Reversible Computing Theory I: Reversible Logic Models

1
Reversible Computing Theory IReversible Logic
Models
2
Reversible Logic Models

• It is useful to have a logic-level (Boolean)
  model of adiabatic circuits.
• Can model all logic using maximally pipelined
  logic elements, which consume their inputs.
• A.k.a., input consuming gates.
• Warning In such models Memory requires
  recirculation! Thus, this is not necessarily
  more energy-efficient in practice for all
  problems than retractile (non-input consuming)
  approaches!
• There is a need for more flexible logic models.
• If inputs are consumed, then the input?output
  logic function must be invertible.

3
Input-consuming inverter
in
out

• Before After in out in out 0 - -
  1 1 - - 0
• E.g. SCRL implementation

Input arrow indicates inputdata is consumed by
element.
Alternate symbol
in
out
Invertible!
(Symmetric)
4
An Irreversible Consuming Gate

• Input-consuming NAND gate Before After
  A B out A B out 0 0 - - - 1 0
  1 - 1 0 - - - 0 1 1 -
• Because its irreversible, it has no
  implementation in SCRL (or any fully adiabatic
  style) as a stand-alone, pipelined logic element!

A
out
B
4 possible inputs, 2possible outputs. At least
2 of the 4 possibleinput cases must lead
todissipation!
5
NAND w. 1 input copied?

• Still not invertible Before After A B A
  out A B A out 0 0 - - - -
  0 1 0 1 - - - - 1
  1 1 0 - -
  - - 1 0 1 1 - -
• At least 1 of the 2 transitions to the A0,
  out1 final state must involve energy dissipation
  of order kBT. How much, exactly? See exercise.

Delay buffer
A
A
out
B
6
NAND w. 2 inputs copied?

• Finally, invertible! Before After
  A B A B out A B A B out 0 0 -
  - - - - 0 0 1 0
  1 - - - - - 0 1 1
  1 0 - - - - - 1 0
  1 1 1 - - - - -
  1 1 0
• Any function can be made invertible by simply
  preserving copies of all inputs in extra outputs.
• Note Not all output combinations here are legal!
• Note there are more outputs than inputs.
• We call this an expanding operation.
• But, copied inputs can be shared by many gates.

A
A
out
B
B
7
SCRL Pipelined NAND
A
B
A
out AB
5T
B
Inverters only neededto restore A, B Can be
shared withother gates that takeA, B as inputs.

• Including inverters 23 transistors
• Not including inverters 7 transistors

8
Non-Expanding Gates

• Controlled-NOT (CNOT) or input-consuming
  XOR A B A C 0 0 0
  0 0 1 0 1 1 0 1
  1 1 1 1 0
• Not universal for classical reversible computing.
  (Even together w. all other 1 2 output rev.
  gates.)
• However, if we add 1-input, 1-output
  quantumgates, the resulting gate set is
  universal!
• More on quantum computing in a couple of weeks.

A
A
A
A
B
C A?B
B
C A?B
Can implement w. a diadic gate in SCRL
9
Toffoli Gate (CCNOT)
A
A
A B C A B C0 0 0 0 0 00 0 1
0 0 10 1 0 0 1 00 1 1 0
1 11 0 0 1 0 01 0 1 1 0
11 1 0 1 1 01 1 1 1 1 1

• Subsumes AND, NAND, XOR, NOT, FAN-OUT,
• Note that this gate is its own inverse.
• Our first universal reversible gate!

A
AA
B
BB
B
B
C
C
C C?AB
C
(XOR)
10
Fredkin Gate

• The first universal reversible logic gate to be
  discovered. (Ed Fredkin, mid 70s)
• B and C are swapped ifA1, else passed
  unchanged.
• Is also conservative, conserves 1s and 0s.
• Thus in theory requires no separate power input,
  even if 1 and 0 have different energy levels!

