Microsoft Performance Point Planning Framework

1
MCS
Microsoft Office PerformancePoint Server 2007
Planning, Monitoring Analytics Project
Methodology
2
Table of Contents

• Overview
• Project Plan Tasks
• Envisioning
• Planning
• Developing
• Server Environment
• PerformancePoint Server Data Structures
• Data Integration, Custom Code Migration
  Scripts
• Custom Dimensions, Rules and Calculations
• Form and Report Creation
• Dashboard Creation
• Security and Workflow
• Stabilizing
• Deploying
• Post Deployment Considerations

3
Overview

• Primary tasks and subtasks to implement
  PerformancePoint Server
• Each primary task has a time estimate
• Each primary task will have documentation and
  template resources to enable each task

4
Typical PerformancePoint Server Solutions

• Estimates are based on the following
• Planning Application
• One to three data sources
• Five to ten reports and forms
• Ninety percent of rules can be implemented as
  PerformancePoint Expression Language rules
• MA Application
• One to three data sources
• 15 to 20 Scorecards and Reports
• Moderate amount of source system complexity (no
  huge data quality issues)
• Moderate amount of data management sophistication

5
Glossary of Terms

• ETL Extract, Transform and Load
• MA PerformancePoint Monitoring
• MCS Microsoft Consulting Services
• OLAP Online Analytical Processing
• Planning Business Modeler - PerformancePoint
  Planning Business Modeler
• Planning PerformancePoint Planning
• QA Quality Assurance
• QFE Quick Fix Engineering
• RTM Release to Manufacturing
• SLA Service Level Agreement
• SME - Subject Matter Expert
• SP Service Packs
• SSAS - SQL Server 2005 Analysis Services
• SSIS SQL Server 2005 Integration Services

6
Project Plan Tasks PerformancePoint Planning
7
Project Plan Tasks PerformancePoint Monitoring
8
Project Plan Tasks PerformancePoint Planning
Timeline
9
Project Plan Tasks PerformancePoint Monitoring
Timeline
10
Project Plan Tasks Project Pre-Requisites

• Project
• Implementation based on RTM and latest QFEs and
  SP
• Implementation project has active support at all
  levels of management
• Client internal resources are trained on
  products, have adequate bandwidth, and have no
  impediments to start the project
• Client has identified and approved a
  consultant/implementation partner
• Client agrees to follow the MCS prescribed
  implementation methodology
• Check points/designated peer reviews
• Client has identified an internal Project
  Manager/ Steering Committee
• Time Estimate
• Time estimates represent dedicated work effort
  for one person
• Some tasks will be performed concurrently

11
Envisioning Phase
Time Range to Complete 3-5 days

• Analyze and document business processes
• Prioritize based on improvement impact,
  readiness, and relative importance
• Identify an initial scope that can be built and
  deployed within a 3-4 month timeframe
• A process that can be implemented end-to-end and
  then expanded to other processes
• Examples
• Forecast process only (expand to Budgeting
  process as a next phase)
• Revenue only (expand to Operational Expenses and
  Headcount as the next phase)
• Data input only (expand modeling capabilities as
  the next phase)
• Revenue and Sales Monitoring (expand to product
  profitability as the next phase)
• Build a roadmap for subsequent or parallel phases

Supporting Document Preliminary Requirements
Gathering and Scoping Questionnaire
12
Planning Phase
Time Range to Complete 2-4 Days

• Identify resources for roles
• Steering committee
• Internal resources (process SME)
• Engagement partner (selection process not
  included in timeframe above)
• Create a Project Plan
• Tasks, resources, work effort
• Major milestone reviews
• Lead time to order hardware
• IT hosting (or outsource hosting)
• Implement a Change Control Process

Supporting Documents Planning Project Plan
Template MA Project Plan Template
13
Roles Defined

• Steering Committee
• In-depth knowledge of implementation objectives
  and stakeholders
• Provide oversight for the implementations
• Remove roadblocks
• Control scope
• Approve and provide funding
• Project Manager
• Experience with Project Management Methodology
  and Tools
• Manage team
• Manage project plan deliverables
• Manage Task plan
• Manage communication between team and Steering
  Committee
• Project Lead
• In-depth knowledge of PerformancePoint Server
• Previous successful PerformancePoint Server
  implementation experience
• Manage and coordinate implementation and
  configuration tasks

• Form/Report Builder(s)
• Excel Experience and knowledge of OLAP
  terminology
• Trained on the PerformancePoint Add-in for Excel
• Create Forms and Reports
• Dashboard Developer
• OLAP and/or SQL Skills
• Trained on PerformancePoint Dashboard Designer
• Reporting Services/ProClarity Development
• SSIS Programmer(s)
• SSIS/SSAS Expertise
• Experience with PerformancePoint Planning Command
  Utility
• Create SSIS packages
• Write Custom code
• Load data
• Hardware Configuration Manager(s)
• Background in hardware configuration

