)-based services
Driven technology
Multimedia, hiburan, dsb
9
What is Third Generation?

• Flexible support of multiple services (data rates
  from kbps to Mbps packet transmission)
• Voice
• Messaging email, fax, etc.
• Medium-rate multimedia Internet access,
  educational
• High-rate multimedia file transfer, video
• High-rate interactive multimedia video
  teleconferencing, telemedicine, etc.
• Mobility quasi-stationary to high-speed
  platforms
• Global roaming ubiquitous, seamless coverage
• Evolution from second generation systems

10
Syarat-Syarat 3G
Data sirkuit dan paket kecepatan tinggi 144 kbps
vehicular 384 kbps pedestrian 2 Mbps Indoor
Transmisi Simetrik Asimetrik
Enhanced Voice
Communications Entertainment E-Commerce Informatio
n Transaction Travel
Aplikasi Multi-Media
Global Roaming 3G? 3G 2G ? 3G
Multi-Environment Operation Vehicular, Outdoor
to Indoor, Indoor Office, Satellite
11
3G didesain untuk memberikan .

• Aplikasi-aplikasi dari lingkup market yang luas
  , market mengendalikan teknologi
• Komunikasi dan terminal yang Advanced,
  lightweight, easy-to-use terminal
• Instant, real-time multimedia communications
• Global mobility and roaming
• A wide range of vendors and operators, offering
  choice, competition and affordability
• High-speed e-mailand Internet access

12
Integrasi Dengan 3G
Ini jaringan 3G dengan kemampuan yang lengkap !!
13
E- Commerce Over 3G
14
Alokasi Spektrum 3G di Dunia
15
Fase Migrasi GSM ke 3G

• Fase 1 Dengan menambah jaringan radio
  packet sebagai sebuah overlay pada struktur
  eksisting.
• Fase 2 Dengan mengganti BS dan BSC dengan
  sub-network UTRA (Universal Terrestrial Radio
  Access)
• Fase 3 Gencar memperkenalkan handset UMTS
  (Universal Mobile Telecommunications System)
  beserta SIM (Subscriber Identity Module)
• Fungsi-fungsi utama jaringan dipertahankan
  selama 3 fase migrasi tersebut
• Penambahan infrastruktur GPRS-EDGE Network
  WCDMA UMTS Release 99 (tahap awal)

16
Migrasi GSM ke 3G
17
Jalur Migrasi GSM ke 3G
18
Spektrum 3G di Indonesia
19
Evolusi Universal Mobile Telecommunication System
(UMTS)
20
Karakteristik UMTS
21
Migrasi GPRS GSM ke UMTS
22
Komponen UMTS
23
Type Layanan UMTS
24
Connection-oriented ServicesPhase 1
Establishment
25
Connection-oriented ServicesPhase 2 Data
Transfer
26
Connection-oriented ServicesPhase 3 Connection
Release
27
Connectionless Services
28
Spesifikasi W-CDMA (UMTS)
29
Model Radio Access W-CDMA
30
Kanal Fisik - UMTS
31
Type Kanal pada UMTS
32
Logical Channel - UMTS
33
Transport Channel - UMTS
34
Physical Channel - UMTS
35
Arsitektur Umum UMTS
36
Arsitektur Jaringan UMTS
37
UMTS Architecture / W-CDMA
Node B
Packet
RNC
network
Uu
PSTN
Iu
MSC
SMS-GMSC
HLR/AuC
Iu
Gr
Gs
Gd
Gr
Gd
Serving GPRS
Packet
Gs
Support Node
SS7
network
Server
Network
Gn
(SGSN)
EIR
GPRS
Border
INFRASTRUCTURE
MAP-F
Gateway (BG)
Packet
Gc
Inter-PLMN
Router
network
Local
Backbone
Firewall
Gp
area
network
Data
network
Packet
Firewall
network
network
Gn
(Internet)
Gi.IP
Gateway GPRS
Support Node
(GGSN)
38
Jalur GSM menuju UMTS