A B C A B C0 0 0 0 0 00 0 1
0 0 10 1 0 0 1 00 1 1 0
1 11 0 0 1 0 01 0 1 1 0
11 1 0 1 1 01 1 1 1 1 1
A
A
B
B
C
C
11
Reversible Computing Theory IIEmulating
Irreversible Machines
12
Motivation for this study

• We want to know how to carry out any arbitrary
  computation in a way that is reversible to an
  arbitrarily high degree.
• Up to limits set by leakage, power supply, etc.
• We want to do this as efficiently as possible
• Using as few device ticks as possible
  (spacetime)
• Minimizes HW cost, leakage losses
• Using as few adiabatic transitions as possible
  (ops)
• Minimizes frictional losses
• But, a desired computation may be originally
  specified in terms of irreversible primitives.

13
General-Case vs. Special-Case

• Wed like to know two kinds of things
• For arbitrary general-purpose computations,
• How to automatically emulate them in a fairly
  efficient reversible way,
• w/o needing new intelligent/creative design work
  in each case?
• Topic of todays lecture
• For various specific computations of interest,
• What are the most efficient reversible
  algorithms?
• Or at least, the most efficient that we can find?
• Note These may not necessarily look anything
  like the most efficient irreversible algorithms!
• More on this point later

14
The Landauer embedding

• The obvious embedding of irreversible ops into
  expanding reversible ones leads to a linear
  increase in space through time. (Landauer 61)
• Or, increase in width of an input-consuming
  circuit

Expandingoperations(e.g., AND)
Desiredoutput
Garbagebits
input
Circuit depth, or time ?
15
Lecerf Reversal

• Lecerf (63) was interested in the group-theory
  question of whether an iterated permutation of
  items would eventually return to initial item.
• Proved undecidable by reducing Turings halting
  problem to this question, w. a reversible TM.
• Reversible TM reverses direction instead of
  halting.
• Returns to initial state iff irreversible TM
  would halt.
• Only problem with thisNo useful output data!

Desiredoutput
f
f ? 1
Garbage
Copy ofInput
Input
16
The Bennett Trick

• Bennett (73) pointed out that you could simply
  fan-out (reversibly copy) the desired output
  before reversing.
• Note O(T) storage is still temporarily needed!

Desired output
f
f ? 1
Copy ofInput
Input
Garbage
17
Improving Spacetime Efficiency

• Bennett 73 transforms a computation taking
  spacetime ST to one taking ?(ST2) spacetime in
  the worst case.
• Can we do better?
• Bennett 89 Described a technique that takes
  spacetime
• Actually, can generalize slightly and arrange for
  exponent on T to be 1?, where ??0 (very slowly)
• Lange, McKenzie, Tapp 97 Space ?(S) is even
  possible, if you use time ?(exp(?(S)))
• Not any more spacetime-efficient than Bennett.

18
Reversible Climbing Game

• Suppose a guy armed with a hammer, N spikes, a
  rope is trying to climb acliff, while obeying
  the following rules.
• Question How high can he climb?
• Rules
• Standing on the ground or on a spike, he
  caninsert remove a spike 1 meter higher up.
• He can raise lower himself betweenspikes the
  ground using his rope.
• He cant insert or remove a spike whiledangling
  from a higher spike!
• Maybe not enough leverage/stability?

19
Analogy w. Emulation Problem

• Height on cliff represents
• How many steps of progress havewe made through
  the irreversiblecomputation?
• Number of spikes represents
• Available memory of reversible machine.
• Spike in cliff at height H represents
• Using a unit of memory to record the state of
  the irreversible machine after H steps.
• Adding/removing a spike at height H1if there is
  a spike is at height H represents
• Computing/uncomputing state at H1 steps given
  state at H.

20
Lets Climb!
0. Standing on ground.
21
How high can we climb?

• Using only N spikes, and the strategy
  illustrated, we can climb to height 2N?1 (wow!)
• Li Vitanyi (Theorem) This is the optimal
  strategy for this game.
• Open question
• Are there more efficient general reversiblization
  techniques that are not based on this game model?