14
Planning Specifications
Time Range to Complete 3-6 Weeks

• Create a hybrid consolidated document
  (Requirements Functional Specification) in
  PerformancePoint Server terms
• Document in terms of Planning
• Data sources (all feeds in and out)
• Data source table structure and how that relates
  back to the Planning data structure
• Input templates and forms
• Map out each input form and output report
• Columns, rows and filters in terms of
  dimensionality
• Hierarchy aggregations
• Input areas versus pre-fed data (note sources)
• Level of input as compared to the source
  hierarchies
• Business rules
• Rules assessment (complexity and scope of rules
  will determine the type of implementation)
• Process flows
• Model concepts
• Workflow and security
• Know the features/limitations of the tool to
  determine which processes can be incorporated
• Identify performance and maintenance expectations
• Optional Build proof of concept or prototype

Supporting Documents PerformancePoint Server
Specifications Template
15
MA Specifications
Time Range to Complete 3-6 Weeks

• Create a hybrid consolidated document
  (Requirements Document Functional
  Specification) in PerformancePoint Server Terms
• Document in terms of MA
• Data sources (all feeds in and out)
• Source System Data Profiling (if applicable)
• Data Acquisition Business Rules
• Excel Spreadsheet definition (if applicable)
• Dashboards
• Key Performance Indicators and Scorecard
  Definition
• Dashboard Design and Layout
• Scorecard and Report View Definition
• Define Reporting Audiences and Functional
  Requirements
• Know the features/limitations of the tool to
  determine which processes can be incorporated
• Identify performance and maintenance expectations
• Optional Build proof of concept or prototype

Supporting Documents PerformancePoint Server
Specifications Template
16
Planning Architecture and Design
Time Range to Complete 2-4 Weeks

• Document and review design before building the
  application
• Document configuration of the application
• What models are required and how does data flow
  between the models?
• Source models versus Input models
• Assumption models
• Consolidation model
• Reporting model
• What dimensions/measures are needed for each
  model?
• What hierarchies/properties are needed?
• Which hierarchies can be sourced through Planning
  Command Utility?
• Which hierarchies need to be custom created in
  Planning vs. flat files?
• What properties are needed for views and/or
  custom ETL?
• Business rules
• Determine optimal rule types for each business
  rule

17
Planning Architecture and Design Continued

• Document data flow
• Mappings between models
• From sources to data warehouse to staging
• From staging to models
• Data flow between models
• Data flow from form contributor to models
• Flow from assumption models to primary models
• Identify process for moving data for the above
• SSIS packages
• Rules
• Planning Command Utility

Supporting Document Design Configuration
Template
18
MA Architecture and Design
Time Range to Complete 2-4 Weeks

• Document and review design before building the
  application
• Document configuration of the application
  components
• SharePoint Portal Server
• PerformancePoint Monitoring Server
• ProClarity Analytics Server
• Database Server (if applicable)
• Security
• Data Acquisition
• Document Data Flow Between Sources and Warehouse
• Transformations and Business Rules
• Data Model (if applicable)
• OLAP Model (if applicable)
• Report Requirements

Supporting Document Design Configuration
Template
19
Server Environment/Migration Plan
Time Range to Complete 1-2 Days per Server
Environment

• Build out separate server environments
• Development
• Test
• Production
• Minimum requirements (development/test should
  mimic production)
• Development/test
• Production
• Configure hardware
• Load required software

20
Planning Configuration Create Data Structures
Time Range to Complete 1-3 Days

• Create data structures to enable Planning Command
  Utility and custom code tasks
• Create application shell for populating data
• Create application
• Create calendar and time views
• Create custom dimensions
• Create dimension properties
• Create models
• Add dimensions/membersets
• Set model properties

21
MA Configuration - Create Data Structures
Time Range to Complete 1 to 2 weeks (varies
based on sophistication)

• Create data structures (dimensional data mart,
  data store, etc.) to support ongoing reporting
  requirements/cubes (if applicable)
• Create staging environment for applying business
  rules to source data through transformations (if
  applicable)
• Create OLAP structures to support reporting
  requirements (if applicable)
• Create Excel spreadsheet to source data from (if
  applicable)

22
Planning ETL, Code Migration Scripts
Time Range to Complete 2-5 days per Data
Feed/SQL Data Move within the Application

• Coding
• ETL for each data feed
• SQL code for data moves within the application
• Configuration
• Staging to application (Planning Command
  Utility)
• Migration
• Scripts to promote the application from
  development via test to the production
  environment
• Testing
• Data validation
• Unit testing for each feed
• Unit testing for each data move
• Migration/portability testing

23
MA Data Acquisition
Time Range to Complete 5 days per Data Feed
(varies based on complexity/approach)

• Data Acquisition
• Extracts for each data source
• Transformations and implementation of business
  logic
• Testing
• Data validation
• Unit testing for each feed
• Unit testing for each data move
• Optimize
• Spend the time to optimize code for better
  performance

