ICHEP04 talk

1
(No Transcript)
2
Semi-Inclusive Deep Inelastic Scattering
The cross section can be expressed as a
convolution of a distribution function and a
fragmentation function.
3
Distribution Functions
Leading Twist

• 3 distribution functions survive the integration
  over transverse quark momentum

unpolarized DF
Helicity DF
Transversity DF
Transversity basis
4
Virtual Photon Asymmetry - Path to Dq

• Virtual photon can only couple to quarks of
  opposite helicity
• Select quark helicity by changing target
  polarization direction
• Different targets give sensitivity to different
  quark flavors

5
Quark Polarizations
Correlation between detected hadron and the
struck quark allows flavor separation
Inclusive DIS ?DS Semi-inclusive ?
6
The HERMES Experiment

• 27.5 GeV polarized positron beam (ltPgt53)
• Longitudinally polarized H
• (ltPgt85)
• Transversely polarized H (ltPgt78)

7
The Measured Hadron Asymmetries
PROTON
DEUTERIUM
8
Polarized Quark Densities

• Polarized parallel to the proton

• Polarized anti-parallel to the proton

• Good agreement with LO-QCD fit

• No indication for
• 0.028 0.033 0.009 Measured range

Submitted Phys.Rev.D
9
Properties of the Transversity DFs

• For non-relativistic quarks dq(x)Dq(x)
• dq(x) probes the relativistic nature of the
  quarks
• Due to Angular Momentum Conservation
• Different QCD evolution
• No gluon component
• Predominately sensitive to valence quarks
• Bounds
• Soffer Bound
• T-even
• Chiral odd
• Not measurable in inclusive DIS

10
Measuring Transversity

• Need a chiral odd fragmentation function
  Collins FF

• Transverse quark polarization affects transverse
  hadron momentum
• Observed asymmetry in azimuthal angle about
  lepton scattering plane

• Collins Effect
• Artru string fragmentation model
• String break produces quark- antiquark pair
• pair must preserve vacuum quantum numbers
• angular momentum conservation gives the produced
  hadron transverse momentum

11
Sivers Function f1T(x)

• Distribution function
• Naïve T-ODD
• Chiral even
• a remnant of the quark transverse momentum can
  survive the photo-absorption and the
  fragmentation process
• Can be inherited in the transverse momentum
  component
• influence azimuthal distribution
• Non-vanishing Sivers function requires quark
  orbital angular momentum
• Cross section depends on the angle between the
  target spin direction and the hadron production
  plane

12
How to Measure Transversity
Collins azimuthal moment
Sivers azimuthal moment
Assuming gaussian distributions for initial an
final quark momentum
13
RESULTS
Collins
Collins Moment

• Unexpected result

Sivers

• Possible interpretation

• Same Size

Sivers Moment

• More theoretical input needed to clarify
  interpretation
• f1T(x) DIS - f1T(x) DY UNIVERSALITY

Submitted to Phys.Rev.Lett.
14
Summary and Conclusions

• Longitudinally Polarized Target Data
• First direct measurement of the helicity
  distributions
• Transversely Polarized Target Data
• Collins Disfavored fragmentation functions
  appear to be important and have opposite sign to
  the favored
• Sivers Amplitude is greater than zero

15
Polarized Sea

• QSM expectation Eur.Phys.J.C14,147(2000)
• Meson cloud model Phys.Rev.D68,074002(2003)

• Unpolarized data on sea shows the Gottfried sum
  rule is broken

• Data favor symmertic ,but large
  uncertainties

16
Purities
-
-
-
17
(No Transcript)