22
Pebble Game Representation
23
Triangle representation
k 2n 3
k 3n 2
24
Analysis of Bennett Algorithm

• n of recursive levels of algorithm
• k of lower-level iterations to go forward 1
  higher-level step
• Tr of reversible lowest-level steps
  executed 2(2k?1)n
• Ti of irreversible steps emulated kn
• So, n logk Ti, and so Tr 2(2k?1)log Ti/log k
  2elog(2k?1)log(Ti)/log k 2Tilog(2k ?1)/log k

(n1 spikes)
25
Linear-Space Emulation
(Lange, McKenzie, Tapp 97)
Unfortunately, the tree may have 2S nodes!
26
Can we do better?

• Bennett 73 takes order-T time, LMT 97 takes
  order-S space.
• Can some technique achieve both, simultaneously?
• Theorem (Frank Ammer 97) The problem of
  iterating a black-box function cannot be done in
  time T space S on a reversible machine.
• Proof really does cover all possible algorithms!
• The paper also proves loose lower bounds on the
  extra space required by a linear-time simulation.
• Results might also be extended to the problem of
  iterating a cryptographic one-way function.
• Its not yet clear if this can be made to work.

27
One-Way Functions

• are invertible functions f such that f is easy
  to compute (e.g., takes polynomial time) but f ?1
  is hard to compute (e.g., takes exponential
  time).
• A simple example
• Consider f(p,q) pq with p,q prime.
• Multiplication of integers is easy.
• Factoring is hard (except using quantum
  computers).
• The one-way-ness of this function is essential
  to the security of the RSA public-key
  cryptosystem.
• No function has yet been proven to be one-way.
• However, certain kinds of one-way functions are
  known to exist if P ? NP.

28
Elements of Frank-Ammer Proof

• Consider a chain of bit-strings (size S each)
  that is incompressible by a certain compressor.
• This is easily proven to exist. (See next slide.)
• Machines job is to follow this chain from one
  node to the next by using a black-box function.
• The compressor can run a reversible machine
  backwards, to reconstruct earlier nodes in the
  chain from later machine configurations.
• If the reversible machine only uses order-S space
  in its configurations, then the chain is
  compressible!
• Contradicts choice of incompressible chain QED.

29
Existence of Incompressibles

• A decompressor or description system s0,1
  maps any bit-string description d to the
  described string x.
• Notation fD means a unary operator on D, fD?D
• x is compressible is s iff ?d s(d)x, dltx
• Notation b means the length of bit-string b in
  bits.
• Theorem Every decompressor has an incompressible
  input of any given length ?.
• Proof There are 2? length-? bit-strings, but
  only shorter descriptions.

30
Cost-Efficiency Analysis

• Cost EfficiencyCost Measures in
  ComputingGeneralized Amdahls Law

31
Cost-Efficiency

• Cost-efficiency of anything is min/,
• The fraction of actual cost that really needed
  to be spent to get the thing, using the best
  poss. method.
• Measures the relative number of instances of the
  thing that can be accomplished per unit cost,
• compared to the maximum number possible
• Inversely proportional to cost .
• Maximizing means minimizing .
• Regardless of what min actually is.
• In computing, the thing is a computational task
  that we wish to carry out.

32
Components of Cost

• The cost of a computation may generally be a
  sum of terms for many different components
• Time-proportional (or related) costs
• Cost to user of having to wait for results
• E.g., missing deadlines, incurring penalties.
• May increase nonlinearly with time for long
  times.
• Spacetime-proportional (or related) costs
• Cost of raw physical spacetime occupied by
  computation.
• Cost to rent the space.
• Cost of hardware (amortized over its lifetime)
• Cost of raw mass-energy, particles, atoms.
• Cost of materials, parts.
• Cost of assembly.
• Cost of parts/labor for operation maintenance.

