SpeechtoSpeech MT CSTARNespoleLingWear

1
Speech-to-Speech MTC-STAR/Nespole!/LingWear

• Lori Levin, Alon Lavie, Alex Waibel,
• Bob Frederking, Tanja Schultz
• LTI Immigration Course
• August 24, 2001

2
Outline

• Problems in Speech-to-Speech MT
• The JANUS Approach
• The Task-oriented Interlingua (IF)
• System Design and Engineering
• The C-STAR Nespole! And LingWear Projects
• Open Problems, Current and Future Research

3
Issues in Speech Translation

• Spoken dialogue is very different from written
  text
• different linguistically syntax, constructions
• contains unique phenomena repairs, hesitations,
  filled pauses
• Speech Translation requires specialized
  approches
• robust analysis
• focus on communicative goals, semantics, rather
  than syntax

4
Our Speech Translation Approach

• Translation via a task-oriented interlingua
  representation
• Focus on large, well-defined domains
• Robust analysis approaches
• Semantic grammars
• Modular grammar design
• Incorporate alternative translation engines

5
The Travel Planning Domain

• General Scenario
• Dialogue between one traveler and a travel
  service provider (agent, hotel clerk, etc.)
• Task oriented goal is to obtain information,
  reserve or purchase services related to travel
• Free spontaneous speech

6
The Travel Planning Domain

• Natural breakdown into several sub-domains
• Hotel Information and Reservation
• Transportation Information and Reservation
• Information about Sights and Events
• General Travel Information
• Cross Domain

7
Semantic Grammars

• Describe structure of semantic concepts instead
  of syntactic constituency of phrases
• Well suited for task-oriented dialogue containing
  many fixed expressions
• Appropriate for spoken language - often disfluent
  and syntactically ill-formed
• Faster to develop reasonable coverage for limited
  domains

8
Semantic Grammars

• Hotel Reservation Example
• Input we have two hotels available
• Parse Tree
• give-informationavailabilityhotel
• (we have hotel-type
• (quantity (two)
• hotel (hotels)
• available)

9
HLT Server Architecture
10
HLT Server Architecture
11
Rule-based Translation Approach
12
The SOUP Parser

• Specifically designed to parse spoken language
  using domain-specific semantic grammars
• Robust - can skip over disfluencies in input
• Stochastic - probabilistic CFG encoded as a
  collection of RTNs with arc probabilities
• Top-Down - parses from top-level concepts of the
  grammar down to matching of terminals
• Chart-based - dynamic matrix of parse DAGs
  indexed by start and end positions and head cat

13
The SOUP Parser

• Supports parsing with large multiple domain
  grammars
• Produces a lattice of parse analyses headed by
  top-level concepts
• Disambiguation heuristics rank the analyses in
  the parse lattice and select a single best path
  through the lattice
• Graphical grammar editor

14
SOUP Disambiguation Heuristics

• Maximize coverage (of input)
• Minimize number of parse trees (fragmentation)
• Minimize number of parse tree nodes
• Minimize the number of wild-card matches
• Maximize the probability of parse trees
• Find sequence of domain tags with maximal
  probability given the input words P(TW), where
  T t1,t2,,tn is a sequence of domain tags

15
Generation Modules

• Two alternative generation modules
• GenKit - unification-based generator augmented
  with Morphe morphology module - used for German
• Top-Down context-free based generator - fast,
  used for English and Japanese

16
Translation with Multiple Domain Grammars
17
A SOUP Parse Lattice
18
Hybrid Stat/Rule-based Analysis

• Developing large coverage semantic analysis
  grammars is time consuming ? difficult to port
  analysis system to new domains
• low-level argument grammars are more
  domain-independent contain many concepts that
  are used across domains time, location, prices,
  etc.
• high-level domain-actions are domain-specific,
  must be redeveloped for each new domain
  give-infoonsetsymptom
• Tagging data sets with interlingua
  representations is less time consuming, needed
  anyway for system development

19
Hybrid Rule/Stat Approach

• Combines grammar-based and statistical approaches
  to analysis
• Develop semantic grammars for phrase-level
  arguments that are more portable to new domains
• Use statistical machine learning techniques for
  classifying into domain-actions
• Porting to a new domain requires
• developing argument parse rules for new domain
• tagging training set with domain-actions for new
  domain
• training the classifiers for domain-actions on
  the tagged data

20
The Hybrid Analysis Process

• Parse an utterance for arguments
• Segment the utterance into sentences
• Extract features from the utterance and the
  single best parse output
• Use a learned classifier to identify the speech
  act
• Use a learned classifier to identify the concept
  sequence
• Combine into a full parse

21
Automatic Classification of Domain Actions

• Train classifiers for speech acts and concepts
• Training data Utterances labeled with speech
  act, concepts, and best argument parse
• Input features
• n most common words
• Arguments and pseudo-arguments in best parse
• Speaker
• Predicted speech act (for concept classifier)