24
Planning Customize Dimensions Rules
Time Range to Complete 1-3 weeks

• Create Custom Members and Membersets
• Create PPS rules for each model - Complexity of
  rules determines time required (Average 1 day per
  rule)
• Unit testing of rule output and rule sequencing
• Create Mapping Dimensions (dimensions used for
  moving data using business mapping rules)

25
Planning Forms and Report Creation
Time Range to Complete 1-2 days per Form/Report

• Create and publish input forms and output reports
• Unit Testing
• Writeable region/security
• Validate data results against source and
  requirements

26
MA Dashboard Creation
Time Range to Complete 2 days per
Scorecard/Report

• Create and publish dashboard component
• Unit Testing
• Security
• Validate data results against source and
  requirements

27
Planning Security and Workflow
Time Range to Complete 2-3 days

• Configure full scale of User Security in Test and
  Production
• Developer access is all that is needed in the
  development environment
• Create roles
• Set role level security
• Load users
• Set user level security
• Unit test
• Test security against the input forms and output
  reports
• Test rule job security

28
Planning Stabilization Input Forms
Time Range to Complete 1-2 days Setup 1 day
per Form/Report

• Load test input form
• Test primary forms to determine impact of
  concurrent user load on performance
• Determine whether environment capacity will be
  sufficient to meet requirements before end-users
  are on the system
• Test in an environment that mimics production
• Test against pre-defined performance benchmarks
• Configure performance tool to the application and
  forms
• Conduct load testing
• Document results
• Determine if changes in design are needed
  (typically form design changes and/or rule
  scoping)

Supporting Documents Performance Testing White
Paper
29
Planning Stabilization Operations and
Maintenance Guide
Time Range to Complete 1-2 Weeks

• Document steps to run the cycles
• Cycles assignments/schedule current period
• Scheduled jobs
• Rule parameters
• Data validation
• Output report review and validation
• User form input guide
• Modeler, SSIS maintenance, SQL log management
• Establish and document application support model
• Back-up and Restore procedures
• SLAs with user community

Supporting Document Operations and Maintenance
Guide Template
30
MA Stabilization Operations and Maintenance
Guide
Time Range to Complete 1-2 Weeks

• Documentation of
• Data acquisition components and schedules
• Scorecards and Reports
• Business Rules applied to the data throughout the
  various layers of the application
• Scorecard User Administration and Usage Guide
• Establish and document support model
• Back-up and Restore procedures
• SLAs with user community

Supporting Document Operations and Maintenance
Guide Template
31
Planning Stabilization User Acceptance Test (UAT)
Time Range to Complete 1-5 days for UAT 1/2
Day per Documented Use Case

• Document use cases by form
• Data input scenarios
• Filter usage
• Calculation scenarios
• Collect form performance data
• Assignment flow (review/approval)
• Document use cases for process/tool owners
• Test operations and maintenance
• Test use case scripts
• User Acceptance Test
• Identify and train UAT user group
• Configure security and workflow for UAT
• Conduct UAT
• Review UAT results
• Identify required fixes
• Implement bug fixes (time not included above)
  Benchmark time 1-5 days
• If the design is right, this should be minimal

Supporting Documents Test Plan Template
32
MA Stabilization User Acceptance Test (UAT)
Time Range to Complete 1-5 days for UAT 1/2
Day per Documented Use Case

• Document use cases by Dashboard
• Dashboard Configuration
• Key Performance Indicators
• Scorecards Views
• Filter/Dimensionality
• Document use cases for process/tool owners
• Test operations and maintenance
• Test use case scripts
• UAT
• Identify and train UAT user group
• Configure security for UAT
• Conduct UAT
• Review UAT results
• Identify required fixes
• Implement bug fixes (time not included above)
  Benchmark time 1-5 days
• If the design is right, this should be minimal

Supporting Documents Test Plan Template
33
Planning Deployment
Time Range to Complete 2-4 days

• Train user base
• Modelers
• Global, data, and user administrators
• Input form contributors
• Output report reviewers and approvers
• Support tiers
• Deploy server environment to hosted environment
• Deploy final application to production
  environment
• Run migration script
• Migrate SSIS packages
• Import input forms and output reports
• Set up security and workflow
• Other manual migrations steps

Supporting Document Training Plan Template
34
MA Deployment
Time Range to Complete 2-4 days

• Train user base
• Power User Training
• Dashboard Developers
• ProClarity Users
• End User Audiences
• Deploy server environment to hosted environment
• Deploy final application to production
  environment
• Historical Data Loads (if applicable)
• Migrate SSIS packages (if applicable)
• Deploy Dashboards and Other Reports
• Configure SharePoint site and security

Supporting Document Training Plan Template
35
Post Deployment Considerations

• Sustain
• Hardware support/IT hosting
• User security and ongoing training support
• Ongoing ETL/data integration support
• Enhance
• Iterate through phases identified on roadmap
  during scoping phase