• Cost of SW licenses

33
More cost components

• Continued...
• Area-time proportional (or related) costs
• Cost to rent a portion of an enclosing convex
  hull for getting things in out of the system
• Energy, heat, information, people, materials,
  entropy.
• Some examples incurring area-time proportional
  costs
• Chip area, power level, cooling capacity, I/O
  bandwidth, desktop footprint, floor space, real
  estate, planetary surface
• Note that area-time costs also scale with the
  maximum number of items that can be
  sent/received.
• Energy expenditure proportional (or related)
  costs
• Cost of raw free energy expenditure (entropy
  generation).
• Cost of energy-delivery system. (Amortized.)
• Cost of cooling system. (Amortized.)

34
General Cost Measures

• The most comprehensive cost measure includes
  terms for all of these potential kinds of costs.
• comprehensive Time SpaceTime AreaTime
  FreeEnergy
• Time is an non-decreasing function
  f(?tstart?end)
• Simple model Time ? ?tstart?end
• FreeEnergy is most generally
• Simple model FreeEnergy ? ?Sgenerated
• SpaceTime and AreaTime are most generally
• Simple model
• SpaceTime ? Space ? Time
• AreaTime ? Area ? Time

Max ops thatcould be done
Max items thatcould be I/Od
35
Generalized Amdahls Law

• Given any cost that is a sum of components, tot
  1 n,
• There are diminishing proportional returns to be
  gained from reducing any single cost component
  (or subset of components) to much less than the
  sum of the remaining components.
• ? Design-optimization effort should concentrate
  on those cost components that dominate total cost
  for the application of interest.
• At a design equilibrium, all cost components
  will be roughly equal (unless externally driven)

36
Reversible vs. Irreversible

• Want to compare their cost-efficiency under
  various cost measures
• Time
• Entropy
• Area-time
• Spacetime
• Note that space (volume, mass, etc.) by itself as
  a cost measure is only significant if either
• (a) The computer isnt reusable, so the cost to
  build it dominates operating costs, or
• (b) I/O latency ? V1/3 affects other costs.

Or, for some applications,one quantity might be
minimizedwhile another one (space, time,
area)is constrained by some hard limit.
37
Time Cost Comparison

• For computations with unlimited power/cooling
  capacity, and no communication requirements
• Reversible is worse than irreversible by a factor
  of sgt1 (adiabatic slowdown factor), times maybe
  a small constant depending on the logic style
  used. r,Time ? i,Time s

38
Time Cost Comparison, cont.

• For parallelizable, power-limited applications
• With nonzero leakage r,Time ? i,Time /
  Ron/offg
• Worst-case computations g ? 0.4
• Best-case computations g 0.5.
• For parallelizable, area-limited,
  entropy-flux-limited, best-case applications
• with leakage ? 0 r,Time ? i,Time / d 1/2
• where d is systems physical diameter.
• (see transparency)

39
Time cost comparison, cont.

• For entropy-flux limited, parallel, heavily
  communication-limited, best case applications
• with leakage approaching 0 r,Time ? i,Time3/4
• where i,Time scales up with the space
  requirement V as i,Time ? V2/9
• so the reversible speedup scales with the 1/18
  power of system size.
• not super-impressive!

(details later)
40
Bennett 89 alg. is not optimal
k 2n 3
k 3n 2
Just look at all the spacetime it wastes!!!
41
Parallel Frank02 algorithm

• We can simply scrunch the triangles closer
  together to eliminate the wasted spacetime!
• Resulting algorithm is linear time for all n and
  k and dominates Ben89 for time, spacetime,
  energy!

k3n2
k2n3
Emulated time
k4n1
Real time
42
Setup for Analysis

• For energy-dominated limit,
• let cost equal energy.
• c energy coefficient, r r(min) leakage
  power
• i energy dissipation per irreversible
  state-change
• Let the on/off ratio Ron/off r(max)/r(min)
  Pmax/Pmin.
• Note that c ? itmin i (i / r(max)),
  so r(max) ? i2/c
• So Ron/off ? i2 / cr(min) i2 / cr