22
Argument Parse Example
We have a double room available for you at
twenty-three thousand five hundred
yen availabilityPSD ( we have
super_room-type ( room-type ( a
roomdouble ( double room ) ) ) available
) arg-partyfor-whomARG ( for you ( you )
) argtimeARG ( point ( at
hour-minute ( bighour ( big23 (
twenty-three ) ) ) ) ) argsuper_priceARG (
price ( one-pricemain-quantity (
n-1000 ( thousand ) pricen-100 ( five
hundred ) ) currency ( yen ( yen ) ) ) )
23
Full Parse Example
We have a double room available for you at
twenty-three thousand five hundred
yen give-informationavailabilityroom
( availabilityPSD ( we have
super_room-type ( room-type ( a
roomdouble ( double room ) ) ) available
) arg-partyfor-whomARG ( for you ( you )
) argtimeARG ( point ( at
hour-minute ( bighour ( big23 (
twenty-three ) ) ) ) ) argsuper_priceARG (
price ( one-pricemain-quantity (
n-1000 ( thousand ) pricen-100 ( five
hundred ) ) currency ( yen ( yen ) ) )
) )
24
Classification Results UsingMemory-based (TiMBL)
Classifiers
25
Alternative Approaches MEMT

• Glossary-based Translation
• Translates directly into target language (no IF)
• Based on Pangloss translation system developed at
  CMU
• Uses a combination of EBMT, phrase glossaries and
  a bilingual dictionary
• Good fall-back for uncovered utterances

26
C-STAR-III

• Partners ATR, CMU, CLIPS, ETRI, IRST, UKA
• Main Research Goals
• Expandability - towards unlimited domains
• Accessibility - Speech Translation over wireless
  phone
• Usability - real service for real users

27

• Speech-to-speech translation for eCommerce
• CMU, Karlsruhe, IRST, CLIPS, 2 commercial
  partners
• Improved limited-domain speech translation
• Experiment with multimodality and with MEMT
• EU-side has strict scheduling and deliverables
• First test domain Italian travel agency
• Second showcase international Help desk
• Tied in to CSTAR-III

28
LingWear for the Information Warrior

• New Ideas
• The pre-development of appropriate interlingua
  representations for domains of interest
  facilitates generation into a new language within
  two weeks.
• The development of new MT engines (e.g.
  learnable transfer rules) and improved
  multi-engine integration supports rapid
  deployment of MT for a new language with scarce
  resources.
• Gisting and summarzation in the source language
  followed by MT is better than vice versa.

• Impact
• Allow military and relief organizations to
  converse in limited domains of interest with the
  local population in an area of conflict and/or
  disaster
• Allow military and other operatives in the field
  to assimilate forien language information they
  encounter on-the-move
• Rapidly port and deploy the technology into new
  languages with scarce resources

Schedule
Port to second language
Baseline summarizer ready
Baseline MT systems ready
Port to third language
Carnegie Mellon University School of Computer
Science A.Waibel, L. Levin, A. Lavie, R.
Frederking
29
Domain Portability Travel to Medical
Knowledge-Based Methods Re-usability of knowledge
sources for translation and speech recognition
Corpus-Based Methods Reduce the amount of new
training data for translation and speech
recognition
30
Portability

• Advantage Interlingua
• Problem Writing semantic grammars
• Domain dependent
• Requires time, effort, and expertise
• Approach
• Grammar modularity
• Domain action learning
• Automatic/Interactive semantic grammar induction

31
Automatic Induction of Semantic Grammars

• Seed grammar for a new domain has very limited
  coverage
• Corpus of development data tagged with
  interlingua representations available
• Expand the seed grammar by learning new rules for
  covering the same domain-actions
• First step how well can we do with no human
  intervention?

32
System Evaluation Methodology

• End-to-end evaluations conducted at the SDU
  (sentence) level
• Multiple bilingual graders compare the input with
  translated output and assign a grade of Perfect,
  OK or Bad
• OK meaning of SDU comes across
• Perfect OK fluent output
• Bad translation incomplete or incorrect

33
C-STAR 1999 Evaluation Results
34
Evaluation - Progress Over Time
35
Current and Future Research

• Expanding the domains of coverage
• Machine Learning-based approaches to analysis
  hybrid rule/stat analysis approach, grammar
  induction
• Multiple interfaces web, phone, PDAs
• Integration of multiple MT approaches into a MEMT
  system
• Disambiguation improved sentence-level
  disambiguation applying discourse contextual
  information for disambiguation

36
Students Working on the Project

• Chad Langley Hybrid Rule/Stat analyzer
• Benjamin Han Grammar Induction
• Stan Jou Phone interfaces and recognizer
• Alicia Tribble Language portability
• Kornel Laskowski H323 Speech Recognizer

37
The C-STAR/Nespole!/LingWear Team

• Project Leaders Lori Levin, Alon Lavie, Alex
  Waibel, Bob Frederking, Tanja Schultz
• Grammar and Component Developers Donna
  Gates, Dorcas Wallace, Kay Peterson, Chad
  Langley, Benjamin Han, Alicia Tribble, Kornel
  Laskowski, Stan Jou, Celine Morel, Susie Burger