43
Time Taken

• There are n levels of recursion.
• Each multiplies the width of the base of the
  triangle by k.
• Lowest-level triangles take time ctop.
• Total time is thus ctopkn.

k4n1
Width 4 sub-units
44
Number of Adiabatic Ops

• Each triangle contains k (k ? 1) 2k ? 1
  immediate sub-triangles.
• There are n levels of recursion.
• Thus number of adiabatic ops is c(2k ? 1)n

k3n2
52 25little triangles(adiabaticoperations)
45
Spacetime Usage

• Each triangle includes the spacetime usage of all
  k ? 1 of its subtriangles,
• Plus,additional spacetime units, each
  consisting of 1 storage unit, for time
  topkn?1

k5n1
1 state of irrev. mach. Being stored
1
2
Time top kn-1
3
Resulting recurrence relationST(k,0) 1 (or
c)ST(k,n) (2k?1)ST(k,n?1) (k2?3k2)kn?1/2
123 units
46
Reversible Cost

• Adiabatic cost plus spacetime cost r a r
  (2k-1)nc/t ST(k,n)rt
• Minimizing over t gives r 2(2k-1)n
  ST(k,n) c r1/2
• But, in energy-dominated limit, c r ? i2 /
  Ron/off,
• So r 2i (2k-1)n ST(k,n) / Ron/off1/2

47
Tot. Cost, Orig. Cost, Advantage

• Total cost i for irreversible operation
  performed at end of algorithm, plus reversible
  cost, gives tot i 1 2(2k-1)n
  ST(k,n) / Ron/off1/2
• Original irreversible machine performing kn ops
  would use cost orig ikn, so,
• Advantage ratio between reversible irreversible
  cost,

48
Optimization Algorithm

• For any given value on Ron/off,
• Scan the possible values of n (up to some limit),
• For each of those, scan the possible values of k,
• Until the maximum R(i/r) for that n is found
• (the function only has a single local maximum)
• And return the max R(i/r) over all n tried.

49
Spacetime blowup
Energy saved
k
n
50
Asymptotic Scaling

• The potential energy savings factor scales as
  R(i/r) ? Ron/off0.4,
• while the spacetime overhead goes only as
  R(i/r) ? R(i/r)0.45, or Ron/off0.18.
• E.g., with an Ron/off of 109, you can do
  worst-case computation in an adiabatic circuit
  with
• An energy savings of up to a factor of 1,200 !
• But, this point is 700,000 less
  hardware-efficient, if Frank02 algorithm is used
  for the emulation.

51
Various Cost Measures

• Entropy - advantage as per previous analysis
• Area times time - scales w. entropy generated
• Performance, given area constraint -
• In leakage-free limit, advantage proportional to
  d1/2
• With leakage, whats the max advantage? (See hw)
• NOW
• Are there any performance/cost advantages from
  adiabatics even when there is no cost or
  constraint for entropy or for area?
• YES, for flux-limited computations that require
  communications. Lets see why

52
Perf. scaling w. of devices

• If alg. is not limited by communications needs,
• Use irreversible processors spread in a 2-D
  layer.
• Remove entropy along perpendicular dimension.
• No entropy removal rate limits,
• so no speed advantage from reversibility.
• If alg. requires only local communication,latency
  ? cyc. time, in an NDNDND mesh,
• Leak-free reversible machine perf. scales better!
• Irreversible tcyc ?(ND1/3)
• Reversible tcyc ?(ND1/4) ?(ND1/12) faster!
• To boost reversibility speedup by 10, one must
  consider 1036-CPU machines (1.7 trillion moles
  of CPUs!)
• 1.7 trillion moles of H atoms weighs 1.7 million
  metric tons!
• A 100-m tall hill of H-atom sized CPUs!

53
Lower bound on irreversible time

• Simulate Nproc ND3 cells for Nsteps ND steps.
• Consider a sequence of ND update steps.
• Final cell value depends on ND4 ops in time T.
• All ops must occur within radius r cT of cell.
• Surface area A ? T2, rate Rop ? T2 sustainable.
• Nops ? Rop T ? T3 needs to be at least ND4.
• ? T must be ?(ND4/3) to do all ND steps.
• Average time per step must be ?(ND1/3).
• Any irreversible machine (of any technology or
  architecture) must obey this bound!

54
Irreversible 3-D Mesh
55
Reversible 3-D Mesh
56
Non-local Communication

• Best computational task for reversibility
• Each processor must exchange messages with
  another that is ND1/2 nodes away on each cycle
• Unsure what real-world problem demands this
  pattern!
• In this case, reversible speedup scales with
  number of CPUs to only the 1/18th power.
• To boost reversibility speedup by 10, only
  need 1018 (or 1.7 micromoles) of CPUs
• If each was a 1-nm cluster of 100 C atoms, this
  is only 2 mg mass, volume 1 mm3.
• Current VLSI Need cost level of 25B before
  you see a speedup.

57
Ballistic Machines

• In the limit if cS ? 0, the asymptotic benefit
  for 3-D meshes goes as ND1/3 or Nproc1/9.
• Only need a billion devices to multiply
  reversible speedup by 10.
• With 1 nm3 devices, a cube 1 ?m on a side
  (bacteria size) would do it!
• Does Drexlers rod logic have low enough cS and
  small enough size to attain this prediction?
• (Need to check.)

58
Minimizing volume via folding

• Allows previoussolutions to bepacked in
  min.volume.
• Volume scalesproportionallyto mass.
• No change inspeed or entropy flux.

59
Cooling Technologies
60
Irreversible Max Perf. Per Area
61
Reversible Entropy Coeffs.
62
Rev. vs. Irrev. Comparisons
63
Sizes of Winning Rev. Machines
64
Some Analytical Challenges

• Combine Frank 02 emulation algorithm,
• Analysis of its energy and space efficiency as a
  function of n and k,
• And plug it into the analysis for the 3-D meshes,
  to see
• What are the optimal speedups for arbitrary mesh
  computations on rev. machines, as a function of
• Ron/off, device volume, entropy flux limit,
  machine size.
• And, does perf./hw improve, and if so, how much?

65
Reversible Processor Architecture
66
Why reversible architectures?

• What about automatic emulation algorithms?
• E.g. Ben73, Ben89, LMT, Frank02.
• Transform an irreversible alg. to an equiv.
  revble one.
• But, these do not yield the most cost-efficient
  reversible algorithms for all problems!
• E.g., log(RE(i./r)/Ron/off) may be only 0.4
  rather than 0.5.
• Finding the best reversible algorithm requires a
  creative algorithm discovery process!
• An optimally cost-efficient general-purpose
  architecture must allow the programmer to specify
  a custom reversible algorithm that is specific to
  his problem.

67
Reversibility Affects All Levels

• As Ron/off increases cost of device manuf.
  declines (while the cost of energy stays high),
• Maximizing overall cost-efficiency requires an
  increasingly large fraction of all bit-ops be
  done adiabatically.
• Maximizing the efficiency of the resulting
  algorithms, in turn, requires reversibility in
• Logic design
• Functional units
• Instruction set architectures
• Programming languages
• High-level algorithms

(unless a perfect emulator is found)
Increasing requirementfor degree of
reversibility
Pro-gram-mingmodel
68
All Known Reversible Architectures

• Ed Barton (MIT class project, 1978)
• Conservative logic, w. garbage stack
• Andrew Ressler (MIT bachelors thesis, 1979 MIT
  masters thesis, 1981)
• Like Bartons, but more detailed. Paired
  branches.
• Henry Baker (1992)
• Reversible pointer automaton machine
  instructions.
• J. Storrs JoSH Hall (1994)
• Retractile-cascade-based PDP-10-like
  architecture.
• Carlin Vieri (MIT masters thesis, 1995)
• Early Pendulum ISA, irrev. impl., full VHDL
  detail.
• Frank Rixner (MIT class project, 1996)
• Tick VLSI schematics layout of Pendulum
  subset, w. paired branches
• Frank Love (MIT class project, 1996)
• FlatTop Adiabatic VLSI impl. of programmable
  reversible gate array
• Vieri (MIT Ph.D. thesis, 1999)
• Fully adiabatic VLSI implementation of Pendulum
  w. paired branches

69
Reversible Programmable Gate-Array Architectures
70
(as of May 99)
71
Photo of packaged FlatTop chip
72
(No Transcript)
73
(No Transcript)
74
A Bouncing BBMCA Ball
75
A BBMCA Fredkin Gate
76
(No Transcript)
77
(No Transcript)
78
(No Transcript)
79
(No Transcript)
80
(No Transcript)
81
(No Transcript)
82
(No Transcript)
83
(No Transcript)
84
(No Transcript)
85
(No Transcript)
86
Reversible von Neumann Architectures
87
Reversible Architecture Issues

• Instruction-Set Architecture (ISA) Issues
• How to define irrev. ops (AND, etc.) reversibly?
• How to do jumps/branches reversibly?
• What kind of memory interface to have?
• What about I/O?
• How to permit efficient reversible algorithms?
• Should the hardware guarantee reversibility?
• Microarchitectural issues
• Register file interface
• Reversible ALU operations
• Shared buses
• Program counter control

88
The Trivial Cases

• Many typical instructions already reversible
• NOT a
• Set register a to its bitwise logical complement,
  a a
• NEG a
• Set a to its twos complement negation
• a -a or a a 1
• INC a
• Increment a by 1 (modulo 2?).
• ADD a b
• Add register b into register a (a (a b)
  mod 2?)
• XOR a b
• Exclusive-or b into a (a a ?
  b)
• ROL a b
• Rotate bits in register a left by positions
  given by b.

89
The Nontrivial Cases

• Other common instructions are not reversible
• CLR a
• Clear register a to 0.
• LD a b
• Load register a from addr. pointed to by b.
• LDI a 3
• Load immediate value 3 into register a.
• AND a b
• Set a to the bitwise AND of a and b
• JMP a
• Jump to the instruction pointed to by a.
• SLL a b
• Shift the bits in a left by b bits, filling with
  0s on right.

90
Irreversible Data Operations

• How to do expanding ops reversibly?
• E.g., AND a b - Prior value of a is lost.
• Approach 1 Garbage Stack approach.
• Based on Landauers embedding.
• Push all data that would otherwise be destroyed
  onto a special garbage stack hidden from pgmr.
• Can unwind computation when finished to recover
  stack space. (Lecerf 63/Bennett 73 approach)
• Problems Large garbage stack memory needed.
• Limits computation length.
• Leaves programmer no opportunity to choose a more
  efficient reversible algorithm!

91
Illustrating Garbage Stack

• Let ? mean reversible move, ? mean reversible
  copy, ? a reversible uncopy.

Garbage StackMemory (GSM)
AND a b
implemented by...
230
0
Garbage StackPointer (GSP)
1. t ? a2. a ? t b3. t ? GSMGSP
1
46
3
17
2
0
3
0
4
...
92
Programmer-Controlled Garbage

• Put extra data in a programmer-manipulable
  location.
• What if destination location isnt empty?
• Signal an error, or
• Use an op that does something reversible anyway
• Provide undo operations to accomplish
  unexpanding inverses of expanding ops.
• 1st method Errors on non-empty destination
• AND A B C -If (A0) A?BC else error
• UNAND A B C -If (ABC) A?BC else error
• 2nd method Use always-reversible store ops.
• ANDX A B C - A ? A ? (B C) (self-undoing!)

93
(No Transcript)
94
Pendulum - packaged die photo
95
(No Transcript)
96
(No Transcript)
97
(No Transcript)
98
(No Transcript)
99
(No Transcript)
100
(No Transcript)
101
(No Transcript)
